Used Chiron Milling Machine for sale (88)

Condition: good (used), Year of construction: 2007, functionality: fully functional, Vertical CNC Machining Center Chiron FZ OSK S Magnum SK with NC swivel head, rotary table package, bar feeder, and discharge unit Year of manufacture: 2007, Factory overhaul in 2017 Operating hours approx. 22,500 h Technical data: Siemens 840D (PCU 20 / NCU 572.4) NC swivel head, swivel range -20° / +115°, water-cooled motor spindle, 15,000 rpm. Axes travel X 450mm / Y 270mm / Z 310mm Rapid traverse in X / Y / Z: 75 m/min. / Acceleration: X 1g / Y 1.5g / Z 2g 40 tool stations HSK-A 40, chip-to-chip time 2.6 sec. (vertical, to DIN standard) Additional equipment: Preparation for bar machining Rotary table package AWU 160 with D105mm (positioning axis), Hainbuch Spanntop collet chuck D100, additional equipment for 6th side machining Part removal handling and discharge unit for finished parts, bar loader IRCO SiMag 100.1-3000 (for round and profile material) Coolant gun, machine prep for high-pressure ICS 70 bar (vario-valve), fixture flushing Scraper-belt chip conveyor with discharge height 1050 mm, vacuum rotation filter VRF 400 ltr., manufacturer KNOLL MAHLE dual change-over filter Electrical cabinet cooler, signal light Tool life monitoring, tool breakage control, Single F500 3D probing system, Renishaw TS27R Brankamp Marposs collision monitoring CMS 100 Accessories: Breuning IRCO guide channel sets and Hainbuch collets (as per agreement) HSK-A40 tool holders Spare parts for this machine type including special operating materials Note on machine concept: Unmanned complete machining 24/7 of cubic components. Material supply via bar loader D100 / 3000 mm for round and profile material. Rotary table as positioning axis and machining of 4 surrounding faces via vertical milling spindle. Machining of the end face (5th side) horizontally with swivel head. Clamping of workpiece via clamping stock, separating workpiece and 180-degree rotation, machining of the 6th side again horizontally with swivel head. Removal handling and discharge unit into parts buffer. Note on machine condition: The machine was factory overhauled and technically updated in 2017 by Chiron (CMS). The last spindle replacement was carried out in September 2025. Itedpfeypbmcex Aaysk The last manufacturer service was in October 2025 (major annual maintenance, 4,000 h). From new until today, the machine has been continuously maintained, repaired, and kept up-to-date by the manufacturer through a full-service contract (preventive maintenance).

Condition: excellent (used), Year of construction: 2015, operating hours: 14,000 h, Chiron Mill FX 800 machining center with 148-position background magazine TECHNICAL DATA Travel, X-axis: 800 mm Travel, Y-axis: 630 mm Travel, Z-axis: 550 mm Swivel axis: +- 120 ° Rotary axis: 360° Rapid traverse speed, X-axis: 60 m/min Rapid traverse speed, Y-axis: 60 m/min Rapid traverse speed, Z-axis: 60 m/min Spindle, max. torque: 180 Nm Spindle power: 17.0 - 47.2 kW Spindle, speed: 12`000 rpm Itedpstvz Azjfx Aayjk Tool holder: HSK-A 63 Rotary table, diameter: 280 mm Thread and fitting hole pattern M16 x 15 H7 X 50 Load capacity: 320 kg SCOPE OF OFFER U.A: (list not exhaustive): Chiron machining center, Year of construction: 2015 Knoll chip conveyor 750 K-1/150 BMF TPF 350S high-pressure pump Renishaw RLP40Q touch probe Receiver: Renishaw RMI-Q Mechatronic flow sensor SB0500 Background magazine, 148-fold Operating documentation Exact scope of supply according to photo gallery No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: ready for operation (used), Year of construction: 1999, Chiron FZ 12 W High Speed Year: 1999 Control: Siemens Sinumerik Type: Vertical machining center with pallet changer Axes travel X axis: approx. 550 mm Y axis: approx. 300 mm Z axis: approx. 425 mm Spindle Spindle taper: SK40 Spindle speed: approx. 10,000 to 10,500 rpm Spindle motor power: approx. 9 to 15 kW Tool system Tool changer capacity: approx. 12 to 20 positions Itsdjy E Ihgopfx Aayjk Max tool weight: approx. 4 kg Tool holder: SK40 Table Table size: approx. 660 x 350 mm Max workpiece weight: approx. 150 kg Table type: pallet changer system Electrical data Voltage: 400 V or 230 V Frequency: 50 to 60 Hz Power consumption: approx. 11 kVA Current: approx. 15 A Machine dimensions and weight Weight: approx. 4000 kg Length: approx. 3000 to 3500 mm Width: approx. 2500 to 3000 mm Height: approx. 2500 to 3000 mm Coolant system Manufacturer: Knoll Type: 340 K 1 600 Year: 1999

