Used Biesse Edgebander for sale (305)

Condition: used, machine/vehicle number: 007357, Position 1: Panel Feeding and Loading BIESSE - RBO-STREAM SB2 9.5 Position 2: Double Sided Squaring/Edgebanding Machines BIESSE - RBO-STREAM SB2 9.5 Position 3: Panel Turning Device BIESSE - RBO-STREAM SB2 9.5 Position 4: Double Sided Squaring/Edgebanding Machines BIESSE - RBO-STREAM SB2 9.5 Position 5: Panel Turning Device BIESSE - RBO-STREAM SB2 9.5 Position 6: Panel Stacking and Offloading BIESSE - RBO-STREAM SB2 9.5 Tsdpfewuz Rtjx Agcsf

Condition: good (used), BIESSE ARROW ATS 5 AXIS NC1000 MACHINING CENTER Tedpeukcy Eofx Agcsf Machining head with revolver tool change BH39 drilling machine, 250m3 vacuum pump (this machine had been in operation for 10 years in a woodworking school)

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: 1000063009, edge thickness (max.): 5 mm, transport length: 3,800 mm, transport width: 700 mm, transport height: 1,700 mm, TECHNICAL DETAILS Number of units: 5 Max. edge band thickness: 5 mm Max. panel thickness: 50 mm MACHINE DETAILS Documentation available: No CE marking present: Yes Serial number: 1000063009 Voltage: 400 V Current consumption: 12.3 A Tedpsw Tzifjfx Agcof Power: 6.8 kW Transport dimensions: 3,800 mm x 700 mm x 1,700 mm (L x W x H) Transport weight: 1,000 kg Number of transport packages: 1

Condition: new, Year of construction: 2010, functionality: fully functional, machine/vehicle number: COD.63-14-A0274, tool type: HSK 63, BIESSE double-sided angle gearbox with 2 collets DM 12 mm and 1 piece DM 10 mm. The unit is in absolutely as-new condition. Tedpswz Nkhsfx Agcsf

Condition: used, Xp 600 Numerical Control with Biesse Works Software Working range in X axis 3000 mm Working field in Y axis 1000 mm Working field in Z axis 60 mm Automatic loading system with motorized belt transfer N° 2 Pliers for blocking and transporting the panel N° 1+1 vertical electrospindle 3 axes (lower + upper) N° 1+1 independent blade (lower + upper) N° 29 + 29 independent spindles for vertical drilling in "X and Y" direction (upper + lower) N° 10 + 10 independent spindles for horizontal drilling in "X and Y" direction (upper + lower) Tedpsuickyefx Agcof Automatic unloading system with motorized belt transfer

Condition: new, machine/vehicle number: 1000007776, CONTROL SYSTEM • Numerical control, PC-based • bSolid software • CAD-CAM 3D module – 3-axis working module – bEdge module TECHNICAL FEATURES • Usable working area (X-Y-Z): approx. 4,320 x 1,600 x 200 mm • Usable working area for edgebanding (X–Y): approx. 3,300 x 1,500 x 60 mm PANEL SUPPORT AREA • 2 independent working zones on the X axis • 10 Set-Up Assistant (SA) working tables for panel support, with manual positioning and illuminated position/direction indicators – 32 rails • 8 lifting bars for loading support • 28 stops (8 rear stops, 8 intermediate stops at 670 mm, 6 side stops, 6 central stops) each with descent verification sensors • 1 vacuum pump, 100 m³/h DRILLING/SAWING UNIT • 1 extra 'Z' pod for rear working unit • 1 BH 24 L boring head GROOVING/MILLING UNIT • 1 electrospindle, 13.2 kW (17.7 HP), HSK F63 tool clamping system, air-cooled, equipped with a 360° working unit and gear C-axis torque • 1 air blowing system with 4 nozzles • 1 revolver tool changer with 16 positions on the X pod EDGEBANDING UNIT • GU60L edgebanding unit for EVA and PUR adhesives, including: – glue pot for EVA and glue pot for PUR – pre-melter for EVA glue – double pressure roller for edgebanding radii up to 30 mm; closed-loop joint sensor • 1 edge magazine for 2 coils positioned on the X pod • 1 edge magazine for 2 coils outside the machine • 1 blower unit for panel cleaning prior to edgebanding • 1 cleaning station for edge trimming units • 1 HSK F63 aggregate for blade diameter max. 215 mm Tsdow Nip Sjpfx Agcef • 1 combined unit for rough trimming, edge scraping, and glue scraping EF60A • 1 unit for edge rounding and end trimming • 1 kit for narrow panels 10-60 mm (edge max. 2 mm) and 12-60 mm (edge max. 3 mm) PREDISPOSITIONS AND ACCESSORIES • Automatic lubrication system • Waste extraction system for wood chips SAFETY STANDARDS AND OPTIONS • Copy of original EC Declaration of Conformity • Bumper system and double front/rear photoelectric safety barriers

