Used Emag Vsc 250 for sale (18)

Condition: good (used), Year of construction: 2015, operating hours: 35,000 h, functionality: fully functional, spindle speed (max.): 6,000 rpm, chuck outer diameter: 250 mm, feed length X-axis: 680 mm, feed length Z-axis: 200 mm, power: 39 kW (53.03 HP), rapid traverse X-axis: 45 m/min, rapid traverse Z-axis: 30 m/min, type of input current: three-phase, controller manufacturer: Siemens, controller model: 840 DS, input voltage: 400 V, coolant supply: 6 bar, nominal power (apparent): 45 kVA, Equipment: rotational speed infinitely variable, type plate available, EMAG VERTICAL SINGLE-SPINDLE TURNING AND GRINDING CENTER EMAG - REINECKER VSC 250 DS Used, year of manufacture 2015 Control: Siemens 840 DS Condition: Used machine in good condition Operating hours (approx.): 35,000 Program run time (approx.): 22,000 hours Operating voltage: 400V Air connection: 6 bar Total power requirement: approx. 45 kVA Cooling unit: water/water Machine dimensions without peripherals (L x W x H): approx. 3200 x 1900 x 2650 mm Ijdpfolfduijx Agqoa CYLINDRICAL GRINDING Integrated motor grinding spindle with max. speed 45,000 rpm and max. output 18 kW Touch dressing for ceramic CBN grinding wheels Vertical CNC turning and grinding center Automation / Gantry: EKF basket stacker cell as raw/finished parts buffer for baskets 400 x 600 mm on floor rollers 3 basket stacks enable uninterrupted operation even during basket changes, loading/unloading via loading gantry The machine is well-maintained and EMAG serviced. The production process includes pre- and finish machining of the bore and end faces by hard turning the face surfaces, as well as turning the diameter/bore followed by bore grinding. No driven tools Viewing under power is possible by appointment. Dismantling and loading of the equipment are to be carried out by the buyer. Price and further details on request / special price All technical details subject to error/typos. Sale only within EU countries.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 72,284 h, functionality: fully functional, feed length X-axis: 685 mm, feed length Z-axis: 200 mm, travel distance X-axis: 685 mm, travel distance Z-axis: 200 mm, chuck outer diameter: 250 mm, rapid traverse X-axis: 45 m/min, rapid traverse Z-axis: 30 m/min, total length: 3,100 mm, total height: 2,650 mm, total width: 4,000 mm, rotational speed (max.): 6,000 rpm, torque: 460 Nm, overall weight: 7,800 kg, controller model: Siemens 840D, control type: CNC control, Equipment: cooling unit, For sale is an EMAG VSC250, year of manufacture 2008. Equipped with a Siemens 840 D control system. Features: - Infeed and outfeed conveyor (O-belt) - Pneumatically operated transfer unit - Stamping unit - Chip conveyor (ejection left) - Coolant system Ijdpfx Ajw Dyqdsgqea - Tool turret 12x VDI40 The machine is powered and available for inspection.

Condition: excellent (used), Year of construction: 2009, operating hours: 67,343 h, functionality: fully functional, All data will be provided upon request regarding this listing. The machine is dirty. Up until July, the machine delivered top tolerances at MAGNA POWERTRAIN and is otherwise in fully functional condition. Iodpfx Agexl Ah Soqea

Condition: good (used), Year of construction: 2002, Machine type: CNC Lathe Manufacturer: Reinecker Karstens Kopp - EMAG Model: VSC 250 DS Serial number: M02.43446 Year of manufacture: 2002 Iedpfxskyrwwe Agqoa Available immediately Ex site for self disassembly Optionally we can offer dismantling and loading