Condition: excellent (used), Vertical Machine Center Chiron FZ12W Magnum Sinumerik 810 M Max RPM 8.000 rpm./min, X = 550 mm Y = 300 mm Z = 425 mm 2 x 4th axis Peiseler RT 160 hydraulik brake Nose tool SK 40, Cooling throw spindel IK ATC 20 pcs Itodpfx Ajlng D Aeayjk Machine is still running the production, and can be inspected any time Machine in very good technical condition. I am giving 3 months startup guarranty

Condition: good (used), Year of construction: 2004, travel distance X-axis: 6,000 mm, travel distance Y-axis: 630 mm, Chiron Mill 6000 / 2013, completely overhauled by Chiron. Year of manufacture: 2004 / overhauled in 2013. Equipped with Siemens 840D control system. Travel X/Y: 6000/630 mm. Pendulum machining possible. 92-position tool changer. HSK-A 63 tool holder. Spindle speed up to 12,000 rpm. Spindle replaced in 2021. NC swivel milling head. Hydraulic unit with 210 bar. 2 hydraulic clamping circuits. Separate clamping pressure control per pendulum field. Clamping pressure monitoring. Pneumatic workpiece stop. 2 separately controllable pneumatic lifting devices. Brankamp collision monitoring system. Scraper belt conveyor. OKZ prepared. Knoll vacuum rotation filter. Rotating viewing window. Automatic loading doors. 5-axis milling package. IKZ 70 bar (internal coolant supply at 70 bar). Oil mist extraction. Pendulum machining possible. Pendulum machining X-axis travel: 1773 mm with face machining (tool length: 120 mm). Linear clamping system with 8 vices. Iedpfx Aaew N Nvfeystk

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, controller manufacturer: Siemens, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Number of axes: 4 Travel in X-axis: 2,000 mm Travel in Y-axis: 500 mm Travel in Z-axis: 550 mm C-axis rotation: 360° Control system: Siemens CNC Table length: 2,600 mm Table width: 550 mm Tool holder: ISO 40 Main spindle power: 22 kW Spindle speed max.: 12,000 rpm Positioning accuracy: 0.01 mm Travel speed: 667 mm/s MACHINE DETAILS Control system: Siemens CNC Connected power: 24 kW Dimensions & Weight Dimensions (L x W x H): 7,500 x 3,700 x 2,500 mm Empty weight: 9,600 kg Transport packages: 2 EQUIPMENT Documentation CE marking Iodpfx Aaezuw Aioyjtk

