Used Ermak Press Brake for sale (75)

Condition: excellent (used), functionality: fully functional, Cutting Length 6100mm Cutting Capacity 25mm Angle 0.5-2.5 Strokes per minute 3-5. Number of hold downs 36 Hnjdpfxeygd Aue Agyok Blade gap 0.005-3.00 Throat Depth 500mm

Condition: excellent (used), Year of construction: 2014, actuation type: hydraulic, working width: 3,100 mm, stroke rate (min.): 13 1/min, sheet thickness (max.): 10 mm, table height: 800 mm, back gauge: 1,000 mm, power: 22 kW (29.91 HP), Equipment: CE marking, emergency stop, finger protection, foot remote control, safety light barrier, We hereby offer you a hydraulic swing beam shear of the brand "ERMAKSON", used, in very good condition. Hnsdjxvinmspfx Agyjk Please feel free to contact us for a quote.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2012, machine/vehicle number: 09233-K06P27, working width: 3,100 mm, stroke rate (max.): 10 1/min, sheet thickness (max.): 16 mm, distance between stands: 3,400 mm, working height: 900 mm, TECHNICAL DETAILS Sheet width: 3,100 mm Sheet thickness: 16 mm Frame gap: 3,400 mm Shearing angle: 2.5° Working height: 900 mm Backgauge: 1,000 mm Hold-downs: 14 units Strokes per minute: 10 MACHINE DETAILS Hnodpfx Agsygw Epeyek Control: CYBELEC CybTouch 6 Total power requirement: 30 kW Dimensions & Weight Space required: approx. 4,150 x 2,360 x 2,450 mm Machine weight: approx. 16,400 kg Oil capacity: 500 l EQUIPMENT Electric backgauge 1,000 mm Electric cutting gap adjustment Electric cutting angle adjustment Cutting length limitation Light barrier at rear of machine Finger guard at front Ball rollers in support table 1x side stop 2x front support arms Foot switch

Condition: new, table length 3000 mm table width 1500 mm burner heads Precitec ProCutter laser capacity in Watt 4000 x-axis 3050 mm z-axis 150 mm y-axis 1550 mm total power requirement 22 kW dimensions 9190 x 3710 x 2200 mm weight of the machine ca. 11200 kg Furnishing: - MOMENTUM GEN - 2 fiber laser cutting machines 3,000 x 1,500 mm - Ytterbium YLS 4000 compact resonator (4 kW) - PRECITEC PROCUTTER laser cutting head - CAD / CAM software BECKHOFF - Controller CP 6242 - 17 "touchscreen, keyboard, control panel, alphanumeric keyboard - Collective conveyor under the cutting table - additional loading unit Cutting capacities: - normal steel ... 20 mm - stainless steel ... 12 mm - aluminum ... 10 mm - brass ... 6.0 mm - Copper ... 5.0 mm Workspace: - max .: 3,000 x 1,500 mm Axes: - Machine axes: 4 axes (X, Y, Z, U) - s speed: 100 m / min (simulated) - Axis speed X / Y: 100 m / min (single) - Positioning accuracy: + - 0.03 mm / min - Burning height: 125 - 200 mm Loading table: - Number of pieces 2 (35 seconds for changing) - automatic change of tables assisting gases: - mild steel - oxygen (0.5 - 25 bar) - stainless steel - nitrogen (0.5 - 25 bar) Hnjdpegvq A Eofx Agyjk - Aluminum - compressed air or nitrogen (0.5 - 25 bar) included : - Compatible suction system - Light barrier safety device - Spare part basic supply package Why Fibermak / Fiberlaser? - Up to 3 times faster cutting compared to other laser technologies - Machines for cutting thin sheets - Axis speed: reach up to 141 m / min. - Accelerations up to 2G - Fiber laser is the green laser technology - Saving of at least 50% energy costs) - There is no need for laser gas mixing - There is no need for optical components - therefore, among other things, very low-maintenance - Save up to 50% per part through more efficient production - Extended options: cutting reflective materials * like aluminum, copper, brass etc., - In addition, precise cuts and smooth surface quality - Heavy-duty constructed frame - equipped with world-famous, durable, high-quality components - Creative design, constant, highest technology and quality - High reliability - High efficiency - High quality - CE declaration

