Used Deckel Milling Machine for sale (704)

Year of construction: 1981, condition: used, Make cover Type FP 4 Table: dimensions 1000 x 470 mm longitudinal movement X - axis 700 mm transversal movement Y - axis 400 mm vertical movement Z - axis 450 mm projection spindle 50 450 mm spindle mounting ISO 40 Number of spindle speeds 18 Spindle speed range 31,5 1600 rpm Number of revolutions horizontal spindle 18 pcs. Speed range horizontal spindle 31,5 1600 rpm Weight machine 2000 kg Fedpsihp U Dsfx Af Eoga feeds X Y Z axis 18 pcs 10 500 mm/min Accessories milling head with quill Table 1000 x 470 mm

Condition: used, x-travel 500 mm y-travel 400 mm z-travel 400 mm Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : DECKEL MAHO CNC Universal Milling Machine model DMU 50 M year 1998 Fgedsv Td Elspfx Af Eoa Working range: Longitudinal stroke X Axis 500 mm Vertical stroke Z Axis 400 mm Cross stroke Y Axis 400 mm C-axis – table turning, manual 360 ° B-axis – table swivelling, manual ° Table area Ø 700 x 500 mm Inclination range of table (manually) + / - ° Rotation of table (manually) 360 ° Max. Table load approx. 200 kg Maximum distance table – spindle nose 550 mm horizontal distance machine – spindle nose 2 – 6 mm Tool holder Taper ISO 40 Spindle speeds 20 – 4,500 rpm Feed rate max. 5.000 mm/min AC main drive, 0% / 40% power-on time approx. 9 / 13 kW Total electrical load, approx. 15 kW - 400 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features • 3 Axis HEIDENHAIN Point to Point Control Model TNC 124 with Monitor, direct programming and input of data and electronic handwheels. • All 3 axis are operated by the milling head, the table is stationary so also out of proportion workpieces can be machined. • Rotary Table can be manually rotated 360° and manually inclined + / -° (each with clamping). The digital read-out of the angles is integrated in the CNC control • Simple coolant unit with pump and tank, built-on switch cabinet (SIEMENS parts) • Pneumatic tool claomping, Some tool holders available, manuals, CE-Certificate, etc. Condition : very good condition ! Ideal for training center or single parts machining ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 0 % Net, after conclusion of contract, before loading We always have a large selection of milling machines - CNC or conventional - available. Please let us know your requirements.

Condition: refurbished (used), Year of construction: 1982, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 3,150 rpm, spindle speed (min.): 31 rpm, type of input current: three-phase, rotational speed (max.): 6,300 rpm, rotational speed (min.): 31 rpm, warranty duration: 3 months, Equipment: documentation/manual, We are offering this overhauled DECKEL FP 2NC with TNC 320 tool milling machine, year of manufacture 1982. Manufacturer: DECKEL Model: FP 2NC with TNC 320 Year of manufacture: 1982 Condition: Completely overhauled Control: TNC 320 Fgjdpfx Afex Sv Rcj Eja Machine type: Tool milling machine If you have any questions or require further information, please feel free to send us a message or call us.

Condition: refurbished (used), Year of construction: 1992, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 2 rpm, table length: 900 mm, table width: 530 mm, type of input current: three-phase, total length: 900 mm, total width: 530 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 2 rpm, warranty duration: 3 months, working range: 900 mm, Equipment: documentation/manual, rotational speed infinitely variable, We are offering this overhauled Deckel FP 4-60T tool milling machine with Dialog 11 control, year of manufacture 1992. Deckel: FP 4-60T Condition: Fully overhauled Fsdpfx Aex Sv Ubef Eega Tool changer: 24 positions Control: Dialog 11 If you have any questions or require further information, please feel free to send us a message or call us.