Condition: ready for operation (used), Year of construction: 2011, operating hours: 21,578 h, travel distance X-axis: 630 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 360 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 12,000 rpm, number of axes: 4, This 4-axis CHIRON DZ15KWM HS was manufactured in 2011. Ideal for precision vertical machining, this model offers robust construction and reliable performance. If you are looking to get high-quality milling capabilities, consider the CHIRON DZ15KWM HS machine we have for sale. Contact us for more information. Extra Information Itodpjzicf Sjfx Aayjk • Machine still under power • Table width 860 mm • Spindle spacing 320 mm • Tool positions 24 • Tool holder HSK63 • Hours 21578 • Internal coolant pressure: 80 bar Optional for extra charge • Optional for extra costs: Tool holders available. see pictures • Kuka robot (see nameplate attached for specification) • Platform, robot base, control cabinet including electronics, fence including door and locking mechanism • 3 conveyor belts including sensors, camera including lighting, automatic washing and blow-off station • Gripper including sensors, PC and touchscreen Technical Specification Taper Size HSK 63 Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2007, A CNC machining center Chiron factory-overhauled by the manufacturer in 2017 is available. Travel path X/Y/Z: 450mm/270mm/310mm, NC head swivel: -20°/115°, tool positions: 40, tool holder: HSK-A40, speed: 15000rpm, control: Siemens 840D, operating hours: approx. 22500h. Including rotary table package AWU 160 with D105, collet chuck, handling, bar feeder Irco SiMag 100.1-3000, through-coolant preparation, scraper belt conveyor (1050mm), duplex filter Mahle, vacuum rotary filter Knoll VRF 400, approx. 500 tool holders HSK-A40 and various spare parts. Documentation vorhanden. An inspection on site is possible. Isdpfxjyn Nz Eo Aayotk

Condition: used, TECHNICAL DETAILS - Number of axes : 7 MILLING SPINDLE - Tool holder type : HSK40 - Spindle speeds : 30.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 450 x 270 x 310 [mm] - Rapid traverses rates (X/Y/Z) : 75 [m/min] B ROTARY AXIS - Travel : -20/+115 [°] - Indexing precision : 0,001 [°] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 20 A ROTARY AXIS - Max. bar diameter : 32 [mm] - Indexing precision : 0,001 [°] - Travel : 360 [°] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 17 [kVA] WEIGHT & DIMENSIONS Itjdpjuhbtqefx Aaysk - Machine floor space : 1.500 x 2.600 [mm] - Machine height : 2.300 [mm] - Machine weight : 5.100 [kg] MACHINE HOURS - Number of working hours : 20.749 [h] EQUIPMENT - CNC : Fanuc 31i-A5 - Interface : USB, PCMCIA, RJ45 - Fire extinguisher * : KRAFT&BAUER FB703 * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Coolant tank - Spindle cooling unit - Oil mist extractor : HIFI FILTER - Tool probe : Renishaw TS27R - Workpiece probe : Renishaw OMP40 - Unit for 6th face machining - Collet chuck : ORTLIEB KSF 30-50 - Tool recognition through RFID scanning : BALLUFF BIS C-650 - Tool-holders : 30

Condition: used, TECHNICAL DETAILS - Number of axes : 7 MILLING SPINDLE - Tool holder type : HSK40 - Spindle speeds : 30000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 450/270/310 [mm] - Rapid traverses rates (X/Y/Z) : 75 [m/min] B ROTARY AXIS - Travel : -20/+90 [°] - Indexing precision : 0.001 [°] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 40 TURNING SPINDLE - Spindle speeds : 8000 [rpm] - Max. bar diameter : 32 [mm] - C axis indexing precision : 0.001 [°] - Travel : 360 [°] POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 1500X2600 [mm] - Machine height : 2300 [mm] - Machine weight : 2850 [kg] MACHINE HOURS EQUIPMENT - CNC : Siemens 840 D Itjdpfx Aaouhbr Tsysk - 3 colors status lamp

