Used Ima Edgebander for sale (139)

Condition: used, Year of construction: 2009, - Edge material thickness: 0.3 - 3.0 mm - Paper, PVC, and ABS edge bands: 0.3 - 3.0 mm - Veneer: 0.5 mm - 3.0 mm - Wood strips: 0.8 - 20 mm - Edge height: 14 mm - 65 mm Single-sided edge banding machine Manufacturer: IMA Type: Novimat Contour/I/G80/790/L20 Year of manufacture: 2009 Technical data - Electronically controlled feed speed: 6-30 m/min - Edge material thickness: 0.3 - 3.0 mm - Paper, PVC, and ABS edge bands: 0.3 - 3.0 mm - Veneer: 0.5 mm - 3.0 mm - Wood strips: 0.8 - 20 mm - Edge height: 14 mm - 65 mm - Maximum edge overhang from above: up to 8 mm edge thickness - 5 mm, over 8 mm - 2 mm Workpiece size: - Minimum workpiece length in the feed direction: 150 mm - Minimum workpiece width: 25 mm, thickness: 65 mm - Minimum workpiece thickness: 8 mm (without profile trimming blades) or 12 mm with profile trimming blades Lredpozuyprsfx Apnsu - Maximum workpiece thickness: without corner copying, max. 60 mm (max. 40 mm with corner copying) - Smallest element: 150 mm x 150 mm or 65 mm x 300 mm Note: *65 mm with a maximum piece thickness of 25 mm The edge banding machine is equipped with: - Hand-adjustable guide rail for inserting workpieces - Trimming units 08.376, 2 motors, each with 4.5 kW, spindle speed 9000 rpm, 150 Hz - Heating unit for warming the workpieces - Gluing unit with drive 283.1513, featuring a tightly sealed oil pan, drive arranged with glue pot content of 0.8 l and glue application height of 60 mm, with a pneumatic quick-clamping system for hot melt and PU adhesives, magazine for edge banding rollers and strips, edge banding roller diameter 800 mm - Glue pellet preheating unit with automatic feeding of glue pellets from a 30 kg container. - Automatic preheating unit for PU cartridges with a weight of approx. 2.5 kg and a capacity of 8-10 kg/h - Trimming unit 08.42/30/B, pneumatic adjustment of the saw blades from 0 - 25°, 2 motors 660 W, 200 Hz with frequency inverter and braking function - Pre-milling unit 08.055, swiveling up to max. 30° - Multi-chamfering unit 08.342, 2 motors, 660 W, 400 V, 200 Hz, 12000 1/min - Cleaning agent dispenser - Profile trimming blades 08.519 - Surface trimming blade 08.521 for removing excess glue from glue joints - Buffing unit 08.617-2, 2 motors with 180 kW, 50 Hz, 1400 rpm - Groove/milling unit with one motor Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2009, Edge banding machine Manufacturer: IMA Type: Novimat/I/G80/650/R3 Year of manufacture: 2009 Technical data - Workpiece overhang from the chain conveyor: 38 mm - Feed width: min. 65 mm (with max. workpiece thickness of 25 mm) - Workpiece length in feed direction: 150 mm - Overall height (top edge of chain conveyor): 960 mm - Feed speed: approx. 6 - 30 m/min, electrically adjustable - Machine control system ICOS open compact Workpiece - Workpiece length: min. 150 mm - Workpiece width: min. 65 mm - Workpiece thickness: 8 - 40 mm (with edge trimming function) / 60 mm (without edge trimming function) - Smallest workpiece: 150 x 150 mm or 65 x 300 mm - Edge material: paper, plastic and veneer - Height: 14 - 65 mm - Roller material thickness: 0.3 - 3.0 mm (veneer edges limited to max. 1.0 mm) - Max. upper edge overhang: 5 mm Units Infeed area - Release agent applicator mounted at the top and bottom, not adjustable Edge trimming - 2 motors 4.5 kW, 150 Hz, 9000 rpm - incl. frequency inverter with braking function - Motor 1 counter-rotating - Motor 2 co-rotating Gluing unit VTG 3-6 - with one preheating nozzle 300 mm for preheating the workpiece edge - 6-position edge magazine for roller material 0.3 - 3 mm thick. - 1 driven main pressure roller and 4 pressure rollers, with scraper, pneumatically adjustable Glue application - with pneumatic quick-lock system - Chem-Coat coating - electronic temperature control - Volume 0.8 l Pre-melting tank approx. 1 l - Heating power 3 x 400 W - with EVA glue, approx. 7.0 kg/h - with filler-free glue, approx. 5.0 kg/h Cutting unit - 2 motors 660 W, 200 Hz - incl. frequency inverter with braking function - pneumatic pivoting 0+25 for straight and bevel cutting Flush trimming - 2 motors each 1000 W, 400 V, 200 Hz, 12000 rpm - with HSK 25 shank - incl. frequency inverter with braking function Multi-profile trimming unit - 2 motors each 660 W, 400 V, 200 Hz, 12000 rpm - with HSK 25 shank - incl. frequency inverter with braking function - for trimming 4 profiles - with stepper motor axes for horizontal and vertical positioning Contour trimming unit KFA x30 - 1 motor 500 W, 400 V, 400 Hz, 18000 rpm - Program-controlled conversion for up to 4 profiles - incl. fine positioning for different edge thicknesses Multi-profile scraping blade - Stepper motor axes for horizontal and vertical positioning - Scanning from above and below (max. 4 profiles) - Scanning from the side via pneumatic pressure Spray nozzles at the top and bottom for applying cleaning agents - fixed, not adjustable Surface scraping blade - with height sensing skid - electronically controlled horizontal positioning Buffing unit - 2 lower and 2 upper motors, 180 W, 50 Hz, 1400 rpm - 1st motor pair with cloth-sisal discs 50x160x19 mm - 2nd motor pair with polishing discs 50x160x19 mm - The motors operate in the same direction and are both tilted and pivoted in the feed direction. - Each motor can be individually adjusted vertically 2x NC-controlled grooving - 2 milling motors each 4.5 kW, 150 Hz, 9000 rpm - incl. frequency inverter with braking function Lsdpfx Apozuyi Eenjru - one manual 90-degree pivoting device from 180 -270 with co- and counter-rotating function - Horizontal, stepless adjustment with AC servo motor for grooving unit Workpiece return Note: The technical data and descriptions are copies of the order confirmation at the time. The information is for informational purposes only and is non-binding.

