Used Mep Bandsaw for sale (140)

Year of construction: 1997, condition: ready for operation (used), Wire diameter (single wire): 6mm-14mm, wire diameter (double wire): 6mm-10mm, maximum bending angle: 180°, motor power: 22kW, feed rate: 1.5m/s, bending speed: 1000°/s, cutting time: 0.4s, hydraulic tank volume: 300l. Machine dimensions X/Y/Z: approx. 4900mm/1640mm/2200mm, weight: approx. 3300kg. Control system defective. Documentation available. On-site inspection is possible. Dkjdpfx Asuwrv Djprjt

Condition: new, Year of construction: 2023, cutting diameter 350 mm saw band length 4640 x 34 x 1,1 mm table height 860 mm 350 mm 15 - 100 m/min 4,0 kW 2800 kg 2200 x 3200 x 2200 mm Display Model Current list price: 55,910 euros Fully automatic band saws with a two-column guide system for production cuts, particularly in materials that are difficult to machine and solid stock. With this machine, MEP offers you a machine that is at the highest technical level and, thanks to the use of the highest-quality materials, features an unmatched, robust, and torsionally rigid structure. An extremely robust saw frame made of gray cast iron provides the necessary stability, which leads to impressive cutting results, and the sturdy gray cast iron columns on which the saw frame glides via preloaded linear guides ensure ensure the highest cutting precision even under maximum load. The modern machine control system (MEP NC 5.0) offers the user maximum ease of operation and ensures trouble-free operation. (Monitoring/Evaluation/Correction in real time) MAXIMUM PERFORMANCE > The two operating modes (semi-automatic and automatic) enable efficient cutting under all conditions. > The control system allows for the storage of up to 100 cutting programs, each with different quantities and lengths, and minimizes programming time for frequently executed jobs. > The automatically detected starting position of the saw head reduces the setup time. > The saw headâ??s feed via linear guides driven by hydraulic cylinders with preloaded ball screws ensures reduction of mechanical vibrations during cutting and greater stability. > The automatic alignment of the front saw blade guide head based on the dimensions of the bars to be cut reduces processing time. > Saw blade tension is controlled by the brushless motor and is constantly monitored and automatically adjusted to the set minimum value. EXTREMELY FLEXIBLE > The feed system, with a 600 mm stroke, is repeatable and cuts all lengths. > The vertical roller pair allows for holding and aligning any type of bar or bundle that is fed into the machine. > The vector drive for stepless adjustment of the blade speed from 15 to 100 m/min enables the cutting of any material. > The motorized chip conveyor can be mounted to the right or left of the cutting area . FEATURES: Fully automatic control â?? NC 5.0 - Innovative (Windows CE-based) touchscreen control with additional soft- touch buttons for frequently used functions -USB port -Joystick for manual control of the axes (X-Y) -Controlled head descent with automatic compensation via a servo valve , constant monitoring of the preselected torque 4, and with precise feed rate adjustment in millimeters per minute 5 -Adjustment/preselection of the continuously variable band speed in m/min. -Band saw tension with tension monitoring and display via an electronic converter -Automatic detection of the start of the cut -Large 7" color touchscreen for displaying and selecting all machine functions and parameters, and programming in seconds. Display of Dodpfx Apelf Tu Uerokt detailed alarm and error messages -Numerous special functions, including executing various lengths and quantities (10 programs) as a sequence, clean cut, step-by-step execution, and much more. -Sturdy, torsion-resistant, and low-vibration saw frame made of cast steel -Carbide band guides for maximum cutting precision, hinged for easy saw band replacement -Large, adjustable cast steel idler ...