Condition: repair required (used), Year of construction: 1991, operating hours: 40,000 h, functionality: limited functionality, machine/vehicle number: 109-43, travel distance X-axis: 550 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 425 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, feed rate X-axis: 4,000 m/min, feed rate Y-axis: 4,000 m/min, feed rate Z-axis: 4,000 m/min, nominal power (apparent): 13 kVA, torque: 35 Nm, controller manufacturer: Fanuc OMB, controller model: 9030556, workpiece length (max.): 220 mm, workpiece diameter (max.): 65 mm, total height: 2,600 mm, total length: 2,800 mm, total width: 1,800 mm, table width: 370 mm, table height: 900 mm, table length: 950 mm, table load: 500 kg, overall weight: 2,500 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 6,000 rpm, distance table center to spindle nose: 615 mm, number of slots in tool magazine: 12, input voltage: 380 V, Equipment: chip conveyor, rotational speed infinitely variable, Chiron Fz 12 S, year of manufacture 1991. Additional indexing device. Currently with a measurement system error on the B-axis. The machine can be inspected at any time during regular opening hours. Itsdpfx Asy R Dqhsayok

Condition: excellent (used), Year of construction: 2002, CHIRON FZ 15S with 4 axis in Perfect Condition Machine can be inspected any time under power Itsdpfx Aergqu Hoayjk

Condition: not inspected (used), Year of construction: 1994, travel distance X-axis: 630 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 426 mm, overall weight: 6,500 kg, number of slots in tool magazine: 20, FZ18W magnum rotary indexing table, Fanuc OM control BT40 spindle, maximum spindle speed 8,000 RPM 20-tool changer Itsdpfx Aaezbal Isyok 2 tables Nikken dividing head

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 425 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, torque: 90 Nm, controller manufacturer: Siemens, controller model: 840D PL, overall weight: 10,000 kg, spindle speed (max.): 12,000 rpm, coolant supply: 25 bar, number of spindles: 1, number of slots in tool magazine: 20, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, We are Chiron experts. The machine is currently being partially overhauled and is in very good condition. If a probe or another option is needed, we can gladly provide it for an additional charge. FZ15W with 4th and 5th axis Machine dimensions: Isdpfx Aajwpcfueyetk approx. 4200mm x 2400mm Travel range -X = 730mm -Y = 400mm -Z = 425mm Control: 840D Powerline Main spindle: -Speed: 12,000 rpm -Tool holder: SK40 -Torque: max. 90NM Tool changer -Tool places: 20 Workpiece changer -Peiseler table with Afrocontroller Chip conveyor Coolant system with internal and external cooling Hydraulic clamping device Complete documentation available Geometry tip-top HS runout 0.008mm QC20 measurement 12.6µm (Manufacturer's tolerance 18µm, new machine 23µm, used machine) The machine can be inspected under power.

Condition: excellent (used), Year of construction: 2013, Heidenheim TNC 530, SK 40, 12,000 rpm, 40 tool positions, through-spindle coolant, direct measuring system on all axes, central lubrication system, automatic loading doors, measuring probe, Ijdpfexfqyvox Aayetk

Condition: ready for operation (used), Year of construction: 2007, operating hours: 22,500 h, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, controller manufacturer: SIEMENS, controller model: 840D, spindle speed (max.): 15,000 rpm, number of axes: 5, This 5-axis CHIRON FZ 08K S Magnum SK was manufactured in 2007. It features a Siemens 840D control unit, with impressive travels of 450 mm in the X-axis, 270 mm in the Y-axis, and 310 mm in the Z-axis. The machine includes a 40-position tool changer and a high-pressure coolant system. If you are looking to get high-quality machining capabilities, consider the CHIRON FZ 08K S Magnum SK vertical machining centre we have for sale. Contact us for further details. • Overhaul: Factory overhauled and technically updated by Chiron (CMS) in 2017 • Last Spindle Replacement: September 2025 • Last Maintenance: Major annual service (4,000 h) performed in October 2025 • NC Swivel Head Range: −20° / +115° • Rapid Feed X/Y/Z: 75 m/min • Acceleration X/Y/Z: 1g / 1.5g / 2g • Tool Changer: 40 positions, HSK-A40 • Chip-to-Chip Time: 2.6 s (vertical) • Rotary Table: AWU 160 with D105 mm positioning axis • Operating Hours: Approximately 22,500 h Additional equipment • Clamping: Hainbuch Spanntop D100 collet chuck • Bar Loader: IRCO SiMag 100.1-3000 for round and profile material • High Pressure Coolant: 70 bar with Vario valve • Coolant Filtration: Knoll VRF, 400-liter vacuum rotation filter • Chip Conveyor: Scraper belt, 1,050 mm discharge height • Measurement/Monitoring: Renishaw TS27R 3D touch probe; tool life monitoring; tool breakage control Itjdoypb Tpopfx Aaysk • Collision Monitoring: Brankamp Marposs CMS 100 • Guide Channel Sets: Breuning IRCO sets included (by arrangement) • Collets: Hainbuch collets included (by arrangement) • Tool Holders: Approximately 500 pieces HSK-A40 • Spare Parts: Included for this machine type • Operating Materials: Specific operating fluids/materials included