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Edges thickness in stips / lippings (min/max) mm 0.8 / 20 Panels thickness (min/max) mm 8 / 60 Numerical Control ICOS Open Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt Safety and sound-proof enclosures/cabins OPTIONAL: Panels in-feed system 63.152 (mm 500 x 500) Ledeyxl Siopfx Apnoru In-feed fence, adjustable by N.C. Pre-milling Unit (vertical joint trimmers) 08.379 (2 x Kw 4,0) adjustable by N.C. Glueing Unit (EVA Glue) 283.1513 Band Pressure zone + Edge coils supporting unit (No. 1+2 reels) Snipping (end-cutting) unit 08.42/30/B (Kw 0,66 x 2) speed 30 m/min (0°-25°) Fine Trimming unit 08.055 (Kw 1,85 x 2) 0°-25° Multi Function Unit (Profile contour Trimming unit) SKF-L (2 x Kw 0,18) + (2 x Kw 0,4) Profile edge scraping unit 08.519 Glue scraping unit 08.521 Spraying Unit (for polishing liquid) Buffing unit 08.617-2 (Kw 0,18 x 2)

Condition: ready for operation (used), Year of construction: 1997, A 1.5-times linked IMA edge processing line with automatic Venjakob workpiece transfer is offered. Max. working width: 2500mm, transfer angle: 90°, distance between the workpiece edges: 6000mm. Control system: Siemens S5. Including peripheral equipment and conveying system. Required installation space: approx. 250-300m², overall dimensions X/Y: approx. 19000mm/13600mm. IMA. Operator PC: renewed in 2018. Inspection possible by appointment. Lredpfx Apjzh Nh Rjnsu