Condition: used, Gehrungs cold-cut circular saw machine MEP Type Tiger 350 CNC FE Factory No. 00011818 Year of manufacture 1995 Cutting range at 90° round: Ø 115 mm Cutting range at 90° rectangle: 180 x 95 mm Cutting range at 45° round: Ø 110 mm Cutting range at 45° rectangle: 125 x 95 mm Cutting range at 30° round: Ø 90 mm Cutting range at 30° rectangle: 90 x 95 mm Cutting range round: Ø 120 mm Rectangle: 180 x 100 mm Vise opening: max. 185 mm Saw blade diameter: 350 mm Miter cut: 60° left to 45° right Saw blade speed: 15 / 30 / 45 and 90 rpm Motor power: 1.8 and 2.6 kW Mains connection: 400 Volt, 50 Hz Compressed air requirement: 6 bar - CNC control for up to 80 different cut lengths with corresponding quantities ???? Dksdpfx Apszrpl Djrjt - CNC control, cut length and quantity programmable - hydro-pneumatic saw head lowering - pneumatic material clamping - pneumatic material support - jaw feed with servo drive and ball screw - feed stroke programmable up to 9999 mm - 2 gear stages and 2 motor speeds - coolant system in the machine stand Space requirement L x W x H: 2000 x 1100 x 2030 mm Weight: 650 kg Good condition

Condition: good (used), Year of construction: 1999, machine/vehicle number: 108401 23-D, Offer 25318 Technical Data: - Manual bandsaw machine - Bandsaw blade dimensions: 2375 x 20 x 0.9 mm - 2 cutting speeds: 33 / 66 rpm - Max. clamping capacity: 205 mm Djdpfoxta N Aex Aprskt - Mitre adjustable left & right: 30° - Cutting range: - 90°: round 160 mm - square 160 mm - flat 200 x 100 mm - 45° left & right: round 140 mm - flat 140 x 60 mm - Drive: 400 V / 1.5 / 1.8 kW - Coolant system - Discharge roller conveyor with stop: 3000 mm - Infeed roller conveyor: 1500 mm - Weight: approx. 350 kg - Space requirement: approx. W 1100 x H 1700 x D 1550 mm

Condition: used, Straight-Cut Cutting Bench 40, manufactured by MEP Number of bars: - n.1 Ø 40 - n.2 Ø 32 - n.3 Ø 26 - n.4 Ø 20 - n.5 Ø 16 22 Fy= 600 N/mm - ft= 650 N/mm Dksdpfovtx Eysx Aprjt Minimum cutting length: 800 mm Maximum length: 12.000 mm Measurement tolerance: +/- 1 mm/m Max. speed positioning: 2m/s Measurement evacuation speed: 2,2 m/s Number of compartments: 5 + 5 Minimum cutting length: 800 mm Maximum length: 12.000 mm Measurement tolerance: +/- 1 mm/m Max. speed positioning: 2m/s Measurement evacuation speed: 2,2 m/s Number of compartments: 5 + 5

Condition: used, For sale: MEP PH 261-1HB band saw for metal. The machine is used, in good condition and fully operational. Inspection and testing on site is possible. The MEP PH 261-1HB is a professional manual gravity band saw for metal, designed for cutting tubes, profiles, and solid materials. The HB system enables automatic descent cutting without operator intervention. Specifications: Model: MEP PH 261-1HB Mitre cutting range: 0° to +60° Cutting capacities: 0° – Ø225 mm, 200 x 200 mm, 240 x 160 mm +45° – Ø160 mm, 140 x 140 mm, 155 x 115 mm +60° – Ø90 mm, 90 x 90 mm Maximum vise opening: 245 mm Blade dimensions: 2450 x 27 x 0.9 mm Blade speed: 46 / 92 m/min Motor power: 0.94 / 1.1 kW Working table height: 950 mm Machine weight: approx. 240 kg Cast iron construction for reduced vibration and increased cutting precision Quick mitre adjustment Suitable for cutting steel, stainless steel, aluminium, and other metals For more information: MEP PH 261-1HB Professional Italian machine for workshops, production, and metalworking companies. Djdpey R Sgwefx Aprjkt If you have any further questions, we will be happy to assist you.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, cutting height (max.): 250 mm, cutting width (max.): 280 mm, saw band length: 2,950 mm, saw band speed: 1,667 mm/s, saw band width: 27 mm, TECHNICAL DETAILS Saw band dimensions: 2,950 x 27 x 0.9 mm Speed: 15-100 m/min Vise opening: 285 mm Cutting capacity at 90° (round): 250 mm Cutting capacity at 90° (square): 220 mm Dksdpfezapxzex Aprjt Cutting capacity at 90° (rectangular): 280 x 220 mm Cutting capacity at 60° (round): 120 mm Cutting capacity at 60° (square): 80 mm Cutting capacity at 60° (rectangular): 140 x 100 mm Cutting capacity at 45° (round): 230/200 mm Cutting capacity at 45° (square): 200/170 mm Cutting capacity at 45° (rectangular): 220 x 200/200 x 140 mm Control: conventional MACHINE DETAILS Total power requirement: 2.2 kW Weight: 990 kg Machine dimensions: 2,500 x 2,230 x 2,050 mm

