Used Scm Edgebander for sale (577)

Condition: like new (used), Year of construction: 2025, functionality: fully functional, Spindle configuration 1st spindle: Planing spindle – 4 kW 2nd spindle: Right vertical spindle – 5.5 kW 3rd spindle: Left vertical spindle – 5.5 kW 4th spindle: Top horizontal spindle – 4 kW 5th spindle: Bottom horizontal spindle – 4 kW 6th spindle: Universal spindle – 4 kW Spindle speed: 6,000 rpm Spindle diameter: 40 mm Working area Working width: 25–230 mm Working height: 10–120 mm Min. workpiece length: 450 / 630 mm (depending on version) Feed Infinitely variable: 5–25 m/min Feed rollers Ø 140 mm Infeed table 2,000 mm Tooling ranges Vertical spindles: 100–180 mm Horizontal spindles: up to 180 mm Max. profiling depth, vertical: 40 mm Ijdpfxeyym Nre Apcjia Features Manual table and central lubrication Robust industrial design, smooth operation and high precision

Condition: used, Year of construction: 2011, AXES Working Range X-Y-Z Axes * mm 3050-1300-180 Workpiece length for pendulum operation mm 1390 Stroke X-Y-Z Axes mm 3460-1735-250 Max. traverse speed of X-Y axes m/min 60 WORK TABLE Number of workpiece supports and vacuum cups 6 / 2 standard type Standard end stops / position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles std/quantity/speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles std/quantity/speed 1/min 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power std./opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer traveling with unit carrier in X 4 places, pneumatic INSTALLATION Isdpjyymz Ujfx Apceia Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction connection diameter mm 150+150 (200) Machine weight Kg 3000 * X: distance between stops; Y: milling center as reference point; Z: workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center, C-frame design, and worktable with adjustable workpiece supports and vacuum suction cups, for: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutter in the “X” direction - General milling work Self-supporting structure and work table Structure made from welded steel construction with control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV carrier options. Box construction made from cold-rolled steel with internal stiffening ribs and protective devices comprising a drilling head with vertical spindles, horizontal spindles, an integrated grooving and saw unit, and an SCM electrospindle with HSK 63 F quick-change tool system. Movement paths of the portal and unit carrier Movement in the X, Y, and Z axes is via linear prismatic guideways with preloaded ball bearings. The X-axis movement (moving gantry) uses a preloaded, backlash-free rack-and-pinion drive with helical gearing. Movement of the unit carrier in Y and Z directions is also preloaded for precision. Positioning of the working units and machine function control is through "brushless" AC servo motors and digital drives. CNC CONTROL The control unit comprises a numerical control for the milling and drilling machines and a PC with a graphical user interface "XILOG PLUS". PC office operating system Windows XP - 17" LCD color screen - QWERTY keyboard - Swiveling control panel - Machine interface: Xilog Plus software Xilog Plus Features Programming - Parametric, graphical, and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation on three axes, spatially linear, spirally on selected plane - Supported programming with graphical and syntax assistance for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on slanted or curved panel sides - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional functions - Calculator for direct transfer of computed data - S

Condition: excellent (used), SCM K360 HP Edgebander Liquids Ijdpoyyvg Hefx Apceia Pre-milling cutters, Glue application by roller, Interchangeable glue tank Equipped with glue discharge Pneumatic pre-cut guillotine, Finishing saws for precise trimming Top-bottom milling unit (multi-cutter R1-R2), Corner rounding unit, Profile scraper (multi R1-R2), Cleaning fluids Flat scraper, Polisher, Machine equipped with NC control Max workpiece height: 60mm Max edgeband thickness in roll: 3mm Feed speed: 11m/min Original mileage less than 10,000 meters; in my opinion, its technical condition is not far from a new machine Can be checked and tested on site

