Used Droop Rein Milling Machine for sale (16)

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 06651, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,700 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 15,000 mm, total width: 7,500 mm, spindle speed (max.): 4,000 rpm, total height: 7,000 mm, table height: 1,100 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 3,300 mm, type of input current: three-phase, table load: 50,000 kg, rotational speed (max.): 4,000 rpm, distance table center to spindle nose: 2,110 mm, overall weight: 110,000 kg, spindle motor power: 50,000 W, control cabinet length: 7,000 mm, control cabinet height: 2,000 mm, control cabinet width: 600 mm, Equipment: rotational speed infinitely variable, MODEL: Portal Type AGE: 1992 S/N #: 06651 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 6800 mm Y-Axis Head Travel: 3700 mm Z-Axis Ram Stroke: 1500 mm, fixed crossrail Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 3300 mm Hsdpfx Acoyahv Se Nefh Distance Table To Ram Face: 2110 mm, vertical passage 2000 mm Table Size: 6000 x 2500 mm Spindle (Quill) Diameter: 250 mm Spindle Taper: ISO #50 Spindle Speeds: 0-4000 RPM Spindle Motor: 50 KW EQUIPPED WITH: FIDIA System C20 CNC Control, new in 2002 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Full Length Chip Conveyors both side Way Covers Rapid movements: Z-10.000 mm/min, X and Y-15.000 mm/min Table load: max 50.000 kg Weight of the machine: 110.000 kg Outside dimensions: 15.000 x 7.500 x 7050 mm Machine has been tested before dismantling and is fully operational, all mechanical components in excellent condition, electrics new in 2018. Machine available from stock. The price is now SPECIAL FROM STOCK. Once we will reassemble the machine, price will grow significantly. We can assist you to assemble and run up the machine.

Condition: used, Year of construction: 1988, total height: 5,200 mm, total width: 6,200 mm, total length: 6,500 mm, overall weight: 55,000 kg, spindle motor power: 30,000 W, Heavy CNC bed milling machine by Droop & Rein in solid cast design for machining large and heavy workpieces. The machine is equipped with a Heidenhain TNC 430 control and was overhauled in 2002.Equipped with a powerful 30 kW milling spindle, SK50 holder, and a swiveling milling head (±45°) for flexible machining operations. The robust construction ensures high stability and precision even in demanding machining tasks.The machine is powered on and can be inspected at any time. Hedpfoy S S Nbjx Ac Nefh Travel Z-axis: 1450 - mm Travel X-axis: 2400 - mm Tool holder type: SK 50 Speed range workpiece spindles: 80 - 3150 rpm Weight approx.: 55,000 kg Travel Y-axis: 2000 - mm Dimensions (LxWxH) approx.: 6500 x 6200 x 5200 mm Power working spindle max.: 30 kW Control: Heidenhain TNC 430 Year of construction: 1,988 Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: From foundation under power: Yes

Condition: excellent (used), X-axis: 6,000 mm Hfedpjzcpwvefx Ac Neh Y-axis: 1,500 mm Z-axis: 1,500 mm Max. workpiece size: 6,000 x 1,500 x 1,500 mm Spindle connection: SK50 Spindle speed: 4,000 rpm Control system: HEIDENHAIN TNC 426 Including documentation. Machine was overhauled in 2002, is in very good condition, and can be inspected while powered on.

