Used Mazak Milling Machine for sale (390)

Condition: used, Year of construction: 2006, x-travel 1050 mm y-travel 510 mm z-travel 510 mm control Fusion 640 M Nexus spindle taper DIN 69871/SK40 Feed speed 8000 mm/min. turning speed range 35 - 12.000 U/min rapid travel x/y/z 36 m/min distance spindle /table max. 660 mm distance spindle /table min. 150 mm no. of tools in the magazine 30 Stück tool taper CAT 40 Tool diameter 80 mm wotkpiece diameter with 2 vacant positions max. 125 mm max. tool weight 8 kg max. tool length 350 mm table length 1300 mm table width 550 mm number of T-slots 3 T-slot - width 18 mm T-slot - distance 100 mm max. table load 1200 kg table height over floor 850 mm Nwodpfx Ajxp Rywofcec coolant tank 250 l coolant pump 4,5 bar internal coolant system feed 15 bar coolant capacity 271 l/min required air pressure 700 l/min spindle drive 18,5 connected load frequency 400 V connected load 36,6 kVA frequency 50 Hz Needed pneumatic pressure 5 (bei 200 l/min) bar weight of the machine ca. 6,9 t dimensions of the machine ca. 2,90 x 2,84 x 2,81 m Including special accessories: -Cooling through the spindle (15 bar) -Chip conveyor, hinged belt on the left side -Torque-dependent drilling cycle (Mazatrol) -Automatic determination of drilling depth increments after torque detection. preferably in combination with HSS tool) -Interface set Contents: - Interface for keyboard - Interface for mouse - Interface for printer Retrofitting not possible Machine color gray / black -CNC Performance Option Package contents: - Shared variables (600 pairs) - MAZAK Tornado thread tapping (EIA/ISO) - Synchronous thread cutting - EIA/ISO input function - EIA/ISO special function Spiral interpolation (G02.1, G03.1), 3D tool correction (G40-G42) Scaling (G50, G51) etc. - EIA/ISO, Constant feed (G93) When using this function, the feed rate remains constant for straight and curved combinations on the contour. - EIA/ISO tool length measurement (G37) - EIA/ISO, programme unit stop function Programme sequence is automatically stopped at a specified programme unit. - MAZACC-2D (Mazatrol & EIA/ISO) Precision control function for precise vector interpolation and optimal acceleration and deceleration at edges and radii. This enables improved two-dimensional shape accuracy. - Additional workpiece coordinate system (G54.1 P1 - 48) 48 pairs - Spiral machining function (G33) for boring head machining (e.g. with d'Andrea tool) - Used machine without warranty - - All dimensions, weight and performance data are non-binding

Condition: used, Year of construction: 2003, Pallet size 400 x 400 mm X/Y/Z movements.- 560/630/600 mm Spindle taper ISO 40 No of tools in tool changer 80 pcs. Pallet indexing 0,001 deg. Control: Mazatrol PC Fusion 640 M Equipped with: Nwedsxfcc Nepfx Afcjc 2 extra pallets Various tool holders

Condition: used, Year of construction: 2001, Palet size 600 x 600 mm X/Y/Z - 1050/800/880 mm Spindle speeds 7000 rpm Spindle taper ISO 50 Tool changer w/80 stations Control: Mazatrol PC-Fusion 640 M Equipped with: Nodpfxoyhzcre Afcswc 2 extra pallets 600 x 600 mm

Condition: used, Year of construction: 2006, Palet size 500 x 500 mm X/Y/Z - 710/610/600 mm Spindle speeds 12000 rpm Spindle taper ISO 40 Tool changer w/80 stations Control: Mazatrol 640 M Equipped with: Nodpfx Afoyhzb Uocewc 2 extra pallets 500 x 500 mm

Year of construction: 1997, condition: ready for operation (used), Travel X/Y/Z: 1300mm/1100mm/1000mm, table dimensions X/Y: 800mm/800mm, number of pallets: 14, max. table load: 2200kg, table indexing: 0.001°. Speed: 7000rpm, spindle power: 50hp, tool magazine: 80, dimensions X/Y/Z: approx. 7000mm/3400mm/3800mm, weight: approx. 24000kg. On-site inspection is possible. Nsdpfx Aetx Dn Usfcewc

