Used Mazak for sale (389)

Year of construction: 1997, condition: ready for operation (used), Travel X/Y/Z: 1300mm/1100mm/1000mm, table dimensions X/Y: 800mm/800mm, number of pallets: 14, max. table load: 2200kg, table indexing: 0.001°. Speed: 7000rpm, spindle power: 50hp, tool magazine: 80, dimensions X/Y/Z: approx. 7000mm/3400mm/3800mm, weight: approx. 24000kg. On-site inspection is possible. Cpedpetx Dn Ujfx Ah Iow

Condition: ready for operation (used), Year of construction: 1998, A Mazak CNC vertical machining center is available. Travel X/Y/Z: 1660mm/760mm/660mm, spindle power: 11kW, spindle speed: 7000rpm, table dimensions X/Y: 2000mm/760mm, max. workpiece weight: 800kg, rapid traverse X/Y/Z: 24m/min/24m/min/20m/min, feed: 5m/min, tool positions: 24. Machine dimensions X/Y/Z: approx. 4350mm/3400mm/2850mm, weight: approx. 8700kg. Documentation available. An on-site inspection is possible. Cpedpfx Ahoxfvicj Iew

Year of construction: 1990, condition: ready for operation (used), Travel X/Y/Z: 3200mm/1400mm/500mm, table dimensions X/Y: 3000mm/1250mm, max. workpiece width: 1500mm. Speed: 10000rpm, spindle mount: CAT50, spindle power: 35hp, tool positions: 30, dimensions X/Y/Z: approx. 8000mm/4000mm/3500mm, weight: approx. 24000kg. On-site inspection is possible. Cpjdjtx Dpfspfx Ah Ijw

Year of construction: 1992, condition: ready for operation (used), Turrets: 2, tool stations: 12, tool holder: VDI 40, max. turning diameter: 320mm, max. swing diameter: 390mm, spindle bore: 61mm, speed: 5000rpm, spindle power: 15kW, travel X/Z: 230mm/430mm, machine dimensions X/Y/Z: 3900mm/2000mm/2900mm, weight: approx. 8600kg. Including robot. Documentation available. On-site inspection is possible. Cpsdpfeyhgpaex Ah Iew

Condition: ready for operation (used), Year of construction: 2010, Workpiece diameter: 500mm, workpiece height: 730mm, travel X/Y/Z: 630mm/765mm/600mm, A-axis: -120°/+30°, C-axis: +/-360°, max. table load: 500kg, spindle interface: HSK-A63, speed: 18000rpm, rapid traverse: 52m/min, feed rate: 52m/min, rotary table diameter: 610mm, tool positions: 30, control: Mazak Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Codpfxox Aunxe Ah Iopw

Year of construction: 2006, condition: ready for operation (used), A Mazak CNC 5-axis turning and milling center with counter spindle is available. Swing diameter: 820mm, machining diameter: 820mm, machining length: 1500mm, max. workpiece weight in chuck/between centers: 650kg/150kg, main spindle speed: 1600rpm, spindle bore: 185mm, power: 30kW/40kW, tailstock force: 15kN, quill stroke: 1466mm, tool holder: BT50, spindle speed: 10000rpm, travel X/Y/Z: 870mm/500mm/1600mm, rapid traverse: 40m/min. Machine dimensions X/Y/Z: approx. 6500mm/3700mm/3200mm, weight: approx. 26000kg, control: Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Cpodpexf Iklofx Ah Ijw

Condition: excellent (used), Year of construction: 1995, Mazatrol M32 B control Travel X/Y/Z: 1660/510/510 mm Cpodpfoyiu Rhsx Ah Isw Spindle speed: 7000 rpm Tool magazine for 24 tools, SK 40 Table size: 2000x510 mm