Condition: used, Year of construction: 1986, x-travel 3300 mm y-travel 2200 mm z-travel 1300 mm w-axis 350 mm workpiece height 1700 mm milling spindle diameter 140 mm diameter of quill 230 mm milling head speed 40-2000 U/min transmission ratio 4 table surface area 4260x2000 mm T-slot - distance 175 mm T-slot - width 28 mm number of T-slots 11 workpiece weight 300000 kg milling spindle motor 30 kW Feed 5-3000 mm/min control Fidia weight of the machine ca. 80 t Machine has been overhauled The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are Hjdpfjyqt T Rsx Ac Nsfh possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2016, x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm Control iTNC 530 HSCI Heidenhain distance between columns max. 5.090 mm distance spindle center to table 1.825 mm type 175149A-0007 turning speed range - main spindle max. 19.800 min/-1 power capacity - main spindel 20 kW tool taper HSK-A63 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° type 178099-0005 turning speed range - main spindle max. 10.020 min/-1 power capacity - main spindel 20 kW tool taper HSK-A100 swivellable B: +115° / -115 ° rotatable C: +/- 200 ° table surface area 6.000 x 3.000 mm max. table load 50,0 t height over floor 100 mm number of T-slots 12 T-slot - width 28H12 mm T-slot - distance 250 mm number of toolpositions 62 (38+24) pos. number of toolpositions HSK A63: 37+1 pos. number of toolpositions HSK A100: 23+1 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 mm max. tool weight HSK A63: - kg max. tool diameter HSK A100: 80 mm max. tool length HSK A100: 450 mm max. tool weight HSK A100: - kg rapid traverse ( X / Y / Z ) 40.000 mm/min rapid traverse B/C: 4.320 °/min Hodpfx Ajx Avqboc Nefh feed speeds X/Y/Z: 30.000 mm/min Working speed B/C: 2.160 °/min Accelaration max. 3,2 m/s² x-axis 6.800 mm y-axis 4.000 mm z-axis 1.500 mm b-axis +115° / -115 ° c-axis +/- 200 ° total power requirement 180 kVA dimensions of the machine ca. 12,5 x 15,0 x 7,0 m 5-Axis-High-Speed-Gantry-Big-Machining-Center DROOP & REIN - FOGS 40 60 C - Fork head

Condition: good (used), Year of construction: 1999, x-travel 2400 mm y-travel 2850 mm z-travel 1000 mm Control FIDIA C20 table dimension - longitudinal 2200 mm table dimension - cross 1800 mm table load 12 t workpiece tool changer 30-fach Hodpfx Asvwgphsc Nofh tool taper ISI SK-50 spindle turning speed range 5000 U/min power capacity - milling spindle 30 kW

Condition: used, Year of construction: 2007, x-axis 10.100 (2x 5.000) mm y-axis 3.000 mm z-axis 1.500 mm Control Sinumerik 840 D Siemens distance between columns max. 3.000 mm passage max. 1.950 mm distance spindle center to table max. 1.800 mm distance spindle nose and table 1.350 / 1.500 mm type P 8005020/00-4 turning speed range - main spindle max. 18.000 min/-1 power capacity - main spindel 20 kW max. Torque 48 Nm tool taper HSK-A63 DIN 69063 Spindle Extension 450 mm swivellable B: +110° / -10 ° rotatable C: +/- 200 ° type P 8002320/00-4 Hedpfx Acjvy Ihds Nsfh turning speed range - main spindle 20 - 5.000 min/-1 power capacity - main spindel 40 kW max. Torque 1.100 Nm tool taper HSK-A100 DIN 69063 Spindle Extension 300 mm swivellable B: +110° / -10 ° rotatable C: +/- 200 ° table surface area 4.000 x 2.200 (2x) mm max. table load 12 / 20 t height over floor 700 mm number of T-slots 11 + 19 T-slot - width 28H7 mm T-slot - distance 200 mm number of toolpositions 327 pos. number of toolpositions HSK A63: 156 pos. number of toolpositions HSK A100: 171 pos. max. tool diameter HSK A63: 52 mm max. tool length HSK A63: 250 / 500 mm max. tool weight HSK A63: 5,0 kg max. tool diameter HSK A100: 315 mm max. tool length HSK A100: 500 / 800 mm max. tool weight HSK A100: 40,0 kg feed speeds X: max. 30.000 mm/min feed speeds Y/Z: max. 40.000 mm/min feed speeds B: 3.600 °/min feed speeds C: 2.160 °/min Accelaration X: max. 1,5 m/s² Accelaration Y/Z: max. 3,2 m/s² x-axis 10.100 (2x 5.000) mm y-axis 3.000 mm z-axis 1.500 mm b-axis +110° / -10 ° c-axis +/- 200 ° total power requirement 150 kVA dimensions of the machine ca. 25,0 x 12,0 x 7,0 m 5-Axis Gantry-Big-Machining-Center DROOP + REIN - TFS 22 40 DT D40 P - two Milling-Heads - ca. 4.000 Power On Hours - X-Achse 10.000mm (coupled) / 2x 5.000mm (single-table) - 3 axes simultaneously (X, Y, Z) - 2 positioning axes (B, C) - tools upon request

