Used Dmg Machining Center for sale (391)

Condition: ready for operation (used), Year of construction: 2010, operating hours: 17,250 h, functionality: fully functional, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, controller model: Heidenhain Mill Plus, spindle speed (max.): 18,000 rpm, In 2015, a new spindle was installed! TECHNICAL DETAILS Travel range X-axis: 710 mm Travel range Y-axis: 520 mm Travel range Z-axis: 520 mm Maximum spindle speed: 18,000 RPM Number of tool magazine slots: 30 Tool holder: SK40 Distance between T-slots: 63 mm Rotational speed of the 4th axis max.: 40 RPM Rotational speed of the 5th axis max.: 40 RPM 4th axis swivel range: 360 x 0.001 degrees 5th axis swivel range: 0 ± 102 x 0.001 degrees MACHINE DETAILS Control system model: Heidenhain - Mill Plus Operating hours: currently 36,500 hours Spindle hours: currently 17,250 hours EQUIPMENT Programmable coolant nozzles Ndjdpfx Aszldqnjh Esc Coolant gun Chip conveyor 40 bar internal coolant system with 600 l paper filter system Measuring probe 3D Quickset Laser tool measurement Visiport Handwheel Signal light Operating mode 4

Condition: ready for operation (used), Year of construction: 2011, operating hours: 34,062 h, spindle speed (max.): 10,000 rpm, overall weight: 15,500 kg, travel distance X-axis: 800 mm, travel distance Y-axis: 1,050 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, workpiece height (max.): 1,330 mm, spindle motor power: 28,000 W, number of slots in tool magazine: 120, swivel angle C-axis (max.): 360 °, number of axes: 5, This 5-axis DMG DMC80U DuoBlock was manufactured in 2011. It features a maximum workpiece diameter of 800 mm and a height of 600 mm, with a load capacity of 800 kg per pallet. The machine is equipped with a dual pallet system and a rapid traverse rate of 60 m/min. If you are looking to get high-quality machining capabilities, consider the DMG DMC80U DuoBlock universal machining centre we have for sale. Contact us for further details. • Control: Heidenhain iTNC 530 3D path control • B-axis Travel: 180° (Universal milling head with controlled B-axis) Ndjdpfx Ahsy Egblj Esc • Spindle Type: Integrated motor spindle without gearbox • Spindle speed ranges: • Operating mode 1: 0–10,000 rpm • Operating mode 2: 0–800 rpm • Operating mode 3: 0–5,000 rpm • Spindle performance: • Spindle Power (40% Duty Cycle): 28 kW • Spindle Power (100% Duty Cycle): 19 kW • Spindle hours: 34,062 h • Machine on hours: 79,252 h • Spindle: New spindle installed end of 2025 • Table Type: NC rotary table with pallet carrier • Pallets Included: 2 pallets • Pallet Clamping Surface: 800 mm x 630 mm • Pallet T-slots: 14 mm per DIN 55201-A2 • Pallet Weight: 300 kg per pallet • Maximum Permissible Workpiece Weight on Pallet: 1,400 kg • Maximum Workpiece Height: 1,330 mm • Maximum Workpiece Diameter: 900 mm • Feed Rate (X/Y/Z): 0 - 60,000 mm/min • Axis Acceleration (X/Y/Z): 7 / 6.5 / 6.5 m/s² • Maximum Feed Force (X/Y): 13 kN • Maximum Feed Force (Z): 9 kN • Linear Scale Resolution (X/Y/Z): 0.001 mm • Table Max Torque (40% duty cycle): 5,000 Nm • Table Holding Torque (40% / 100% duty cycle): 5,000 Nm / 3,660 Nm • Table Maximum Rotation: 35 rpm • Pallet Changer Type: Rotary pallet changer • Measuring Probe: Heidenhain TS 649 DMG Infrared probe • Kinematics Verification: 3D quickSET toolkit • Chip Management: Chip conveyor • Mist Extraction System: Oil and emulsion mist extraction system with mechanical filter (1,600 m³/h flow rate) • Cooling Capacity (Machine / Cabinet): 3.3 kW / 1.0 kW • Electrical Connection Data: 86 kVA, 400 V, 50 Hz, Max Nominal Current 124 A • Workpiece dimensions (max): Diameter 800 mm, height 600 mm • Feed force (X/Y/Z): 10 kN • Rapid traverse: 60 m/min • Tool Holder Taper: SK 50 per DIN 69871 Form AD / Form B • Tool Clamping Pull Stud: DIN 69872 Form A / Form B or ISO 7388/2 Typ B • Tool Clamping Mechanism: Mechanical via spring force, hydraulic release • Tool Magazine Capacity: 120 slots (vertical chain magazine) • Delivery: January 2027 Additional equipment • Dual pallet changer system • Internal coolant supply (ICS) with 980 l tank and band filter (40 bar through spindle center) • Clamping hydraulics • Infrared measuring probe Technical Specification Taper Size SK 50 Through-spindle Coolant Yes

