Used Biesse Edgebander for sale (329)

Condition: excellent (used), LOADER (BRIDGE-FRAME) WITH DOUBLE PICK-UP STATION Vacuum system (with its pump) N. 4 Vertical supporting columns of the top supporting beam N. 1 Horizontal top supporting beam (where the carriage slide on) N. 1 Motorized sliding carriage with horizontal metal arms N. 2 Horizontal metal arms with vacuum cups, adjustables N. 2 Out-side rollers ways (on gound) to in-feed pile of panels to the Loader N. 1 Out-side motorized rollers table (which in-feed the panels to the Unloader), with also cross motorized conveyor belts (at 90°), dimensions mm 7232 (ca.) Separate electric and command panel Electronic Programmer OMRON Perimetral safety metal grids Hnjdpjd Rg Dpefx Ahuog Working capacity (cycles/min) 16 - 20 (ca.) Min/Max panels thickness mm 10 - 50 (ca.) Min dimensions of the panels mm 250 x 320 (ca.) Max dimensions of the panels mm 1200 x 3200 (ca.) Total installed motor power Kw 23.3

Condition: excellent (used), UNLOADER (SINGLE-CAGE) - Vacuum system with its pump - Top holding bar deplacement (pivoting) of 180° - Horizontal-longitudinal bars (rocker arms) for the vacuum cups supporting - In-side lifting table, surface with motorized-rollers - Front-side sliding door (or metal grid) to out-feed the stack of the panels - Separated electric and command panel - Out-side rollers way (on ground) to out-feed pile of panels from the Unloader - Out-side motorized rollers table (which brings panels to the Unloader), with also cross motorized conveyor belts (at 90°) - Working capacity (cycles/min): 12-15 - Min/Max panels thickness mm 10 - 40 - Min dimensions of the panels mm 250 x 320 (estimated) Hjdpfxecggy Se Ahujng - Max dimensions of the panels mm 1200 x 3000 - Total installed motor power KW 10

Condition: excellent (used), Automatic ELECTRONIC Drilling and Dowels inserting LINE, CNC controlled: VZ0250A) LOADING SYSTEM “RBO” Tornado C 1300 with motorized rollers table and conveyoring belts to in-feed the 1st multi-borer VZ0250B) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT with CNC - No. 2 through-feed motorised belts, feeding speed up to 75 m/min - No. 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.8 each), - No. 4 bottom vertical units (each with 2 turnable drilling heads at various spindles, HP 1.8 ea) - No. 3 top vertical units (each with 2 turnable drilling heads at various spindles, HP 1.8 each) - No. 3 top pressing devices - No. 2 endless screws to evacuate the wastes. With CNC NC 500 to control, manage and run the 2 machines of this line VZ0250C) THROUGH-FEED MULTI-BORER & DOWELS INSERTER “BIESSE” Techno SDT with CNC - No. 2 through-feed motorised belts, feeding speed up to 75 m/min - No. 2 horizontal units (each with 6 inserting nozzles, such as Glue injectors and dowel drivers) - No. 2 bottom units (each with 2 turnable drilling heads at various spindles, HP 1.8 each) - No. 2 Top pressing devices - No. 2 endless screws to evacuate the wastes. Hsdpfxod Nviqo Ahuong VZ0250D) BRUSHING-CLEANING MACHINE "PIZZIGALLI" Mod. GP 11 VZ0250E) UNLOADING “RBO” Tornado SC/FE 1300 with motorized rollers table and conveyoring belts out-feed from 2nd multi borer (and dowels inserter)