Condition: excellent (used), Double side - Independent Machine (or 1st and/or 2nd in a line) Edges (tape) thickness in rolls (min/max) mm 0,3 / 3 Edges thickness in stips / lippings (min/max) max mm 1,0 Panels thickness (min/max) mm 8 / 45 (60) Working width (min/max) mm 236 (266) / 3300 Numerical Control / Software ICOS Open (Windows base) Adjustable feeding speed (m/min ) 10 - 50 Safety and sound-proof enclosures/cabins SIZING PART (for each side): Anti-chipping Milling Unit 75.186 (1 x Kw 4,4) Hogging Units (2 x Kw 6,6) Free space EDGE-BANDING PART (for each side): Lamps to heat the workpieces side Glueing Unit (Hot Melt glue) 04.1570 - Pressure zone Edge coils supporting unit (No. of reels) 2 Snipping (end-cutting) unit 08.42 (2 x Kw 0,66) 30 m/min (0°-25°) Rough Trimming unit 08.0555 (1 x Kw 0,66) Multi Function Unit (Profile contour Trimming unit) MFA 08.342 (2 x Kw 0,66) SERVO - 20m/min Profile Scraping unit 08.519 Glue scraping unit 08.50 Buffing unit 08.617-2 (2 x Kw 0,18) Lredpfx Aozz R Rgopneu Milling grooving unit: 75.30 (2 x Kw 4,4)

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Edges thickness in stips / lippings (min/max) mm 0.8 / 20 Panels thickness (min/max) mm 8 / 60 Numerical Control ICOS Open Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt Safety and sound-proof enclosures/cabins OPTIONAL: Panels in-feed system 63.152 (mm 500 x 500) In-feed fence, adjustable by N.C. Pre-milling Unit (vertical joint trimmers) 08.379 (2 x Kw 4,0) adjustable by N.C. Glueing Unit (EVA Glue) 283.1513 Band Pressure zone + Edge coils supporting unit (No. 1+2 reels) Snipping (end-cutting) unit 08.42/30/B (Kw 0,66 x 2) speed 30 m/min (0°-25°) Fine Trimming unit 08.055 (Kw 1,85 x 2) 0°-25° Multi Function Unit (Profile contour Trimming unit) SKF-L (2 x Kw 0,18) + (2 x Kw 0,4) Profile edge scraping unit 08.519 Glue scraping unit 08.521 Lrodpfx Asyk Tkvjpnsu Spraying Unit (for polishing liquid) Buffing unit 08.617-2 (Kw 0,18 x 2)

Condition: excellent (used), Double-side Sizing-Milling & Edge Banding - First (1st) machine in a line Edges (tape) thickness in rolls (min/max) mm 0,3 / 3 Panels thickness (min/max) mm 8 / 45 (60) Working width (min/max) mm 250 / 1300 Ljdpsxggthjfx Apnoru Numerical Control / Software ICOS Open (Windows base) Adjustable feeding speed (m/min ) 10 - 50 (Master & Slave) Safety and sound-proof enclosures/cabins SIZING PART (for each side): Hogging Units (2 x Kw 6,6) Max 35 m/min Milling unit (joint Trimmer) 75.186 (1 x Kw 4,4) EDGE-BANDING PART (for each side): Glueing Unit (PUR. Glue + Quick Melt system + EVA Glue) VTG 3-24 + 283.201 + 283.19 + 283.203 Pressure zone Edge coils supporting unit (No. 24 reels) Rough/Fine Trimming unit 08.055 (2 x Kw 1) 0°-30° (30 m/min) Rough/Fine Trimming unit 08.055 (2 x Kw 1) 0°-30° (30 m/min) Profile Scraping unit 08.515 Glue scraping unit 08.521 Buffing unit 08.617-2 (2 x Kw 0,18) No. 3 Grooving units 08.190 (2 x Left-hand + 1 x Right-hand) (Kw 4,5 x 3) swivelling 90°/180°/270°

Condition: used, machine/vehicle number: 006089, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Lodpfx Aoy Nknwepnoru Max feed speed: 30 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr

Year of construction: 2007, condition: excellent (used), Complex of portal center with two work areas and nesting with 1 work table: - two working spindles with a magazine for 18 sockets; L and R - industrial edging aggregates shop for 12 edges - EVA, PUR - station; - additional polyurethane station. The complex is designed for complete processing of details from chipboard and veneered MDF, etc. - cutting of details with nesting technology and complete processing of a portal center. The price does not include: - transport - dismantling - installation. Fully serviced by German IMA Schelling team in 2022. The edging unit is hardly used. Ledjizi Ttjpfx Apnoru