Condition: used, machine/vehicle number: 007870, Max. panel width: 3200 mm Tjdswimz Hepfx Agcsf No of Bottom Units: 2 No of injectors: 7

Condition: good (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 1000028154, Equipment: rotational speed infinitely variable, The machine was commissioned in 2019, single owner. It has seen very little use. Description Useful working area, 5-axis configuration: X=3280mm, Y=1600mm Axis travel: X=3706mm, Y=2294mm, Z1=515mm, Z2=371mm Axis traverse speed: X=80m/min, Y=60m/min, Z=30m/min Electrospindle: HSD, 5 axes 11 kW, with continuous 360° rotation on B and C axes, enabling high-precision machining of complex shapes liquid-cooled Drilling head: Todpfx Ajxdl H Usgcsf HSD 20 vertical spindles 4 horizontal spindles grooving discs on X-axis grooving discs on Y-axis Work table: 6 cross beams Isbjwhypnjni Itxtobb 4 suction cups per beam preparation for uniclamp Tool magazines: 16-position revolver-type tool changer Vacuum system: Vacuum pump with a capacity of 250 m³/h, ensuring firm clamping of the parts during processing

Condition: used, Year of construction: 2017, Numerical Control with B-Solid Software - 3D CAD-CAM program to design, simulate, and manage processes of machining of Biesse machining centers and drilling machines BNest Software - Software module dedicated to processing in Nesting mode that allows you to create projects containing the list of articles with the quantities to be produced and the list of plates to be used with the aim of minimize the material used and processing times Working field in X axis mm 4300 Working range in Y axis mm 2200 N ° 2 work fields Nesting work plan Automatic loading system with side lift table Panel detachment system with 2 suction cups N° 1 vertical 3-axis electrospindle, Kw 13.2, with automatic tool change, Hsk cone type Automatic tool change system with 16 positions - positioned on the rear of the machine BH 10 boring head with 10 spindles arranged as follows: - N ° 5 vertical in X axis - N° 5 verticals in Y axis Automatic unloading system with motorized belt Worktop cleaning system Printing and application system of adhesive labels with labeling machine, 22" monitor, keyboard and mouse with dedicated PC Protection and safety system with perimeter grids Safety system with bumper Automatic lubrication system Air conditioning system for cooling and cleaning the machine control N° 2 vacuum pumps 250 m3/h Installed power Kw 31 Tsdpfx Ast Ul Dnegcsf

Condition: used, machine/vehicle number: 007869, Max. panel width: 3200 mm No of Bottom Units: 5 Lateral horizontal groups: yes Tsdjwimzyspfx Agcof