Condition: excellent (used), functionality: fully functional, Blade inclination -45° / +45°. Maximum vise opening 180 mm Maximum non-feedable length 385 mm Disc size 350 mm Dsdpfx Aox Hw Sqeprokt Blade rotation speed 1700 / 3400 rpm - 2 speeds

Year of construction: 1998, condition: good (used), machine/vehicle number: 080024-38 U, Offer 23332 Dksdpfx Ajp Ebn Seprjt Technical data: - Saw blade dimension 250 x 2 x 40 mm - Saw blade spindle speed 52 rpm - cutting range at 90° round 80 mm - flat 95 x 60 mm - miter adjustable up to 45 ° - Material vice - Drive 400 V / 0,5 kW - Space requirement approx. W 650 x H 1500 x D 750 mm - Weight approx. 100 kg

Condition: good (used), Metal band saw, fully automatic, band saw machine, band saw, vertical band saw, horizontal band saw, hydraulic horizontal band saw machine, automatic band saw, automatic metal band saw -Manufacturer: MEP, Horizontal band saw, Automatic band saw -Drive: 4.4/5.7 kW -Cutting data flat 90°: 320 x 200 mm Djdpsy Hu H Eofx Aprjkt -Cutting data for 90° square: 250 mm -Cutting data flat 45°: 240 x 200 mm -Cutting data for 45° square: 210 mm -Saw blade speed: 2x speeds -Saw blade: 3150 mm -Coolant system -Transport dimensions: 3 meters -Weight: 1300 kg

Condition: used, Year of construction: 1999, saw blade diameter 275 mm capacity 90 degrees: round 80 mm capacity 90 degrees: square 70 mm capacity 90 degrees: flat 100 x 60 mm capacity 45 degrees: round 70 mm capacity 45 degrees: square 60 mm capacity 60 degrees: flat 80 x 50 mm clamping range 110 mm Dodpfjl R Nnnsx Aprskt turning speeds 45 / 90 U/min total power requirement 0,5 kW weight of the machine ca. 0,07 t dimensions of the machine ca. 900 x 700 x 1600 m Manual cold circular saw with: - Machine base - Support rail 1500mm

Year of construction: 2003, condition: used, cutting capacity - round 300 mm dimensions of saw-band 3320 x 27 x 0,9 mm cutting capacity - flat 330 x 260 mm cutting capacity - square 260 mm Control evolution work height max. 870 mm 40 / 80 mt/min weight of the machine ca. 1050 kg Dedpfx Aera Rrloprskt

Condition: new, capacity 90 degrees: round 300 mm capacity 90 degrees: square 250 mm capacity 90 degrees: flat 380x250 mm 260 mm 250 mm Djdpjyv Ntrofx Aprokt 300x200 mm 180 mm 170 mm 200x170 mm 240 mm 210 mm 280x160 mm dimensions of saw-band 3770x27x0,9 mm speed 40/80 m/min 385 mm total power requirement 1,5/1,8 kW weight 695 kg