Condition: excellent (used), Double-side Sizing-Milling & Edge Banding - First (1st) machine in a line Edges (tape) thickness in rolls (min/max) mm 0,3 / 3 Panels thickness (min/max) mm 8 / 45 (60) Working width (min/max) mm 236 / 1300 Numerical Control / Software ICOS Open (Windows base) Adjustable feeding speed (m/min ) 10 - 50 Safety and sound-proof enclosures/cabins Ljdpfsunrwnex Apnjru SIZING PART (for each side): Hogging Units 75.30 (2 x Kw 6,6) Free space EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) 04.1570 + 283.201 Pressure zone Edge coils supporting unit (No. of reels) 6 Rough Trimming unit 08.055 (2 x Kw 1) 0°-30° Fine Trimming unit 08.055 (2 x Kw 0,66) 0°-30° Profile Scraping unit 08.515 Free space Buffing unit 08.617-2 (2 x Kw 0,18) Nr. 2 Milling grooving units RIGHT: 75.30 (2 x Kw 4,4) 90°-180°

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Edges thickness in stips / lippings (max) mm 1 Panels thickness (min/max) mm 8 - 60 Numerical Control ICOS Open Compact Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt Spraying unit (Anti-sticking liquid) In-feed fence, adjustable by N.C. Pre-milling Unit (vertical joint trimmers) by N.C. 08.378 (2 x Kw 4,5) Lamps to heat the workpieces side Glueing Unit (Hot Melt + Quick Melt Unit) 04.1570 Ledpfx Apsm Udfwsnjru Spraying Unit (for anti-release liquid) Band Pressure zone + Edge coils supporting unit (N. 16 reels) Snipping (end-cutting) unit 08.42/30/B (2 x Kw 0,66 - Pneu 0° - 25°) 30 m/min Fine Trimming unit (Multi-profile, by N.C.) 08.0587 (2 x Kw 1) + Spraying Unit (for sliding liquid) Multi-Profile Copying unit by N.C (fine and contour trimming) KFA 30 (08.355 - 1 x Kw 0,5) 30 m/min Corner Rounding unit (Contour Trimming) 08.604 with 4 brushes (4 x Kw 0,25) Profile edge scraping unit (Multi-profile, by N.C.) 08.516 Glue scraping unit 08.521 Spraying Unit (for polishing liquid) + Buffing unit 08.617-4 (4 x Kw 0,18) Smoothing unit with spheres 08.53

Condition: used, Year of construction: 1994, Storage location: Nattheim Lrjdpewmm Nrjfx Apnsu

Condition: ready for operation (used), Year of construction: 2005, number of axes: 4, total width: 3,830 mm, overall weight: 6,000 kg, spindle motor power: 7,500 W, product length (max.): 5,750 mm, spindle speed (max.): 18,000 rpm, This 4-axis IMA BIMA 300 CNC Wood Machining Centre was manufactured in 2005. It features an impressive X-axis machining range of 4300 mm and a Y-axis machining range of 1400 mm. The spindle power is 7.5 kW with a maximum speed of 18,000 rpm. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 300 machine we have for sale. Contact us for further details. Working area • X-axis machining range: 4300 mm (4600 mm per manual; to be confirmed) • Y-axis machining range with main spindle and Ø20 mm tool: 1400 mm • Y-axis machining range with drilling unit (all vertical spindles): 1100 mm • Maximum workpiece height above vacuum cup surface: 125 mm • Maximum workpiece thickness: Depending on equipment and application • Working height: approx. 950 mm • Two-zone working area without pendulum machining: 2 × 2050 mm; central clearance: 200 mm • Two-zone working area with pendulum machining: 2 × 1750 mm; central clearance: 800 mmMain spindle • Tool interface: HSK-F63 • Taper diameter: 38 mm • Automatic tool clamping (clamping force: 11,000 N; unclamping force: 20,400 N) • Maximum tool weight: 6 kg • Rotation direction: Programmable CW/CCW • Drive: Three-phase motor with frequency inverter • Lubrication: Factory-lubricated • Cooling: Air-cooled • Integrated CNC-controlled rotary axis for aggregate positioning through 360°, with torque support and pneumatic connectionAxis speeds • Rapid traverse X/Y: 60 m/min • Rapid traverse Z: 30 m/minVacuum, extraction and compressed air • Required compressed air pressure: 7 bar • Extraction connection diameter: 250 mm • Required extraction air velocity: 28 m/s • Required extraction airflow: 4,950 m³/h • Vacuum pump capacity: 90 m³/h Additional equipment Ljdpfx Apo Ad Hhdonoru • 90° angle drilling aggregate • 3x HSK tool holders