Condition: good (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 183-89, CNC Vertical Machining Center Make: CHIRON Group Model: CHIRON FZ 12 W Year of manufacture: 1999 Machine No.: 183-89 Typical technical specifications of the CHIRON FZ 12 W: Machine type: Control system: usually Siemens 840D or Heidenhain X-axis travel: approx. 550 mm Y-axis travel: approx. 300 mm Z-axis travel: approx. 425 mm Table size: approx. 660 × 350 mm Table load capacity: approx. 500 kg Spindle speed: depending on version, 10,000 – 20,000 rpm Tool holder: SK40 or HSK-A63 Tool changer: 12–24 positions Itsdpfey Sr Iksx Aayok Rapid traverse: up to 60 m/min Main spindle power: approx. 10–15 kW Coolant system Central lubrication Fully enclosed safety cabin Machine weight: approx. 4,500–5,500 kg The machine is part of CHIRON's well-known FZ series and is especially suited for high-speed aluminum and steel machining.

Condition: ready for operation (used), Year of construction: 1998, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 630 mm, controller manufacturer: SIEMENS, table width: 850 mm, table length: 1,250 mm, overall weight: 8,000 kg, spindle speed (max.): 10,500 rpm, number of slots in tool magazine: 24, number of axes: 3, This 3-axis CHIRON DZ 18 W MAGNUM was manufactured in 1998. It features an X-axis travel of 400 mm, Y-axis travel of 400 mm, and Z-axis travel of 630 mm. The machine includes a table size of 1250 × 850 mm and a tool magazine capacity of 24 tools. If you are looking to get high-quality machining capabilities, consider the CHIRON DZ 18 W MAGNUM vertical machining centre we have for sale. Contact us for further details. - Control System: Siemens CNC- Spindle Taper/Chuck: SK40- Spindle Speed Range: 320 – 10,500 rpm- Tool Magazine Capacity: 2 × 12 slots (24 tools total)- Tool Change Time: approx. 1.9 s- Chip-to-Chip Time: approx. 3.9 s- Retrofit/Overhaul Date: 2021 - Complete modernization: Ijdpfozcyh Eex Aayetk • main spindles overhauled • ball screws replaced • tool changer overhauled, • axis systems/guides/bearings overhauled • hydraulic/pneumatic systems updated • electrical system and cabling modernized • safety elements replaced • geometry adjusted- Cooling System: Internal cooling (IKZ) via Knoll paper band filter and high-pressure unit (Unit Number: 646)- Chip Management: Integrated chip conveyor and swarf bin- Workholding: Hydraulic workpiece clamping on a 180-degree workpiece changing table (W-axis)- Additional Features: Prepared for 4th/5th axis integration, attached cabinet climate control unit

Condition: used, Year of construction: 2017, operating hours: 18,074 h, machine/vehicle number: 302-58, Travel ranges (X/Y/Z): 550/300/425 mm, spindle speed max.: 10,500 rpm, tool holder SK 40, machine weight: 6,500 kg, control system SIEMENS Sinumerik 840 D, chip conveyor KNOLL 600 K-1/320, belt filter system BÜRENER MASCHINENFABRIK KA M. TPF 150/510S, year of manufacture: 2017, rotary table. Drilling emulsion/lubricants must be extracted and disposed of by the customer in a professional manner. Itodpfx Aezqy Utsayek

