Used Kent Surface Grinding Machine for sale (11)

Year of construction: 2014, Condition: ready for operation (used), General Data Measurements width 2500 mm Measurements depth 2600 mm Machine weight 1910 kg Main Drive Number of spindles 1 Spindle speed range 1450 rpm Spindle motor power 4 kW Movement X-Axis Movement 660 mm Y-Axis Movement 370 mm Additional Equipment Table size: 300 x 600 mm Distance table-spindle: 540 mm Maximum table load: 420 kg Table speed: 5 - 25 m/min Rapid traverse speed: 790 mm/min Grinding wheel size: 355 x 40 x 127 mm Uelxre8Kgx This Kent KGS 1224 AHD surface grinding machine was manufactured in 2014. It features a table size of 300 x 600 mm, with a maximum load capacity of 420 kg. The grinding wheel size is 355 x 40 x 127 mm, and it operates with a main motor power of 4 kW. Ideal for precision grinding, the Kent KGS 1224 AHD machine we have for sale is robust and efficient. Contact us for further details regarding this surface grinding machine. Application Types Grinding

Condition: excellent (used), Uncoiler S253, made KENT Coil weight 3Tn Coil width 250 mm 7Fjnbcb Thickness 0.8 - 3.2 mm SCOPE OF SUPPLY 3Tn Single expandable uncoiler Strip retainer Control panel

Year of construction: 2003, Condition: ready for operation (used), - USED - SURFACE GRINDING MACHINE MAX GRINDING LENGTH: 460 mm MAX GRINDING WIDTH: 200 mm LONGITUDINAL TRAVEL: 540 mm TRANSVERSAL TRAVEL: 260 mm MAX ADMITTED LOAD: 103 Kg Bjgegycin0S GRINDING WHEEL SIZE: 180 x 12 x 31,75 mm GRINDING WHEEL SPEED: 2000 rpm MOTOR POWER: 1,5 kW WEIGHT: 1300 Kg OVERALL DIMENSIONS: 1800 x 1400 x 1775 mm

Condition: as good as new (ex-display), Year of construction: 2021, Functionality: fully functional, grinding length: 600 mm, grinding width: 300 mm, total length: 3,330 mm, total width: 2,500 mm, grinding wheel diameter: 355 mm, distance table to spindle center: 520 mm, grinding wheel width: 38 mm, grinding spindle speed: 1,450 rpm, Sanding area: 600 x 300 mm Table load: 420 kg (incl. magnetic clamping plate) Longitudinal table movement: 710 mm Distance table to spindle center: 520 mm Automatic vertical infeed via servo motor 0.001 - 0.025 mm Vertical rapid traverse: 300 mm/min Automatic cross travel: 340 mm Grinding spindle motor 3.7 kW Grinding spindle speed 1450 rpm Grinding wheel size: 355 x 38 x 127 mm Machine weight approx. 1750 kg Operation/control: Servo-controlled vertical infeed in the sanding cycle Electrical cross travel with memorizable reversal points via control panel Electronic handwheel Movable control panel with 7" color screen and touch function Programmable sanding cycles in 4 variants for vertical axis Workpiece memory, 10 sanding cycles for quick recall Features include Splash guard cladding with sliding door, right-hand side with Plexiglas protection, open at the top Separate hydraulic system Infinitely variable longitudinal and transverse table movement with automatic table reversal Table reversal via inductive proximity switches Clamping device for transverse movement Automatic central lubrication Rear and side chip and splash guard LED light 1 balancing stand for grinding wheels, incl. balancing mandrel 1 grinding wheel flange for grinding wheel bore 127 mm 1 grinding wheel 355 x 38 x 127 mm 1 grinding wheel flange pressing device 1 table dresser Optional: Electro-magnetic clamping plate 600 x 300 mm Coolant tank (max. 135 L) with magnetic separator Ccb3Kwvta Manual dresser with hand lever