Condition: like new (used), User surplus stock E ARIAXIS i-500 AT730 30 HSK tool magazine (n/a Euchner) NP326 5-axis machining package for SmoothX MO084 Manual pulse generator (wired/detachable) NO442 B) G00 slope constant NO600 B) Cylindrical interpolation SF060 Scale feedback system X, Y & Z axis NO123 F) Tool radius compensation/5 axis SR534 Spindle speed 18,000rpm (HSK n/a Euchner) PL083 Signal tower (3 colour lights) NO091 B) Synchronised tapping MB269 RMP600 radio-type touch probe CV546 Preparation for chip conveyor (right) Cpedpfx Aeynwxfsh Iow NO610 Work setting error compensation XXX Laser Mill Tool Measurement (NC4/ with airblast) O_2354hng Chip Conveyor, Local Manufacture (with transporter / ICON-P)

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes Cedpfetuggcox Ah Iepw - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: used, turning diameter 340 mm turning length 575 mm control Mazatrol SmoothEZ max. swing diameter over bed 695 mm Standard machining diameter 235 mm bar material dia. max. 65 mm x-axis 215 mm rapid traverse X-axis 30 m/min y-axis 100 mm rapid traverse Y-axis 10 m/min z-axis 605 mm rapid traverse Z-axis 30 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 15 KW 11 KW Max. Torque 167 Nm turning speeds 35 - 6000 U/min spindle nose A2-5 Motor output (40%ED) ca. 7,5 KW Power (continuous operation) 5,5 KW Max. Torque 53 Nm Milling spindle speeds ( driven tools) 20 - 4500 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20 coolant tank 225 l Chuck diameter main spindle 8 '' Chuck diameter counter spindle 6 '' w-axis 585 mm rapid travel W 30 m/min c-axis 555 weight of the machine ca. 4,9 t dimensions of the machine ca. 2,8 x 2 x 1,8 m Special accessories: - Chip conveyor, hinged belt, side ejector - Production package, this package includes Preparation for bar feed Automatic parts catcher (Ø:80mm x L:120mm x 2.5 kg) 15 bar high-pressure coolant system Preparation for chip conveyor (lateral) Signal light (3-colour LED), rectangular C-axis counter spindle 0.0001° Automatic tool eye 8" power chuck Kitag. BR08 & Cyl. SR1566C (HD1) GENERAL MACHINE OPTIONS Air blowing device on the chuck (counter spindle) Transformer for the European market Linear roller guides SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB - Memory Interface (1 slot) CE marking CE marking, metric, 50 Hz Counter spindle positioning 0.0001 degrees without C-axis Tool turret with 12 stations Y-axis control ADDITIONAL PROCESS SOFTWARE Smooth restart function / restart mode Set of manuals in electronic form on CD Main spindle motor AC 15 kW (20 hp) 2nd spindle motor AC 7.5kW (20 hp) Main spindle motor AC 7.5kW MAIN SPINDLE C-axis main spindle Input accuracy (contour/index) 0.0001° Mazak standard colour (F white(fine)/S black) Automatic switch-off via circuit breaker trip Double foot switch Hydraulic pressure interlock RFID door interlock Safety foot switch with locking mechanism Safety measures according to worldwide standard Work area lighting Complete coolant system Automatic opening/closing of chuck jaws (main and counter spindle) Feedback of the chuck status (main and counter spindle) Feedback of the chuck status via sensors. 8" power chuck 6" power chuck (counter spindle) Absolute positioning system Synchronous tapping with milling spindle Relocation Detector NC control Mazatrol SmoothEz 15" colour Lcd (touch screen) User macro (common variables: 600 pairs) EIA/ISO package EIA/ISO - input function EIA/ISO - additional functions Bolt line interpolation 3D tool compensation Workpiece coordinate rotation Geometric function Scaling External data input/output Tapping function (G33) Reverse feed rate G93 G37 Tool length measurement Polar coordinate input (EIA) Csdpfx Ahswngkle Ijpw Optional stop Additional workpiece coordinate systems 300 pieces User macro (600 variables) Mazak tapping/drilling cycle EIA/ISO - input function Scaling External data input/output Thr...