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is Nodpfetuggcox Afcjwc programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: ready for operation (used), Year of construction: 2008, Make: MAZAK Type of machine: INTEGREX 300-4ST Year of manufacture: 2008 Control system: Mazatrol Matrix Machine's weight: 13.900 kg Njdoyh I Tdjpfx Afcewc Tool holder: Capto C6 x-travel: 530 mm y-travel: 200 mm z-travel: 1.065 mm Speed range: 4.000 U/min Cutting diameter: 300 mm Turning length: 1.000 mm Overall dimensions: 6.500 × 3.000 × 3.200 mm Tool turret - slots: 80 Pl.

Condition: ready for operation (used), Year of construction: 2004, Make: MAZAK Type of machine: INTEGREX 300-3ST Year of manufacture: 2004 Control system: Mazatrol 640 CNC-Steuerung Machine's weight: 14.200 kg Tool holder: Capto C6 x-travel: 530 mm Nwedpfx Ajyh I Rvjfcsc y-travel: 200 mm z-travel: 1.065 mm Speed range: 4.000 U/min Cutting diameter: 300 mm Turning length: 1.000 mm Overall dimensions: 6.500 × 3.000 × 3.200 mm Tool turret - slots: 80 Pl.

Condition: used, Year of construction: 1996, x-travel 1500 mm y-travel 650 mm z-travel 650 mm size of pallet 1740 x 650 mm spindle taper SK 50 Nwodpsyg N Shofx Afcjc spindle turning speed range 25 - 6000 U/min feeds longditudinal/cross/vertical max. 8 mm/min rapid traverse longitudinal and cross 26 m/min rapid traverse vertical 20 m/min spindle throat 665 mm distance spindle nose and table 200 / 850 mm drilling in full material 50 mmø threading M 45 ATC 60 Pos tool diameter 125 mm wotkpiece diameter with 2 vacant positions 260 mm workpiece length 400 mm weight of tools max. 20 kg spindle drive 18,5 kW control MAZATROL M PLUS Accessories: chip conveyor, coolant

Condition: excellent (used), Year of construction: 2018, mazak j-200s technical dataFor this search query, no AI-generated overview is availableCurrently, an AI-generated overview cannot be provided. Please try again later.AI overview +6 The Mazak INTEGREX j-200S is a compact 5-axis multitasking machine with sub-spindle (S) for complex turning and milling operations. Key features include an 8-inch main chuck, a maximum machining diameter of {\(\emptyset 500\text{\ mm}\)}, and a machining length of up to {\(910\text{\ mm}\)}. The B-axis offers a swivel range from {\(-30^{\circ }\)} to {\(+190^{\circ }\)}. Main technical data (Integrex j-200S): Machining capacity:Max. swing diameter: {\(530\text{\ mm}\)}Max. machining diameter: {\(\emptyset 500\text{\ mm}\)}Max. machining length: {\(910\text{\ mm}\)}Main spindle & sub-spindle:Chuck size (main & sub-spindle): 8 inchesMain spindle speed: {\(5,000\text{\ min}^{-1}\)}Main spindle power (40% duty cycle): {\(18.5\text{\ kW}\)}Milling spindle (B-axis):Speed: {\(12,000\text{\ min}^{-1}\)} (typical for the j-series, may vary with optional configurations)Swivel range: {\(-30^{\circ }\)} to {\(+190^{\circ }\)} (or a total range of 220°)Tool interface: KM63 or CAPTO C6Axes & capacity:Y-axis travel: {\(200\text{\ mm}\)} ({\(\pm 100\text{\ mm}\)})X/Z axes: {\(450\text{\ mm}\)} / {\(1119\text{\ mm}\)}Tool magazine: 20–36 tools (depending on configuration)Control: MAZATROL SmoothG or Matrix Nexus 2 The machine features a full C-axis for both spindles and an automatic tool changer, making it suitable for highly productive applications in a compact design. Nodpjyfgdljfx Afcjwc