Condition: used, Year of construction: 2001, Offered is a vertical single spindle pick up turning machine EMAG VSC 250 built 2001. The machine is equipped with a conveyor belt (O-Type) that runs through the machine. The automation belt is loaded with workpieces at the front of the machine. The work area has one working spindle and one turret with 12 tool positions. Other accessories such as a chip conveyor, coolant equipment or independent extractor unit are not included in the advertisement. The machine was taken out of service a few years ago. After inspection, the VSC 250 is fully functional and in good condition, as can be seen in the pictures. The machine has been completely cleaned and repainted. All control cabinet components and cables are still in their original condition. COTROL Siemens Powerline TECHNICAL DATA workpiece diameter: max. 200 mm workpiece height: max. 150 mm swing diameter: 250 mm Isdpfotrwdtsx Agqea X-stroke: 685 mm Z-stroke: 200 mm MAIN SPINDLE power: 28 kW speed: max. 6000 rpm TOOL CARRIER 1x disc turrets, 12x D40 without driven tools The machine is sold without any warranty claims. Delivery time of the machine on request.

Year of construction: 2014, condition: like new (used), machine/vehicle number: 105488, Technical data: Chuck diameter max. 250 / 315 mm Swing diameter 350 mm Workpiece diameter max. 250 mm Traverse path: X-axis:745 mm Z-axis: 300 mm Loading times: Loading times (depending on workpiece) s 4 - 6 Main spindle: Spindle flange DIN 5502: 6 Spindle bearing, front through. Max. 110 mm Speed max. 5500 min. Disc turret: Number of tool holders: 12 Shank diameter: 40 mm Ijdjfyaaijpfx Agqoa Driven tools Maximum power: 8,5 kW Speed: max. 6000 min Turret swivel time: 0.3 s Control: Bosch Rexroth MTX

Condition: used, Year of construction: 2008, Article: Vertical turning and grinding centre Manufacturer: EMAG Type: VSC 250 DS Yob: 2008 Control: SIEMENS 840D Grinding spindle speed: 30,000 rpm Rotation spindle speed: 3,000 rpm Tool places turret: 12 Cooler for spindle and machine bed cooling Cooling lubricant - lifting station (no independent cooling lubricant supply) Chip conveyor Parts handling Iodpfx Agoia Rtdsqja Air through the spindle Two clamping circuits through the spindle (air and oil) Unfortunately, the grinding spindle is defective. However, this can be overhauled in a spindle factory. Otherwise the machine is in a very good condition and fully functional. Please, contact us for getting more information and pictures on mail(at) or *

Condition: used, Year of construction: 2004, turning diameter 250 mm turning length 100 mm control SIEMENS 840 D total power requirement 35 kW weight of the machine ca. 7500 kg dimensions of the machine ca. m E M A G (Germany) Vertical CNC Controlled Hard Turning and Grinding machine with tool turret and workpiece handling System Model VSC 250 DS Year 2004 # M7 28.69324 _____ Turning Ø, max. 250 mm Turning length internal / external 100 mm Workpiece length min./max. 29 – 100 mm 6-positon tool turret Ø / swing-Ø 480/790 mm Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm Feed rate / Quick feed X/Z 45/30 m/min. Feed force X/Z 5,5/11 kN Spindle speed 4.300 / 6.000 rpm Spindle drive 28 kW Total electrical load, approx. 35 kW - 400 V - 50 Hz Weight, approx. 7,500 kg Accessories / Special Features: * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor, graphics, menu-supervised dialogue programming, and all the usual options, cycles and subprograms, etc. * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without motorized tools posts, two positions T 3 u. T 6 equipped with grinding spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp. regular grinding tools * Workpiece handling device with WP transportation frames and circulation system and pick-up and unloading of finished parts directly through the motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW Autobloc with membrane clamping and clamping control system. * MARPOSS MIDA Measuring Probe for measuring blank parts a. the finished parts * NORGREN air measuring system, hydraulic weight compensation of spindle, * Main elements of machine are temperature stabilized by a coolant system made by HYFRA * Recooler for the grinding coolant sitting on a large Coolant device consisting of SEITZ Paper Band filter and a mobile Chipconveyor, Magnetic separator, Centrallubrication, etc. Vertical CNC lathes offer a thermo-resistant construction (chips do not fall onto the machine bed),fast workpiece change times (pick-up system through the main spindle) and a ridged tool arrangement,which also allows unrelated machining work, like hard turning or grinding process on the same machine. Iedpet Hxa Tofx Agqsa Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 2015, Technical details: turning diameter: 200 mm Iedpfxeq Sc Huo Agqja swing diameter: 260 mm turning height: 60 mm