Condition: refurbished (used), Year of construction: 1985, functionality: fully functional, feed length X-axis: 500 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, total length: 800 mm, table width: 460 mm, table length: 800 mm, type of input current: three-phase, rotational speed (max.): 2,500 rpm, rotational speed (min.): 50 rpm, warranty duration: 3 months, Equipment: documentation/manual, We are offering this fully overhauled Deckel FP4 M milling machine, year of manufacture 1985. Manufacturer: Deckel Model: FP4 M Year: 1985 Condition: overhauled Control: TNC113 Aktiv control Optional: universal table with a clamping surface of 800mm x 370mm Fodpjx Sllpefx Af Eoga If you have any questions or require further information, please send us a message or give us a call.

Condition: refurbished (used), Year of construction: 1968, travel distance X-axis: 800 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, quill travel distance: 80 mm, total length: 1,000 mm, table width: 520 mm, table length: 1,000 mm, table load: 2,000 kg, overall weight: 2,500 kg, input voltage: 400 V, workpiece weight (max.): 2,000 kg, We are offering this refurbished DECKEL FP2LB milling machine, year of manufacture 1968. Manufacturer: DECKEL Model: FP2LB Year of manufacture: 1968 Condition: refurbished Machine type: milling machine Fgedpox Sdxzofx Af Eja If you have any questions or need further information, please feel free to send us a message or give us a call.

Condition: used, Year of construction: 1984, functionality: fully functional, Technical Data: Working Area X axis: 500 mm Y axis: 400 mm Z axis: 300 mm Working Spindle with rotary table Tool holder: ISO 40 Automatic feeds: 0.2 - 0.6 - 0.12 mm/min Spindle speeds: 20 - 4000 rpm, directly programmable Feed range: X / Y / Z = 1 - 3000 mm/min Fixed table: 700 x 350 mm, 5 T-slots Fixed table: max. load 250 kg Connection: 400 V Weight, approx.: 1900 kg Machine dimensions, approx.: 2400 x 1850 x 1850 mm Space requirement: 3200 x 4100 mm, height 1920 mm Fgsdpfxeyzy Azo Af Eea Equipment: - CNC control - Fixed table - Milling head swivels +/- 90° - Hydraulic clamping device - Coolant system - Emergency stop push button

Condition: used, Geldmacher MST / Deckel FP4M Milling Machine, Tool Milling Machine Weight: approx. 1,450 kg Year of manufacture: 2012 Installation dimensions: Reference value: approx. 2,500 × 2,700 × 2,100 mm (Length × Depth × Height) Travels: X-axis: approx. 500 mm Y-axis: approx. 400 mm Z-axis: approx. 400 mm Spindle taper / Tool holder: SK 40 Quill stroke: Vertical quill: approx. 90 mm travel; additionally, the vertical milling head is movable on the spindle head Spindle speed range: Approx. 50 - 2,500 rpm Feed rates: Feed: approx. 8 - 630 mm/min; Rapid traverse (max. feed rate): approx. 1,300 mm/min The machine is in very good condition. You are welcome to arrange an inspection. We can also organize cost-effective shipping for you! You will receive a proper invoice. For international customers, we can issue a net invoice (VAT-free) provided you supply a valid VAT ID number. Subject to prior sale. Visit our shop and take a look at our other offers as well. The stated company names and trademarks are the property of their respective owners and are used for identification and description purposes only. Fgsdpfx Aexcldkjf Esa Deviations from the technical data as well as mistakes in the article description may occur and are subject to change.

Condition: used, Year of construction: 1989, x-travel 300 mm y-travel 300 mm z-travel 400 mm CNC-control DIALOG 11 spindle taper ISO 40 spindle turning speed range 31 - 5.000 U/min table-size 620 x 390 mm table load 250 kg power capacity 5,5 kW feeds -stepless- 2 - 6.000 mm/min quill stroke 80 mm Fodpfxsx Ndbqj Af Eoga voltage 380 V total power requirement 11,0 kVA weight of the machine ca. 1,65 t dimensions of the machine ca. 1,85 x 1,90 x 1,80 m electric cabinet 1,35 x 0,70 x 1,70 m - Serial-No.: 2836-0175 - control: DIALOG 11 - electrical hand wheel - horizontal milling spindle - coolant equipment

