Used Deckel Fp1 for sale (701)

Condition: reconditioned (used), Deckel FP1 AKTIV (3-Axis Active) Machine No. 2102-5745 Year of manufacture: approx. 1988 Travel distances: X-axis: 300 mm Y-axis: 150 mm Hodpfx Aoxpwfgohuofb Z-axis: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 - S20x2 Spindle speed: 40–2000 rpm Motor power: 1.6 and 2 kW Power supply: 380 Volt, 50 Hz Equipment: - HEIDENHAIN 3-axis active digital readout, type TNC 113 - Infinitely variable feed on X, Y, and Z axes - Quill movement on vertical milling head: 60 mm - Vertical milling head swivels and extends horizontally by 100 mm - Coolant system (coolant tank in machine base) - Documentation - Centralized lubrication Space requirements (L x W x H): 1350 x 1100 x 1700 mm Weight: 850 kg The machine has been visually refurbished and technically inspected. Geometry measurement videos can be provided upon request. Backlash Y-axis: 0.15 mm Backlash X-axis: 0.3 mm Backlash Z-axis: 0.2 mm Runout horizontal spindle: 0.002 mm Runout vertical spindle: 0.002 mm Parallelism deviation Y-axis: 0.002 mm (measuring length 150 mm) Parallelism deviation X-axis: 0.002 mm (measuring length 300 mm) The following parts have been renewed: - Centralized lubrication checked - Heidenhain digital readout overhauled - New wiper set installed - LEDs in the Active display replaced - Oil changed - Vertical milling head fitted with new bearings - Oil sight glass replaced Net price, ex stock, free loaded

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 30000452, travel distance X-axis: 300 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 340 mm, quill travel distance: 60 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, table length: 600 mm, table width: 210 mm, overall weight: 710 kg, table load: 200 kg, Equipment: documentation/manual, DECKEL FP1 – completely overhauled in 2012 by FPS (Germany), equipped with Heidenhain digital display, tool cabinet with accessories, and dividing head. Since the overhaul, the machine has seen very light use and is therefore in like-new condition. About FPS: Specialized in the complete refurbishment of DECKEL machines. MANUFACTURER: DECKEL MODEL: FP1 CONDITION: Overhauled (2012) – mechanically and electronically as new! LOCATION: Graz (Austria) IMAGES/VIDEOS: For additional photographs and videos of the machine in operation, please contact us. Description: This high-quality DECKEL FP1 milling machine has been completely refurbished, with both mechanical and electrical components upgraded to the latest standards. A new CE-compliant control cabinet was installed in accordance with current statutory requirements (BGVA 3 / DIN-EN 60204-1, new machinery standard). During the overhaul, the control system, drive package, and drive motors were all replaced and brought up to date. The modernization also included the installation of a new, touch-safe control panel and new motor. Technical data: Operation: manual, with option for automatic positioning Control: 3-axis Heidenhain digital readout Spindle speed range: 40 – 2000 rpm (geometrically stepped, 16 speed stages) Feed rate: 10 – 500 mm/min (stepless adjustment) Rapid traverse: 1.2 m/min (stepless adjustment) Hfodpfx Aexywhcjhusb Quill: Vertical & horizontal extension 60 mm, SK40 Travel (X/Y/Z): 300 / 150 / 340 mm Table size: 600 × 210 mm Table load: max. 200 kg Machine weight: 710 kg incl. angle table and milling head Footprint: 1600 x 1400 x 1750 mm (W / D / H) Equipment: Vertical and horizontal spindle Milling head manually swivels ± 90° Completely new electrics and drive packages Overhauled – mechanically and electronically as new Extras: Z-axis bellows Special paintwork Highlights: Heidenhain digital readout for precise operation During overhaul, entire control system, drive package, and drive motors were renewed Contact us to arrange a viewing appointment.

Condition: reconditioned (used), Year of construction: 1990, Universal Tool Milling Machine Make: DECKEL Hfjdpfex It Rxjx Ahuob Model: FP 1 Aktiv Year of manufacture: 1990 – workshop-inspected Machine no.: 2102-5866 Milling head type: 2171 Milling head no.: 4613 Geometric inspection with test report Accessories: - 3-axis active digital readout HEIDENHAIN TNC 113 with active function in X, Y, and Z axes - Universal table 590 x 250 mm (T-slot: 12 mm) - Vertical milling head SK 40 with pull stud thread S 20 x 2 - Without coolant system; can be retrofitted if required - Centralized lubrication, electric - Operating manual Used as seen, sold without warranty The machine is technically in the condition of its year of manufacture.