Condition: used, Year of construction: 1994, Used machine Year of manufacture: 1994 Iiedpfjxwz Izox Apcsa Equipment and technical data: - Planing width: 410 mm - Min. thicknessing height: 3 mm - Max. thicknessing height: 240 mm - Max. cutting depth: 7 mm - Total table length: 2060 mm - Number of knives: 3 pcs. Tersa knives - Thickness table adjustment: motorised - Thickness display: mechanical - Motor: 4 kW - Feed speed: 6/12 m/min - Infeed roller: steel - Outfeed roller: steel - Extraction port diameter: 120 mm Availability: short term Röllbach

Condition: excellent (used), LOADER (BRIDGE-FRAME) WITH DOUBLE PICK-UP STATION Iijdoyywi Ajpfx Apcea Gantry (Portal) machine, belonging to the line (SOFIT code: W05025) Vacuum system (with its pump) N. 2 Vertical supporting columns of the top supporting beam N. 1 Horizontal top supporting beam (where the carriage slide on) N. 1 Motorized sliding carriage with horizontal metal arms N. 2 Horizontal metal arms with vacuum cups, adjustables N. 2 Out-side rollers ways (on gound) to in-feed pile of panels to the Loader N. 1 Out-side motorized rollers table (which out-feed the panels from the Unloader) Separate electric and command panel Electronic Programmer PLC MAGELIS Perimetral safety metal grids Working capacity (cycles/min) 15-18 (ca.) Min/Max panels thickness mm 10 - 60 (ca.) Min dimensions of the panels mm 210 x 230 (ca.) Max dimensions of the panels mm 1200 x 3200 (ca.) Total installed motor power Kw

Condition: used, Year of construction: 2018, functionality: fully functional, power: 4 kW (5.44 HP), input voltage: 400 V, input frequency: 50 Hz, cutting height (max.): 100 mm, saw blade diameter: 315 mm, saw blade bore: 30 mm, overall weight: 295 kg, extraction nozzle diameter: 120 mm, sliding table length: 1,600 mm, The used SCM panel saw SC 2C is a modern and precise panel saw designed for professional woodworking applications. It stands out with its compact design, high cutting accuracy, and easy operation. The machine comes from private ownership and is therefore offered without deductible VAT. Isdpfxoyyl Hvs Apcoia

Condition: excellent (used), 4-SIDED SIZING-SHAPING LINE (currently for Internal Doors). Composed by of the following machines: X10023A) Motorized infeed rollers table "CELASCHI"" X10023B) Double End Tenoner "CELASCHI" Mod. TSA 3 B 480 A Installed power KW 65 Iiodpfx Apswzmbqecsa X10023C) 90° Motorized Transfer ("L-shape") conveyor "CELASCHI" Mod. X10023D) Double End Tenoner "CELASCHI"" Mod. TSA 2 B 360 Installed power KW 60

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Maximum panel thickness: 60 mm Isdpsyziutofx Apceia Pre-milling unit Gluing unit with glue pot Edge trimming unit Corner rounding unit Edge and glue scraping unit Polishing brushes Control: StarTouch with touchscreen