Year of construction: 2002, condition: good (used), MEP CONDOR 90 CNC MR automatic CNC-controlled miter saw for cutting aluminum profiles, with automatic feed. Used, in excellent condition. Dksdpoikztpofx Apret

Condition: good (used), Cold circular saw, metal circular saw, miter saw, circular saw, sawing system, metal saw -Manufacturer: MEP, cold circular saw metal circular saw type TRL 300 pivoting on both sides -Engine: Type C 112 M Dkodpfx Apsxlzyterjt -Power: 2.2 / 3.0 kW -Speed: 720 / 1450 rpm -Saw blade: Ø 315 mm -Cutting area at 90 degrees flat: 110 x 70 mm -Cutting range at 45 degrees: 100 mm -Accessories: incl.2 saw blades, see photos -Dimensions: 1230/630/H1800 mm -Weight: 273 kg

Condition: new, 36/72 m/min 285 mm capacity 90 degrees: round 250 mm capacity 90 degrees: square 230 mm capacity 90 degrees: flat 280x200 mm capacity 45 degrees: round 190 mm capacity 45 degrees: square 180 mm capacity 45 degrees: flat 180x180 mm capacity 60 degrees: round 120 mm capacity 60 degrees: square 110 mm capacity 60 degrees: flat 110x110 mm dimensions of saw-band 2950 x 27 x 0,9 mm output 1,5 / 1,8 kW Weight 435 kg dimensions 1700x1000x1840 mm Semi-automatic function: - Vice closes and engine starts - Saw head lowers for the cut - Engine shuts off Dsdpfjyv Nfuox Aprjkt - Saw head lifts - vise opens

Condition: new, Year of construction: 2024, * Manual cutting cycle * Automatic cutting: (via selector switch) with stepless adjustment of the feed rate and adjustment of the cutting pressure via a compensating spring * Stable, torsion-resistant, and vibration-damped saw frame made of cast steel * Large, easily adjustable, and mounted rotary table, with a centrally aligned rotary table with indexing at 0° / 45° / 60° and an internal table clamping mechanism for intermediate angles * Vise with quick adjustment * Carbide band guides for maximum cutting precision * Hydraulic unit for saw band tensioning and monitoring with display on a pressure gauge * Clear control panel with all control elements * Base frame, coolant tank, coolant pump, and chip brush * Cutting diameter 250 mm * Cutting width 280 mm * Saw band dimensions 2950 x 27 x 0.9 mm * Vise opening max. 285 mm * Band speed 36 / 72 m/min * Cutting range at 90 degrees: round 250 mm * Cutting range at 90 degrees: square 220 mm * Cutting range at 90 degrees: flat 280 x 220 mm * Cutting range at 60 degrees: round 120 mm * Cutting range at 60 degrees: flat 140 x 80 mm * Cutting range at 60 degrees: square 80 mm * Cutting range at 45 degrees: round 200 mm * Cutting range at 45 degrees: flat, left 220 x 200 / right mm * Cutting range at 45 degrees: square, left 200 / right 170 mm * Machine weight approx. 0.4 t * Space requirement approx. 1.8 x 1.3 x 1.8 m Dedsftmxvjpfx Aprokt

Condition: new, dimensions of saw-band 3320x27x0,9 mm 40/80 m/min 335 mm capacity 90 degrees: round 300 mm Dksdpfx Apjyv Na Serjt capacity 90 degrees: square 260 mm capacity 90 degrees: flat 330x260 mm 260 mm 250 270x200 mm capacity 60 degrees: round 180 mm capacity 60 degrees: square 170 mm capacity 60 degrees: flat 170x170 mm 200 mm 180 mm 200x160 mm weight of the machine ca. 640 kg dimensions of the machine ca. 2140x1300x1950 mm