Condition: used, Year of construction: 2019, Smart Touch Numerical Control with Sintra HD Software Panel height 10 - 60 mm 22 mm solid wood Pvc / Abs mm 3 Feed speed up to 25 meters / min Working height electronically adjustable by C.N. Motorized rubber belt with higher pressure Motorized and electronically adjustable panel support guide by C.N. Side roller conveyor with idle wheels for panel support ADZ-700 anti-adhesive group Rectifier unit with 2 electronically adjustable motors by C.N FI-502 Lamps to heat the edge of the AdIRL-700 panel Reel holder plate at 1 position Gluing unit for EVA hot melt glue with QM-705 glue pot Additional glue tank Edge pressure group on straight profiles with electronically adjustable pressure rollers by C.N. Anti-adhesive group End trimming unit with 2 IN-801 motors Offset trimming / gleaning unit with 2 motors electronically adjustable by C.N RF400 PRO-NESTING KIT for gleaning unit Non-stick group Rounding unit with 2 multifunction motors (gleaner + rounder) AR30 NC LPT-700 non-stick liquid application system Electronic edge scraper unit electronically adjustable by C.N RB400 PRO-NESTING KIT for edge scraper group Tedpjr Ip Sdofx Agcsf RCC-701 glue scraper unit Brush group "SP-501" "PH-700" hairdryer group

Condition: used, machine/vehicle number: 008112, X axis working area: 3390 mm Y axis working area: 1535 mm Working Table: Pod and Rail Main Electrospindle power: 15 KW Number of controlled axes: 5 axes Total number of drilling spindles: 21 Total number of tool changer positions: 14 Todpfx Agjw Idgvscsf

Condition: used, Year of construction: 2013, Working center with automatic robot for panel loading and unloading management Biesse XP600 Numerical Control with Biesse Works ADVANCE graphic interface software - machine version and version office - WRT technology (Widows real time) the machine control logic is processed directly on the PC and not on a dedicated special device Working field in X axis 6200 mm Working range in Y axis mm 1552 Working field in Z axis 180 mm Z axis travel mm 235 N ° 2 work fields in X axis Bar worktop \ console No. 10 EPS electronically adjustable bars for suction cup support N° 8 pneumatic bakelite bars for lifting the panel - loading / unloading aid N° 4 EPS electronically adjustable suction cups for each bar with vacuum seal for fixing the panel during the processing N° 1 vertical electrospindle, with automatic tool change, motor KW 12 - 12000 RPM - flange for aggregates - preparation for C-Axis Vector Automatic tool change system with 12 positions - positioned on the machine head BH35L boring head with spindles arranged as follows: Todokvrxuspfx Agcjf - N° 14 verticals in X axis - N° 10 vertical in Y axis - N° 6 horizontal in X axis - N° 4 horizontal in Y axis Independent blade for making grooves in the X axis - diam. 120 mm Front protection and safety system with carpets Perimeter protection grids Automatic lubrication system Machine control cooling and cleaning system with conditioner Vacuum pump mc / h 250 Kuka industrial robot with 6 articulated axes with point-to-point positioning. Independent control panel Panel alignment table Barcode reader on the robot arm Panel introduction system via: * 1 motorized roller conveyor for panel stack preloading * 1 translating motorized roller conveyor * 1 motorized panel stack unloading roller conveyor Technical features: * Type : KR210-2 * Number of axles : 6 * Admissible nominal load : Kg 210 * Machine weight : Kg 1267 * Sound level: 75dB * Installed power: 25.8 kW * Panel dimensions - Min\max length: mm 300\3000 * Panel dimensions - Min\max width: 180\1500 mm * Panel dimensions - Min\max thickness: 8\60 mm * Max panel weight: Kg 90

