Used Deckel Milling Machine for sale (702)

Condition: used, x-travel 800 mm y-travel 400 mm z-travel 300 mm digital readout Heidenhain table surface area 1000 x 520 mm turning speed range 40 x 2000 U/min spindle taper SK 40 total power requirement 2,2 kW Ffedpfx Aeqpl Uujgmot weight of the machine ca. 2,2 t dimensions of the machine ca. 1700 x 1600 x 1800 m

Condition: good (used), Year of construction: 1990, 1 used well preserved CNC controlled tool milling machine as travelling column version with CNC path control GRUNDIG Dialog 11 table size 1600 x 675 mm tool holder SK / ISO 40 traverse X-axis, longitudinal 1200 mm Y-axis, cross 600 mm Z-axis, vertical 500 mm table load 2000 kg speed range 20 - 6300 rpm feed range, stepless 2 - 10.000 mm/min rapid traverse in all axes 10 m/min quill stroke 80 mm Drive power 100 % ED 7.5 kW 40 % ED 12 kW Machine dimensions L x W x H 3600 x 3000 x 2300 mm Fedpfehhuf Hox Agmoft Machine weight 6800 kg Control cabinet dimensions L x W x H 1700 x 900 x 1750 mm Switch cabinet weight 470 kg Accessories / Special features: - CNC tool milling machine suitable for tool, jig and fixture making, training as well as mold making. - CNC path control GRUNDIG Dialog 11 - Screen graphics, dialog guided input, 3 D linear interpolation, circular interpolation, helical interpolation, polar coordinate input, numerous drilling and milling cycles, cycle input graphically supported, milling cycles "contour pocket" for automatic free milling of irregular pockets also with islands, shift and rotation of the coordinate system - Electronic handwheel - Interface RS 232 - Swiveling vertical milling head +/- 90 - Hydraulic tool clamping, DIN 2080 with clamping groove, Ott system - Spindle sleeve adjustment 80 mm - Horizontal milling device - Full protection cabin - Ball screw spindles in all 3-axes - Coolant system - Bele

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, 3-Axis Active Linear Control Heidenhain TNC 123 Speed 40 - 2000 rpm, geometrically stepped direct drive with 16 gear stages for maximum torque/milling performance Feed 5 to 500 mm/min, continuously variable Rapid traverse 1.2 m/min Quill: Extendable quill, vertical 60 mm SK40 M16 drawbar thread X/Y/Z axes 300/160/340 mm Angle table 600 x 210 mm, max. load 200 kg Fedpfxjv Nqu Eo Agmeft

Condition: used, Universal tool milling machine DECKEL type FP 1 Machine no.: 52185 Year of manufacture: 1968 Travel X: 300 mm Y: 150 mm Z: 340 mm Table size: 600 x 250 mm Spindle taper: SK 40 - S20 x 2 Spindle speed: 40-2000 rpm, 16 steps Motor power: 1.0 and 1.4 kW, pole-switchable Mains connection: 380 Volt, 50 Hz Fedpfxedzqb So Agmsft - Feed on X and Z axes - Two motor speeds and 8 gearbox speeds - Quill stroke on vertical milling head: 60 mm - Fixed angle table - Coolant system in the machine base - Free-standing control cabinet - Counter support with counter bearing for horizontal milling SK 40 Required space (L x W x H): 1200 x 1100 x 1600 mm Weight: approx. 1000 kg Very good condition

Condition: good (used), functionality: fully functional, Travel X: 500 mm Travel Y: 400 mm Travel Z: 400 mm Spindle speed: 50 – 2500 rpm Drive power: 2.7 / 4.4 kW Tool holder: SK 40 with hydraulic clamp DIN 2080 Fodpfx Agew I A D Tsmjft Table type: Fixed table or swivelling table Table clamping surface: 650 x 380 mm Weight: 1600 kg Dimensions (including safety area): approx. 2500 x 2700 x 1950 mm Paint finish: RAL 6011 reseda green Digital readout: 3-axis HEIDENHAIN Accessories: Central lubrication, coolant tray, further accessories upon request