Condition: new, cutting range 300 mm capacity 90 degrees: flat 330 x 260 mm capacity 90 degrees: square 260 x 260 mm capacity 45 degrees: round 260 mm capacity 45 degrees: flat 270 x 200 mm capacity 45 degrees: square 250 mm capacity 60 degrees: round 180 mm capacity 60 degrees: flat 170 x 170 mm capacity 60 degrees: square 180 mm automatic feeds 9999,9 mm feed minimum 2 mm cutting diameter minimum 5 mm band speed 15 - 100 m/min vice 340 mm Öffnung dimensions of saw-band 3650 x 27 x 0,9 mm total power requirement 2,2 kW weight 1240 kg range L-W-H 1800 x 1900 x 1750 mm Equipment: - robust electro-hydraulic fully automatic band saw (INDUSTRY) - with additional semi-automatic function, for cuts from 0° to 60° left - WINDOWS “CE” based MEP 50 – control and 7” touch screen display * simple and quick setting of all machine parameters * with additional soft keys + backlit display * 10 programs, each with a maximum of 9999 pieces . and a maximum length of 9999.9 mm - material feed with stepper motor via ball screw * single stroke 600 mm repeatable to saw any length * accuracy of ± 0.1/600 mm - feeder with protective cover and safety limit switch - precise setting of the cutting feed with indication in mm/min - positioning of the saw head and movement of the feeder using a joystick - automatic detection of the start of the cut - large deflection discs, adjustable from cast steel - Saw blade tension with blade tension control and display - Hard metal blade guides for maximum cutting precision - Automatic monitoring of the cutting load - Vice with quick adjustment Dksdpfxexabwhe Aprot * with interchangeable clamping and stop jaws - Large, laterally extendable chip tray and coolant container * equipped with 2 electric pumps for lubricating and cooling the saw blade * Coolant gun for cleaning the machine - Chip removal brush for cleaning the saw blade - Operating instructions DE Information from the manufacturer: When installing this saw in the network with a residual current device (FI), this should be universally sensitive and not less than 300 mA. SPECIAL ACCESSORIES INCLUDED: - MEP LubeCut micro dosing device

Condition: new, cutting diameter 300 mm capacity 90 degrees: flat 330 x 260 mm capacity 90 degrees: square 260 x 260 mm capacity 45 degrees: round 260 mm capacity 45 degrees: flat 270 x 200 mm capacity 60 degrees: round 180 mm capacity 60 degrees: flat 170 x 170 mm height of material-table 600 mm Pitch min/max 50.000 mm vice 335 mm Öffnung band speed 15 - 100 m/min automatic feeds 600 mm dimensions of saw-band 3650 x 27 x 0,9 mm total power requirement 2,2 kW weight 1.105 kg range L-W-H 3,3 x 2,83 x 2,23 m electro-hydraulic band saw fully automatic, with additional : * semi-automatic * semi-automatic-dynamic * manual .. operation Dkedpfx Aexab S Eeprjt Description: - robust electro-hydraulic band saw fully automatic (INDUSTRY) * MEP - WINDOWS numerical control unit * User interface with 7” touch screen display * mechanical buttons for the sawing machine’s operating functions * guarantees reliable operation, simple and intuitive * real-time control of all cutting parameters * pivoting arm enables comfortable and safe operation * display and recording of alarm and error messages - miter cuts with automatic cycle from 0° to 60° left - semi-automatic, semi-automatic-dynamic and manual cycle * miter cuts from 45° right to 60° left - manual or semi-automatic dynamic cycle selectable * to make cuts without programming - protective housing for the safety of the worker - continuous regulation of the cutting speed from 15 to 100 m/min * via frequency converter (inverter) - Latest generation hydraulic unit * extremely powerful with low energy consumption. - Material feed with stepper motor via ball screw * mounted on opposing ball bearings * Single stroke 600 mm repeatable to saw any length. - Positioning of the saw head and movement of the feeder using a joystick. - Automatic detection of the cutting start position - Manually operated band tension control with display * using an electronic converter - Automatic monitoring of the cutting load * using a servo valve mounted directly on the cylinder - The coolant tray is built into the base frame - Chip removal brush - Bimetal saw band for solid and profile material - Tools and operating instructions with spare parts list * Angularity = 2/12 degrees * Length accuracy = plus/minus 0.1 mm per feed SPECIAL ACCESSORIES INCLUDED: - MEP LubeCut micro dosing device