Condition: used, Year of construction: 2015, Numerical Control NC 1000 Software Biesse Works Working field in X axis 4300 mm Working field in Y axis 2205 mm FT nesting full plane worktable Automatic loading system with side lifting table Automatic labeling machine for barcode printing Automatic printing and application system of adhesive labels N ° 1 vertical electrospindle, with automatic tool change, HSK F63 Blade unit integrated in the drilling head on X axis - diam. 120 mm Blade unit integrated in the drilling head on Y axis - diam. 120 mm Automatic tool change system with 8 positions - positioned on the machine operating head Automatic tool change system with 21 positions - positioned on the rear of the machine with chain BH 20 boring head with independent spindles arranged as follows: - N ° 8 vertical in X axis - N ° 8 vertical in Y axis - N ° 4 horizontal in X axis - N ° 4 horizontal in Y axis Automatic unloading system with motorized belt Front protection and safety system with carpets and perimeter nets Automatic lubrication system Air conditioning system for the electrical panel Vacuum pumps Tsdpowt Snyofx Agcof

Condition: used, Year of construction: 2017, Osi Plus Numerical Control QUICK OPTI software for cutting pattern optimization directly on the machine Cutting optimization software OPTIPLANNING PROFESSIONAL version Barcode Label Printer - OS-Labelling Additional key for office programming software Electrical cabinet air conditioner Cutting length mm 4400 Cutting width mm 4300 Blade projection 90 mm Manual front panel loading Lateral aligner integrated into the blade carriage No. 1 fixed front bakelite table with air curtain system for unloading the panels (mm 2050 x 850) No. 3 adjustable front bakelite tables with air curtain system for unloading the panels (mm 2050 x 650) Main blade group (max. blade diam. / power) 355 mm / 11 kW Engraving group (max blade diam. / power) 200 mm / Kw 2.2 Adjustable speed of the blade carriage Pusher carriage with 9 clamps Blade carriage speed 120 m/min Twin Pusher 1.2 system with 1 additional clamp on pusher carriage (position 570 mm) to perform different patterns cutting at the same time TECHNICAL DETAILS TO BE CHECKED Tsdpfx Agevtbzkscjf

Condition: used, Year of construction: 2009, Biesse Works Control Working range on X axis mm 3500 Working range on Y axis mm 1585 Working stroke in Z axis mm 350 N ° 2 work fields Bar worktop No. 8 adjustable bars N° 4 pneumatic Bakelite bars for lifting the panel No. 3 adjustable suction cups for each bar with vacuum seal for fixing the panel during processing No. 1 4-axis vertical electrospindle (Vektor), with automatic tool change, HSK type cones 10-position rotary tool change system on the operating head 24-position chain tool change system - located on the rear of the chain machine Drilling head with vertical and horizontal spindles composed as follows: n. 12 vertical spindles in X n. 12 vertical spindles in Y n. 6 horizontal spindles in X n. 4 horizontal spindles in Y n. 1 independent blade for making X-grooves Front protection and safety system with carpets Perimeter protection grids Chip evacuation system with motorized belt Air conditioning system for cooling and cleaning of machine control Vacuum pump 250mc/h TECHNICAL DETAILS TO BE CHECKED Tedsw D Dhajpfx Agcsf

Condition: used, Year of construction: 2009, Numerical Control Sintra Panel height 60 mm Solid wood mm 20 Tjdjh Uhxnepfx Agcjf Pvc / Abs mm 3 Feed speed up to 25 meters / min Working height electronically adjustable by C.N. Motorized rubber belt with higher pressure Motorized and electronically adjustable panel support guide by C.N. Panel introduction table to facilitate the alignment of the input panel Side roller conveyor with idle wheels for panel support Grinding group Coil holder magazine with 2 positions with automatic edge change from C.N. Gluing unit for EVA hot melt glue with pre-melter and glue pot Predisposition for gluing unit for PUR glue Edge pressure group on straight profiles with electronically adjustable pressure rollers by C.N. End trimming unit with 2 motors with automatic inclination adjustment Refilling unit with 2 superimposed motors Gleaning unit with 2 tilting motors Multifunction 4-motor rounding unit (gleaner + rounder) with numerical control adjustment in automatic Non-stick group Adjustable edge scraper group Glue scraping unit Oscillating brush group