Condition: ready for operation (used), Year of construction: 2007, 3-Axis Vertical Machining Center MAZAK - NEXUS VCN 510 C-II CNC: MAZATROL MATRIX NEXUS Year: 2007 (8,300 spindle hours) Specifications: X-axis travel: 1,050 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Rapid traverse: 36 m/min Table size: 1,300 x 550 mm Nwodpeyfgw Ejfx Afcsc Maximum table load: 1,200 kg Spindle speed: 12,000 rpm Spindle power: 18.5 kW Spindle taper: BT 40 Max. tool diameter: 80 mm Max. tool length: 350 mm Max. tool weight: 8 kg Approx. machine dimensions: 2,820 x 2,830 x H 2,840 mm Approx. weight: 6,700 kg Equipped with: - 30-tool magazine - Through-spindle coolant - Chip conveyor - Tool probe

Condition: used, Year of construction: 2000, Turning length 1000 mm Nodpep Ui N Hsfx Afcswc Max. swing 640 mm dia. Max. turning 540 mm dia. Spindle bore 51 mm Max. Spindle speeds 4000 rpm (same for subspindle) Max. spindle speeds on milling spindle 6000 rpm No. of stations in tool changer 40 pcs. Control: PC Fusion 640 MT Equipped with: Gantry loader 10 pcs. tool holders

Condition: used, Year of construction: 2004, Clamping area 630 x 500 mm X axis - 630 mm Y axis - 765 mm Z axis - 510 mm A axis - 0,001 deg. (+30/-120 deg.) C axis - 0,001 deg. (360 deg.) Spindle speeds 35-12000 rpm Nedsxdfiiepfx Afcswc Spindle taper ISO 40 Control: Mazatrol 640 M 5X Equipped with: Coolant through spindle (20 bar)

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, General Information Machine Type: Vertical Machining Centre, Travelling Column Control Unit (CNC): MAZATROL Fusion 640M Year of Manufacture: 2003 Number of Axes (Controlled): 3 (Standard), 4 (Optional with rotary table) Travels and Working Area X-Axis Travel (Longitudinal): 1740 mm Y-Axis Travel (Cross): 760 mm Z-Axis Travel (Vertical): 660 mm Table Length: 2000 mm Table Width: 760 mm Maximum Workpiece Weight (Table Load): 1400 kg Spindle and Performance Spindle Taper: SK 40 (or ISO/BT 40) Maximum Spindle Speed: 12 000 min$^{-1}$ (rpm) Main Spindle Motor Power: 18.5 kW (Kilowatts) (Often a 10-min rating, continuous power may be lower) Rapid Traverse Rate (X-Axis): Up to 42 m/min (Metres per minute) Rapid Traverse Rate (Y/Z-Axes): Up to 36 m/min (Metres per minute) or 42 m/min (depending on configuration) Cutting Feed Rate: Up to 36 000 mm/min Tool Changer (ATC) Tool Magazine Capacity: 30 tools (Standard), 48 tools (Optional) Maximum Tool Weight: 8 kg Maximum Tool Length: 350 mm Nwsdpfox Ezntex Afcec Maximum Tool Diameter (with adjacent tools): 80 mm Maximum Tool Diameter (without adjacent tools): 110 mm Machine Dimensions and Weight Machine Length (L): Approx. 4450 mm Machine Width (W): Approx. 3460 mm Machine Height (H): Approx. 3100 mm Machine Weight: Approx. 11 500 kg (11.5 tonnes) Coolant Tank Capacity: Approx. 450 l (Litres) Total Power Requirement: Approx. 46.7 kW Air Pressure Required: 5 - 9 bar