Condition: new, table length 4000 mm Hnjdpfx Aexabn Hsgyok table width 2000 mm burner heads Precitec Procutter x-axis 4050 mm z-axis 150 mm y-axis 2050 mm total power requirement 18,0 kW weight of the machine ca. 18.150 kg dimensions of the machine ca. 12430 X 5664 X 2310 m

Condition: new, table length 3000 mm table width 1500 mm burner heads Precitec ProCutter laser capacity in Watt 6000 x-axis 3050 mm z-axis 150 mm y-axis 1550 mm total power requirement 21 kW dimensions 9190 x 3710 x 2200 mm weight of the machine ca. 11200 kg Furnishing: - Resonator Ytterbium YLS 4000 compact - Beckhoff controller - Precitec ProCutter Automatic cutting head - autom. Lubrication system - CAD / CAM software LANTEK EXPERT CUT - 17 "touchscreen, keyboard, control panel - Collective conveyor under the cutting table - additional loading unit Cutting capacities: - normal steel 25 mm - stainless steel 15 mm - aluminum 12 mm - brass 8 mm - copper 8 mm Axes: - Machine axes: 4 axes (X, Y, Z, U) - s speed: 100 m / min (simulated) - Axis speed X / Y: 100 m / min (single) - Positioning accuracy: + - 0.03 mm / min - Burning height: 125 - 200 mm Loading table: - Number of pieces 2 (35 seconds for changing) - automatic change of tables - d 2,500 kg. assisting gases: - mild steel - oxygen (0.5 - 25 bar) - stainless steel - nitrogen (0.5 - 25 bar) - Aluminum - compressed air or nitrogen (0.5 - 25 bar) including: - Compatible suction system - Sick light barrier safety device - Spare part basic supply package Why Fibermak? - Up to 3 times faster cutting compared to other laser technologies - Machines for cutting thin sheets - axes equipped with linear motors / Servo motors reach up to 141 m / min. - Accelerations up to 2G - Fiber laser is the green laser technology (Saving of at least 50% energy costs) - There is no need for laser gas mixing - There is no need for optical Components / therefore very low-maintenance - Save up to 50% per part through more efficient production - Extended options: cutting from reflective materials like aluminum, copper, brass etc., - In addition, precise cuts and smooth surface quality Hedpfjgvq D Usx Agysnk - Heavy-duty constructed frame, equipped with world-famous, durable, high-quality components - ERMAK passes the price advantage on to its customers thanks to its fast and high quality production - Creative design, constant, highest technology and quality - High reliability - High efficiency - High quality - CE declaration

Condition: new, table length 3000 mm table width 1500 mm Hjdpovuz I Hjfx Agyenk burner heads 1 Control CNC workpiece weight 1500 kg total power requirement 21 kW weight of the machine ca. 10,4 t dimensions of the machine ca. 5,2 x 4,2 x 2,62 m CUTTING CAPACITY: STRUCTURAL STEEL 25 mm STAINLESS STEEL 15 mm ALUMINUM 12mm BRASS 8mm COPPER 8mm MACHINE AXES: 4 axes [X, Y, Z, U ] CUTTING HEAD: Precitec ProCutter CAD/CAM SOFTWARE: LANTEK EXPERT CUT *4 servo motors for all axial movements *CNC CONTROL PANEL 15 5” touch screen *IPG laser sources and coolers integrated *Precitec Procutter cutting head system *AIR FILTER (compressed air filter) *CONVEYOR BELT under cutting area *Closed housing and specially coated filter protection windows *LOADING / DISCHARGING SYSTEM *PROPORTIONAL GAS AND PIPE SYSTEM

Condition: new, pressure 80.0 t chamfer lenght 2600 mm distance between columns 2200 mm column arm 250 mm ram stroke speed 90.0 mm/sec work speed 7.5 mm/min return speed 60.0 mm/sec work stroke 160 mm dayligth 380 mm table height 900 mm oil volume 150 ltr. voltage 400 Volt weight 5227 kg range L-W-H 3750 x 1950 x 2400 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X Hsdpfoxaafwex Agyenk - AKAS laser in front of the machine - manual crowning - Upper tool, deer foot - Lower tool, die block with 4Vs - SICK light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes

Condition: new, pressure 200 t chamfer lenght 3100 mm distance between columns 2600 mm column arm 250 mm ram stroke speed 100 mm/sec return speed 75,0 mm/sec work speed 7,0 mm/min work stroke 180 mm dayligth 415 mm oil volume 200 ltr. table height 900 mm voltage 400 Volt Hnodsxaalwspfx Agyek range L-W-H 4450x2050x2650 mm Furnishing: - DELEM - CNC control model DA-58T - controlled axes: Y1 - Y2 and X - FIESSLER AKAS - laser protection in front of the machine - Deer foot upper tool - Universal die block - manual table crowning - Safety device: light barrier behind the machine - 2 front support arms - SIEMENS - electrical system - BOSCH / HOERBIGER hydraulic system - CE mark / declaration of conformity - Operating manual: machine and control - Safety manual: press brakes

Condition: new, sheet width 3100 mm plate thickness 10,0 mm Hedpexabdbefx Agysnk thickness at "Niro-steel" 6,0 mm down holder 14 Stück no. of strokes 13 Hub/min oil volume 260 ltr. cutting angle 2,0 ° throat 350 mm engine output 22,0 kW back stop - adjustable 1.000 mm weight 10.575 kg. range L-W-H 4,05 x 2,5 x 2,17 m ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, pressure 175 t chamfer lenght 3100 mm distance between columns 2600 mm column arm 410 mm ram stroke speed 180 mm/sec work speed 12.0 mm/min return speed 190 mm/sec work stroke 275 mm dayligth 550 mm oil volume 300 ltr. table height 900 mm table width 90.0 mm voltage 400 Volt total power requirement 15.0 kW weight 9800 kg range L-W-H 4150 x 2150 x 2800 mm ----- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection ----- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 Hsdpfoxabfxox Agyonk - split upper deer foot tool Roleri 135.85.R08, "System A" - with additional crowning of the upper wedge - Split universal die block M 460 R, including die shoe C 1050-R - LEUZE light barrier behind d. machine - BOSCH / HOERBIGER hydr. Components - SIEMENS - electrical system - FIESSLER AKAS laser protection device in front of the machine (including FPSC) - 2 front support arms with SLIDING system (plain bearings) - Double foot operation - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: new, sheet width 4100 mm plate thickness 10,0 mm thickness at "Niro-steel" 6,0 mm down holder 28 Stück no. of strokes 18 Hub/min oil volume 260 ltr. cutting angle 0,5 - 2 ° control CYBELEC Cybtouch engine output 22,0 kW back stop - adjustable 1000 mm range L-W-H 6100 x 2580 x 2460 mm weight 15.100 kg. ----- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting Hnsdexabwuopfx Agyek - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device * Monoblock design

Condition: new, pressure 220 t chamfer lenght 4100 mm distance between columns 3600 mm column arm 410 mm ram stroke speed 180 mm/sec work speed 10.0 mm/sec return speed 160 mm/sec work stroke 275 mm Hodpfx Aoxaathegysnk dayligth 550 mm table height 900 mm table width 160 mm oil volume 300 ltr. voltage 400 Volt total power requirement 18.5 kW weight 13800 kg range L-W-H 5150 x 2250 x 3000 mm ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA-58T graphics / touchscreen * 2D graphic programming * 15 "high definition color TFT screen * Bending sequence calculation * Product programming and display in real size * USB interface - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - Universal die block - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine - Swiveling control panel, mounted on the left - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: new, sheet width 3100 mm plate thickness 6,0 mm thickness at "Niro-steel" 4,0 mm distance between columns 3100 mm down holder 14 Stück oil volume 150 ltr. no. of strokes 18 Hub/min cutting angle 1,2 ° control CYBELEC CybTouch total power requirement 11,0 kW weight 6300 kg range L-W-H 4.000 x 2.100 x 1.640 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German Hnedpfxsxaa D Hj Agyjk including special equipment: - pneumatic sheet metal holding device