Condition: new, cutting diameter 250 mm capacity 90 degrees: flat 280 x 220 mm capacity 90 degrees: square 220 x 220 mm capacity 45 degrees: flat 220 x 200 mm capacity 45 degrees: round 230 mm capacity 45 degrees: square 200 x 200 mm capacity 60 degrees: flat 140 x 100 mm capacity 60 degrees: square 100 x 100 mm capacity 60 degrees: round 150 mm vice 285 mm turning speed range: 36/72 m/min dimensions of saw-band 2950 x 27 x 0,9 mm total power requirement 1,5 / 1,8 kW weight of the machine ca. 460 kg dimensions of the machine ca. 1150 x 1970 mm Equipment: - robust electro-hydraulic semi-automatic band saw (INDUSTRY) - with miter cuts from 45° right to 60° left * Miter adjustment via large turntable - MEP microprocessor control EVO to control all functions * front right, rotatable - optional manual or automatic lowering of the saw bow Dkodpfx Apoxaa S Rjrot * stepless adjustment of the saw bow lowering - saw band guide made of hard metal plates - hydraulic saw band tension - including digital value display - 2x saw band speeds - 1x BI-metal saw band - 1x angle stop - chip removal brush - machine base frame with forklift pockets - operating instructions in German Functioning of semi-automatic operation: - electro-hydraulic clamping of the vice - electro-hydraulic lowering of the saw bow - electro-hydraulic raising of the saw bow - electro-hydraulic opening of the vice SPECIAL ACCESSORIES INCLUDED: - MEP LubeCut micro dosing device

Condition: new, cutting diameter 300 mm capacity 90 degrees: flat 330 x 260 mm capacity 90 degrees: square 260 x 260 mm capacity 45 degrees: flat 270 x 200 mm capacity 45 degrees: round 260 mm capacity 45 degrees: square 250 x 250 mm capacity 60 degrees: flat 170 x 170 mm capacity 60 degrees: square 170 x 170 mm capacity 60 degrees: round 180 mm turning speed range: 40 / 80 m/min dimensions of saw-band 3650 x 27 x 0,9 mm engine output 1,5 / 1,8 kW weight 670 kg Dedpfx Apjxaagbjrskt Equipment: - robust electro-hydraulic semi-automatic band saw (INDUSTRY) - with miter cuts from 45° right to 60° left * Miter adjustment via large turntable - MEP microprocessor control EVO to control all functions * front right, rotatable - optional manual or automatic lowering of the saw bow * stepless adjustment of the saw bow lowering - saw band guide made of hard metal plates - hydraulic saw band tension - including digital value display - 2x saw band speeds - 1x BI-metal saw band - 1x angle stop - chip removal brush - machine base frame with forklift pockets - operating instructions in German Functioning of semi-automatic operation: - electro-hydraulic clamping of the vice - electro-hydraulic lowering of the saw bow - electro-hydraulic raising of the saw bow - electro-hydraulic opening of the vice SPECIAL ACCESSORIES INCLUDED: - MEP LubeCut micro dosing device