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, For Sale: Used EMAG VSC 250 Vertical CNC Lathe (Year of Manufacture 2011) - High Precision and Automation We are offering for sale a used EMAG VSC 250 Vertical CNC Lathe from the year of manufacture 2011. This machine is designed for efficient and precise turning operations, especially for workpieces weighing up to approximately 6 kg. Thanks to its vertical design and advanced automation, this machine is ideal for medium to large-series production, ensuring high efficiency and repeatability. Main Features and Capabilities: • Vertical Design: Optimal chip evacuation and easy loading/unloading. Iodjwp Ukvspfx Agqsa • Control: Siemens SINUMERIK 840Dsl with integrated PLC S7-300 and a 15-inch TFT monitor. • High Precision: Positioning accuracy in X and Z axes is ±0.001 mm. • Main Spindle: High power and wide speed range. • Automated Loading/Unloading: Parts are fed to and removed from the machine via integrated automation. • Live Tools: The possibility of using live tools extends the machining range to include drilling and milling. Technical Data (EMAG VSC 250): • Manufacturer: EMAG • Year of Manufacture: 2011 • Machine Number: 103035 1. Main Drive: * Connected Load: 400 V/50 Hz / 43 kW * Drive Power of Main Spindle (100% ED / 40% ED): 18 kW / 28 kW * Main Spindle Torque: 300 Nm * Speed Range: 0-4500 rpm * Spindle Head: DIN 55026-A6 * Max. Workpiece Weight: ≤ approx. 6 kg 2. Chuck: * Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication. * Type: 6AGF 260 K6 K14 * Diameter: 260 mm * Weight: 57 kg * Max. Clamping Force (internal clamping at 50 bar): 12.8 kN * Max. Clamping Force (external clamping at 50 bar): 4.2 kN * Clamping Jaws: Special gripper jaws EMAG: HB-I-G-146-K14 for machining brass sheet (6-fold). * Adapter Jaws: (6-fold) L90x840xH50 with fine serration (SAV). * Weight of Adapter Jaw Set: 5.53 kg. * Soft Gripper Jaws: SMW MWB-DA 165 No. 03611 L70x B40x H60. * Weight of Soft Jaw Set: 2.70 kg. 3. Working Area: * Travel X-axis: 745 mm * Travel Z-axis: 300 mm * Rapid Traverse X-axis: 60 m/min * Rapid Traverse Z-axis: 30 m/min * Feed Force X-axis: 10 kN * Feed Force Z-axis: 10 kN 4. Control: * Siemens SINUMERIK 840Dsl with integrated PLC S7-300. * 15-inch TFT Monitor. * V24 Interface. 5. Working Accuracy: * Axes (X-axis / Z-axis): ±0.001 mm * Spindle (C-axis): ±0.01° 6. Tool Carrier: * EMAG Flange Turret Generation C361 - VDI 40. * Tool Stations: 12. * VDI Holder Shank Diameter: 40 mm. * Max. Tool Dimensions: Workpiece-dependent. * Tool Change Times (Turret / Live Tool): 0.03 min / 0.04 min. * Max. Speed of Live Tool: 6000 rpm. * Max. Torque of Live Tool (100% ED / 10% ED): 15 Nm/3.5 kW / 40 Nm/8.5 kW. 7. Coolant System: * Standard Delivery Pressure / Max. Delivery Pressure: 7 bar * Pressure Range of Internal Coolant Supply: 7 bar (not adjustable) * Coolant Tank Capacity: 360 liters 8. Part Catcher: * No part catcher available. Parts are fed to and removed from the machine via automation. 9. General: * Machine Dimensions (L x W x H): 3900 mm x 1500 mm x 3200 mm * Machine Weight: approx. 7000 kg * Ambient Conditions (Room temperature / Air humidity): up to approx. 30°C / max. 50% * Noise Level (Sound Pressure Level / Sound Power Level): 78 dB(A) Location: Zabrze, Poland Keywords: vertical lathe, CNC lathe, EMAG VSC 250, metalworking, turning, production machine, used lathe, Siemens Sinumerik 840Dsl, automation, live tools, Zabrze, Poland.