Condition: excellent (used), Year of construction: 2020, operating hours: 916 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 530 mm, workpiece weight (max.): 500 kg, overall weight: 10,000 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 11,000 W, number of slots in tool magazine: 60, tool length: 300 mm, tool diameter: 130 mm, tool weight: 8,000 g, input voltage: 400 V, type of input current: three-phase, Equipment: documentation/manual, MAZAK Variaxis C600 – Vertical Machining Center TECHNICAL CHARACTERISTICS: Number of simultaneous axes: 5 Stroke X axis: 650 [mm] Stroke Y axis: 550 [mm] Stroke Z axis: 530 [mm] Feed rate on X, Y and Z axes: 42000 [mm/min] Min. distance spindle nose / table: 50 [mm] Max. distance spindle nose / table: 580 [mm] Table dimensions: Ø600 x 500 [mm] Max. load on table: 500 [Kg] Stroke C axis : table revolution: 360 [°] B axis swivelling stroke: -30 [°] / +120 [°] Spindle type: BT40 Max. spindle speed: 12000 [rpm] Spindle power: 11 [kW] Tool changer magazin number of stations: 60 Max. tool length: 300 [mm] Max. weight of single tool: 8 [Kg] Max. tool diameter: 80 - 130 [mm] Total power required: 46.7 [kVA] Supply voltage: 400 [V] Number of running hours: 916 [h] Machine dimensions: 2350 x 2962 x 3039 [mm] Layout dimensions: 5010 x 2470 [mm] Weight: 10000 [Kg] EQUIPMENT INCLUDED: x1 RENISHAW part probe type RMP600 x1 RENISHAW tool probe type PRIMO LTS x1 RENISHAW calibration sphere x1 electronic handwheel x1 chip conveyor Nwedpfx Ajwv T I Hjfcoc x1 high-pressure pump 15 [bar] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Machine similar to Mikron, Hermle, DMG Mori, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas, Alzmetall, as well as milling machines, drill and tap machines, and CNC grinding machines.

Condition: good (used), Year of construction: 2009, travel distance X-axis: 1,120 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 36,000 m/min, rapid traverse Y-axis: 36,000 m/min, rapid traverse Z-axis: 36,000 m/min, table width: 510 mm, table length: 1,460 mm, table load: 800 kg, Renishaw measuring probe MP-12 IKZ 15 Bar Interface set Performabnce software package Nwsdpfxew Rm Die Afcoc Monitoring B prepared not included X - Travel: 1120mm Y - Travel: 510mm Z - Travel: 510mm Table Length: 1460mm Table Width: 510mm Table load: 800 Feed rate X-Axis: 36000mm/min. Feed rate Y-Axis: 36000mm/min. Feed rate Z-Axis: 36000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 18.5kW Speeds / ranges: 12000Rpm ATC / revolver: 30 Coolant through spindle / Bar:Yes Number of controlled axis: 3 Chip conveyor: Yes Coolantsystem: Yes Length: 3300mm Width: 2850mm Height: 2800mm Weight: 6100kg

Condition: good (used), Year of construction: 2007, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, rapid traverse X-axis: 36,000 m/min, rapid traverse Y-axis: 36,000 m/min, rapid traverse Z-axis: 36,000 m/min, table width: 760 mm, table length: 2,000 mm, table load: 1,400 kg, IKZ 15 BAar Measuring probe MP12 Bohrzyklus with torq depending Performance package Pendel screen Interface set X - Travel: 1740mm Y - Travel: 760mm Z - Travel: 660mm Table Length: 2000mm Table Width: 760mm Table load: 1400 Feed rate X-Axis: 36000mm/min. Feed rate Y-Axis: 36000mm/min. Feed rate Z-Axis: 36000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 15kW Speeds / ranges: 12000Rpm ATC / revolver: 30 Coolant through spindle / Bar:Yes Number of controlled axis: 3 Chip conveyor: Yes Nwedsw Rntrepfx Afcoc Coolantsystem: Yes Length: 4450mm Width: 3460mm Height: 2900mm Weight: 10500kg