Condition: used, Complete factory for the production of furniture cabinets, composed by: SZ0M23) Angular Panel Saw "GIBEN" Tip 17 (mm 5600x2700) with "SIRIO" automatic unloading and stacking system SZ0M25) Panel Saw “GIBEN” Mod. GammaDue (mm 3800x2200) SZ0M26) Panel Saw (Multi-saws) “GABBIANI” (finished panels mm 4250x2120) SZ0M27) Laminating Line “BARBERAN” for melamine papers (glue on paper) SZ0M29) Pressing Line “COLOMBO REMO” (mm 1400 x 9600) for paper / veneer / laminates SZ0M30) Pressing Line “FRIZ” (mm 1400 x 6200) for paper / veneer / laminates SZ0M41) 4-sides Sizing & Edge Banding Line “IMA” Combima fast handling “RBO-BIESSE” SZ0M42) 4-sides Sizing & Edge Banding Line “IMA” Combima softforming with a second double side Sizing & banding machine STEFANI and automatic handling equipment “TOMASSINI” SZ0M39-40) Edge Banding Line (single side) for narrow pieces “HOMAG” Mod. KAL 310 with Splitter "NARDELLO" Mod. Elegance SZ0M35-36) Multi-Borer “BIESSE” Techno Logic with Loader + Unloader “TOMASSINI” SZ0M45) CNC Multi Boring and Dowels Inserting Line “BIESSE” Techno FDT with fast handling “RBO-BIESSE” SZ0M37) CNC Working Center “MORBIDELLI” Mod. Author 600 KL SZ0M56) Reel Cutting and winding machine “CEFLA-DUSPOHL” Tipo RSW 2200 T SZ0M01) Wooden strips end-cutting Line "OGAM+SALVADOR" Hnedpfecr U Urox Ahujg SZ0M07) Wooden strips end-cutting and stacking Line “SALVADOR+SACOT” SZ0M08) Wooden strips end-cutting and stacking Line “SALVADOR+CMA” SZ0M11-17) Preparing Line for honey-comb panels SZ0M18) No. 6 Mutli-openings (daylights) hot hydraulic presses "COLOMBO REMO" SZ0M21) Sizing and top & bottom Calibrating line for honey-comb panels "GABBIANI + CELASCHI + ELMAG + COSTA Sanding Machines" And many other machines (i.e. multi-borer "VITAP", circular saws, glue spreaders, etc.), saw-dust suction system, rollers ways, shelvings, fork-lift, transpallets, etc. Machines still installed at the end-user's factory. They can be inspected by appointment.

Condition: excellent (used), Numerical Control Type NC 400 Deluxe Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 1 Splindles for each horizontal drilling head (N°) 20 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 Hodorm Ik Topfx Ahueng Vertical top pressure clamps (N°) 3 Transport belts to evacute chips (wastes) (N°) 2 Total installed power (Kw) The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts

Condition: excellent (used), Universal DOUBLE-SIDE SIZING & EDGE BANDING MACHINE (for both 1st and 2nd pass) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Panels thickness (min/max) mm 10 - 60 Working width (min/max) mm 240 - 2700 Numerical Control /Software SINITRA Adjustable feeding speed (m/min ) 10 - 40 (INVERTER C.N.) Safety and sound-proof enclosures/cabins Distance (center-axes) of the Disappearing Dogs (mm) 500 SIZING PART (for each side): Anti-chipping Milling Unit AS 10 (Kw 5,8) Hnedpfsu Tg Uqjx Ahueg N° 2 Hogging Units (1 Top + 1 Bottom) DT 10 (5,8 + 5,8) - Spraying unit (Anti-sticking liquid) EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) SP30 (High Melt + Edge Guide Z-axe) Band Pressure zone (N.C. adjustment) . Edge coils supporting unit (No. 6 reels) Snipping (end-cutting) unit IT 90-S (Kw 0,3 x 2) speed 28m/min. 0 - 25°. PNEU Fine Trimming unit (Multi-profile, by N.C.) RF 30 (Kw 0,65 x 2) 0 - 25° Multi Function Unit (Profile contour Trimming unit) AR 80 (Kw 0,3 x 2) max 25 m/min - ROTAX motors with automatic tool change (8+8 position store) Profile Scraping unit (Multi-profile, by N.C.) RB 30 Glue scraping unit RC 20 + Spraying Unit (for polishing liquid) Buffing unit SZ 30 (Kw 0,37 x 2) With ‘hopper’ for panels (useful height mm 80), as a buffer, to speed up the work cycle