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 685 mm, travel distance Z-axis: 200 mm, workpiece diameter (max.): 200 mm, workpiece height (max.): 150 mm, turning diameter over bed slide: 250 mm, The machine has been fully cleaned and newly painted! TECHNICAL DETAILS Machining Area Workpiece diameter: max. 200 mm Workpiece height: max. 150 mm Swing diameter: 250 mm Ijdpfxow Hzupe Agqoa Axes X-axis travel: 685 mm Z-axis travel: 200 mm Main Spindle Main spindle power: 28 kW Main spindle speed: max. 6,000 rpm MACHINE DETAILS Control: Siemens Powerline EQUIPMENT Round belt 1x disc turret, 12x D40

Condition: like new (used), Year of construction: 2014, machine/vehicle number: 105488, Technical data: Chuck diameter max. 250 / 315 mm Swing diameter 350 mm Workpiece diameter max. 250 mm Traverse path: X-axis:745 mm Z-axis: 300 mm Loading times: Loading times (depending on workpiece) s 4 - 6 Main spindle: Ijdpfx Ajwfgzlogqja Spindle flange DIN 5502: 6 Spindle bearing, front through. Max. 110 mm Speed max. 5500 min. Disc turret: Number of tool holders: 12 Shank diameter: 40 mm Driven tools Maximum power: 8,5 kW Speed: max. 6000 min Turret swivel time: 0.3 s Control: Bosch Rexroth MTX

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: 2841823, Maximum workpiece diameter: 250 mm Maximum workpiece length: 175 mm Maximum chuck diameter: 315 mm Axis travel: X-axis: 860 mm Ijdpfx Aov U Emtegqja Z-axis: 200 mm Rapid traverse: X-axis: 45 m/min Z-axis: 30 m/min Main spindle speed: up to 4500 rpm Main spindle power: 28 kW Control system: SIEMENS SINUMERIK 840Dsl Tool turret: 12 positions Maximum workpiece weight: 6 kg

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, year of last overhaul: 2023, Offered is a VSC 250 vertical turning center, which has been mechanically and electrically overhauled by EMAG. Ijdpferq Damex Agqsa The control system was upgrated to Siemens Sinumerik One. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens Sinumerik One TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: refurbished (used), Year of construction: 2012, Offered is a VSC 250 vertical turning center, which has been mechanically overhauled by EMAG. All control components of the Siemens 840 Dsl control have been tested. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. Isdpjh Ryp Ssfx Agqea CONTROL Siemens 840Dsl TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 Delivery time and additional equipment of the machine on request.

Condition: refurbished (used), Year of construction: 2014, functionality: fully functional, total width: 2,500 mm, total length: 4,500 mm, total height: 3,200 mm, Offered is a double spindle pick up turning machine VSC 250 DUO. There are 2 nearly identical machines available. Each machine is equipped with 2 independent working spindles and 2 EMAG turrets. The machine can produce 2 identical workpieces with the same machining operation, as well as one workpiece in two successive machining operations. The VSC 250 DUO will receive a general overhaul before delivery and gets a control upgrade to Siemens Sinumerik ONE. The machine can be equipped with other periphery (chip conveyor, coolant system, external automation, etc.), depending on requirements. COTROL Siemens Sinumerik One TECHNICAL DATA workpiece diameter: max. 250 mm Ijdpfx Ajr Nc Ufsgqea workpiece height: max. 150 mm chuck diameter: 250/315 mm swing diameter: 350 mm X-stroke: 745 mm Z-stroke: 300 mm TOOL CARRIER working area 1 1x EMAG disc turrets, 12x VDI 50 without driven tools working area 2 1x EMAG disc turret, 12x VDI 50 with driven tools Price, delivery time and equipment of the machine on request.