Condition: excellent (used), Year of construction: 2020, operating hours: 8,052 h, functionality: fully functional, travel distance X-axis: 1,875 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,345 mm, rapid traverse X-axis: 24 m/min, rapid traverse Y-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, feed length X-axis: 1,875 mm, feed length Y-axis: 1,250 mm, feed length Z-axis: 1,345 mm, feed rate X-axis: 24,000 m/min, feed rate Y-axis: 24,000 m/min, feed rate Z-axis: 24,000 m/min, torque: 3,430 Nm, workpiece weight (max.): 4,000 kg, total height: 4,950 mm, total length: 7,029 mm, total width: 5,200 mm, rotational speed (min.): 10 rpm, rotational speed (max.): 10,000 rpm, overall weight: 51,200 kg, spindle speed (min.): 1 rpm, spindle speed (max.): 500 rpm, distance table center to spindle nose: 1,600 mm, spindle motor power: 37,000 W, spindle nose: A2-11, tool length: 300 mm, type of input current: AC, turning diameter: 1,450 mm, turning diameter over cross slide: 1,250 mm, spindle diameter: 160 mm, bar passage: 160 mm, chuck outer diameter: 500 mm, collet bore: 160 mm, feed force X-axis: 20,000 N, feed force Y-axis: 20,000 N, feed force Z-axis: 25,000 N, milling spindle length: 300 mm, quill diameter: 160 mm, quill stroke: 250 mm, quill travel distance: 250 mm, spindle bore: 160 mm, swing diameter over bed slide: 1,450 mm, swing diameter over cross slide: 1,250 mm, swing diameter over top slide: 1,100 mm, turning diameter over bed slide: 1,300 mm, turning length: 1,600 mm, Equipment: chip conveyor, documentation/manual, For sale: Mazak Integrex e-1250 V/8 mill-turn center complete with extensive accessories and a Mazak Palletech High Rise (800B) automation system. The system combines milling, turning, and automated pallet handling – ideal for complex workpieces in a single setup. _____ Technical Specifications – Integrex e-1250 V/8 • Travel: X = 1,875 mm, Y = 1,250 mm, Z = 1,345 mm • Rotary table: Ø 800 mm, 500 rpm • Tool magazine: 120 positions (CAPTO) • Control: Mazak SmoothX with 5-axis functionality • Operations: Milling, turning, drilling, tapping, 5-axis simultaneous machining • Coolant system: High-pressure system up to 70 bar, Mayfran belt filter system, oil separator, coolant guns • Accessories: Tool Eye, Renishaw touch probe, HD camera system, overload monitoring _____ Software & Control Package • Synchronous tapping (G84.2 / G84.3) Nedpfx Aoxgu E Ejfcjwc • Engraving and re-cutting functions • Cylindrical & polar interpolation (EIA) • Tool length & radius compensation (5-axis) • Fine spline interpolation (EIA) • Mazatrol turning/milling function • MT Connect adapter for networking _____ Automation – Palletech High Rise (800B) • Pallet transport system (mixed type) • Expandable high-bay racking solution for flexible manufacturing • Ideal for both series and mixed production • Note: Pallets to be procured separately _____ Special Features • Complete documentation (digital & print) • Full package: machine + automation + accessories _____ Your Advantage • “Done in One®” concept: all machining in a single setup • Productivity: 5-axis machining + turning + pallet automation • Flexibility: From single parts to series production • Efficiency: Automatic pallet change & integrated measurement technology 📍 Location: Southern Germany 👉 Price and delivery terms upon request

Condition: used, Year of construction: 1984, x-travel 1000 mm y-travel 508 mm z-travel 460 mm size of pallet 1240 x 550 mm numbers of pallets 2 workpiece weight 800 kg spindle taper ISO 40 spindle motor 5,5 kW turning speed range 28 - 4000 U/min no. of tools in magazin 30 control MAZATROL M 1 total power requirement kW weight of the machine ca. 5,6 t Nsdpfetqqk Ijx Afcswc dimensions of the machine ca. 4,50 x 3,00 x 2,65 m acc.: chip conveyor

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol 640 Nexus, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 560 mm Travel Y-axis: 410 mm Travel Z-axis: 510 mm Table dimensions: 900 mm x 410 mm Nwsdpfxsymzmko Afcoc Spindle speed: 12,000 rpm Tool holder: SK40 Number of stations in tool changer: 30 Internal coolant supply: 15 bar MACHINE DETAILS Control: Mazatrol 640 Nexus Machine weight: 5,010 kg EQUIPMENT Chip conveyor

Condition: good (used), Year of construction: 2013, Swing over bed 660mm, Nwedpfx Asyna Ngofcec maximum machining diameter 350mm, maximum machining length 540mm, bar capacity 65mm, spindle speed 5,000rpm, 12 station turret, Mazatrol Smart control, swarf conveyor, & 3 jaw chuck.