Condition: ready for operation (used), Year of construction: 2008, grinding length: 1,000 mm, grinding width: 500 mm, Surface grinding machine Kent model KGS 510VM1 year 2008 max sanding length 1000mm max sanding width: 500mm distance table to spindle center: 550mm The machine is still in use. Location of the machine: Bremen _____ Our general terms and conditions apply, and the seller is not liable for typing or data transmission errors. The appearance of the items on offer corresponds to their age and the pictures shown. The technology and wear of the items on offer are in keeping with their age. Brzbjw9Kweu Dpdyx7 Used machines are sold exclusively to traders and without warranty.

Condition: good (used), Year of construction: 2013, Surface grinding machine Kent KGS 715 , year 2013 Dpnxdx Table clamping surface; 1500 x 700 mm Max. Table load: 1400 kg Longitudinal table movement: 1600 mm Distance table-spindle center: 600 mm Grinding spindle speed: 1450 1/min Grinding wheel standard: 355 x 50 x 127 mm Accessories: Standard, wet grinding unit with filter, hydraulic system, magnetic plate, handwheel & documentation

Condition: excellent (used), Brand: KENT Model: KGS-250AHD Type : Tangential Cavxalzmkm Work surface 460x200 mm Longitudinal course 540 mm Cross course 260 mm Distance form center to table 490 mm Max. Weight on the table including magnetic chuck 103 for series 250 kg 150 for series 818 kg Slote in T 14x 1 mm/N Longitudinal table speed 5- 23 m/min Crank cords feed 1 gra 0,02 mm - 1 rev 4 mm Automatic traerse feed per pass 0.1 -5.5 mm Automatic advance 50 Hz- 820 mm /min. - 60Hz 980 mm/min Wheel size 180 x 13 x 31. 75 mm Spindle speed 50 Hz 2850 rpm - 60 Hz 3480 rpm Upright crank 1 gra 0,01 mm - 1 rev 2 mm Automatic feed increment 0,002- 0,02 mm Spindle motor 2 x 2 HP X P Hoist motor NA kg x cm Hydraulic motor pump 1 X 6 HP X P Drain motor 1/8 X 2 HP X P Transverse agace engine 1/5 x 6 HP X P Machine height 1775 mm Machine dimension 3260 x 2460 mm Net weight 1300 kg Gross weight 1500 K

Condition: as good as new (ex-display), Year of construction: 2023, Functionality: fully functional, grinding length: 1,000 mm, grinding width: 500 mm, total height: 2,400 mm, total length: 4,445 mm, total width: 2,100 mm, grinding wheel diameter: 355 mm, distance table to spindle center: 550 mm, grinding wheel width: 38 mm, spindle speed (max.): 1,450 rpm, overall weight: 5,800 kg, grinding spindle speed: 1,450 rpm, Table clamping surface: 1000 x 500 mm Table load max. 1000 kg (incl. magnetic clamping plate) Distance table to spindle center 550 mm Sanding spindle motor 5.5 kW Sanding spindle speed 1450 rpm Guide system Flat guides Machine weight approx. 5800 kg Operation/control: Servo-controlled vertical infeed in the sanding cycle Electrical cross travel with memorizable reversal points via control panel Electronic handwheel Movable control panel with 7" color screen and touch function Programmable sanding cycles in 4 variants for vertical axis Workpiece memory, 10 sanding cycles for quick recall Cklpwetq Including the following standard accessories: Full enclosure open at the top Separate hydraulic system Infinitely variable longitudinal table movement with automatic table reversal Quick vertical adjustment for the sanding head 300 mm/min (rapid traverse) Automatic stepless vertical infeed from 0.001 - 0.025 mm via servo motor Adjustable magnet incl. clamping force monitoring Automatic central lubrication with visual inspection 1 balancing device for grinding wheels, incl. balancing mandrel 1 grinding wheel flange for grinding wheel bore 127 mm 1 grinding wheel 355 x 38.1 x 127 mm 1 Table dresser 1 Rear splash guard 1 Set of leveling screws for alignment and machine feet 1 Operating instructions incl. wiring diagram 1 acceptance report for machine geometry and grinding spindle according to DIN 8632 Optional: Fine-pole electromagnetic clamping plate 1000 x 500 mm Coolant tank (max. 135 L) with magnetic separator and paper belt filter Manual dresser with hand lever