Condition: used, Year of construction: 1982, x-travel 300 mm y-travel 160 mm z-travel 340 mm feeds -stepless- 5-500 mm/min rapid traverse 1200 mm/min spindle turning speed range 40 - 2000 U/min tool taper Normkegel 40 table length 600 mm table width 120 mm voltage 380 V frequency 50 Hz rated current 13 A weight of the machine ca. 0,750 t dimensions of the machine ca. 1,8 x 1,5 x 1,8 m DESCRIPTION Machine incl: active three-axis digital readout HEIDENHAIN documentation various tool holders Hfsdpjvvnfuefx Ahusb Machine vice etc.

Condition: good (used), Year of construction: 1985, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, 3 active axes, rigid table, SK 40 M16 spindle taper. Central lubrication, operating manuals included. Good operational condition, comes from a vocational training center. Can be demonstrated under power by arrangement. Hfjdpfxexwunze Ahujb

Condition: good (used), DECKEL High-Speed Milling Head No. 2021-2230 / FP 4 - 0199 This high-speed milling head is suitable for a DECKEL FP 1 / 2 / 3 / 4. When used on an FP 1, an intermediate plate is required. Spindle mount SK 40 Spindle speed range 40 - 2000 + 125 - 6300 rpm. Quill adjustment Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 Hjdpfxowg Rybe Ahujfb DE - 44143 Dortmund - Wambel

Condition: used, Universal Tool Milling Machine with Active Digital Display DECKEL Type FP 1 Universal Milling Machine Machine No. 2102 - 3322 Year of manufacture: 1986 Travel distance X: 300 mm, Y: 150 mm, Z: 330 mm Table size: 600 x 210 mm Spindle mount: SK 40 - S20x2 Spindle speed: 40–2000 rpm, 16 steps Feed (X and Y axes): 5 to 500 mm/min Hjdpfx Ajr D T Uyohujfb Rapid traverse: 1200 mm/min Motor power: 1.6 and 2 kW, pole-changeable Electrical connection: 380 Volt, 50 Hz - HEIDENHAIN active 3-axis digital readout, type TNC 113 - Infinitely variable feed on X, Y, and Z axes - Spindle speed via 2 motor speeds and 8 gearbox steps - Quill travel on vertical milling head: 60 mm - Vertical milling head swiveling and extendable 100 mm horizontally - Fixed angle table 600 x 210 mm - Coolant device integrated in machine base - Separate electrical cabinet - Original chip tray for mounting on machine base - Operating manual, electrical diagrams, and spare parts list available Space requirements (L x W x H): 1350 x 1100 x 1700 mm Weight: 830 kg Good condition

Condition: used, tool adaptor 88 length 560 mm center height of top slides 65 mm weight 17 kg Counter holder / horizontal milling device for tool milling machine Deckel Mod. FP 1 consisting of upper beam and mounting of the milling arbor. The distance from the middle of the milling arbor to the lower edge of the counter holder is 65 mm, the width of the guide is 88 mm. Machine dealer with own stock of 1600 m². Hsdpfx Ahov Dxzcjuefb

Condition: reconditioned (used), Year of construction: 1987, Universal tool milling machine Make: DECKEL Model: FP 1 Active Year of manufacture: 1987 - overhauled, repainted, RAL7035 light gray / RAL7012 basalt gray Mach. no.: 2102-3429 with guarantee geometric acceptance with test report Accessories: - 3-axis active digital display HEIDENHAIN TNC 113 with active function in X, Y and Z axes - Fixed table 600 x 210 (T-slot: 12 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - Coolant system - Central lubrication, electric - Operating instructions Hsdpfxehtrd Is Ahujfb - Used as seen -

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions Hjdpfx Ahew A Ap Housfb

Condition: good (used), Year of construction: 1980, Cover FP1 Active with 3 axes Heidenhain digital readout , 2 axes Active , rigid table , SK 40 S20x2 spindle holder. Good working condition, ready for demonstration under power by arrangement. Hfsdpfsumcmqsx Ahueb