Condition: good (used), Year of construction: 1986, Milling machine Deckel FP3NC Manufacturer: Deckel Fjdpfxsw Ein Uj Agmsft Type: FP3NC Year of manufacture: 1986 Control: Dialog 4 Condition: used Travel paths: X 400 / Y 400 / Z 400 mm Quill stroke: 80 mm Speed: 40 rpm. Up to 3600 rpm. Pivoting milling head. Hydraulic tool holder vertical/horizontal SK40 Electronic handwheel. Control bar. For changing tools and starting programs. Documentation. Lamp. Coolant system. Full cabin. NC T400 rotary table Weight: approx. 2000 kg. Control cabinet weight: 300 kg

Year of construction: 1988, condition: used, x-travel 500 mm y-travel 400 mm z-travel 400 mm digital readout Heidenhain 3 Achsen spindle taper SK 40 spindle turning speed range 50 - 2500 U/min table-size 650 x 375 mm weight of the machine ca. 1,5 t Ffedjqpl Uqjpfx Agmjt dimensions ca. mm

Year of construction: 1968, condition: used, Cover milling machine FP1 with 3 axis digital display 380V Machine no. 37729 120-1900 rpm Travel X-axis:300 mm Travel Y-axis:150 mm Z-axis travel:340 mm Tool holder: MK 4 with tightening thread S 20 x 2 Fedpjpmrpxjfx Agmeft Milling head type:Vertical milling head Table type:Fixed table Table clamping surface:600 x 210 mm T-slot size:12 mm X-axis feed:290 mm Y-axis feed:150 mm Z-axis feed:330 mm Weight:700 kg Cover milling machine FP1 ID: M100000409

Condition: excellent (used), Year of construction: 1990, machine/vehicle number: 30216 & 30277, feed length X-axis: 1,000 mm, travel distance X-axis: 1,000 mm, Universal tool milling machine Make: MAHO Model: MH 1000 2x available! x-way 1000 mm tool holder SK 40 digital display . Head tiltable +/- . Table tilt and swivel +/- . Quill stroke . - 3-axis digital display - Universal table 1.250 x 740 mm (T-slot 16 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - 6 autom. quill feeds 0,02/0,03/0,05/0,08/0,12/0,20 mm/Umdr. - central lubrication, manually operated The machine can be inspected with pleasure. Immediately ready for use Ffsdpsp S Schsfx Agmst Free loading, transport no problem.

Condition: used, CNC 3+2 axis vertical machining center DECKEL MAHO type DMU 35 M CNC control SIEMENS 810D with ShopMill Manufacturer no. 11065353554 Year of manufacture 2001 Travel paths: X: 350 mm, Y: 240 mm, Z: 340 mm Table movements: C-axis: 360° Swivel range: +105° / -15° Universal swivel - rotary table: 400 x 290 mm, center hole 30H6 Table load: max. 100 kg Distance spindle nose - table: min. 145 mm to max. 485 mm Feed rate: 5,000 mm/min Rapid traverse (X / Y / Z): 5 m/min Input resolution: 0.01 mm Total power requirement: 15 kVA Speed range - main spindle: 20 - 6,300 min/-1 Drive power - main spindle: 6.3 / 10 kW (100% / 40% ED) Torque: max. 55 / 80 Nm Tool holder: SK 40 DIN 69871 Pull bolt: DIN 69872 or ISO 7388/2 Type B Interface: Serial RS232C, LAN (RJ45) Power connection: 400 volts, 50 Hz, 15 kVA Compressed air connection: 6 bar - CNC control Siemens Sinumerik 810D with ShopMill V05.03.22, NCU 03.03.34-CCU1E, MMC103 - 3-axis controlled (X, Y and Z axis) - Manual swivel rotary table, C axis = table rotation 360°, B-axis = swivel range +105°/ -15° - direct path measuring system for all 5 axes - electronic handwheel - spindle drive via servo motor with toothed belt and 2 gear stages - fully protected cabin with sliding door - swiveling control panel - coolant nozzles on the vertical head - chip tray with coolant container and cooling lubricant pump - work area lighting - documentation available space requirement L x W x H 2000 x 2000 x 2100 mm weight 1750 kg good condition Ffodovt D D Ujpfx Agmet

Condition: repair required (used), Year of construction: 1989, functionality: limited functionality, machine/vehicle number: 2821-0457, Equipment: documentation/manual, Machine was functional until we moved it. Now a control problem, control cannot be switched on is I think a small thing. Documentation is available! Ffsdou It A Topfx Agmjt Tool holder needs to be straightened, concentricity is no longer great.