Condition: excellent (used), Double side - Independent Machine (or 1st and/or 2nd in a line) Edges (tape) thickness in rolls (min/max) mm 0,3 / 3 + in stips / lippings (max mm 1) Panels thickness (min/max) mm 8 / 45 (60) Working width (min/max) mm 236 (266) / 3300 Numerical Control / Software ICOS Open (Windows base) Adjustable feeding speed (m/min ) 10 - 50 (Master & Slave) Safety and sound-proof enclosures/cabins SIZING PART (for each side): Anti-chipping Milling Unit 75.186 (1 x Kw 4,4) Hogging Units (2 x Kw 6,6) Max 35 m/min Milling unit (Joint Trimmer) 75.186 (1 x Kw 4,4) EDGE-BANDING PART (for each side): Glueing Unit (P.U.R. Glue + Quick Melt system) VTG 3-24 + 283.203 Pressure zone + Edge coils supporting unit (No. 24 reels) Snipping (end-cutting) unit 08.42 / 30 / B (2 x Kw 0,66) 30 m/min (0°-25°) Rough/Fine Trimming unit 08.055 (2 x Kw 1) 0°-30° (30 m/min) Multi Function Unit (Profile contour Trimming unit) MFA 08.342 (2 x Kw 0,66) SERVO - 20m/min OPTIONAL: KFA 30 Lredpfx Apsxggzleneu Profile Scraping unit 08.519 Glue scraping unit 08.521 Buffing unit 08.604 (Kw 0,25 x 4) No. 2 Grooving units 08.190 (1 x Left-hand + 1 x Right-hand) (Kw 4,5 x 2) swivelling 90°/180°/270°

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, This 3-axis IMA BIMA 410 CNC Wood Machining Centre was manufactured in 2000. It features a working area of 3000 mm in X and 1200 mm in Y, with a maximum clamping height of 100 mm. The machine is equipped with an automatic central lubrication system and AC servo motors for precise operation. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 410 machine we have for sale. Contact us for further details. • Working area X: 3000 mm • Working area Y: 1200 mm • Max. clamping height Z1: 100 mm • Max. workpiece thickness Z2: depending on equipment/application • Table height: approx. 1000 mm • Pendulum operation X: 2 × 1400 mm • Free space center X: 200 mm • Pendulum operation alternative X: 2 × 900 mm • Free space center alternative X: 1200 mm • Machine weight: approx. 6000 kg • Guide system: precision linear guides hardened approx. 62 HRC Lrsdpfjzug Afsx Apneu • Central lubrication: automatic for all main axes and ball screw • Drive system: AC servo motors with encoder • X/Y drive: rack and pinion • Z drive: ball screw • Feed rate: 40 m/min • Rapid traverse X/Y: 80 m/min • Rapid traverse Z: 25 m/min • Acceleration: 3 m/s² • Extraction connection main spindle: 300 mm • Extraction connection drilling spindles: 120 mm • Air speed: approx. 28 m/s • Air volume: approx. 7080 m³/h • Vacuum pump capacity: 100 m³/h • Compressed air connection: 1/2" • Air pressure: 6 bar • Control voltage: 24 V DC • Connected load: approx. 24 kVA • Power supply: 3/N/PE 400/230 V 50 Hz • Frequency converter: 0–480 Hz • Ambient temperature: +15 to +35 °C • Control system: IMATRONIC NT 231 • Interpolation: linear all axes, circular 2.5D • Resolution: 0.001 mm • Spindle: HSK F63 • Tool clamping force: 11000 N • Max tool weight: 6 kg • Speed range: 1500–18000 rpm • Spindle power: 7.5 kW • Cooling: water cooled • CNC axis: 360° rotating • Tool magazine type: plate changer • Tool positions: 18 • Max tool length: 150 mm • Max tool diameter: 100 mm (150 mm with free сосед positions) • Max load: 60 kg • Saw unit motor: 1.5 kW • Saw speed: 5600 rpm • Saw blade diameter: max. 150 mm • Drilling unit: 14 spindles • Spindle stroke: 70 mm • Drive: 2.2 kW • Speed: 3150 rpm • Drill diameter max: 20 mm • Adapter head spindles: 4 • Speed max: 6000 rpm • Drill diameter max: 12 mm Table equipment: • 6 adjustable support arms • 12 suction cups 114 × 159 × 100 mm • 6 suction cups 125 × 75 × 100 mm • Vacuum system: 2-circuit clamping system • Electrical cabinet size: 2000 × 1800 × 600 mm DEFECT: • The main spindle no longer releases the interchangeable drill head