Condition: used, Year of construction: 2011, Base Machine M800 X5 TV 1 WORKING RANGE X: 5,020 mm Y: 1,830 mm Z: 675 mm Clearance Height: 300 mm (from 50 mm suction cup height) MACHINE STRUCTURE The base structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed with welded components, providing exceptional stability. The table design, with its large base, is the key to ensuring lasting precision and stability. The machine’s layout enables the operator to achieve optimal workflow with minimal space requirements. The mobile gantry is built as a solid monoblock. It is positioned in the X direction on prismatic, ground guides with recirculating ball carriages. The machining unit is mounted on this mobile support carriage, also on prismatic, ground guides and recirculating ball carriages. AXIS MOVEMENT All axes travel on prismatic linear guides with large cross-section and recirculating ball shoes with a wide contact surface, which ensures optimal sliding, even at high speeds and accelerations. The precise and fast positioning of the movable gantry (X-axis) is achieved via helical rack and pinion. Large cross-section recirculating ball screws ensure accurate positioning of the machining unit along the movable gantry (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. Max. axis speeds: · X-axis = 90 m/min · Y-axis = 90 m/min · Z-axis = 30 m/min Safety device with bumper and light barrier 1 Bumpers with sensors are fitted to the movable upright, and a light barrier system is installed at the front of the machine. If the operator enters the active zone, the X-axis travel speed is reduced to a lower value of 25 m/min without stopping the machine. This system allows parts to be loaded during pendulum operation without the limitation of access areas, as seen with pressure mat systems. This prevents unwanted interruptions in the machining cycle and offers greater freedom of movement around the worktable. CE certification for the safety system 1 Safety protection fence 1 Side and rear protection fence Automatic central lubrication controlled via CNC 1 The lubrication of the X, Y, and Z axes is controlled by the CNC; intervals are regulated automatically, without manual intervention. Central extraction connector 1 All individual extraction connections of the machining units are collected into a central extraction port. Inside the port, there are various slider valves controlled by the NC. This reduces the required extraction air volume. Chip conveyor 1 Maxi – 5-axis electrospindle 11 kW HSK-63 “Prisma K 1 5-axis electrospindle, 11 kW at 20,000 rpm S1 (100% duty cycle) Speed: max. 20,000 rpm Rotation direction: left/right Liquid cooling Tool interface HSK 63F Inverter 18 kW, stepless, smooth power delivery Max. rotation B-axis = 200° (+-100°) C-axis = 650° Thanks to the non-orthogonal axes, it is possible to perform complex horizontal positioning in a small workspace. This enables the machining of complex geometries without the risk of collision. Ijdpexy Tmnofx Apcsia

Condition: used, SCM Sandya LS1 R110 calibrating machine with 1100 mm roller and brush. Approximate power consumption: 13 kW. Used. 11 kw roller Iiedpfxouk Hi Rs Apcea 2.2 kW brush Carpet 0.75 kw

Condition: excellent (used), Wide Belt Sander SCM sandya 7 Sanding width: 1100 mm Iisdpfx Apoyx Dvyjcsa 1st unit with metal calibration roller, 15 kW 2nd combination unit with rubber roller and pad, 15 kW Minimum electrical protection: 32A Pad with quick lift and drop function Pneumatic oscillation Variable feed speed Electric table height adjustment Table position display Pneumatic feed belt centering Robust sander, excellent sanding quality

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Iijdpfx Asw Dcccjpcsa

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Ijdpew Dcb Ssfx Apceia

Condition: used, Year of construction: 2022, PANEL SAW WITH TILTING SAW BLADE Linvincibile SI 5 KEY FEATURES SLIDING TABLE: GUARANTEED SUPERIOR CUTTING QUALITY OVER THE LONG TERM TELESCOPIC ARM: AN “UNBEATABLE” SMOOTH MOVEMENT SAW UNIT: FOR A PERFECT CUT Technical Data SI 5 Main saw blade diameter (mm): 550 Cutting capacity with extendable fence - with table 3200 mm - with table 3800 mm 3200x3200 3800x3200 Saw blade tilt (degrees): 46 Max. cutting height at 90° (mm): 200 Max. cutting height at 45° (mm): 130 Saw blade speed (rpm): 2500-3500-5000 Scoring blade speed (rpm): 8500 - Extractor port diameter: - on frame - on blade guard 120 100 Main motor power [S6 -40%] Hz50 kW: 7 Scoring motor power [S6 -40%] Hz50 kW: 0.9 Cutting width at rip fence (mm): 1600 Standard equipment and accessories - Optimizer/Process control app for tablets: SCM Thundercut. The app can be downloaded from the App Store or Play Store for tablets compatible with iPadOS or Android. It can be activated via the QR code supplied with the machine. The app enables: * Management of machine fleet and material/panel storage * Creation and editing of projects, importing projects from main furniture design software (file format "cpout"), importing cutting lists * Optimization of cutting lists by selecting one or more proposals from the optimization software integrated into the app * Correct machine settings for each cut, thanks to the simple and intuitive graphics of the 3D sequencer, guiding the operator step by step * Printing barcode labels to identify the various parts, via Bluetooth connection with compatible label printers. - 10-year warranty on the sliding table guide system - Sliding carriage entirely made of aluminum structure with guidance on crimped, hardened and arc-ground steel rails with large contact area - Max. saw blade diameter* up to 450mm with scoring blade mounted* up to 550mm without scoring blade - eye-S 15" electronic control including: * 15" touchscreen monitor * Direct control of the following working axes with manual, semi-automatic, automatic, and incremental modes: - Height adjustment of the main saw blade - Tilt adjustment of the saw unit - Rip fence adjustment - Height and lateral adjustment of the scorer (the scorer is automatically raised to the set position on activation and lowered on deactivation) * Operator assistance functions for complex cuts * Ability to store up to 1000 programs with associated image * Ability to store up to 1000 different tools with associated image * Cutting process management of preloaded parametric machining programs * Environment for creating and storing new sequenced working programs * Automatic import of working dimensions from Thundercut app * USB port * Ready for network connection - Auxiliary function of the electronic control, including: * Determination of correct fence position on rip fence for format processing with tilted saw blade * Determination of correct fence position on rip fence for angle cuts with mitre fence on the work table with or without tilted saw blade - Pivoting control panel above the table - Scoring unit with independent Iiedpfx Asxqtvqspcea