Condition: good (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 2803-2693, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 6,300 rpm, spindle speed (min.): 32 rpm, quill stroke: 80 mm, quill travel distance: 80 mm, type of input current: three-phase, Equipment: documentation/manual, For sale is a precise and robust Friedrich Deckel FP3NC tool milling machine, year of manufacture 1985, equipped with a Dialog 4 CNC control system. The machine is German-made, renowned for its quality, and is suitable for tool and mould making as well as precise single-part and small-batch production. Technical Data (extract) Model: FP3NC Control: Deckel Dialog 4 Year: 1985 Serial Number: 12767 Main spindle power: 2.0 / 3.0 kW, pole-changeable three-phase brake motor Spindle speeds: 31.5 – 6300 rpm (2 ranges, manually switchable) Tool holder: SK 40 Quill Stroke (manual): 80 / 80 mm (horizontal/vertical) Travel paths: X-axis: 400 mm Y-axis: 400 mm Z-axis: 400 mm Feed rate: 2 – 3600 mm/min Fgsdpfxjxlghpe Af Eja Rapid traverse: 4000 mm/min Clamping slots in table: 4 slots, 14H7, 63 mm spacing Total weight: approx. 1800 kg Electrical connection: 380 V, 50/60 Hz, connected load 14.5 kVA Rated current: 22 A Control voltage: 24 V Equipment & Control - 4-axis contouring operation with dialog-guided input - 3D linear and circular interpolation, helical interpolation, polar coordinates - Extensive drilling and milling cycles, graphical cycle entry support - “Contour pocket” milling cycle for pocket machining (including irregular shapes and islands) - Subroutine functions, program memory up to 512 kByte - Tool offsets for up to 100 tools - Interfaces for cassette recorder, punch tape reader, floppy disk or Winchester drive (DNC-capable) Condition & Features - Machine is fully functional - High-precision, stable design – ideal for workshops, training or production - Operating manual and technical documentation available - Inspection by appointment possible

Condition: used, control Dialog 4 x-travel 400 mm y-travel 315 mm z-travel 400 mm spindle tunring speed 3.150 U/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Fsdpfx Asyyqp Ajf Esga Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: used, x-travel 400 mm y-travel 200 mm z-travel 400 mm turning speeds 40 - 2.000 U/min tool taper SK 40 In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Fgodpfx Ajyyqpvsf Esa Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: used, Year of construction: 1991, travel distance X-axis: 560 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 450 mm, quill stroke: 80 mm, overall weight: 2,590 kg, table load: 450 kg, input voltage: 380 V, See AMG machine card Control Dialog 11 Fgjdpfsyynrujx Af Eja

Condition: excellent (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 14672, Equipment: documentation/manual, The Deckel FP 1 machine is in a well-maintained and fully functional condition. The FP1 comes equipped with a dividing head and an original pneumatic Erowa clamping system (ITS 148), including a table. Comprehensive accessories, the original cabinet, and complete documentation are available. Upon request, a tilting table can be purchased additionally (price: €400). The Deckel machine has seen little use and is suitable for toolmaking, electrode/single-part production, or for training purposes. An inspection and test run are possible at any time by arrangement. If you are interested or have any questions, please feel free to contact me. Serious inquiries only, please. Fjdpfoyyydvjx Af Eega

Condition: good (used), Year of construction: 1989, Lid FP1 Active with 3-axis Heidenhain digital readout, rigid table, SK 40 M16 spindle holder. Good working condition, ready for demonstration under power by arrangement. Fgodpfx Afetp Nyfe Eea

Condition: good (used), Year of construction: 1981, Cover FP1 Active with 3 axes Heidenhain digital readout , 2 axes Active , rigid table , SK 40 S20x2 spindle holder. Good working condition, ready for demonstration under power by arrangement. Fjdpfx Afsuvgnqs Eoga

Condition: good (used), Year of construction: 1980, Cover FP1 Active with 3 axes Heidenhain digital readout , 2 axes Active , rigid table , SK 40 S20x2 spindle holder. Good working condition, ready for demonstration under power by arrangement. Fedeumcmqopfx Af Esga