Condition: like new (used), Year of construction: 2006, Technical data Manufacturer: KENT Model: VK 1600MC Year : 2.006 Serial number: 2200139 Control unit: FANUC 18 iMD Location: Tabaza (Asturias - Spain) Table Dimensions Working Surface: 1700 x 810 mm. T-Slot ( Size x Number x Center distance): 22 x 5 x 160 mm. Max. Table Load: 2.000 kg. Travel X axis traverse: 1600 mm. Y axis traverse: 815 mm. Z axis traverse: 815 mm. Distance from Spindle nose to table: 220 ~ 1035 mm. Distance from Spindle center to Column: 865 mm. Spindle Taper: BT50 Spindle speed (Gear type): 30 – 6000 rpm. ZF GEAR BOX (2 ranges): Yes Max. Tool Weight: 15 kg. Max. Tool Size (Diameter x Length): 125 x 300 mm. Biplbgw87Ve ATC Max. tool Ø x L: Ø125 x L250 Max. tool weight: 15 kg. Number of tools: 32 Feedrates Cutting Feed Rate: 1 – 10.000 mm./min. Rapid Traverse: 18/18/18 mm./min. Motor Spindle Drive Motor (30 Min Rating): 15/18,5 Kw. X,Y,Z Axis Drive Motor: X: 5.5 | Y: 5.5 | Z:5.5 Coolant Pump CTS: One air & two coolants – 4 bar. + 6 bar / 20 bar Weight and dimensions Machine weight: 16.150 kg Machine dimens: 4.488 x 3.448 x 3.250 mm. Base space: 5.000 x 3.500 mm.

Condition: ready for operation (used), Year of construction: 2019, Functionality: fully functional, grinding length: 920 mm, grinding width: 450 mm, total height: 1,875 mm, total length: 3,600 mm, total width: 2,600 mm, feed rate X-axis: 300 m/min, table length: 800 mm, table load: 700 kg, table width: 400 mm, grinding wheel width: 355 mm, overall weight: 2,800 kg, distance stand to spindle center: 600 mm, grinding wheel speed: 1,450 rpm, WORKING AREA: Workin plane 800x400 mm Longitudinal stroke 920 mm Crossl stroke 450 mm Distance spindle center-table 600 mm Bskkjy7Gogo Max load capacity on the table (including magnetic chuck) 700 kg Longitudinal table speed m/min 1-28 Min. cross feed with handwheel 0.002 mm Automatic cross feeds with handwheel 0.1-12 mm Rapid cross feeds mm/min 1000 WHEEL: Grinding wheel dimensions 355x38x127 mm Spindle speed Rpm 1450 VERTICAL MOVEMENT: Min. wheel descent increment (1gra/1rev) mm 0.001-0.1 Range automatic increase of descent mm 0.001 to 0.099 Rapid vertical elevation mm/min 300 MOTORS: Spindle motor kW 5.6 WEIGHTS AND DIMENSIONS: Net weight 2.800 kg Machine height 1875 mm Space occupied on the ground 3600x2600 mm EQUIPPED WITH: -SPD magnetic chuck -Filter USED MACHINE YEAR 2019

Year of construction: 2017, Condition: as good as new (ex-display), Flowmeter for water Make ABB Kent Messtechnik Bftmvsoabv type 656 WP 4800 Pn 16 bar Qn 25 m3/h Ap 0,3 bar 30 degrees 30 degrees