Condition: good (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 533143283, travel distance X-axis: 2,000 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, controller manufacturer: MAZATROL, workpiece height (max.): 750 mm, workpiece weight (max.): 3,000 kg, table width: 800 mm, table length: 2,240 mm, overall weight: 14,000 kg, Mazak MTV-815/80 • Table size: 2,240 mm × 810 mm • Maximum table/workpiece load: 3,000 kg evenly distributed • Maximum spindle speed: 40 - 6,000 rpm • Spindle taper: SK 50 Nwjdjx E Twaspfx Afcoc • Spindle power/torque (standard): e.g. 18.5 kW and 759 N·m at 40% duty cycle / 30 min rating; for high-power version: 26 kW and 1,067 N·m. All information provided without guarantee

Condition: used, Year of construction: 2022, turning diameter 276 mm turning length 500 mm control Mazatrol Smooth G max. swing diameter over bed 695 mm Distance spindle end - turret 710 mm bar material dia. max. 65 mm turning speed range - spindle 35 - 5000 U/min max. torque on the spindle 465 Nm x-axis 234 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 21 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min spindle nose A2-6 spindle passage 76 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW tailstock quill taper MT 5 Travel- tailstock 550 mm Tool turret 1 Numbers of tools 12 (angetrieben) tool taper VDI 30 min rated capacity 42,6 kVA Required air-pressure 0,5 / 330 MPa / l/min distance spindle /table 710 mm total power requirement 37 kW weight of the machine ca. 5,7 t dimensions of the machine ca. 2,8 x 2 x 1,9 m With the following special accessories: - Mayfran chip conveyor, side ejector, hinged belt conveyor - Engraving function ACCESSORIES / MACHINE OPTIONS Automatic on/off switch and warm-up function A warm-up is necessary to avoid problems such as abnormal wear of the sliding Nwedpfx Aeynbd Ssfcec surfaces and sluggish movement. A sufficient warm-up provides the machine with the heat resistance it needs to machine workpieces with consistent, high precision. Transformer for the European market 8" chuck for main spindle with enlarged passage USB connection (1 connection) Mazak standard colour Main spindle motor AC 26 kW Tool turret with 12 stations VDI, also for driven tools in every position. For maximum performance, only the cutting tool is driven. Programmable tailstock (MK5) Tailstock quill (MK5) Y-axis control SAFETY DEVICES Operator door with lock switch Double foot switch Opening and closing of the chuck by means of a separate switch. Hydraulic pressure lock Fully enclosed work area Work area lighting COOLANT SUPPLY High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system CHUCK, ETC. Automatic opening/closing of chuck jaws 8" power chuck with enlarged passage (main spindle) Kitagawa BB208 MEASURING SYSTEM Automatic Tool Eye NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (shared variables: 600 pairs) Mazak tapping/drilling cycle Tornado in EIA/ISO. (Only possible on machines with Y-axis. EIA/ISO package EIA/ISO input function EIA/ISO additional functions - Helical interpolation - 3D tool correction - Workpiece coordinate rotation - Geometric function - Scaling - External data input/output Thread cutting function (G33) Reverse time feed G93 G37 Tool length measurement Polar coordinate input (EIA) Optional stop (optional stop) Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak thread tapping/drilling cycle Tornado in EIA/ISO. EIA/ISO drilling cycles (arc, grid, circle, circular arc, line) Machining on inclined surfaces EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Interface for LAN SD memory card I/F Smooth standard software for lathes (milling) MAZACC 2D software Workpiece shape compensation Rapid traverse paths Rounding function - Seamless co...