Condition: used, Year of construction: 2001, Min./Max. working width (finished size): 23 - 180 mm Min./Max. working height (finished size): 6 - 105 mm Min. workpiece length: 300 mm Feed speed: 6 - 12 rpm Spindle speed: 6000 rpm Spindle diameter: 35 mm Motor power, horizontal spindle: 10 kW Motor power, vertical spindle: 7.5 kW Feed motor power: 1 kW Diameter of feed rollers: 120 mm Extraction port diameter 1 pc: 150 mm Extraction port diameter 2 pcs: 120 mm Weight: approx. 950 kg Storage location: Supplier Iiedeym D Eijpfx Apcsa

Condition: used, machine/vehicle number: 008047, Position 1: Brushing Machines SCM-BRAVOROBOT P1 Position 2: spraying machine SCM-BRAVOROBOT P1 Isdpfx Aow Idbyopcjia Position 3: Roller Conveyors SCM-BRAVOROBOT P1 Position 4: Compressed Air Dryers SCM-BRAVOROBOT P1 Position 5: Ovens SCM-BRAVOROBOT P1

Condition: excellent (used), Cutting dimensions: 3300x3300 mm Iijdpfxjyyzl Io Apcja Cutting height: 55 mm 3 air tables Length of air tables: 2.6 m 9 grippers Maximum saw blade diameter: 300 mm Maximum scoring blade diameter: 160 mm Saw carriage feed speed: 0–60 m/min Pusher beam feed speed: 0–60 m/min Main saw motor power: 9 kW Scoring saw motor power: 1.3 kW Year of manufacture: 2018

Condition: good (used), Year of construction: 2017, In good technical condition. Year of manufacture: 2017. Suitable for dry deburring and disinfection of metal surfaces. Burr removal. Oxide removal on edges and surface finishing. Manufacturer: SCM Group spa Italy. Model: DMC M950. 400V, 71A. Machine weight: 2260 kg. Iisdpfx Ajx Ttn Ujpcea

Condition: used, Year of construction: 1995, functionality: fully functional, SCM si150 Panel Saw Specification: • Condition – used, after a comprehensive overhaul • Manufacturer – SCM • Model – si 150 • Sliding table length: 150 cm • Blade diameter: 300 mm • Machine equipped with a scoring unit • Main saw motor: 4.0 kW • Blade tilting: manual • Manual blade raising and lowering • Blade guard on spring support • Maximum cutting height: 95 mm • Side table dimensions: 85 x 60 cm • Extraction port diameter: 100 mm • Cart with wheels for machine relocation included • Weight: 480 kg • Year of manufacture: 1995 • Overall dimensions: 151 x 270 x 137 cm (W x L x H) • Transport dimensions: 151 x 125 x 137 cm (W x L x H) Additional information: • The machine is in good technical condition, ready for immediate use Iodpfx Asyy Sq Uspcoia • The presented photos show the actual condition of the item for sale • Testing and demonstration on-site available • Free training on machine operation (at company headquarters) • The auction price does not include VAT or transport costs Financing and transport: • We organize transport with our MDD fleet, courier services, or external carriers • Financing available through leasing or a lease loan