Condition: good (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, controller manufacturer: Heidenhain, controller model: iTNC530, total height: 2,950 mm, total length: 6,000 mm, total width: 3,800 mm, table width: 900 mm, table length: 3,100 mm, rotational speed (min.): 20 rpm, rotational speed (max.): 18,000 rpm, overall weight: 25,000 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 18,000 rpm, coolant supply: 40 bar, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, X-axis travel: 2500 mm Y-axis travel: 920 mm Z-axis travel: 820 mm Table size: 3100 x 900 mm Spindle nose: SK/ISO40 Spindle speeds: 20 - 18.000 rpm Toolchanger: 30 pockets Controller: Heidenhain iTNC 530 Nodpfxsyac Tlj Ah Ejdc Featured with: - Chipconveyor - Cooling through spindle 40 Bar - ISO40 tools - Machine manuals Country of origin: Germany Motor power: 35 KW Machine LxWxH: 6000 x 3800 x 2950 mm Machine weight: 25.000 kg

Condition: excellent (used), Year of construction: 2012, Technical specifications: 5-axis machine: X, Y, Z, C, B Travel distances (X/Y/Z): 500 / 450 / 400 mm Travel range B axis: +110/-5° Travel range C axis: 360° CNC control: SIEMENS 840D Table width: 500 mm Table diameter: 630 mm Table angle adjustable in degrees Max. workpiece weight: 200 kg Number of tool changer positions: 30 Spindle speed: 20 – 10,000 rpm Motor power: 13 kW Dimensions (L x W x H): approx. 3400 x 2550 x 2200 mm Machine weight: approx. 4.8 t Nsdpfx Ahoyzzpve Eedc Additional equipment: Workpiece measuring probe Chip conveyor Condition: Very good condition, little used, approximately 12,850 operating hours

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, We offer you: CNC bed milling machine Manufacturer: DMG MORI Type: CMX 70 U Year of manufacture: 2022 Control system: Celos with Siemens 840D sl Operate Technical data: Travel distances: X-axis: 750 mm Y-axis: 600 mm Z-axis: 520 mm B-axis: -10 to +95° C-axis: 360° Main spindle: Tool interface: SK 40 Speed range - main spindle: 20 - 15,000 rpm Drive power - main spindle (40/100%): 20 / 14.5 kW Torque - main spindle (40/100%): 121 / 84 Nm Work table: Table size: D 800 x 620 mm Tool changer: Number of tool positions: 30 Max. tool diameter: 80 / 130 mm Max. tool length: 300 mm Max. tool weight: 8 kg Max. magazine load: 120 kg Feed rates: Rapid traverse (x/y/z): 30 m/min Operating hours: approx. 5,300 h Spindle hours: approx. 3,010 h Technical features & accessories: Njdpfx Ahszcy I Se Eedc - Direct linear measuring system in x, y, and z, incl. air purging - Compressed air switching via M function - Chip disposal package, includes: - Chip conveyor, tank 300 l - Spray gun - Signal light, 4-color - Tropical package, includes: - Active control cabinet cooling - Additional cooler on the control panel - Hydraulic oil temperature sensor - Cooling unit 3.3 kW for the main drive - Preparation for oil mist separator - Measuring probe kit, manufacturer Heidenhain, includes: - TS460 workpiece measuring probe - Measuring cycles - Tool length/diameter kit, manufacturer Heidenhain, includes: - TT160 for tool measurement - Measuring cycles, incl. tool breakage monitoring - Automation package, includes: - Loading and unloading via automatic magazine door - Automatic closing of the tool magazine - Cabin roof - Electronic handwheel - ATC (Application Tuning Cycle) - Preparation for 3D quickSET Accessories, tools and clamping devices shown in the pictures are only included in the scope of delivery if this is stated in the additional information. Subject to changes and errors in technical data and specifications, as well as prior sale!