Condition: new, cutting diameter 250 mm capacity 90 degrees: flat 280 x 220 mm capacity 90 degrees: square 220 x 220 mm capacity 45 degrees: round 230 mm capacity 45 degrees: flat 220 x 200 mm capacity 45 degrees: square 200 x 200 mm capacity 60 degrees: flat 140 x 100 mm capacity 60 degrees: square 100 x 100 mm capacity 60 degrees: round 110 mm vice 285 mm turning speed range: 36/72 m/min saw band length 2.950 x 27 x 0,9 mm total power requirement 1,5/1,8 kW weight of the machine ca. 440 kg. dimensions of the machine ca. 1620 x 1360 mtr. Equipment: Dkodpfx Apexabpwsrst - robust electro-hydraulic band saw (INDUSTRY) - large bearing-mounted rotary table * for miter cuts from 45° right to 60° left - automatic saw bow lowering * with continuously adjustable feed * limit switch at the end of the cut - manual cutting function selectable - saw band guide made of hard metal plates - 1x saw band - 1x angle stop - moving chip removal brush - control panel - front right - hydraulic pressure box for saw band tension * with analogue pressure display (manometer) - machine base frame with forklift pockets - operating instructions in German SPECIAL ACCESSORIES INCLUDED: - MEP LubeCut micro dosing device

Condition: new, cutting diameter 250 mm capacity 90 degrees: flat 280 x 220 mm capacity 90 degrees: square 220 x 220 mm vice 285 mm turning speed range: 36/72 m/min dimensions of saw-band 2950x27x0,9 mm total power requirement 1,5 / 1,8 kW weight of the machine ca. 485 kg dimensions of the machine ca. 1700 x 1000 x 1800 mm Electro-hydraulic semi-automatic band saw SHARK 282 SXI EVO with semi-automatic-dynamic, manual function, has a MEP-28 control for miter cuts from 45° right to 60° left. Semi-automatic function: At the start of the cycle: - Vice closes and motor starts – Saw head lowers for the cut – Motor switches off – Saw head rises – Vise opens. Semi-automatic dynamic system (manual lowering of the saw band bow up to to the desired position and cycle start via the manual button.) Some features: New centralized control console on an articulated arm to allow the operator can be easily switched from any working position. Low voltage control panel: Polyester membrane keyboard with thermoformed highlighted Push buttons and actuation control signal. Display to show: Djdpfjfg E H Sjx Aprjkt * Diagnostics (messages in the user language) * Alarms (description of alarm causes) * State of inputs and outputs * Counting cuts * Time taken for the cut made * Current consumption of the saw blade motor * Saw blade tension * Blade speed * Numerical display of head position. Switch handle IP55 of manual 24V cycle. Complete program of all special cutting cycles. Identification of other possible special cutting cycles for special ones Applications New, latest generation hydraulic control unit, extremely powerful and with low energy consumption. Large work surface with turntable on roller bearings, measuring 265 mm preloaded thrust bearing, mounted. Double belt speed (36/72 m/min.) with control Intended to accommodate an electronic inverter for the Continuous regulation of the belt speed from 20 to 90 m/min. Stroke of the saw bow can be programmed directly from the control panel Adaptation to the cutting material. Clamping device can be moved laterally to the left and right Quick release vice. Manually operated strap tension control with display on the screen electronic converter. Base frame with pull-out coolant tray. Electric coolant pump for cooling and lubricating the saw band. Preparation for installing the minimum blade lubrication kit (Optional), in addition to the conventional standard lubrication Emulsion oil. Chip clearing brush. The machine is intended for pallet truck transport. Length stop for cuts of the same length Material support arm with roller for attaching the loading platform Bimetal saw band for solid and profile material. Tools and instructions for use in the respective user language.

Condition: new, dimensions of saw-blade 350x32x4 mm vice 180 mm 1700/3400 U/min Dksdsy Dh Nnjpfx Aprst capacity 90 degrees: round 120 mm capacity 90 degrees: square 105 mm capacity 90 degrees: flat 180x70 mm capacity 45 degrees: round 120/110 mm capacity 45 degrees: square 100/95 mm capacity 45 degrees: flat 135x60 mm output 2,2 kw weight 225 kg