Condition: ready for operation (used), Year of construction: 2002, operating hours: 76,130 h, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 426, overall weight: 5,700 kg, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 48, number of axes: 5, This 5-axis CHIRON FZ 15FX was manufactured in 2002. It features a spindle speed of 12,000 rpm and a 48-station tool magazine for efficient operation. The machine is equipped with a Peiseler rotary table and an internal through-spindle cooling system, ensuring optimal performance. If you are looking to get high-quality machining capabilities, consider the CHIRON FZ 15FX vertical machining centre we have for sale. Contact us for further details. - Kinematics: 5-axis (3+2 axes configuration)- A axis range is between A -100 -> +90- Table System: Peiseler rotary table equipped with LANG clamping system- Cooling System: Internal through-spindle cooling system- Chip Management: Chip conveyor- Workpiece Measuring: Renishaw probe- Manual Operation: Operator's handwheel- Working Voltage: 400 V- Control Voltage: 230/24 V- Frequency: 50/60 Hz- Current Type: 3/N/PE ~- Rated Current: 67 A- Rating/Power: 47 kVA- Fuse Protection: 80 A Iodpfezgf Ttjx Aaystk Technical Specification Through-spindle Coolant Yes

Condition: ready for operation (used), Year of construction: 2019, operating hours: 13,572 h, travel distance X-axis: 800 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 450 mm, controller manufacturer: FANUC, controller model: 31i-B5, spindle speed (max.): 12,000 rpm, spindle motor power: 22,000 W, tool weight: 8,000 g, number of axes: 5, This 5-axis CHIRON FZ18W was manufactured in 2019, featuring a FANUC 31i-B5 control system and continuous 5-axis control. It boasts a spindle speed of up to 12,000 rpm, a tool capacity of 70, and rapid traverse rates of 75 m/min. Ideal for complex machining tasks with its automatic pallet changer and dual rotary tables. If you are looking to get high-quality milling capabilities consider the CHIRON FZ18W machine we have for sale. Contact us for more information. • Number of axes: 5 (X, Y, Z + 2 rotary axes via pallet/rotary table) • Spindle: • AC spindle motor: 7.5 kW (100% duty), 22.0 kW (10% duty) • Max torque: 140 Nm • Taper: HSK-A63 (DIN 69893) • Drilling capacity: Ø 42 mm • Tapping capacity: M30 • Milling capacity: 500 cm³/min (steel E355) • Tool changer: • Type: Fully enclosed chain magazine • Capacity: 70 tools • Max tool Ø: 78 mm (160 mm with free adjacent positions) • Max tool length: 380 mm • Max magazine load: 240 kg • Tool change time: ~0.9 s • Chip-to-chip time: ~2.6 s • Feed rates & dynamics: • Rapid traverse (X/Y/Z): 75 m/min • Acceleration: 0.6 – 1.2 – 1.4 g • Drives: Direct digital drives with absolute measuring system • Machine functions/utilities: Itedpfoyaz Emox Aaysk • Automatic washdown of work area and fixtures • Automatic centralized grease lubrication • Hydraulic unit: 200 bar • Compressed air treatment with filtration to 0.01 µm • Cooling unit for machine components • Measuring, monitoring, software: • FANUC 3D collision control • Tool monitoring and sister tool management • Electrical & interfaces: • Ethernet RJ45, USB, PCMCIA • Remote diagnostics: CHIRON remoteLine • Data monitoring & OEE: CHIRON dataLine • Compliance: CE Additional equipment (robots, automation, peripherals) • Automation/palletizing: • Automatic pallet changer IWV 0°/180° (change time ~3.5 s) • Rotary table ATU 200, 2 units • Positioning accuracy/repeatability: ±5″ • Max clamping torque: 1,200 Nm • Max load per side (APC): 250 kg • Max weight difference between pallets: 0 kg • Coolant and chip management: • Through-spindle coolant (predisposition) • High-pressure coolant system up to 30 bar • Coolant filtration: Drum filter TPF 350 S (50 µm) • Chip conveyor: Hinged belt • Coolant tank: 230 L • Pump: 250 L/min @ 1.4 bar • Probing/tool control: • Renishaw RLP40Q probe (predisposition) • Laser tool breakage control (Single F1000)