Condition: used, Year of construction: 1971, x-travel 2000 mm y-travel 1000 mm z-travel 1000 mm Control Heidenhain type TNC 430 spindle turning speed range 15-1450 U/min Table area 2300x1200 mm Spindle 200 mm spindle stroke 200 mm Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Hfjdpfxeyt R Dxe Ac Noh If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1991, x-travel 5300 mm y-travel 2500 mm z-travel 1200 mm Table load 60000 kg column daylight 2700 mm workpiece height max. 1700 mm Table dimensions 5000x2250 mm control Heidenhain Hodpfxeyq Swho Ac Nsfh type 430 Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, spindle diameter 160 mm x-travel 4000 mm y-travel 2200 mm Hedpfx Acsyq Swbo Njfh z-travel 1500 mm 270 mm spindle turning speed range 20-2000 U/min Control Heidenhain type TNC530i table surface area 3000x1600 mm table load 40 t spindle taper ISO 50 spindle motor 50 kW T-slot - width 28 mm number of T-slots 9 Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1986, x-travel 2400 mm y-travel 2000 mm z-travel 1450 mm table surface area 5000 x 1400 mm spindle taper SK 50 Control Fidia C1 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Hjdpfx Aceyqwb So Nefh We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1986, x-travel 5300 mm y-travel 3300 mm z-travel 1300 mm Table load 50000 kg column daylight 2600 mm workpiece height max. 1700 mm Table dimensions 5000x2000 mm control Heidenhain type ITNC530 Maschine wurde überholt machine is retofit The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are Hfsdjyqtm Repfx Ac Neh possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Table unit from a DROOP & REIN portal milling machine Clamping plate with T-slots made of cast steel gray cast iron Table unit with clamping plate and very solid guideway Table clamping surface 5500 x 2000 mm Travel of the table clamping plate approx. 3100 mm Table height 1050 mm Table load: max. 20 tons Ball screw: Ø 100 mm Thread pitch: 20 mm (single-start) - Processing table guided very stably on the bed - Metal telescopic guideway cover - comes from a DROOP & REIN portal milling machine Hfedpfxjthuzpj Ac Nsh - Longitudinal table movement via ball screw and SIEMENS servo motor - Clamping surface with 11 T-slots 28 mm - Drive via SIEMENS 1FT6134-6AB71-1AG2 servo motor with IC200448S/R encoder (RN 000 B25) Total length 9500 mm Width 2000 mm Overall height 1050 mm dead weight 28 ton. good condition

Condition: ready for operation (used), DROOP & REIN SZ 100 / Keyway Broaching Machine for Lubrication Grooves - Maximum machinable diameter: 140 mm - Spindle bore: 40 mm - Groove length per stroke: 100 mm - Distance between chuck and tailstock center: 350 mm - 3 working speeds - Electric chuck guard - Good / fully operational condition Dimensions: LxWxH 0.9x0.6x1.5 meters / Weight: 300 kg Hfedpjyl R Etjfx Ac Nsh Subject to errors and omissions

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 2,400 mm, travel distance Y-axis: 2,850 mm, travel distance Z-axis: 1,000 mm, feed length X-axis: 20,000 mm, feed length Y-axis: 30,000 mm, feed length Z-axis: 20,000 mm, Droop & Rein Modimill built in 2001 Fidia C20 Hsdpfovk Ubxex Ac Nsfh

Condition: used, Vertical Milling Machine Droop & Rein type FS130 Travel X: 2000 mm Travel Y: 1000 mm Travel Z: 1000 mm Spindle SA 50 Sensitive spindle exit: 200 mm Hfedsxxl Hdopfx Ac Neh Rotation: from 31,5 to 1600 RPM Table size: 2400 x 1070 mm Throat depth: 950 mm Tilt head Spindle motor: 22 kW Scale HEIDENHAIN 3 axes Year of construction: 1976 New electrical panel in 2006 Voltage : 380 V Width : 3500 mm Depth : 4700 mm Total height : 4500 mm Weight : 26 T