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, operating hours: 2,900 h, table length: 1,400 mm, table width: 560 mm, feed length X-axis: 1,100 mm, feed length Y-axis: 560 mm, feed length Z-axis: 510 mm, Equipment: documentation/manual, The machine is in very good condition and was purchased new from DMG Pleszew. It was bought to carry out an EU-funded project, as we specialize in building prototypes and are not a company involved in mass production. The machine is in 100% working order. It can be inspected on-site, and tests can be performed, along with training on its operation. We are selling the machine because we have two units and want to replace one with a 5-axis machine. Additionally included in the package: - Renishaw measuring probes for parts and tools - Precision vice (jaws 150mm), length 350 mm - 8 tool sets with SK40 tool holders Ndedeq E Ivpopfx Ah Eec Operating hours: 2900 h Control system: Heidenhain TNC 620 The machine is ready for operation. In August, the set of wipers and a package of basic consumables such as filters and belts were replaced. Price negotiable.

Condition: excellent (used), Working travels 635 x 510 x 460 mm Table size 790 x 560 mm Spindle taper SK40 Spindle speeds -14'000 rpm Tool changer 30 Pos. Control HEIDENHAIN iTNC-530 3D measuring taper Chip conveyor Misc. accessories Ndsdpfx Ahsrx Spmj Ejc MARCELS MASCHINEN CH

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 460 mm, controller model: HEIDENHAIN ITNC 530, spindle speed (max.): 28,000 rpm, TECHNICAL DETAILS Number of axes: 5 Njdpfx Ahszaqhqj Ejdc Travel range, X-axis: 450 mm Travel range, Y-axis: 650 mm Travel range, Z-axis: 460 mm Swivel angle (A-axis): -10 / +110 ° Tool magazine Number of positions: 60 Maximum tool diameter: 80 mm Maximum tool length: 250 mm Maximum tool weight: 6 kg Tool holder and spindle Tool holder: HSK 63 Minimum spindle speed: 2 rpm Maximum spindle speed: 28,000 rpm MACHINE DETAILS Operating time according to counter: 94,552 h Operating hours according to counter: 24,219 h Connection voltage: 400 V Spindle power: 38 / 28 kW Total power consumption: 70 kVA Dimensions & Weight Dimensions (L x W x H): 3,210 x 2,930 x 2,900 mm Machine weight: approx. 9,500 kg

Condition: excellent (used), Year of construction: 2002, Control Siemens Sinumerik 840D Travel paths X/Y/Z: 560 x 560 x 510 mm Spindle speed 15,000 min-1 2-fold pallet changer 400 x 400 mm Tool magazine for 40 tools, SK 40 Paper filter Chip conveyor Ndjdpjyrir Sofx Ah Eec

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 1120 000155 3, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 530, spindle speed (max.): 12,000 rpm, Submitting a bid obligates you to collect the item by 16.01.2026! For loading, a complete semi-trailer with a height of 3 m is required. The consignment comprises 8 packages. Ndedpfx Ahjxywlzo Eoc

Condition: good (used), Plates Size: 520x520x40mm We have 16 plates in the stock Ndodpfjl D Nxkex Ah Eec Price for one plate 450 eur

Condition: used, Year of construction: 1996, x-travel 600 mm y-travel 560 mm z-travel 560 mm Control Siemens size of pallet 400x500 mm Table load 300 kg feed 40.000 m/min spindle speed: 20-8000 U/min spindle taper ISO 40 Spindle capacity 13/20 KW Torque 191 Nm 4-axis horizontal machining center. Dual pallet changer. B-axis table indexing 0.001°. Ndsdpfx Ahoyutu Ao Eoc B-axis rapid traverse 40 rpm. KNOLL coolant system with filter and chip conveyor. 40 bar coolant supply via collar. Good condition. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 2008, Working hours: - Power on: 44113 - Spindle hours: 13284 Equipped with: * CNC control SIEMENS 810 D powerline * 20-station ATC * Coolant equipment * Chip conveyor x-travel 1035 mm y-travel 560 mm z-travel 510 mm Ndjdpfxozquqio Ah Eoc table surface area 1200 x 560 mm table load 1000 kg tool taper SK 40 spindle turning speed - stepless 20 - 8000 rpm feeds longditudinal/cross/vertical - 20000 mm/min rapid traverse 25 m/min spindle drive motor 13 kW dimensions of machine 2,6 x 2,6 x 2,7 m weight of the machine approx. 4,1 t