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-88, Technical specifications: # Working area: X 550 mm; Y 400 mm; Z 360 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary axes B with indexing head, direct angular measuring system, max. speed 50 rpm, accuracy +/- 5" # A-axis swivel: +/-110˚ # Max. clamping/part size: Ø247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between dividing heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools, tool-to-tool average 2.5 sec # Max. tool diameter: Ø82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical system: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: Isdoxw Uplspfx Aayotk # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Power Line # Chip conveyor: Spring Knoll # Oil cooling unit # Oil filtration system up to 80 bar: Knoll HL 450/1200 # Shaft, linear guide and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery unit: LTA AC3002 # Fire suppression: Kraft & Bauer # Part presence check with low-pressure air sensors # In-process control: Marposs T25 # Tool support monitoring system at spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Operator protection screen damaged – operator panel functional # Tool magazine chain # Ballbar X # Ballbar Y # Pullbar spindle # Axis drive power supply X # Axis drive power supply Y # Main drive power supply # Complete hydraulic unit defective

Condition: used, Rotary indexing thread tapping machine, 8-station rotary table. 1 inspection station, 1 vertical and 1 horizontal thread tapping unit. With guide bush 1 mm pitch Chiron, thread tapping unit with guide bush 0.7 mm pitch, M4. One discharge station, coolant system. Iedpfjyl Ntpex Aayetk

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-89, Technical characteristics: - Machining workspace: X 550 mm; Y 400 mm; Z 360 mm - Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary divider head axes B, equipped with direct angular measuring system, max rotation speed 50 rpm, accuracy +/- 5" - Axis A swivel range: +/- 110° - Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg - Rapid traverse rate: X/Y/Z 40/40/40 m/min - Distance between divider heads B1/B2: 250 mm - Spindle speed: 1–10,000 rpm - Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) Itjdpfx Aaexxi Rmjyjk - Automatic tool changer: 1x48 positions / chip-to-chip average 2.5 sec - Max. tool diameter: 82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical specifications: - Supply voltage: 3x400V/50Hz - Installed power: approx. 45 kVA / 80A Dimensions: - Installation space: approx. 4.4 x 2.3 x 3.1 m - Weight: approx. 8,500 kg Equipment includes: - CNC control: Siemens 840D Power Line - Chip conveyor: Spring Knoll - Oil cooling system - High-pressure oil filtration system (max. 80 bar): Knoll HL 450/1200 - Shaft cooling system, guideways and control cabinet - 2 oil lubrication units - Oil mist extraction/recovery: LTA - Fire protection: Kraft & Bauer - Part presence P/Y detection: with low-pressure air sensors - In-process inspection: Marposs T25 - Tool holder presence detection in spindle - Documentation: incomplete Machine status: NOT OPERATIONAL: Hydraulic power unit motor burned out.

Condition: used, Year of construction: 2015, CNC machining center Manufacturer: Chiron Type: FZ 12 W Magnum Year of manufacture: 2015 CNC control: Siemens 840D solution line Travel distances: X/Y/Z = 550 x 400 x 360 mm Spindle: 15,000 rpm Tool interface: HSK63 Internal coolant supply Rotary table Integrated workpiece changer 32-position tool changer Isdpezfppcsfx Aaystk Glass scales Chip conveyor Laser control for breakage monitoring 3826