Condition: excellent (used), Splitting - Grooving Machine (used to groove and/or split in two parts the unique panel): - Minimum length of the workpiece: mm 500 - Maximum length of the workpiece: mm 2700 - Minimum width of the workpiece: mm 300 ca. - Maximum width of the workpiece: mm 700 - Thickness (min./max) of the workpiece: mm 10 / 30 ca. - Max feeding speed: m/min 50 - Total installed power Kw 43.2 Along with the following groups: POS. 1 Milling unit for execution of bottom slots/grooves (Kw 7,4) max. blade diameter mm 300 POS. 2 Lower scoring blade unit (Kw 7.4) max. blade diameter mm 350 POS. 3 Upper scoring blade unit (Kw 7.4) max. blade diameter mm 350 POS. 4 Lower main blade (sawing) unit (Kw 7.4) max. diameter mm 350 Hnodpfju Tqb Usx Ahujg

Condition: excellent (used), Automatic ELECTRONIC Drilling and Dowels inserting LINE, CNC controlled: Hsdow Uhbkspfx Ahusng O03009A) THROUGH-FEED MULTI-BORER “BIESSE” Techno Logic with CNC No. 2 through-feed motorised belts, feeding speed up to 75 m/min No. 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.8 each), No. 5 bottom vertical units (each with 2 turnable drilling heads at various spindles, HP 1.8 ea) No. 3 top vertical units (each with 2 turnable drilling heads at various spindles, HP 1.8 each) No. 5 top pressing devices No. 2 endless screws to evacuate the wastes. Numerical Control Type CNI O03009B) THROUGH-FEED MULTI-BORER & DOWELS INSERTER “BIESSE” Techno INFOR a C.N. No. 2 through-feed motorised belts, feeding speed up to 75 m/min No. 2 horizontal units (each with 6 inserting nozzles, such as Glue injectors and dowel drivers) No. 2 bottom units (each with 2 turnable drilling heads at various spindles, HP 1.8 each) No. 2 Top pressing devices No. 2 endless screws to evacuate the wastes.

Condition: excellent (used), Electronic programmer NC 400 Through-feed motorized conveyoring belts (No.) 2 Hnsdpfx Ahjlwqrtsueg Horizontal units/supports (No.) 2 Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) Bottom vertical units/supports (No.) 6 Drilling heads/blocks for each bottom vertical unit (N°) 2 Vertical top pressure clamps (N°) 4 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 27.7 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (Z axe) of all the vertical units

Condition: excellent (used), Complete factory for the production of furniture cabinets, composed by: KZ2207) “BIESSE” FDT - CN Drilling and Dowels Inserting Line, composed by: Loader "RBO" Tornado, 2 x CN Multi-Borers "BIESSE" FDT, 1 x CN Multi-borer and dowels inserter "BIESSE" SDT CN, Stacker "RBO" Tornado KZ2205) 4-sides Sizing and Edge Banding LINE "HOMAG", composta da Double-station portal Loader "ESSE2", 1st Double-side Sizing and Edge banding machine "HOMAG" PowerLine KF 20/20/QA/15, Turning station at 90° "HOMAG" TD 31/30/12, 2nd Double-side Sizing and Edge banding machine "HOMAG" PowerLine KF 20/21/QA/35, 2nd Turning station at 90° "ESSE2", Double-station portal Stacker "ESSE2" KZ2210) 'BREMA (BIESSE)' Mod. Vektor CNC-LINE for Drilling-Routering-Inserting: Hedgehog (18 positions), CNC Vektor GLR 30-13, Vektor XL 40-30, Idrak-3, various Transfers KZ2090) Sander (Veneer Sanding machine) "COSTA LEVIGATRICE" SN TR TT TT TR 1350 KZ2045) Gantry-CNC with edge banding unit "MORBIDELLI" Planet HP6018 (2 Tables, 6 reels) KZ2033) Edge bander "HOMAG" KAL 310 with Loader-feeder "ESSE2" Hnsdpfeh T Dvtjx Ahusg KZ2075) Furniture assembling LINE "TERMOPAK" with carcasse press (through-feed) KZ2203) Sawing LINE "SALVADOR" (panels cross-cutter + splitter) with Loader "ESSE2" KZ2009) VENEER Department (double-knife guillotine "MONGUZZI", cross-cut shear "MONGUZZI"; splicing machine "KUPER", guillotine shear "TAGLIABUE", ecc) KZ2201) Short-cycle Pressing LINE "WEMHONER" useful size mm 1300x6200 KZ2215) Automatic panels storage System "ESSE2" Mod. MAGAZZINO N° 3 Saw-dust Filtering Stations "MION" (1st of Kw 132, 2nd of Kw 55, 3rd of Kw 22) Various vehicles (truck, van, etc.) And many other machines (i.e. CNC "BIESSE" Skipper 130, small multi-borers "VITAP" and MORBIDELLI", circular saws, etc.), rollers ways, shelvings, fork-lift, transpallets, etc. Machines still installed at the end-user's factory. They can be inspected by appointment.