Condition: like new (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 2,600 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 900 mm, total height: 3,300 mm, total length: 9,000 mm, total width: 6,000 mm, overall weight: 28,000 kg, number of slots in tool magazine: 60, Equipment: chip conveyor, 5-axis machining centre DMG DMF 260-11 Year of manuf. 2012 Control Heidenhain iTNC 530 Speed [rpm] 10000 Movement X/Y/Z [mm] 2600/1100/900 Tool holder SK50 Spindle Speed 10.000 U/min Power 44 kW Ndjdjzucm Hepfx Ah Esc Torque 288 Nm Taper SK 50 Media feed-through Blast air, Coolant 4. NC-Axis Technologie NC-Swicel head Stroke +/- 100° Clamping Hydraulic 5.NC-Axis Technolgie NC-Round table Stroke 360° Diamenter 1.050 mm Clamping Hydraulic Load capaity 1.200 kg Tool magazin 60 stations Rapid travers 40 m/min Chip managment Chip conveyor Coolant mangament Coolant through spindle, 80 bar Positioning sensor Direct scale in all Axis Workpiece measurment Touch probe, Heidenhein TS 649 Oil mist seperator: Media feed-through spindle Blast air, Coolant Process observation Operation mode 4

Condition: used, Year of construction: 2017, Manufacturer: DMG MORI, Type: DMU 75 monoBLOCK, Year of manufacture: 2017, Serial number: 12430007443, Operating hours: 28,368, Spindle hours: 11,627, Control system, Manufacturer: Heidenhain, Type: iTNC 530, 21" Operator terminal ERGOline Touchscreen, Tool changer, 63-position SK 40, Travel range X/Y/Z: 735 x 650 x 560 mm, Spindle speed max.: 12,000 rpm, Machine table clamping area: 1,000 x 650 mm, Coolant system, Oil mist extraction, Chip conveyor, Chip cart +++ IMPORTANT: This machine is part of an online auction! +++ Ndsdpfxsz Tluce Ah Eoc

Condition: good (used), Year of construction: 2010, Ref. -No.: 10287 Manufacturer: DMG Type: DMC 210 FD Year of construction: 2010 Type of control: CNC-Steuerung Control: Heidenhain Mill Plus Storage location: Halberstadt Country of origin: Deutschland X-Travel: 2100 mm Y-Travel: 2100 mm Z-Travel: 1250 mm Machine length: 11.000 mm Machine width: 5.000 mm Machine Height: 3.500 mm Max. Workpiece diameter: 2500 mm Max. Workpiece Weight: 6.000 kg Max. rotary table diameter: 1.850 O Table speed range: 250 min/-1 Tool Taper: HSK-A100 Tool Piece Magazine With: 183 Pcs./pcs. Spindle Speed: 12.000 RPM Max. Torque On The Boring Spindle: 288 Nm Max. Torque: 2.000 Nm Feed Speeds X/Y/Z Axis: 30.000 mm / min Max. Workpiece height: 1.460 mm axes: 5 Further information: Turning and milling center incl. pallet changing system Gear spindle Coolant treatment system, with belt filter, 710 x 50mm 1 Knoll 600S2 chip conveyor 2 Losma oil mist extraction units 1 steel platform (storage space for clamping device): 5,300 x 2,900 mm - Axes renewed 11.2024 - New encoder, electrical components renewed - Geometry protocols available Machine is still in production and under power. The machine can be viewed at any time by appointment. Ndedpfx Aszkpupjh Esc

Condition: used, Year of construction: 2012, x-travel 1.035 mm y-travel 560 mm z-travel 510 mm CNC-control HEIDENHAIN TNC620 table-size 1200 x 560 mm max. table load 1000 kg spindle taper SK 40 spindle turning speed range 10.000 U/min drive capacity - spindle motor 13 kW feed stepless 20.000 mm/min rapid traverse 25 m/min tool change unit 20 Pos. coolant IKZ 20 bar Ndjdpfx Ahow A Spvo Ejc voltage 400 V total power requirement 17 kVA weight of the machine ca. 4,1 t dimensions of the machine ca. 2,55 x 2,30 x 2,25 m chip conveyor 3,90 x 0,95 x 1,60 m - Serial No.: 1539000377A - Machine ON: 21.689 h - Program Run: 9.021 h - CNC-Control: Heidenhain TNC620 - elektronic hand wheel - chip conveyor - coolant through spindle 20 bar