Condition: used, Year of construction: 1996, - Double-sided IMA COMBIMA for longitudinal machining - Swiveling device - Double-sided IMA COMBIMA for transverse machining 1 used edge processing line IMA COMBIMA / K/ II/ R75 / 1075 / V / R3 Year of manufacture: 1996 Consisting of: - Double-sided IMA COMBIMA for longitudinal machining: Double edging unit 2 x milling units Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Cutting unit Flush trimming 2 x fine milling units Profile trimming blade Surface trimming blade Buffing unit Smoothing unit - Swiveling device from longitudinal to transverse - Double-sided IMA COMBIMA for transverse machining Protective milling Double edging Grooving milling unit Ljdpfx Apozuypxoneru Gluing unit with granular pre-melting device 6-position roller magazine for edge material 1 x main pressure roller and 4 x follow-up pressure rollers Capping at the top pressure (retrofit to current model) Flush trimming Fine milling 2 x MFA milling units Grooving milling unit Profile trimming blade Surface trimming blade Copy buffing (4 motors) Buffing (2 motors) Smoothing unit Note: The technical data and descriptions are a transcript of the order confirmation at the time. Data is for informational purposes only and is not binding.

Condition: good (used), Year of construction: 2008, machine/vehicle number: 50028, functionality: fully functional, operating hours: 16,000 h, The machine has the following functions: 1. Pre-milling cutters. 2. All lamps are in working order. 3. One container. 4. It has saws that cut forward and backward. 5. It has milling cutters at the top and bottom. 6. It has a rounding cutter for shaping edges. 7. It has a cycling function for processing solid wood. 8. It has a cleaning unit. 9. It has two bottles for cleaning. Lrodpfx Aoz H I H Hepnsu

Condition: used, machine/vehicle number: 006054, X axis working area: 5300 mm Y axis working area: 1300 mm Working Table: Pod and Rail Main Electrospindle power: 9 KW Lrjdpjwcx T Uefx Apnju Number of controlled axes: 5 axes Total number of drilling spindles: 32 Total number of tool changer positions: 8

Condition: excellent (used), C.N.C. WORKING CENTER with 4 axes (X-Y-Z-C) for routering, boring, cutting and edge banding Numerical Control ICOS CNC (software IMAWOP) Max useful working area (without edge banding process) mm 6100 x 2000 x 125 Max useful working area (edge banding process) mm 3100 x 1925 x 100 (panel thickness) No. 10 movable rails (supports) 6 x length mm 1400, + 4 x length mm 1450 LED displaying both the axe X and axe Y position Vacuum cups (with No. 2 vacuum pump, capacity 140 m3/h) Clamps for workpieces fixing Safety side metal grids and front emergency carpets Motorized carpet to evacuate chips and wastes Separate electric and command cabinet No. 1 Vertical Electro-spindle HSK F63 ( Kw 18) Automatic Tools Changing System, with 18 folds (places) Banding group on board - (Y AXIS) Glueing Unit (P.U.R. Glue + Quick Melt unit) VT 100/100 with NORDSON premelter Edge coils supporting unit (No. 2 reels) Lsdpfxez Dtuds Apneru OPTIONALS: N° 1 Aggregate Boring Unit, "cross" shape, with 4 horizontal spindles N° 1 Circular saw (diam. mm 200) N° 1 Combined unit: Corner rounding / Edge scraping (with glue scraping extension)