Condition: excellent (used), LINE (half line) of Double-side Sizing-Milling & Edge Banding, with automatic handling system. Composed of the following machines: A) LOADER (Portal) with double station "RBO" Mod. Advantage C 3200 and central motorized rollers table. B) Infeeding Rollerway, with double-cone TURNING Device "RBO" Mod. GPK-1 C) Double-side SIZING and EDGE BANDING machine "BIESSE" Mod. Stream SB2 11.0 D) UPSIDE DOWN 180° TURNING MACHINE "RBO" Mod. Ribaltatore Hnedpfshvah Nsx Ahuog E) Outfeeding Rollerway, with double-cone TURNING Device "RBO" Mod. GPK-2 F) STACKER (Portal) with double station "RBO" Mod. Advantage SC 3200, with central motorized rollers table.

Condition: excellent (used), Electronic Programmer NC 400 Software Biesse Through-feed motorized conveyoring belts (No.) 2 Horizontal units/supports (No.) 2 Dowels inserting nozzles (and Glue Injectors) N. 5+5 Max. working width (mm) 3200 Hedpfxsd Nuwij Ahujng Min. working width (mm) 235 Bottom vertical units/supports (N°) 6 Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 Vertical top pressure clamps (N°) 2 Motorized endless screws to evacuate wastes/chips (N°) 2 Motorized carpet to evacuate chips and wastes The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops

Condition: excellent (used), Universal DOUBLE-SIDE SIZING & EDGE BANDING MACHINE (for both 1st and 2nd pass) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Panels thickness (min/max) mm 10 - 60 Working width (min/max) mm 240 - 2700 Numerical Control /Software SINITRA Adjustable feeding speed (m/min ) 10 - 40 (INVERTER C.N.) Safety and sound-proof enclosures/cabins Working line (work units support tables), manual adjustment Distance (center-axes) of the Disappearing Dogs (mm) 500 SIZING PART (for each side): Anti-chipping Milling Unit AS 10 (Kw 5,8) N° 2 Hogging Units (1 Top + 1 Bottom) DT 10 (5,8 + 5,8) Spraying unit (Anti-sticking liquid) EDGE-BANDING PART (for each side): Glueing Unit (Hot Melt + Quick Melt Unit) SP30 (High Melt + Edge Control EC 40) Band Pressure zone (N.C. adjustment) . Edge coils supporting unit (No. 6 reels) Hsdpshvahhsfx Ahusng Snipping (end-cutting) unit IT 90-S (Kw 0,65 x 2) speed 28m/min. 0 - 25°. PNEU Fine Trimming unit (Multi-profile, by N.C.) RF 40 (Kw 1 x 2) 0 - 25° Multi Function Unit (Profile contour Trimming unit) AR 80 (Kw 0, 65 x 2) max speed 25 m/min - ROTAX motors with automatic tool change (tools) Milling grooving Unit 2 x FB 30 (Kw 5 x 2) 0 - 90° Profile Scraping unit (Multi-profile, by N.C.) RBK - 503 (2 POSITIONS) Glue scraping unit RC 20 + Spraying Unit (for polishing liquid) + Buffing unit SZ 30 (Kw 0,37 x 2)