Condition: new, pressure 320 t Hedpfx Agsxaba Nsyonk chamfer lenght 4100 mm distance between columns 3600 mm column arm 410 mm ram stroke speed 140 mm/sec work speed 10.5 mm/sec return speed 150 mm/sec work stroke 375 mm dayligth 650 mm table height 900 mm table width 220 mm oil volume 400 ltr. voltage 400 Volt total power requirement 30.0 kW weight 22064 kg Dimensions (HxWxD) 5350 x 2450 x 3150 mm ----- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection ----- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, "System A" - with additional crowning of the upper wedge - Universal die block - LEUZE light barrier behind d. machine - BOSCH / HOERBIGER hydr. Components - SIEMENS - electrical system - FIESSLER AKAS laser protection device in front of the machine (including FPSC) - 2 front support arms with SLIDING system (plain bearings) - Double foot operation - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes Special equipment including: - electrical central lubrication

Condition: new, pressure 220 t chamfer lenght 3760 mm distance between columns 3250 mm column arm 410 mm ram stroke speed 180 mm/sec work speed 10.0 mm/sec return speed 160 mm/sec work stroke 275 mm dayligth 550 mm table height 900 mm table width 160 mm oil volume 300 ltr. voltage 400 Volt total power requirement 18.5 kW weight 12906 kg range L-W-H 5100 x 2250 x 2900 mm Hjdpew U U Rrjfx Agyenk ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - Universal die block - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine - Swiveling control panel, mounted on the left - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: new, pressure 100 t chamfer lenght 2600 mm distance between columns 2200 mm column arm 410 mm ram stroke speed 200 mm/sec work speed 9.5 mm/sec return speed 155 mm/sec work stroke 275 mm dayligth 530 mm table height 900 mm table width 90.0 mm oil volume 150 ltr. voltage 400 Volt total power requirement 7.5 kW weight 6850 kg range L-W-H 3750 x 1950 x 2800 mm ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm holder - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine - Swiveling control panel, mounted on the left Hnodsxaaqyepfx Agyok - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: new, pressure 320 t chamfer lenght 3100 mm distance between columns 2600 mm column arm 410 mm ram stroke speed 140 mm/sec work speed 10.5 mm/sec return speed 150 mm/sec work stroke 375 mm dayligth 650 mm table height 900 mm table width 240 mm oil volume 400 ltr. voltage 400 Volt total power requirement 30.0 kW weight 17082 kg Dimensions (HxWxD) 4550 x 2450 x 3200 mm ----- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection ----- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, "System A" - with additional crowning of the upper wedge - Universal die block - LEUZE light barrier behind d. machine - BOSCH / HOERBIGER hydr. Components - SIEMENS - electrical system - FIESSLER AKAS laser protection device in front of the machine (including FPSC) - 2 front support arms with SLIDING system (plain bearings) - Double foot operation - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes Hnjdpfsxabdzjx Agyok Special equipment including: - electrical central lubrication

Condition: new, sheet width 3100 mm plate thickness 6,0 mm thickness at "Niro-steel" 4,0 mm distance between columns 3100 mm down holder 14 Stück no. of strokes 18 Hub/min oil volume 150 ltr. cutting angle 1,2 ° control CYBELEC CybTouch Hnjdexabzgopfx Agyek total power requirement 11,0 kW weight 6300 kg range L-W-H 4.000 x 2.100 x 1.640 mm ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device (monoblock)

Condition: used, Year of construction: 2022, sheet width 3100 mm plate thickness 10.0 mm thickness at "Niro-steel" 6.0 mm down holder 14 Stück no. of strokes 13 Hub/min cutting angle 2.0 ° throat 350 mm back stop - adjustable 1000 (+) mm oil volume 260 ltr. engine output 22.0 kW weight 10.575 kg range L-W-H 4100 x 2400 x 2170 mm Demonstration/demo machine (!!) from our exhibition (like NEW) with very few operating hours ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - Light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device Hodpexab I Hofx Agysnk