Condition: used, functionality: fully functional, SCM 900 RT Wide Belt Sander Specification: • Condition - used, after a comprehensive inspection, calibration, and replacement of all seals • Manufacturer - SCM • Model - 900 RT • Working width - 900 mm • Maximum working height - 160 mm • 1 combination sanding unit (hard roller with 200 mm diameter + sanding pad) • Main motor power - 7.5 kW • 2 machine feed speeds • 2 conveyor speeds • Analog thickness indicator for the workpiece • Pneumatic oscillation • Abrasive belt size - 2300 x 900 mm • Weight approx. 1200 kg • Overall dimensions: 185 x 155 x 210 cm (L x W x H) Iedpfx Apeyy Ngyjcsia Additional Information: • The machine is in good technical condition and ready for immediate use • The photos shown reflect the actual condition of the sale item • Possibility to switch on and inspect the machine on site • The auction price does not include VAT or transport costs Financing and Transport: • We organize transport using the MDD fleet, courier companies or external carriers • We offer financing support in the form of leasing or lease-loan

Condition: used, Year of construction: 2014, functionality: fully functional, SCM Sandya 1S 950 RT Wide Belt Sander Specification: • Condition – Machine is virtually new, 100% original • Manufacturer – SCM • Model – Sandya 1S Iisdeyy Nc Uopfx Apcsa • Working width – 950 mm • Max working height – 160 mm • 1 combination sanding unit (steel roller + pad) • Main motor power – 5.5 kW • 2 feed speeds • 2 conveyor speeds • Electronic thickness gauge for sanded workpiece • Optical oscillation system • Thickness meter for sanded element • Abrasive belt size – 1530 x 970 mm • Complete documentation from the manufacturer (in Italian) • Weight – 650 kg • Year of manufacture – 2014 • Overall dimensions: 150 x 143 x 170 cm (L x W x H) Additional information: • The machine is in perfect technical condition, ready for immediate operation • The attached photos show the actual condition of the item for sale • Possibility to power on and test the machine on site • Free operator training provided at company premises • The price listed in the auction does not include VAT or transport costs Financing and transport: • We organise transport using the MDD fleet, courier companies, or external carriers • Financing options available in the form of leasing or lease-loan

Condition: used, Year of construction: 2012, functionality: fully functional, input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, cutting height (max.): 100 mm, cutting width (max.): 1,330 mm, saw blade diameter: 315 mm, tilt adjustment saw blade: 45 °, height adjustment type: mechanical, saw blade bore: 30 mm, overall weight: 670 kg, Equipment: CE marking, saw blade guard, – Italian production – year of manufacture: 2012 TECHNICAL SPECIFICATIONS: – carriage length: 3200 mm – cutting width on the right: 1330 mm – saw blade diameter: min. 250 mm, max. 315 mm – scorer blade diameter: 120 mm – main motor: 5.5 kW – scorer motor: 0.75 kW – brake – main saw spindle diameter: 30 mm – scorer spindle diameter: 20 mm – cutting height adjustment – cutting angle adjustment: 0° - 45° – max. cutting height: 100 mm – two latches Isdpjyxph Usfx Apcjia – movable guard – extraction nozzle diameter: 80 and 120 mm – dimensions (L/W/H): 340 / 220 / 170 cm – weight: ~ 670 kg

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Ijdovvi I Rjpfx Apceia

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Iiodpfxovwbp Aj Apcsa

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Iiodpfx Aevvi Htopcsa Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Storage location: Sonnefeld