Condition: reconditioned (used), Year of construction: 2008, Partially overhauled milling machine Axes: 5 Control: Siemens 840 Solutionline Spindle: SK 40 / 18,000 rpm Equipment: 3D Quick Set for kinematic measurement, Heidenhain 3D measuring probe Handwheel Ffedpfxjv Acgye Agmjt Internal cooling system 40 bar Chip tray (no chip conveyor)

Condition: like new (used), functionality: fully functional, Universal milling machine Deckel FP3 with new 3-axis FPS active digital display Heidenhain General overhaul by FPS 2015 Mint condition Technical data: >> Year of construction 1980 Machine no. 2201-5045 >> Rigid angle table >> Speed: 25 - 2500 rpm >> Infinitely variable feed in 3 axes >> rapid traverse in 3 axes >> Drive power .:2,0 / 4,0 KW >> Spindle brake >> Travel X/Y/Z: 500/300/400 mm >> Vertical milling head can be moved 200 mm on headstock >> Vertical quill and horizontal quill - SK40 extendable >> Tightening system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3 axes active digital display Heidenhain (latest version) >> Coolant device >> Central lubrication To the machine : Fjdpfxeu Dm E He Agmsft On offer is a Deckel FP3 universal milling machine in mint condition. The FP3 was overhauled by FPS in 2015 and has only been used a little since then. The machine has little crank play and all spindles can be moved easily. On this newer FP3 model, the feed is infinitely variable in three axes, and the machine also has a rapid traverse for each axis. A major advantage is the active 3-axis digital display. With this Heidenhain line control you can enter dimensions which the machine automatically approaches. An oil change has been carried out. Mechanically and electrically tested. The digital display from Heidenhain makes work easier and even more precise. Take the opportunity to inspect and try out this machine on site under power. The machine is available immediately.

Year of construction: 1981, condition: used, Make cover Type FP 4 Table: dimensions 1000 x 470 mm longitudinal movement X - axis 700 mm transversal movement Y - axis 400 mm vertical movement Z - axis 450 mm projection spindle 50 450 mm spindle mounting ISO 40 Number of spindle speeds 18 Fjdpfsihp U Dsx Agmoft Spindle speed range 31,5 1600 rpm Number of revolutions horizontal spindle 18 pcs. Speed range horizontal spindle 31,5 1600 rpm Weight machine 2000 kg feeds X Y Z axis 18 pcs 10 500 mm/min Accessories milling head with quill Table 1000 x 470 mm

Condition: excellent (used), Year of construction: 1986, Dear Sir or Madam, We are offering you very well-maintained milling machines of the Deckel FP4M type. The machine is at least technically tested in our workshop and is therefore fully functional. We look forward to your inquiry! Delivery time: on request Machine no. xxxx-xxxx Year of manufacture: xxxx Table design: rigid Speed: 50 - 2500 rpm Feed: 8 - 630 mm/min Rapid traverse: 1300mm/min Drive power: 3.7kW / 4.4kW Ffsdpfx Aelrw Tiegmet Rapid traverse: 1300mm/min Travel paths X/Y/Z: 500/400/400mm Tool holder: SK40 Tightening system: M16 Quill stroke vertical: 90mm Weight: approx. 1.6t Other equipment and accessories: on request Our service promise to you: - We are a certified master company in the field of mechanical engineering - All machines are thoroughly checked - All lubricants and any worn parts are replaced in advance - On request, we can overhaul the selected machine completely or in part - You are free to choose the paint color of the selected machine decide - If you wish, you can order additional accessories such as tools etc. directly - If you wish, we can install additional accessories such as safety devices etc. - We will be happy to take care of the shipping and/or delivery