Condition: excellent (used), FULL LINE of Double-side Sizing-Milling & Edge Banding, composed of the following machines: OZ2050A) Loader (Double-cage, double pick-up) "MEINERT" Mod. P 415 D/B - L with central motorized rollers table. With two external roller ways to in-feed the piles (stacks) of panels to loader. OZ2050B) 1st Double-side Sizing & Edge Bander "IMA" Mod. Combima / II / 440 / A / R3 OZ2050C) Connecting Roller Table "IMA" Mod. IDK L/Q with turning device (from lengthwise to crosswise) with double cone system. Ledpoxftt Eofx Apnoru OZ2050D) 2nd Double-side Sizing & Edge Bander "IMA" Mod. Combima / II / 590 / B / R3 OZ2050E) Connecting Roller Table "IMA" Mod. IDK Q/L with Turning device (from crosswise to lengthwise) with double cone system. OZ2050F) Unloader (Double-Cage, double storage) "MEINERT" Mod. P 415 D/S - L With central motorized rollers table. With 2 on-ground motorized roller ways to out-feed the piles (stacks) of panels from the Unloader.

Condition: ready for operation (used), Year of construction: 1996, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, number of slots in tool magazine: 5, total height: 3,100 mm, overall weight: 7,500 kg, table length: 4,000 mm, table width: 1,200 mm, spindle motor power: 7,500 W, spindle speed (max.): 18,000 rpm, This 3-axis IMA BIMA 610 V CNC Wood Machining Centre was manufactured in 1996. It features a working area of 4000 mm in the X-axis and 1200 mm in the Y-axis, with a maximum drilling diameter of 45 mm. The machine is equipped with 5 drilling spindles in the X direction and 11 in the Y direction. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 610 V machine we have for sale. Contact us for further details. • CNC Control: NUM CNC Control • Drive System: Siemens SIMODRIVE 611 • Maximum Workpiece Length: 4000 mm • Minimum Workpiece Length: 150 mm • Maximum Workpiece Width: 1650 mm • Minimum Workpiece Thickness: 10 mm • Maximum Workpiece Thickness: 65 mm • Drilling Spindles (X): 5 • Drilling Spindles (Y): 11 • Maximum Drilling Diameter: 45 mm • Main Spindle Power: 7.5 kW Ljdpfezug Aljx Apnoru • Main Spindle Motor: Water-cooled • Tool Holder: HSK F63 DIN 69893 • Feed Drive Motor Power: 4 kW • Feed Speed: 1,500–18,000 mm/min • Maximum Tool Weight: 5 kg • Maximum Tool Clamping Force: 10,000 N • Operating Voltage: 400 V ±5% • Supply Voltage: 3/N/PE, 400 V, 50 Hz • Frequency: 50 Hz • Total Connected Load: 33 kVA • Rated Power: 41 kW • Rated Current: 62 A • Connection Cross Section: 16 mm² • Control Voltage: 24 V • Control Current: 52 A • Compressed Air Pressure: 6–10 bar • Air Connection: 1/2" • Required Air Consumption: 28 m³/h • Dust Extraction Connection: Ø100–300 mm • Air Flow Ø100: 14 m³/min • Air Flow Ø140: 28 m³/min • Air Flow Ø160: 36 m³/min • Air Flow Ø180: 46 m³/min • Air Flow Ø200: 56 m³/min • Air Flow Ø280: 105 m³/min • Air Flow Ø300: 127 m³/min • Number of Dust Extraction Ports: 1 • Machine Condition: Disassembled but fully functional Optional Equipment, not included: • Vacuum block suction cups (aluminum) and sliding console • Two milling spindles for synchronous milling with integrated tool changers • Safety fence with associated safety mats • Control cabinet and operating unit • Waste conveyor belt for milled sections

Condition: used, machine/vehicle number: 008269, Position 1: Panel Feeding and Loading IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 2: Panel Turning Device IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 3: Double Sided Squaring/Edgebanding Machines IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Position 4: Panel Turning Device IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3 Lrsdjx A Hggepfx Apnou Position 5: Panel Stacking and Offloading IMA+BARGSTEDT+SAG-COMBIMA/CONCEPT/II/500/B/R3