Condition: used, Year of construction: 1989, Universal tool milling machine Make: DECKEL Model: FP 1 Active Year of manufacture: 1989 - workshop tested Machine no.: 2102-5561 Milling head type: 2171 Milling head number: 4393 geometric acceptance with test report Accessories: - 3-axis active digital readout HEIDENHAIN TNC 113 with active function in X-, Y- and Z-axis - Fixed table 600 x 210 (T-slot: 12 mm) - SK 40 vertical milling head with tightening thread S 20 x 2 - Coolant device - Central lubrication, electric - Operating instructions used as seen, without guarantee The machine corresponds technically Hfedpfxor En Dyo Ahusb the state of the year of construction at that time.

Condition: used, Year of construction: 1980, x-travel 300 mm y-travel 160 mm Hfsdpfx Ahew A Apyeuob z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1200x1100x1600 m - Active feed in the X and Z axes - Additional swiveling table 600 x 210 mm - Coolant system - Counter bearing for horizontal milling - Several fixtures and clamping devices/milling cutters - Operating instructions

Condition: good (used), Year of construction: 1989, Lid FP1 Active with 3-axis Heidenhain digital readout, rigid table, SK 40 M16 spindle holder. Good working condition, ready for demonstration under power by arrangement. Hfjdpfxetp Nyfo Ahueb

Condition: good (used), Year of construction: 1981, Cover FP1 Active with 3 axes Heidenhain digital readout , 2 axes Active , rigid table , SK 40 S20x2 spindle holder. Good working condition, ready for demonstration under power by arrangement. Hjdeuvgnqspfx Ahujfb

Year of construction: 1988, condition: good (used), Lid FP1 Active with 3-axis Heidenhain digital readout, rigid table, SK 40 S20x2 spindle holder. Good working condition, ready for demonstration under power by arrangement. Hfedpfx Aork Aaaohueb

Condition: ready for operation (used), Year of construction: 2004, operating hours: 55,476 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: HEIDENHAIN Mill Plus IT, spindle speed (max.): 12,000 rpm, New motor spindle in 2012 TECHNICAL DETAILS Travel X-axis: 800 mm Travel Y-axis: 700 mm Travel Z-axis: 600 mm Motor spindle speed: 12,000 rpm Tool holder: HSK-A 63 Tool magazine positions: 120 Table speed: 500 rpm Torque: 1692 Nm Table diameter: Ø 800 + 630 mm Load limit: 800 kg MACHINE DETAILS Control: HEIDENHAIN Mill Plus IT Spindle hours: 55,476 h EQUIPMENT Universal milling head with controlled B-axis Hfodjx Sqr Ispfx Ahujb 2 pallets 800 mm x 630 mm Pallet changer Rotating inspection window Operating mode 4 Tool breakage monitoring

Condition: used, Motor output 3 kW total power requirement 3 kw Weight 1.400 kg Hfsdpfx Ahov Nq Skeuob

Condition: used, Year of construction: 2006, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 Nm Hfodpfx Aeyackdehueb tool taper HSK-A 63 swivellable B: +30° / -120 ° table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg rotatable C: 360 ° number of toolpositions 2x16 pos. tool taper HSK-A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool weight 8,0 kg max. tool length 315 mm feed speeds max. 30.000 mm/min rapid traverse 30 m/min total power requirement 48 kVA weight of the machine ca. 14,0 t dimensions of the machine ca. 4,5 x 4,0 x 2,6 m 5 Axis CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 monoBLOCK - NC-Rotary Table (C-Achse) integrated in rigid-table - Swivel-Milling-Head (B-Achse)

Condition: used, Year of construction: 2005, x-travel 500 mm y-travel 450 mm z-travel 400 mm control Heidenhain iTNC 530 c-axis 360 b-axis -5/+110 ° turning speeds 20- 10000 U/min Hjdsw Eyg Iopfx Ahujfb power capacity - milling spindle 13 kW tool taper SK 40 no. of workpieces in the magazine 16 Stück rapid traverse 24 m/min table surface area 630 x 500 mm table load 200 kg weight of the machine ca. 4,0 t dimensions 2,3x 3,2 x 2,75 m 3 + 2 axis Milling Center - Turn-/swiveling table full programmable - electr. hand wheel - new spindel in 2015