Condition: used, Univ. tool milling machine DECKEL type FP 1 Machine No. 28317 Year of construction approx. 1960 travel X: 245 mm Y: 150 mm Z: 340 mm table size 600 x 210 mm spindle admission horizontal MK 4 - S20 x 2 Fedpfjiy Ekvox Agmsft spindle speed vertical 95-1900 rpm. 12 steps Spindle speed horizontal 60-1200 rpm. 12 steps motor power 0,8 and 1,1 kW pole-changing Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 6 gear steps - feed in X- and Z-axis - Coolant device with mechanical pump in machine base - Pinol shift at vertical milling head 60 mm - vertical milling head +/- 90° tiltable - Metal base made of angle iron with machine feet space requirement L x W x H 1100 x 900 x 1650 mm weight 650 kg good condition

Condition: used, Year of construction: 1976, x-travel 350 mm y-travel 150 mm z-travel 340 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 40 - 2000 U/min feeds 5 - 500 mm/min Ffsdpfx Ajwwwr Esgmet rapid traverse 1,2 m/min total power requirement 1,9 kW weight of the machine ca. 0,7 t - machine out of teaching shop - Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, various tool fixtures, various collets, original DECKEL tool cabinet

Condition: excellent (used), functionality: fully functional, Universal milling machine Deckel FP3L with 3-axis digital display K&C NEW, very good condition Fjdpfx Agsvn N Hdemeft Technical data: >> Year of manufacture approx. 1975 Machine no. 0924 >> Rigid angle table (clamping surface 1000 mm x 440 mm) >> Speed: 40 - 2000 rpm >> Feed and rapid traverse in 3 axes >> Feed from 10 to 500 mm/min >> Rapid traverse 1500 mm/min in all feed directions >> Drive power: 2.2 KW >> Travel X/Y/Z: 800/300/400 mm (travel Y can still be moved by 200) >> Equipment: Vertical & horizontal spindle >> Vertical quill and horizontal quill extendable SK40 >> Tightening system S20x2 >> Weight approx. 1900 kg Accessories and equipment: >> 3-axis digital display K&C Newly installed with manufacturer's guarantee and operating instructions. Display device: reference points, setting zero points, entering coordinates, mm/inch switching, absolute or incremental coordinates, circular functions, rows of holes, radius milling functions, etc. >> Mechanical central lubrication >> Operating instructions >> Hydraulic vice 160mm >> Walter rotary table 500mm About the machine: A Deckel FP3L universal milling machine in very good condition is offered. The vertical head can be moved by 200 mm to allow an even larger working area. A central pump ensures the lubrication of the various axes. The special feature of this type of machine is the basic structure; it is a machine with an inclined table bed. The movements are assigned to the work spindle and thus to the tool. The accuracy is therefore very high, since different workpiece weights have no influence on the axis movements. Mechanically and electrically tested. Take the opportunity to view and try out the machine on site with power on.

Condition: used, Universal milling machine directly from a clearance Milling machine DECKEL type FP 4 Machine no.: 1 Year of manufacture: 1978 Travel X: 700 mm, Y: 400 mm, Z: 450 mm Table clamping surface: 860 x 500 mm Fsdpfx Asv Srf Dogmsft Spindle taper: SK 40 - M16 Spindle speed: 31.5 - 1600 rpm, 18 steps Quill travel: horizontal and vertical Main spindle drive: 4 kW Power supply: 380 Volt, 50 Hz - 3-axis digital readout HEIDENHAIN - Universal swivel-tilt rotary table - Coolant system integrated in the machine base - Machine vice - Without tools Required space (L x W x H): 2100 x 1750 x 1900 mm Weight: approx. 3 tons.

Condition: used, Year of construction: 1978, x-travel 300 mm y-travel 160 mm z-travel 340 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 40 - 2000 U/min feeds 5 - 500 mm/min rapid traverse 1,2 m/min total power requirement 1,9 kW weight of the machine ca. 0,7 t - machine out of teaching shop - Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, counter bearing, various tool fixtures, various collets, original DECKEL tool cabinet Ffsdpfxswl N R No Agmjt