Condition: used, turning diameter max. 360 mm turning length 505 mm control Mazatrol SmoothC max. swing diameter over bed 660 mm swing diameter over slide guides max 255 mm bar material dia. max. 80 mm turning speed range - spindle 35 - 4000 U/min max. torque on the spindle 358 Nm x-axis 225 mm rapid traverse X-axis 30 m/min z-axis 605 mm rapid traverse Z-axis 33 m/min spindle nose A2-8'' spindle bore 91 mm spindle hollow 80 mm Milling spindle speeds ( driven tools) 5000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40%ED) kW tailstock quill taper MT 5 Travel- tailstock 565 mm Axial pressure max 5000 Nm Tool turret 1 Numbers of tools 12 (angetrieben) turning tool - shaft cross cut 25 x 25 mm tool taper BMT Required air-pressure 5 / 160 bar / l/min voltage 400 V coolant tank 180 l engine output 18,5 (30min Betrieb) kW Rated power (100% continuous operation) 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 3,6 x 2 x 1,8 m Machine incl. the following special accessories: Chip conveyor on the right side Productivity package C - special according to storage machine This package includes: High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min Preparation for chip conveyor (lateral) Automatic tool eye STANDARD ACCESSORIES Transformer for the European market Use of linear systems with guide carriage SD MEMORY I/F(1P) + USB MEMORY I/F(1P) 1 x USB memory interface (1 slot) Spindle bore 91 mm Csdjv Dxw Rjpfx Ah Ijpw Set of manuals in electronic form on CD Mazak standard colour CE marking, metric, 50 Hz C-axis input accuracy 0.0001° NC controlled tailstock Tailstock pressure adjustment Tailstock with fixed quill MK5 SAFETY DEVICES Operator door with interlock switch Double foot switch Hydraulic pressure lock Fully enclosed work area Work area lighting Safety precautions according to global standard COOLANT SUPPLY Grundfos coolant pump type MTA (0.25kW / 7.6L/min) Complete coolant system Automatic switch-off via circuit breaker triggering MESSSYSTEM Absolute positioning system NUMERICAL CONTROL Synchronous tapping with milling spindle Relocation Detector Mazatrol SmoothC 10.4’ colour screen User macro (600 variables) EIA/ISO input function Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN Various tool holders - All dimensions, weights and performance data are non-binding - Used machine without warranty -

Condition: like new (used), Year of construction: 2010, operating hours: 4,600 h, MAZAK QUICK TURN NEXUS 200-M CNC lathe Mazak Quick Turn Nexus 200 M equipped with Mazatrol Nexus 640T control, tool probe, parts catcher, chip conveyor, set of tool holders, collet chuck, and bar feeder interface. Technical specifications: Maximum machining diameter: 380 mm Maximum bar capacity: 65 mm Maximum machining length: 541 mm Maximum speed: 5,000 rpm Spindle motor power (30 min): 19 kW / 25.0 HP Number of turret tools (upper): 12 Maximum turret speed: 4,500 rpm Turret motor power (5 min): 6 kW / 7.5 HP Axis travel (X-axis): 230 mm Axis travel (Z-axis): 575 mm Drawer cabinet full of equipment Cjdpfx Aeykk A Aoh Iepw No. 3 driven tools included Chuck diameter: 210 mm Complete documentation Year of first installation: 2010