Condition: used, Year of construction: 2004, travel distance X-axis: 1,800 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,100 mm, total height: 4,375 mm, total length: 12,300 mm, total width: 11,200 mm, table width: 1,400 mm, table length: 1,600 mm, table load: 3,500 kg, Equipment: documentation/manual, 5-axis CNC Universal Machining centre, simultaneous Control: Heidenhain iTNC 530 Table size: 1600x1400 mm Table load: 3500 kg Number of pallets: 2 x Maximum workpiece diameterxheight: 1950x1100 mm Movement X-axis: 1800 mm Movement Y-axis: 2000 mm Movement Z-axis: 1100 mm C-Axis table rotation: 360 ° B-Axis travel: -7 / 187 ° Spindle Speed: 18000 1/min Spindle taper: HSK-A63 Spindle motor: 28/19 kW Magazin capacity: 120 Required floor space: 11200x12300 mm Height: 4375 mm Weight: 58000 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Hodpfox Tulnex Ahusfb

Condition: used, Year of construction: 1999, serial number 10970000633 control 3D Bahnsteuerung MILLPLUS letzte Ausbaust Control 67 10.221.661 x-travel 600 mm y-travel 700 mm z-travel 550 mm spindle SK40 - neu - 380 Std. spindle speed: 12.000 U/min tool change unit 30 Plätze Infrarot-Taster 600 L 40 bar mode of operation 3 + 4 Hfjdpfxox Uz Aps Ahuob MillPlus IT flushing gun mit Pumpe Durchmesser 630 mm T-slots 9 T-Nuten 14 H7 / 63 mm capacity 700 kg

Condition: used, Year of construction: 2007, x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 Nm tool taper HSK-A 63 swivellable B: +30° / -120 ° table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg rotatable C: 360 ° number of toolpositions 2x16 pos. tool taper HSK-A 63 max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool weight 8,0 kg max. tool length 315 mm feed speeds max. 30.000 mm/min rapid traverse 30 m/min total power requirement 48 kVA weight of the machine ca. 14,0 t dimensions of the machine ca. 4,5 x 4,0 x 2,6 m 5 Axis CNC - MachiningCenter Universal DECKEL MAHO - DMU 80 monoBLOCK Hfsdpfeyaci Tox Ahusb - NC-Rotary Table (C-Achse) integrated in rigid-table - Swivel-Milling-Head (B-Achse)

Condition: used, Year of construction: 1999, serial number 10970000633 control 3D Bahnsteuerung MILLPLUS letzte Ausbaust Control 67 10.221.661 x-travel 600 mm y-travel 700 mm z-travel 550 mm spindle SK40 - neu - 380 Std. spindle speed: 12.000 U/min tool change unit 30 Plätze Infrarot-Taster 600 L 40 bar mode of operation 3 + 4 MillPlus IT Hodpjx Uz Avsfx Ahujfb flushing gun mit Pumpe Durchmesser 630 mm T-slots 9 T-Nuten 14 H7 / 63 mm capacity 700 kg

Condition: used, Year of construction: 2007, x-travel 635 mm y-travel 510 mm z-travel 460 mm Hsdpfxoyaci Hj Ahuefb control iTNC 530 Heidenhain power capacity - main spindel 13 / 9 kW turning speed range - main spindle 20 - 10.000 min/-1 Torque 83 / 57 Nm tool taper SK 40 tension force 10 kN table surface area 790 x 560 mm number of T-slots 4 + 1 T-slot - width 4 x 14H12 / 1 x 14H7 mm T-slot - distance 100 mm max. table load 600 kg table height over floor 720 mm number of toolpositions 30 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool length 300 mm max. tool weight 6 kg Total weight, approx. max. 60 kg feed speeds max. 20.000 mm/min Feed force 5 kN input unit 0,01 mm rapid traverse 30 m/min total power requirement 20 kVA weight of the machine ca. 4,1 t dimensions of the machine ca. 4,5 x 4,0 x 2,8 m CNC-Machining Center Vertikal DECKEL MAHO - DMC 635 V - Spindle-Runtime only approx. 7.883h - Power-On approx. 23.023h