Condition: used, Numerical Control NC 1000 Software Biesse Works Working field in X axis 3685 mm Working field in Y axis 1290 mm Working stroke in Z axis 200 mm - piece passage 70 mm FT nesting full plane worktable Automatic loading system with side lifting table N ° 1 vertical electrospindle, with automatic tool change, Automatic tool change system with 18 positions - positioned on the rear of the machine Boring head with independent spindles arranged as follows: - N ° 7 vertical in X axis - N ° 7 vertical in Y axis - N ° 2 horizontal in X axis - N ° 2 horizontal in Y axis Automatic unloading system with motorized belt Front protection and safety system with carpets and perimeter nets Automatic lubrication system Air conditioning system for the electrical panel Vacuum pumps TECHNICAL DETAILS TO BE CHECKED UPON ARRIVAL OF THE MACHINE Tedpfxswufv Tj Agcof

Condition: used, XNC Numerical Control Working range on X axis mm 3400 Working range on Y axis mm 1300 Working stroke in Z axis mm 155 N ° 2 work fields Bar worktop No. 8 manually adjustable bars for suction cup support with display for viewing working heights No. 8 pneumatic bakelite bars for lifting the panel No. 3 manually adjustable suction cups for each bar with vacuum seal for fixing the panel during assembly processing No. 1 vertical electrospindle with C-axis Vector, with automatic tool change, Iso 30 type cones, flange for use aggregates Automatic tool change system with 3 positions for aggregates positioned on the side Automatic tool change system with 20 positions and chain Drilling head with mandrels arranged as follows: - No. 10 verticals on X axis - No. 12 verticals in Y axis - N° 6 horizontal on X axis - No. 2 horizontals on Y axis Front protection and safety system with carpets Perimeter protection grids Motorized carpet for chip evacuation Vacuum pump Tsdpfsv Edggox Agcef

Condition: used, Year of construction: 2017, Numerical Control with B-Solid Software Working range in X axis 3600 mm Working range in Y axis 1800 mm N ° 2 work fields Nesting worktable Tjdjqvt D Rjpfx Agcsf Automatic loading system with side lifting table Label printing system with automatic application on the loading table Panel detachment system with suction cups N° 1 3-axis vertical electrospindle, 13.2 kW, with automatic tool change, ISO 30 cone type Automatic tool change system with 16 positions - positioned on the back of the machine Automatic tool change system with 8 positions - on the machine BH 10 drilling head with 10 spindles arranged as follows: - N° 15 verticals on the X axis - N° 17 verticals on the Y axis Automatic unloading system with motorized belt Worktop cleaning system Protection and safety system with perimeter grilles Security system with Bumper Automatic lubrication system Air conditioning system for cooling and cleaning the machine control 250 m3/h vacuum pumps

Condition: used, Xp 600 Numerical Control with Biesse Works Software Working range in X axis 3000 mm Working field in Y axis 1000 mm Working field in Z axis 60 mm Todpfx Aopp Thnsgcof Automatic loading system with motorized belt transfer N° 2 Pliers for blocking and transporting the panel N° 1+1 vertical electrospindle 3 axes (lower + upper) N° 1+1 independent blade (lower + upper) N° 29 + 29 independent spindles for vertical drilling in "X and Y" direction (upper + lower) N° 10 + 10 independent spindles for horizontal drilling in "X and Y" direction (upper + lower) Automatic unloading system with motorized belt transfer