Condition: refurbished (used), Year of construction: 2012, Offered is a vertical turning and grinding center EMAG VSC 250 DS. The machine will be mechanically overhauled and rebuilt by EMAG. Depending on requirements, the machine can be equipped with various automation options (shuttle, O-type conveyor, L-type conveyor, turn around station) and other peripherals such as chip conveyors, coolant systems, etc. CONTROL Siemens 840Dsl TECHNICAL DATA Workpiece diameter: 250 mm Workpiece height: 100 mm X-stroke: 860 mm Z-stroke: 200 mm MAIN SPINDLE Iedpfx Aoh Tkdqogqja power 28 kW TOOL CARRIER EMAG wheel turret, 12x VDI 40 console with grinding spindle 18 kW, 45000 1/min Delivery time and additional equipment of the machine on request.

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: M250.81009, Technical characteristics: # Main Drive: * Connected Load: 400 V/50 Hz / 43 kW * Main Spindle Drive Power (100% duty cycle / 40% duty cycle): 18 kW / 28 kW * Main Spindle Torque: 300 Nm Iodexvx T Sjpfx Agqoa * Spindle Speed Range: 0-4500 rpm * Spindle Nose: DIN 55026-A6 # Working Area: * Rapid traverse, X-axis: 60 m/min * Rapid traverse, Z-axis: 30 m/min * Feed force, X-axis: 10 kN * Feed force, Z-axis: 10 kN # Control System: * Siemens SINUMERIK 840Dsl * 15'' TFT monitor # Working Accuracy: * Axes (X / Z): ±0.001 mm * Spindle (C-axis): ±0.01° # Tool Carrier: * EMAG Flange Turret, Generation C361 - Capto C5 * Tool shank diameter: TN340009 * Max. tool dimensions: Workpiece-dependent * Tool change times (turret / driven tool): 0.03 min / 0.04 min * Max. speed, driven tool: 6000 rpm * Max. torque, driven tool (100% duty cycle / 10% duty cycle): 15 Nm / 3.5 kW / 40 Nm / 8.5 kW # Coolant System: * Standard delivery pressure / Max. delivery pressure: 7 bar * Pressure range for internal coolant supply: 7 bar (non-adjustable) * Coolant tank capacity: 360 liters # Part Handling: * No part catcher installed. Parts are loaded and unloaded via automation. * Ambient conditions (Room temperature / Humidity): up to approx. 30°C / max. 50% * Noise levels (Sound pressure / Sound power): 78 dB(A) # General Data: * Machine dimensions (L x W x H): 3900 mm x 1500 mm x 3200 mm * Machine weight: approx. 7,000 kg Main Features and Capabilities: # Vertical Design: Optimized for chip evacuation and convenient loading/unloading. # Control: Siemens SINUMERIK 840Dsl with integrated S7-300 PLC and 15'' TFT monitor. # High Precision: Positioning accuracy in X and Z axes of ±0.001 mm. # Main Spindle: High power and wide speed range. # Automated Loading/Unloading: Workpieces are handled automatically through integrated automation systems. # Driven Tools: Capability to use driven tools for extended machining, including drilling and milling operations. # Chip Conveyor # Equipped Chuck: EMB3 Expanding Mandrel (Autoblock) # Capto C5 Tool Holders on Turret (for external/internal machining, 2 units & 2 driven tools) # Tool Load Monitoring: Artis system capability available