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Cpedpsu U R E Asfx Ah Isw

Condition: used, Year of construction: 2006, travel distance X-axis: 1,050 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 560 mm, controller manufacturer: Mazatrol, total height: 2,700 mm, total length: 3,445 mm, total width: 3,301 mm, overall weight: 8,900 kg, table length: 550 mm, table width: 1,300 mm, controller model: 640 M, spindle speed (max.): 6,000 rpm, spindle speed (min.): 25 rpm, Equipment: documentation/manual, CNC Vertical Machining Centre CNC Control: Mazatrol 640M Table size: 1300 x 550 mm Table load: 1500 kg Movement X-Axis: 1050 mm Movement Y-Axis: 510 mm Cpedpfsygw Ecex Ah Ijw Movement Z-Axis: 560 mm Spindle taper: MAS BT 50 Spindle speed: 25 -6000 1/min. Magazine capacity: 30 positions Weight of the machine: 8900 kg If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2000, travel distance X-axis: 1,020 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, workpiece weight (max.): 1,200 kg, total height: 2,900 mm, total length: 2,995 mm, total width: 2,350 mm, overall weight: 6,700 kg, table length: 550 mm, table width: 1,200 mm, coolant supply: 15 bar, rotational speed (max.): 12,000 rpm, rotational speed (min.): 35 rpm, table load: 1,200 kg, CNC Vertical Traveling Column Machining Centre CNC Control Mazatrol 640 M Csdpfx Aoygw D Esh Ijpw Table size 1200 x 550 mm Table load 1200 kg Number of pallets: 1 x Movement X-axis 1020 mm Movement Y-axis 510 mm Movement Z-axis 460 mm Spindle taper MAS BT 40 Spindle speed 35 - 12.000 1/min Spindle motor 22/15 kW Magazin capacity 30 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: used, Year of construction: 2000, Year of manufacture: 2000 Control: Mazatrol 640 Documents included Chip conveyor TECHNICAL DATA – MAZAK INTEGREX 200SY Performance / Capacity Max. swing: Ø 540 mm Chuck size: 8" Max. machining diameter: Ø 540 mm Max. machining length: 1018 mm Max. outside diameter for bar material: Ø 51 mm Main spindle Spindle nose: JIS A2-6" Spindle bore diameter: Ø 61 mm Spindle speed: 35 – 5000 rpm (Standard) / 35 – 4500 rpm (Option: 5000)* Motor power (30 min. rating): 22 kW (18.5 kW*) Max. torque: 350 Nm (35.7 kgf·m) Sub spindle (counter spindle) Spindle nose: JIS A2-6" Spindle bore diameter: Ø 44 mm Spindle speed: 35 – 5000 rpm Motor power (10 min. rating): 7.5 kW Max. torque: 57 Nm (5.8 kgf·m) Cpodpfx Ajyh E Irjh Isw Turret / Tool data Turret type: With ATC, spindle turret External turning tool size: □ 25 mm Internal turning tool size: Ø 40 mm Milling tool: Max. Ø120 × 250 mm length Indexing time (90°): 0.5 s Milling spindle speed: 15 – 6000 rpm (Option: 10000) Milling spindle motor power: 7.5 kW Max. milling spindle torque: 62.29 Nm (6.35 kgf·m) Feed axes X-axis: Travel 530 mm / Rapid traverse 30,000 mm/min Z-axis: Travel 1065 mm / Rapid traverse 33,000 mm/min Y-axis: Travel 140 mm / Rapid traverse 15,000 mm/min Z2-axis: Travel 1005 mm / Rapid traverse 20,000 mm/min Media / Control Coolant tank volume: 250 L Power consumption (continuous): 32.7 kVA Machine dimensions / Weight Overall length: 3485 mm Overall width: 2105 mm Overall height: 2416 mm Weight: 73,575 N (7,500 kgf)

Year of construction: 1997, condition: ready for operation (used), Controls: MAZATROL M PLUS, weight: 5.85t, operational hours counter: 42,150h, with magazine and accessories. Cjdpfeiph Ukox Ah Ijpw

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg workpiece height max.: 1.000 mm interference area: 900 mm Csdpfowix Hhox Ah Iepw 2 pcs. horizontal machining centers (HCN 6000-II + HCN 6000, 2005), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, *

Condition: used, Technical details: x-travel: 800 mm y-travel: 800 mm z-travel: 800 mm turning speeds: 35-10.000 1/min spindle: 37 / 30 kW max. torque on the spindle: 525 / 206 Nm Tool bore: BT 50 rapid traverse: 60 m/min tool change unit: 160 Pos. size of pallet: 500 X 500 mm control: MAZATROL 640M Nexus c-axis: 0,001° x 360.000 workpiece weight: 1.000 kg Cpodpfx Ahswix E Ro Iow workpiece height max.: 1.000 mm interference area: 900 mm 2 pcs. horizontal machining centers (HCN 6000 + HCN 6000-II, 2008), interlinked with pallet pool (16 pallets) MAZAK FMS, 2 pallet changer, chipconveyor, coolant device with internal coolant supply, *