Condition: used, Year of construction: 2023, Numerical Control BH 660 with BSolid Working range on X-axis mm 4320 Working range on Y axis mm 1660 Working range on Z axis mm 200 No. 2 work fields on X axis Bar worktop No. 8 adjustable bars for suction cup support No. 8 pneumatic bakelite bars for lifting the panel No. 3 adjustable suction cups for each bar with vacuum seal for fixing the panel during processing No. 1 5-axis vertical electrospindle, with automatic tool change, liquid cooling, HSK63 type cones, KW 13 (HP 17.4) Automatic tool change system with 16 positions with revolver positioned along the X axis on the back of the machine Automatic tool magazine with 12 positions positioned on the machine side BH24 L drilling head with spindles arranged as follows: - No. 8 verticals on X axis - N° 6 verticals in Y axis - N° 6 horizontal on X axis - N° 4 horizontal in Y axis - N° 1 Integrated blade for making grooves Chip evacuation system with motorized belt Front protection and safety system with carpets Automatic lubrication system Air conditioning system for cooling and cleaning of machine control 250m/c vacuum pump TECHNICAL DETAILS TO BE CHECKED Tedswgc D Espfx Agcjf

Condition: used, Year of construction: 2017, Osi Plus Numerical Control QUICK OPTI software for cutting pattern optimization directly on the machine Cutting optimization software OPTIPLANNING PROFESSIONAL version Barcode Label Printer - OS-Labelling Electrical cabinet air conditioner Cutting length mm 4400 Cutting width mm 4300 Blade projection 75 mm Manual front panel loading Lateral aligner integrated into the blade carriage No. 1 fixed front bakelite table with air curtain system for unloading the panels (mm 2050 x 850) No. 3 adjustable front bakelite tables with air curtain system for unloading the panels (mm 2050 x 650) Main blade group (max. blade diam. / power) 355 mm / 7.5 kW Engraving group (max blade diam. / power) 200 mm / Kw 2.2 Adjustable speed of the blade carriage Pusher wagon with 10 clamps Blade carriage speed 1-120 m/min Pusher speed 60 m/min Twin Pusher 1.2 system with 1 additional clamp on pusher carriage (position 570 mm) to perform different patterns cutting at the same time TECHNICAL DETAILS TO BE CHECKED Tjdpfx Agsv Amx Tocof

Condition: used, Year of construction: 2019, Numerical control with bSolid software The multi-document software application in Windows environment allows the design of the finished product, the definition of its processes, the definition of the work plan, the simulation of the piece machining operations on the 3D model of the machine and generation of the necessary machine programs. bSolid - 3-Axis Machining bSolid - 5-Axis Machining Module for surface machining with 5-axis units and interpolation movements on all 5 available axes (X,Y,Z,C,B). The module includes the following commands: · assignment to surfaces three-dimensional roughing and finishing operations · spread or project a path onto a curved surface machining lying on a plane · follow 2D or 3D curves with any type of tool bSolid - 3D Engraving bSolid - Import external formats Fields of work: X = 5055 mm; Y = 1650 mm (may vary depending on configuration) Z = 200 mm with modules H=74 mm Z = 245 mm with modules H=29 mm Loadable piece in Y: * 1650 mm, with thickness up to 60 mm on H=74 mm modules * 1600 mm, with thickness over 60 mm on H=74 mm modules. 10 ATS floors – 40 trolleys The code includes: • 2 aluminium bars (n. 1 left and n. 1 right) on which the lateral stops slide. • 10 aluminum worktops. The worktops slide on hardened and ground linear guides using recirculating ball bearing slides. Locking occurs on both linear guides, front and rear, by means of four pneumatic cylinders. The control is activated by a button located in front of the work surface. The carriages slide on steel guides positioned above the extrusion. Pneumatic locking system divided into 2 locking zones in X Automatic positioning (EPS) for worktops. "EPS" (Electronic Positioning System) device for the automatic positioning by NC of the work surfaces and trolleys complete with locking devices capable of eliminate possible operator errors. Rear row stop, with 140 mm stroke Intermediate row stop, positioned at 405 mm, with 140 mm stroke. Front row stop, positioned at 1460 mm, with 140 mm stroke 4 lateral stops, with 140 mm stroke (2 right + 2 left) with system 2 additional side stops, with 140 mm stroke (1 right + 1 left). Sensor for checking whether the stops have descended 12 clamping devices for clamping narrow workpieces 6 loading aid bar lifts, for H=74 mm modules Configuration 5A, for Rover B. Configuration for high productivity and flexibility, thanks to the two operating groups 4 and 5 axes and the possibility of performing tool changes in concurrent time. It includes the axes and carriages for the movement of the main operating groups. Includes 2 inverters. Second Y-axis. Introduces the separation of the front and rear Y-carriages, with independent motorization. The two Y-carts have a maximum speed of 118 m/min. 13.2 kW (17.7 HP) electrospindle, HSK F63 connection, air-cooled. Main features: • 11 kW (14.7 HP) from 12,000 to 15,000 rpm in S1 service. • 13.2 kW (17.7 HP) from 12,000 to 15,000 rpm in S6 service. • Bearings ceramics. • Right and left rotation. • Rotation speed from 1,000 to 24,000 rpm programmable by NC. • The release pneumatic operation is carried out via a prismatic linear guide and recirculating ball bearings. A cover is included for chip extraction, with 6 different positions in Z managed by the NC, depending on the length of the tool, or by program. The suction mouth is automatically closed when the electrospindle is not working. Provision for subsequent installation of the 360° operating group (C-axis) Revolver tool maga... Tjdpfsw D E A Ejx Agcof