Condition: new, sheet width 3100 mm plate thickness 6,0 mm distance between columns 3.100 mm down holder 14 Stück no. of strokes 16 - 24 Hub/min oil volume 150 ltr. cutting angle 0,5 - 1,5 ° thickness at "Niro-steel" 4,0 mm column arm 350 mm engine output 11,0 kW Hnedpoxabcqefx Agyjk weight of the machine ca. 7.060 kg range L-W-H 4,1 x 2,2 x 2,19 m ----- electr. / hydraulic CNC guillotine shears - guided by a backdrop * with CYBELEC CNC touch screen control * with electr. / hydr. Cutting gap and cutting angle adjustment ----- Furnishing: - CNC guillotine guillotine shears - with electr. / hydr. Cutting gap and cutting angle adjustment - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German including special equipment: - pneumatic sheet metal holding device

Condition: new, pressure 40.0 t chamfer lenght 1270 mm distance between columns 1050 mm column arm 350 mm dayligth 387 mm work stroke 170 mm table height 850 mm back stop - adjustable 800 mm adjustment speed 230 mm/min Hnedpfew U U Rlex Agyok ajustment speed 140 mm/sec working feed 10.0 mm/sec return speed 170 mm/sec total power requirement 5.5 kW weight of the machine ca. 3220 kg dimensions of the machine ca. 2150 x 1650 x 2300 mm ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA 58T (TouchScreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm holder - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine - Swiveling control panel, mounted on the left - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes

Condition: new, pressure 400 t chamfer lenght 4100 mm distance between columns 3550 mm Hedpfx Asxaadtogyenk column arm 510 mm ram stroke speed 110 mm/sec work speed 8.4 mm/sec return speed 130 mm/sec work stroke 375 mm dayligth 650 mm table height 1000 mm table width 240 mm back stop - adjustable max. 800 mm oil volume 400 ltr. voltage 400 Volt total power requirement 30.0 kW weight 26409 kg range L-W-H 5450 x 2650 x 3470 mm ----- HIGH-SPEED hydraulic press brake with increased installation height increased cylinder stroke enlarged projection ----- Furnishing: - DELEM CNC control model DA 66T - swiveling touchscreen control unit - 7 controlled axes: Y1 - Y2 - X - R - Z1 and Z2, as well as CNC crowning - electr. controlled backgauge X-axis = 800 mm / R-axis = 250 mm - on ball screws - controlled electr. Stop fingers Z1 + Z2 - split upper deer foot tool Roleri 135.85.R08, "System A" - with additional crowning of the upper wedge - Universal die block - LEUZE light barrier behind d. machine - BOSCH / HOERBIGER hydr. Components - SIEMENS - electrical system - FIESSLER AKAS laser protection device in front of the machine (including FPSC) - 2 front support arms with SLIDING system (plain bearings) - Double foot operation - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes Special equipment including: - electrical central lubrication

Condition: new, sheet width 3100 mm plate thickness 13,0 mm thickness at "Niro-steel" 8,0 mm down holder 14 Stück no. of strokes 11 Hub/min oil volume 310 ltr. cutting angle 2,0 ° throat 350 mm table height 900 mm total power requirement 22,0 kW weight of the machine ca. 12200 kg range L-W-H ca. 4100 x 2300 x 2235 mm ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table Hodpjxaa U Ssfx Agyonk - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, pressure 60.0 t chamfer lenght 2100 mm distance between columns 1700 mm column arm 410 mm ram stroke speed 160 mm/sec work speed 10.0 mm/sec return speed 165 mm/sec work stroke 275 mm dayligth 530 mm table height 900 mm table width 90.0 mm oil volume 150 ltr. Hnodjxabckepfx Agysk voltage 400 Volt total power requirement 7.5 kW weight 5640 kg range L-W-H 3250 x 1960 x 2750 mm ----- Press brake with special equipment * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Furnishing: - DELEM CNC control model DA 53T (touchscreen) - Motorized backgauge with R-axis, on recirculating ball spindles - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes Y1 - Y2 - X - R - C (crowning) - electr. Crowning controlled by CNC - Upper deer foot tool with PS 135.85-R08, system "A" with quick-change clamp - Additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm holder - BOSCH / HOERBIGER hydr. Components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protective device v.d. machine - Swiveling control panel, mounted on the left - 2x front support arms "sliding system", with T-slot and tilting cam - 1x double foot control - CE mark / declaration of conformity - User manual: machine and control in German - Safety manual: press brakes