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Movable panel (workpiece), movable working head. Vertical position of the panel (workpiece) Numerical Control TPA - Software Albatros Safety cabin (enclosure) of the working head Panels feeding by motorized chain/track Rubber-coated vertical rollers as fence and feeders during workpieces process In-feeding table (with motorized belts) - Out-feeding table (with motorized belts) Hsdpfx Ahjihfiisusng With workpiece return system to the operator (180°) Min. useful working area (X - Y - Z) mm 260 x 40 x 10 (ca.) Max. useful working area (X - Y - Z) mm infinite x 1300 x 80 (ca.) Separate electric and command cabinet Total installed power (Kw) 35 WORKING GROUPS: Drilling heads with vertical spindles (No.) 1 Independent vertical boring spindles (No.) 24 (7 in X + 17 in Y) Drilling heads with horizontal spindles (No.) 2 Independent horizontal boring spindles (No.) 36 (9 LEFT + 9 RIGHT = 18 x 2) Drilling head motor-power (Kw) 3 x 3 (ca.) Vertical electro-spindle (No.) 1. Vertical electro-spindle motor power (Kw) 7,5 (ca.) Automatic Tools Changing System Revolver, with Tools storage plate (No. of folds-positions) 10

Condition: excellent (used), Automatic through-feed ELECTRONIC Drilling LINE (CNC controlled): Also for NARROW PIECES (min. mm 100). W05024F) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT with CNC - N° 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.5 each), - N° 6 bottom vertical units (each with 2 drilling heads at various spindles, HP 2.3 each) - N° 4 top vertical units (each with 2 drilling heads at various spindles, HP 2.3 each) - N° 6 top pressing devices + N° 2 endless screws to evacuate the wastes. With CNC - PC DESK TOP (Modul Editor) - software Tooling System W05024G) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT with CNC - No. 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.5 each), - No. 6 bottom vertical units (each with 2 drilling heads at various spindles, HP 2.3 each) - No. 3 top vertical units (each with 2 drilling heads at various spindles, HP 2.3 each) - No. 6 top pressing devices + N° 2 endless screws to evacuate the wastes. 2nd Drilling Machine connected to the NC of the 1st Machine Hodeu Tp Slopfx Ahueng

Condition: excellent (used), Double-sided machine, which can be placed in line after a through-feed Multi Borer for the automatic processing cycle of boring and dowels inserting - Electronic Programmer "CNI" NC 400 - Built-in command and electric cabinet - Max. distance between the horizontal heads mm 3200 approx - Movable and adjustable right side of the machine (according to the width of the panels) - No. 2 motorized conveyoring belts (HP 0.25 x 2 motors) - No. 1+1 dowels storage tanks for the automatic feeding to the nozzles - No. 6+6 horizonal inseritng nozzles (Glue injectors and dowel drivers) - High-pressure Glue-feeding system Hjdpfow Ug A Hox Ahueng - Total installed power KW 5 ca.