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain in special paint light gray !!! Technical data: >> Year of construction 1987 Machine no. 2203-2772 >> Rigid angle table >> Speed: 50 - 2500 rpm >> Feed: 8 - 630 mm/min >> Drive power: 3.7 / 4.4 KW >> Spindle brake >> rapid traverse 1300 mm/min >> Traverse paths X/Y/Z: 500/400/400 mm >> Vertical milling head can be moved 150 mm on headstock >> Vertical quill and horizontal quill - SK40 >> Vertical quill 90mm extendable >> Tightening system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3-axis digital display Heidenhain >> Coolant device >> Chip tray >> Central lubrication To the machine : We are offering a Deckel FP4M universal milling machine in very good condition. The machine has little crank play and all spindles can be moved easily and evenly. The milling machine runs smoothly even at maximum speeds. Rapid traverse in all axes. A reliable and user-friendly machine. An oil change has been carried out. Mechanically and electrically tested. The Heidenhain digital display makes work easier and even more precise. Take the opportunity to inspect and try out the machine under power on site. Ffodsvg Ewcjpfx Agmet

Condition: used, Universal tool milling machine DECKEL type FP 1 Machine No. 33064 Year of manufacture approx. 1960, overhauled in 2012 Travel X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: MK 4 - S20 x 2 Vertical spindle speed: 95–1900 rpm, 12 steps Horizontal spindle speed: 60–1200 rpm, 12 steps Ffedpfxjdzp T Ee Agmot Motor power: 1.1 and 1.4 kW Power supply: 380 Volt, 50 Hz - Feed on X and Y axes - Quill adjustment on the vertical milling head - Fixed angle table - Coolant system with mechanical pump in the machine base - Separate control cabinet with cable connector Space requirement L x W x H: 1100 x 900 x 1600 mm Weight: approx. 900 kg Good condition Machine was overhauled in 2012

Condition: used, Year of construction: 1985, x-travel 485 mm y-travel 385 mm z-travel 380 mm table surface area 800 x 460 mm spindle taper SK 40 control CONTOUR 1 spindle turning speed range 50 - 2500 U/min feeds 10 - 1000 mm/min rapid traverse 2 m/min table load capacity 600 kg quill stroke 80 mm total power requirement 7,5 kW weight of the machine ca. 2,0 t dimensions 2,4 x 1,7 x 1,98 m Ffodpfxetqqlle Agmjt Acc.: vertical head with hydr. tool clamping and quill retraction, solid table, coolant - movement of X/Y/Z also possible via handwheels -

Condition: excellent (used), Year of construction: 1986, functionality: fully functional, Universal milling machine Deckel FP4M with 3-axis digital display Heidenhain in special paint light gray !!! Technical data: >> Year of construction 1986 Machine no. 2203-2486 >> Rigid angle table >> Speed: 50 - 2500 rpm >> Feed: 8 - 630 mm/min >> Drive power: 3.7 / 4.4 KW >> Spindle brake >> rapid traverse 1300 mm/min >> Traverse paths X/Y/Z: 500/400/400 mm >> Vertical milling head can be moved 150 mm on headstock >> Vertical quill and horizontal quill - SK40 >> Vertical quill 90mm extendable >> Tightening system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3-axis digital display Heidenhain Ffjdpfx Agsvb T Ufjmst >> Coolant device >> Chip tray >> Central lubrication To the machine : We are offering a Deckel FP4M universal milling machine in very good condition. The machine has little crank play and all spindles can be moved easily and evenly. The milling machine runs smoothly even at maximum speeds. Rapid traverse in all axes. A reliable and user-friendly machine. An oil change has been carried out. Mechanically and electrically tested. The Heidenhain digital display makes work easier and even more precise. Take the opportunity to inspect and try out the machine under power on site.

Condition: used, Universal swivel, tilting, and rotary table DECKEL Universal add-on table for tool milling machines suitable for FP 2L, FP 3L, or FP 4L No. 2314 Year of manufacture: approx. 1975 Clamping surface: 1000 x 520 mm Ffodpfx Aed E A I Nsgmot - 6 clamping slots, 16 mm, spacing 90 mm - Clamping plate can be rotated horizontally to the right and left up to 45 degrees, with scale - Can be tilted to/from the machine +/- 15 degrees - Swivel range +/- 15 degrees - Swivel table, tilting table, angle table Permissible load max. 1000 kg Weight: 400 kg Good condition