Condition: used, Year of construction: 2008, turning diameter / mm centre distance / mm swing diameter / mm Manufacturer: DMG GILDEMEISTER Model: CTX 510 eco Year of manufacture: 2008 Machine type: CNC lathe / turning center Control system: Siemens SINUMERIK 810D Powerline Max. spindle speed: 3,250 rpm Spindle speed range: approx. 500–3,250 rpm Spindle power: 33 kW at 40% duty cycle / 22 kW at 100% duty cycle Spindle torque: 630 Nm at 40% duty cycle / 420 Nm at 100% duty cycle X-axis travel: 300 mm Z-axis travel: 1,050 mm Max. turning diameter: 465 mm Max. swing / turning diameter: 680 mm Spindle bore / bar capacity: approx. 76–92 mm (depending on configuration) Front spindle diameter: 140 mm Turret: 12-station Driven tool speed: up to 4,000 rpm Driven tool power: approx. 8.4 kW Ndedpfx Ahozu A Uks Eoc Chuck: 250 mm or 315 mm Max. workpiece weight between centers: 350 kg Total power requirement: approx. 50 kVA Power supply: 400 V, 50/60 Hz Machine weight: 7,500 kg Incl. chip conveyor Note: All technical specifications are for guidance only and are subject to change. Actual machine data may vary due to different equipment variants and subsequent modifications. No warranty or guarantee is provided regarding the accuracy or completeness of the technical specifications. The specifications and actual condition of the offered machine are the sole determining factors.

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 1,110 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 90 m/min, rapid traverse Y-axis: 90 m/min, rapid traverse Z-axis: 90 m/min, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, rotational speed (max.): 28,000 rpm, overall weight: 14,000 kg, spindle speed (max.): 28,000 rpm, operating hours of spindle: 10,000 h, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-axis continuous machining center Linear motors 28,000 rpm spindle with HSK 63A, recently replaced Rotary table, 950mm diameter Wireless workpiece probe MH Laser presetter for tool inspection Optical scales Remote handwheel Chip conveyor NO coolant supply through the spindle Complete with manuals Nodpfx Ahezmxmte Eodc Disconnection scheduled for August 25th Removal scheduled for August 26th

Condition: used, Year of construction: 2007, x-travel 1350 mm y-travel 560 mm z-travel 510 mm Control Heidenhain iTNC 530 total power requirement 13 kW weight of the machine ca. 5 t Ndjdpezlb Dfefx Ah Ejc

Condition: used, Year of construction: 2010, operating hours: 62,569 h, functionality: fully functional, machine/vehicle number: 00410001121, spindle speed (max.): 5,000 rpm, overall weight: 5,695 kg, Equipment: documentation/manual, We are offering this used DMG CTX beta 500 V6 CNC turning and milling center, year of manufacture 2010. Serial number: 00410001121 Year of manufacture: 2010 Max. main spindle speed: 5000 rpm Max. counter spindle speed: 6000 rpm Nsdpfxszv Tbqs Ah Esdc Weight: 5695 kg If you have any questions or require further information, please feel free to send us a message or call us.

Condition: excellent (used), Year of construction: 2008, x-travel 630 mm y-travel 560 mm z-travel 560 mm Control MillPlus HEIDENHAIN Njdpfx Ahovwgp Uo Eedc table dimension - longitudinal 1000 mm table dimension - cross 600 mm spindle turning speed range 12000 U/min Number of axles 4 St. rapid traverse 30 m/min tool change unit 24 -fach weight of the machine ca. 9 t The DMU 60 monoBlock is in very good condition and immediately available. Accessories: - Measuring probe