Condition: excellent (used), Automatic through-feed ELECTRONIC Drilling LINE (CNC controlled): W05022F) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT with CNC - N° 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.8 each), - N° 6 bottom vertical units (each with 2 drilling heads at various spindles, HP 1.8 each) - N° 3 top vertical units (each with 2 drilling heads at various spindles, HP 1.8 each) - N° 5 top pressing devices + N° 2 endless screws to evacuate the wastes. With CNC NC 500 (Software Tooling System + Woodmaster) W05022G) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT with CNC - No. 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.8 each), - No. 6 bottom vertical units (each with 2 drilling heads at various spindles, HP 1.8 each) - No. 3 top vertical units (each with 2 drilling heads at various spindles, HP 1.8 each) - No. 5 top pressing devices + N° 2 endless screws to evacuate the wastes. 2nd Drilling Machine connected to the NC of the 1st Machine Hsdpfx Ahet Ig A Ssueng

Condition: excellent (used), Angular sawing plant Numerical Control OSI Plus - Software Optiplanning N. 2 Pre-loading roller tables (mm) approx. 4500 x 2200 each Lifting table (mm) 4500 x 2200 1° Rear-pusher, with No. 5 clamps/grippers Turning device (rotating unit) at 90° 1° Panel saw (longitudinal) max. cutting width (mm) 4500 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 ( Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min Hodpfx Asukhd Ashuong Cutter for shredding trimmings 2° Rear-pusher, with No. 10 clamps/grippers 2° Panel Saw - Max cutting width mm 2200 Max blade projection (mm) 152 Scoring Unit (max. diameter saw) mm approx. 215 Main Sawing Unit (max. diameter saw / power) mm 530 (Kw 30) Adjustable speed of the saw carriage (m/min) 1 - 170 m/min No. 2 Front supporting tables with Air blowing system mm 2200 x 1500 Automatic unloader (bridge) for cut panels "RBO (BIESSE)" Mod. Lifter with 6 stacking stations

Condition: excellent (used), AUTOMATIC Drilling and Dowels inserting LINE (2 machines): Hnsdevnq Txopfx Ahusg W12054A) THROUGH-FEED MULTI-BORER “BIESSE” Techno FDT - No. 2 through-feed motorised belts, feeding speed up to 75 m/min - No. 2 horizontal units (each with 2 drilling heads at 11 spindles each, HP 1.8 each), - No. 5 bottom vertical units (each with 2 swivelling drilling heads at various spindles, HP 2.3 ea) - No. 1 top vertical unit (with 2 swivelling drilling heads at various spindles, HP 2.3 each) - No. 5 top pressing devices - No. 2 endless screws to evacuate the wastes. With NC (software Modul Tooling System) to control, manage and run the 2 machines of this line W12054B) THROUGH-FEED MULTI-BORER & DOWELS INSERTER “BIESSE” Techno SDT - No. 2 through-feed motorised belts, feeding speed up to 75 m/min - No. 2 horizontal units (each with 8 inserting nozzles, such as Glue injectors and dowel drivers) - No. 3 bottom units (each with 2 swivelling drilling heads at various spindles, HP 2.3 each) - No. 1 top vertical unit (with 2 swivelling drilling heads at various spindles, HP 2.3 each) - No. 3 Top pressing devices - No. 2 endless screws to evacuate the wastes.

Condition: excellent (used), Numerical Control Type NC 400 Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) Hnedoidqd Tjpfx Ahueg No. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 4 Transport belt to evacute chips (wastes) Digital quota (axes) display Total installed power (Kw) 59,1 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts

Condition: excellent (used), Numerical Control Type NC 400 Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 6 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 5 Transport belt to evacute chips (wastes) Digital quota (axes) display Total installed power (Kw) 59,1 The CNC controls the movement (X axe) of the mobile horizontal unit Hedpfxoidqf Rj Ahueng The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts

Condition: excellent (used), Numerical Control Type NC 400 (with work cycle management software) Through-feed motorized conveyoring belts (No.) 2 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 No. 4 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 2 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 25 The CNC controls the movement (X axe) of the mobile horizontal unit Hnjdpfxoi D D Tfo Ahusg The CNC controls the movement (Y axe) of the stops OPTION: Front feed hopper/loader (for narrow pieces: Min 60mm - Max 260mm)