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 - in stips / lippings mm max 1 Panels thickness (min/max) mm 14 / 60 (LASER - Max 50) Numerical Control ICOS Open Lrodpfxei Hn Srs Apnju Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt Spraying unit (Anti-sticking liquid) In-feed fence, adjustable by N.C. Panels in-feed (servo) system A1 / 15 Pre-milling Unit (vertical joint trimmers) 08.378 (2 x Kw 4,5) adjustable by N.C. Glueing Unit (P.U.R. Glue + Quick Melt unit) 283.201 + 283.203 Glueing Unit (Thermofusion with Laser) Laser System LASERLINE Spraying Unit (for anti-release liquid) Band Pressure zone + Edge coils supporting unit (No. 36 + 12 reels) Snipping (end-cutting) 08.42 (Kw 0,2 x 2) work speed up to 30 m/min (0°-25°) Rough Trimming unit 08.0555 HS/LS1 (Kw 1 x 2) Fine Trimming unit (Multi-profile, by N.C. adjustment, for 4 profiles) 08.0587 (Kw 0,66 x 1) Multi-Profile Copying unit by N.C (fine + contour trimming) KFA 30 (Kw 0,5 x 1) max 30 m/min Profile Scraping unit (Multi-profile, by N.C. adjustment, for 4 profiles) 08.0516 Glue scraping unit 08.521 Spraying Unit (for polishing liquid) Buffing unit 08.614 (Kw 0.25 x 4) No. 2 Milling grooving units 08.190 (Kw 4,5 x 2) swivelling 90°/180°/270° (adjustable by CN)

Condition: excellent (used), SINGLE-SIDE EDGE BANDER (LEFT-side) Edges (band in rolls) thickness (Min/Max) mm 0,3 - 3 Panels thickness (min/max) mm 8 - 60 Numerical Control ICOS open compact Feeding speed (adjustable) m/min 6 - 30 Top pressure system with rubber belt, Spraying unit (Anti-sticking liquid) Automatic and accurate Panels in-feed system Mod. A1 / 15 In-feed fence, adjustable by N.C. Panels in-feed system Bar Code Reader Pre-milling Unit (vertical joint trimmers) by N.C. 08.379 (2 x Kw 4,0) Lamps to heat the workpieces side Glueing Unit (P.U.R. Glue + Quick Melt system) VTG + 283.203 Band Pressure zone. Height adjustment of the band by N.C. Edge coils supporting unit (reels N°) 12 Snipping (end-cutting) unit 08.42 / 30 / B (Kw 0,66 x 2) (PNEU 0°-25°) 30m / min Rough Trimming unit 08.0555 (Kw 1 x 2) Lredpfx Asltmnlspnou Fine Trimming unit (Multi-profile, by N.C.) 08.0587 (Kw 0,66 x 2) 4 PROFILES HSK 25 Spraying Unit (for sliding liquid) Multi-Profile Copying unit by N.C (fine and contour trimming) KFA 30 (Kw 0,5 x 1) 30m/min Profile edge scraping unit (Multi-profile, by N.C.) 08.516 (4 PROFILES) Glue scraping unit 08.521 Spraying Unit (for polishing liquid) Buffing unit 08.617 (Kw 0,25 x 4). Free space Milling grooving unit 08.190 (Kw 4,5 x 1)

Condition: used, Year of construction: 2008, - Machining area 4300 x 1250 mm - 8 pcs. workpiece supports - Main spindle 7.5 Kw / 11kw - Vertical drilling unit - Horizontal drilling unit - Dado cutter - Tool changer for 18 positions CNC machining center Manufacturer: IMA Type: Bima 300 Year of manufacture: 2008 Technical data - Machining area 4300 x 1250 mm - 8 pcs. workpiece supports - 1x Main spindle 7.5 Kw / 11kw (S1 / S6) HSK F63 1500 - 18000 rpm - Horizontal drilling unit - Vertical drilling unit - Dado cutter - 2x Vacuum pump, each 90 m³/h Lodpfxezux Tij Apnoru - Safety mats - IMA Wop software + office license