Condition: good (used), Year of construction: 1985, Deckel FP1 Aktiv with 3-axis Heidenhain digital readout, 3 active axes, rigid table, SK 40 M16 spindle taper. Central lubrication, operating manuals included. Good operational condition, comes from a vocational training center. Can be demonstrated under power by arrangement. Fgsdpsxwunzjfx Af Eea

Condition: used, Year of construction: 1994, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, quill stroke: 80 mm, rapid traverse X-axis: 6 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 6 m/min, workpiece weight (max.): 6 kg, Tool holder: 40 Magazine positions: 20 Machine weight: 3,200 kg Dimensions: Fgodeymc T Espfx Af Eja Length: 2,740 mm Width: 2,660 mm Height: 2,140 mm Note: We offer flexible financing solutions for all machines as well as a professional relocation service. Disassembly, transport, and expert installation – all from one source. Billing according to individual terms and duration. Contact us for your personal offer.

Condition: used, Year of construction: 1989, functionality: fully functional, travel distance X-axis: 490 mm, travel distance Y-axis: 290 mm, travel distance Z-axis: 390 mm, Technical Data: Main Drive: Pole-reversible three-phase brake motor with right/left rotation ..... .. 2.0/4.0 kW 21 programmable spindle speeds ..... 25 ... 2500 rpm Tool holder in retractable quill . . . . . . NK40 Switch-operated tool clamp Feed Drive: Central DC motor with electromagnetic clutches ..... . ..... 1.4 kW (5Nm) Feed rate (programmable) ·· . . . . . . 5 ... 500 mm/min Feed correction ... ! . . ... . . . . . . from 20 to 120% Rapid traverse for X, Y, Z ..... ... . 1500 mm/min Travel range, motor/manual: X (longitudinal) . . . . . . . . . . . . . . . . . 490/500 mm Y (lateral) . . . . . . . . . . . . . . . . . . . . 290/300 mm Z (vertical) without bellows . . . . . . 390/400 mm with bellows . . . . . . . . . . . . . . . . . 345/355 mm + Vertical milling head on spindle carrier manually adjustable ..... ... ..... .. ... 200 mm Machine dimensions (min.) Length/Width/Height ..... . 1420x1290x1870 mm (see also foundation plan) Fgsdoymc Upspfx Af Eea Note: We offer flexible financing solutions for all machines as well as a professional relocation service. Dismantling, transport, and expert installation – all from a single source. Billing based on individual conditions and contract term. Contact us for your personal offer.

Condition: good (used), Year of construction: 1975, Deckel FP2 FPS retrofit tool milling machine with 3-axis Heidenhain digital readout. The machine is in good condition and comes from a training department. Fixed table, extended milling head, SK 40 spindle taper. Accessories include various collets and arbor holders. Good, operational condition. Can be demonstrated under power by arrangement. Fedoyhbn Repfx Af Eega

Year of construction: 1974, condition: like new (used), As good as new Deckel FP1 tool milling machine overhauled by FPS with 3-axis Heidenhain digital readout , Adjustable angle table , SK 40 spindle mount. Spindle brake , accessories : Counter holder , various collets. Very good working condition, can be demonstrated under power by arrangement. Fgodpfx Aoq A Icqsf Eja

Year of construction: 1976, condition: good (used), Deckel FP1 tool milling machine, 3-axis Heidenhain digital readout, machine was overhauled by FPS years ago. Rigid table, SK 40 spindle holder vertical, SK 40 horizontal, accessories: various collets and milling arbors, counter holder, good working condition, paint is no longer so nice, can be demonstrated under power by arrangement. Fgsdpfsrhzcusx Af Eja

Condition: good (used), Year of construction: 1973, Deckel FP2 tool milling machine with 2-axis Heidenhain digital readout, rigid table, SK 40 spindle holder. Long sliding milling head, accessories: various collets and milling arbors, counter holder. Good working condition, can be demonstrated under power by arrangement. Fgedpfx Asumclasf Eoa

Condition: good (used), Year of construction: 1975, Cover FP3L with.3-axis Heidenhain digital readout , rigid table , vertical milling head , SK 40 S20x2 spindle mount . Good working condition. Ready for demonstration under power by arrangement. Fedpfjuclbzjx Af Eega