Condition: ready for operation (used), Year of construction: 2018, operating hours: 18,600 h, travel distance X-axis: 650 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 475 mm, controller manufacturer: SIEMENS, controller model: 840D sl, table width: 630 mm, table length: 500 mm, table load: 300 kg, overall weight: 7,420 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 21,000 W, number of slots in tool magazine: 30, number of axes: 5, This 5-axis DMG DMU 50 was manufactured in 2018. It features a working table size of Ø 630 x 500 mm and a maximum table load of 300 kg. The machine is equipped with a high-speed spindle capable of 15,000 rpm and a tool magazine with 30 positions. If you are looking to get high-quality machining capabilities, consider the DMG DMU 50 vertical machining centre we have for sale. Contact us for further details. Control System: CELOS with Siemens 840D sl Operate (21.5-inch ERGOline Multi-Touch display)Machining Type: 5-axis simultaneous machiningWorking Table / NC Swivel Rotary Table: Ø 630 x 500 mmSwivel / Rotary Axes: B: -35° to +110°, C: 360°Rapid Traverse X / Y / Z: 42 m/minMain Spindle: speedMASTER 20 - 15,000 rpm (SK40 / CAT40 taper)Spindle Power: 21 kW (40% duty cycle) / 16 kW (100% duty cycle)Tool Magazine: 30 positions (SK40)Operating Hours (Control/On-Hours): 33,089 hSpindle Hours: 18,597 hInternal Coolant Supply (IKZ): 40 bar / 600 l with paper band filter and cabin rootChip Conveyor: Scraper belt typeOptional Equipment:Renishaw PP60 optical infrared workpiece probe (OMP60)Heidenhain TT160 tool measurement / length, diameter, and breakage detection3D quickSET (kinematics check and correction)ATC (Application Tuning Cycle)Electronic handwheelManual double switch filter (25 µm)Air blast through spindle center (selectable via M-function)Rinsing gun for chip flushingThe image was generated by AI.Images available on request Technical Specification Taper Size SK 40 Nodpfe Ad Rgwsx Ah Ejdc

Condition: used, Year of construction: 2017, travel distance X-axis: 650 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 475 mm, Equipment: chip conveyor, MACHINING CENTER DMG MORI DMC 650 V Year: 2017 Manufacturer: DMG MORI Model: DMC 650 V CNC Control: Celos with Siemens 840D Machine dimensions: 4725 x 5090 x H 2670 mm Weight: 5,900 kg AXIS TRAVELS X-axis: 650 mm Y-axis: 520 mm Z-axis: 475 mm Rapid traverse: 42 m/min Feed rate: up to 42,000 mm/min SPINDLE speedMASTER Spindle speeds - Continuously programmable: up to 20,000 rpm - In setup mode: 800 rpm Motor power - Max. drive power (40% duty cycle): 35 kW - Rated power (100% duty cycle): 25 kW Torque - Max. spindle torque (40% duty cycle): 130 Nm - Rated torque (100% duty cycle): 86 Nm Tool holder: SK40 Tool clamping force: 11.2 kN TABLE Table size: 960 x 570 mm T-slot spacing: 100 mm Nedpoy Nkcnefx Ah Eedc Number of T-slots: 4 / 14H12 Reference slot: 1 / 14H7 Max. table load: 800 kg Loading height (floor to table top): 800 mm 4TH AXIS – NC ROTARY TABLE MORI SEIKI DDRT 200X Center height: 140 mm Table diameter: 200 mm Center hole diameter: 65H7 mm Clamping surface diameter: 50 mm Clamping slot: 14h6 mm Clamping torque: 600 Nm Max. torque: 280 Nm Rotational speed: 150 rpm Positioning time: 5 s Repeatability: 3 s Max. workpiece diameter: 250 mm Max. speed: 200 rpm Load capacities - Max. clamping weight (one-sided): 102 kg - Max. vertical load: 100 kg - Max. vertical load with tailstock: 250 kg - Max. horizontal load: 250 kg Weight of NC rotary table: 115 kg TOOL MEASUREMENT – TT160 Probing accuracy: < 15 µm Max. deviation of measuring element: 5 mm Axial triggering force: 8 N Radial triggering force: 1 N Max. probing speed: 5 m/min Protection class: IP67 (EN 60529) Working temperature: 10–40°C CHIP CONVEYOR WITH COOLANT EXTENSION SYSTEM Coolant tank capacity: 230 l MACHINE COOLING UNIT Effective cooling capacity: 4.5 kW Cooling circuit pump: 40 l/min Refrigerant: R 134a Coolant: Water - Antifrogen® L 70/30 % Coolant filling volume: 38 l Coolant discharge temperature: +15° to +30°C Permitted ambient temperature: +10° to +45°C Unit weight (dry): 130 kg Additional Information Operating hours: approx. 2,200 20-position tool magazine Machine supplied with manuals and CE certificate of conformity All technical data provided are for reference only and subject to change without notice, and therefore are not legally binding.

Condition: excellent (used), Year of construction: 2015, X-axis 850 mm Y-axis 520 mm Z-axis 475 mm Spindle speed 10,000 rpm Spindle mount HSK 100 Tool changer 40 positions Control SIEMENS 840 Dsl Njdewvr Tnepfx Ah Eedc Power 33 kVA Including internal coolant (IKZ) Including various tool holders Including measuring probe TS 649 Including Rotoclear Spindle hours: 10,730 h