Condition: excellent (used), Universal DOUBLE-SIDE SIZING & EDGE BANDING MACHINE (for both 1st and 2nd pass) Edges (tape) thickness in rolls (min/max) mm 0,3 - 3 Panels thickness (min/max) mm 10 - 60 Working width (min/max) mm 240 - 2700 Numerical Control PC Base Windows /Software SINITRA Adjustable feeding speed (m/min ) 10 - 40 (INVERTER C.N.) Distance (center-axes) of the Disappearing Dogs (mm) 500 SIZING PART (for each side): Anti-chipping Milling Unit AS 10 (Kw 5,8) pneumatic N° 2 Hogging Units (1 Top + 1 Bottom) DT 10 (Kw 5,8 x 2) Spraying unit (Anti-sticking liquid) EDGE-BANDING PART (for each side): Hnsdpfx Ahsu Rc Anjujg 1° Glueing Unit (Hot Melt + Quick Melt Unit) SP30 (High Melt + Edge Control EC 40) 2° Glueing Unit (Thermofusion with hot air) Air Force System Band Pressure zone (N.C. adjustment) . Edge coils supporting unit (No. 6 reels) Snipping (end-cutting) unit IT 90-X (Kw 0,65 x 2) speed 28m/min. 0 - 25° Rough Trimming unit RS 10 (2 x Kw 2) Fine Trimming unit (Multi-profile, by N.C.) RF 40 (Kw 1 x 2) 0 - 25° Multi Function Unit (Profile contour Trimming unit) AR 80 (Kw 0, 65 x 2) max speed 25 m/min - ROTAX motors with automatic tool change (tools) Profile Scraping unit (Multi-profile, by N.C.) RB 40 (multiprofile) Glue scraping unit RC 20 + Spraying Unit (for polishing liquid) Buffing unit SZ 30 (Kw 0,37 x 2)

Condition: excellent (used), Double-side Sizing & Edge Banding - First Machine (1st in a line) Double side TWIN machine (1 Left Side single machine + 1 Right-side sigle machine) Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3 Panels thickness (min/max) mm 10 / 60 Working width (min/max) mm 100 / 1200 Numerical Control PC base Windows /Software PC / SINTRA Adjustable feeding speed (m/min) 10 - 40 (INVERTER C.N.) SIZING PART (for each side): Spraying unit (Anti-sticking liquid) No. 2 Hogging Units (1 Top + 1 Bottom) DT 10 (Kw 5,8 x 2) Hnjdpfxju Rc Hyo Ahujg Free space EDGE-BANDING PART (for each side): 1° Glueing Unit (Hot Melt Glue + Quick Melt system) SP 30 (High Melt + Edge Control EC 40) 2° Glueing Unit (Thermofusion with hot air) Air Force System Band Pressure zone (N.C. adjustment) Edge coils supporting unit (No. 6 reels) Rough Trimming unit RS 10 (2 x Kw 2) Fine Trimming unit (Multi-profile, by N.C.) RF 40 (2 x Kw 1) 0°-25° No. 1 Milling grooving unit EB 60 (1 x Kw 5) 0°-90°, ISO 30 motor Profile Scraping unit (Multi-profile, by N.C.) RB 40 Glue scraping unit RC 20 Spraying Unit (for polishing liquid) Buffing unit SZ 30 (2 x Kw 0,37)

Condition: excellent (used), ELECTRONIC (CNC control) machine, Numerical Control Type NC 500 - Software Tooling System N. 2 Through-feed motorized conveyoring belts - Feeding speed (m/min) 35 - 75 ca. N. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 x HP 1,8 Hedpfxshvi Duj Ahuong Max. working width (mm) 3200 - Min. working width (mm) 215 N. 7 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 N. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 x HP 1,8 N. 5 Vertical top pressure clamps - N. 2 Motorized endless screws to evacuate wastes/chips The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the vertical movement (Hv) of the 2 horizontal units The CNC controls the movement (X axe) of all the vertical units The CNC controls the movement (Y1 and Y2 axes) of the boring heads The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the pressure clamps The CNC controls the movement (X axe) of the conveyor belts The CNC controls programming of the working cycles