Condition: used, Year of construction: 2018, Numerical Control BH 660 with BIESSE BSolid software bEdge module for edge management bSolid surface design Sophia - IoT Connection Office control Tsdpfx Agsugpwnjcef Working range on X-axis mm 3228 Working range on Y axis mm 1580 Working range on Z axis mm 200 with H74 mm suction cups Working range on Z axis mm 245 with H29 mm suction cups No. 8 adjustable ATS panel support bars Installation of the pneumatic lock divided into two zones in Y No. 6 Pneumatic Bakelite bars for panel lifting No. 3 adjustable suction cups for bar Set-Up Assistant for Suction Cups No. 1 electrospindle (pantograph) with 4 axes, automatic tool change, KW 13 (HP 17.4) motor, cooling liquid, HSK cone attachment, 20000 RPM Automatic tool change with 16 positions on the X-axis of the carriage Drilling tesa BH17 independent spindles arranged as follows: No. 5 independent spindles for vertical drilling in the "X" direction No. 5 independent spindles for vertical drilling in the "Y" direction No. 4 spindles for horizontal drilling in the "X" direction No. 2 spindles for horizontal drilling in "Y" direction No. 1 blade integrated into the drilling head diam 120 mm (useful cut 25 mm) GU60L gluing unit for EVA glue with pre-melter - edge pressure system with double rubber roller for spokes maximum internal 30 mm and edge joint sensor - 500 ml glue pot installed on the glue roller - lamp edge heating - edge feed system - edge cutting system - possibility of Introduction of the manual edge Plastic edge thickness from 0.4 to 3 mm Wood edge thickness from 0.4 to 2 mm Laminated edge thickness from 0.4 to 1.2 mm Maximum edge width 65 mm Workpiece thickness from 10 to 60 mm Minimum internal radius workable with 30 mm edging Maximum external radius for edging, proportionate to the thickness and stiffness of the edge: * 10 mm with edge up to 1 mm thick * 20mm with 2mm thick edge * 30mm with 3mm thick edge Minimum dimensions of the edging panel 300 x 300 mm Minimum internal diameter for edging: 350 mm with plastic edges less than 1 mm thick and with panel maximum thickness 18 mm 2-position edge storage unit positioned inside the protective casings for edges with maximum thickness 65 mm Finishing aggregate cleaning station with automatic dispensing of special cleaning liquids and with a cleaning cycle No. 1 aggregate for edge trimming / rounding No. 1 EF60A combi aggregate trimmer / edge scraper / glue scraper Perimeter protection grids Chip evacuation system with motorized belt Liquid cooling system Automatic lubrication system No. 1 vacuum pump of 250 m3/h TECHNICAL DETAILS TO BE CONFIRMED