Condition: used, Year of construction: 2012, turning diameter 203 mm turning length 300 mm Nedpfsynbd Eox Afcewc control Mazatrol Smart Distance spindle end - turret 99-434 mm max. turning diameter 280 mm bar material dia. 51 mm travel -x axis 200 mm travel -z axis 340 mm spindle turning speed range 35 - 6000 U/min rapid traverse X-axis 33 m/min rapid traverse Z-axis 36 m/min spindle bore 61 mm Tool turret 12 -fach turning tool - shaft cross cut 20 Boring bar- Ø 32 mm workpiece weight 150 kg spindle nose A2-5 taper in tailstock-quill MK4 Travel- tailstock 350 mm total power requirement 16,3 kW weight of the machine ca. 3,5 t dimensions of the machine ca. 1,9 x 1,6 x 1,8 m Special accessories: Autom Tool Eye Spindle orientation Signal light Additional coolant nozzles above the chuck Automatic switch-off Interface for bar feed Automatic parts catcher Ø 51 x L:100 x 2.5 kg Workpiece conveyor for automatic parts catcher with workpiece tray Chip conveyor, side ejection Includes: Automatic short bar loading magazine LNS QUICK LOAD SERVO 80_S2 Diameter range: 6 - 80 mm round and hexagonal material Bar lengths: 350 - 1600 mm, however max. headstock length /UVV Weight max. 67 kg / bar Burr-free bars or bar sections Depth 600 mm for holding bars Input voltages from 200 – 460 volts / operating voltage 24 V DC, LNS control programmed on SIEMENS STEP 7 PLC, flexible control panel with large screen, user guidance via symbols for easy operation and adjustment. Device cover with 2 viewing windows made of Plexiglas.

Condition: used, Year of construction: 2016, The Mazak VTC 800 series is a line of powerful, large-format 5-axis turning centers for large workpieces, known for their high precision and rigidity, ideal for aerospace, energy and heavy machinery, with functions such as integrated spindles, fast tool change, and for efficient complete processing. Accessories/Options: Tool magazine for 30 tools Tool length measurement, tool breakage detection Factory-installed preparation for chip conveyor (left) Magazine (HSK) for 155 tools Air blower at the workpiece Signal light (end of machining: yellow) Additional: Work area lighting Coolant gun Air blower through the spindle 70 bar preparation, including interface for high-pressure system Automatic opening/closing of the operator door Mazak Monitoring System B RMP 60 (only/H/V) Collision monitoring by Brankamp 2 Renishaw TS27R tool presetting devices NC rotary table Holding device for vertical use of the NC rotary table Table center partition for pendulum machining 3D model of the work area in STEP format 5-axis milling technology Knoll compact filter KF400/2300 (filtration capacity 400 l/min, tank volume 2300 l/min) 1) High-pressure cooling 70 bar, 7 pressure stages Chip conveyor, hinged belt design Additional M-codes: 1 set = 2 M-codes Preparation for dual extraction system (mechanical nozzle) 0.198 mm Transformer for the European market 1 set of manuals in electronic form on CD 1 set of adjustment tools Foundation set (anchor bolts + plates) MAZAK standard paint Work area lighting Additional items: AirFresh FMN V12 extraction system (installed on both sides and coupled with a door sensor) Holding device for vertical operation of the rotary table 2 x Renishaw TS27R integrated tool presetting devices Spare parts: Y-axis motor, tool magazine Linear axis shifter motor Rotary axis shifter motor Cylinder for swivel unit width: 3500 mm length: 820 mm X-axis travel range: 3000 mm Y-axis travel range: 800 mm Traversal range Z-axis: 720 mm min. distance spindle nose to table top: 140 mm max. distance from spindle nose to table top: 860 mm max. table load: 2500 kgf B-axis: ± 110 degrees Working spindle taper: HSK63 Max speed: 18,000 RPM Min. Drehzahl: 35 min-1 Rated power: ( 100 % continuous operation) 33,0 kW Emergency travel speed X-Y & Z axis: 50 m/min Working table width: 3500 mm Worktable length: 820 mm Width of T-slots: 18 mm Number of T-slots: 7 Distance of T-slots: 100 mm Table height from the floor: 870 mm Tool changer number of tool places (Standard): 30 Number of tool stations (optional): 48 Tool selection method: shortest path tool shank: Steep cone 40 With occupied side positions: 80 mm With available spaces: 130 mm max. tool weight: 8kgf Total weight of all magazine tools: 150 kgf max. tool length: 350 mm Tool change time: (Span-to-Span) 4.7 s Connected load: 400 V / 50/60 Hz Air pressure: 5 – 9 bar Air volume: 260 l/min Tank capacity: 500 l Dimensions (Height x Length x Width): 3376 x 5480 x 4051 mm Weight approx: 16300 kg colour: Gray / Black Njdpfsx Idwijx Afcewc