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, Travel distances: X-axis: 560 mm, Y-axis: 640 mm, Z-axis: 640 mm Table: Pallet size: 400 x 400 mm Number of pallets: 2 Indexing: 1° steps Spindle: Spindle taper: SK-40 Max. speed: 18,000 rpm Power: 35 kW Tool magazine: Capacity: 60 tools Equipment: Control: Mazatrol SmoothG Tool length measurement Through-spindle coolant with 32 bar Niagara flushing Through-spindle air supply Renishaw OMP 60 probe Renishaw Inspection + (Version 2022) Tool ID system Chip conveyor Additional filter cartridges Thread cutting without compensation chuck Cjdoyhczfspfx Ah Ispw G00 inclination function CE marking The machine can be inspected under power.

Condition: good (used), Year of construction: 2008, Table size, pallet size: 500 x 500 mm Pallet quantity: 2 Maximum workpiece size: 730 x 500 mm Maximum table load: 500 kg Travel paths: X-axis: 630 mm Cpjdpjr Drcmofx Ah Isw Y-axis: 765 mm Z-axis: 510 mm C-axis: 360° (turntable) A-axis: +30°/-120° (swivel table) Speed range: 12 000 rpm Tool holder: SK 40 Tool positions: 80 Internal tool cooling: 20 bar Main drive power: 26 KW Machine weight: 17 000 kg Space requirement (LxWxH): 5 500 x 4 000 x 3 400 mm Control system: Mazatrol Matrix Accessories: Chip conveyor, complete documentation for the machine.

Condition: used, YOM 2004 Mazatrol PC Fusion 640 M Axis X 1660 mm Axis Y 510 mm Axis Z 510 mm Table length 2000 mm Table width 510 mm Max. part weight 1000 kg Number of tool pockets 30 Codpfov Ax Uyex Ah Iepw Spindle taper CAT 40 Max. spindle speed 10000 rpm Spindle motor power 18.5 kW

Condition: reconditioned (used), Year of construction: 2007, MAZAK QUICK TURN NEXUS 200-II MSY Max. turning diameter: 380 mm Max. machining length: 511 mm Max. milling speed: 4,500 rpm Max. spindle speed: 5,000 rpm Max. bar diameter: 65 mm Machine is equipped with: - CNC control Mazatrol Matrix Cpedpfx Ahjyhwy Ie Iow - KITAGAWA three-jaw chuck for main spindle, diameter 210 mm - KITAGAWA three-jaw chuck for secondary spindle, diameter 169 mm - Tool Eye - C-axis - C-axis on sub-spindle - Y-axis - Interface for bar loader magazine - Automatic parts catcher - Reinforced coolant pump - Chip conveyor - 8 stationary tool holders - 2 driven tool holders

Condition: excellent (used), Year of construction: 2020, Clamping area: Ø700 x 500 mm Rapid traverse X/Y/Z: 60/60/56 m/min Milling spindle Max. spindle speed: 18,000 rpm SK-40 Additional equipment Air at the workpiece Through-spindle coolant, 70 bar Csdpfx Ahsyhc E Dj Iopw Renishaw RMP 600 probe F) Tool tip control, 5-axis simultaneous machining Tool radius compensation – 5-axis simultaneous Drilling cycle with torque-dependent chip breaking G00 slope constant Synchronous tapping Cylinder interpolation EIA Dynamic Compensation 2 (includes 1) KNOLL coolant system KF200/1250 Paper band filter 70 bar high-pressure pump KNOLL chip conveyor 640-S-1

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Equipment: chip conveyor, Options: Chip conveyor Tool feeler 15-bar coolant Air blower Performance package Memory extension 8 MB Csdovb Ufxopfx Ah Ijpw 2 additional M codes Central partition
