Used Chiron Milling Machine for sale (106)

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, controller manufacturer: Siemens, controller model: 840Dsl, General Speed: 10,500 rpm Max. power: 23.3 kW Tool holder: SK 40 Travel X: 550 mm Travel Y: 400 mm Travel Z: 425 mm Cpjdpoyimyuefx Ah Isw Tool changer: 20 stations

Condition: used, Year of construction: 2015, x-axis 1250 mm y-axis 840 mm z-axis 550 mm control Siemens 840D turning speed range - main spindle 12000 min/-1 drive capacity - main spindle 22,5 kW Torque max. 140 Nm Number of tools 24 St. max. tool length 320 mm spindle taper HSK 63 Number of working hours 56000 h spindle hours 17500 h Cpodjx I Sh Aepfx Ah Isw weight of the machine ca. 9,7 t This machine can be viewed under power by appointment and is in our estimation in very good condition. Furnishing: - IKZ - chip conveyor - Glass measuring rods in all axes - automatic door - Swivel axis with counter bearing, Fibro There are 4 identical machines available. The machines were used for light countersinking and drilling work. Changes and errors in the technical data and information, as well Subject to prior sale!

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 194-03, travel distance X-axis: 2,000 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 425 mm, table width: 450 mm, table length: 2,280 mm, TECHNICAL DETAILS Travel X-axis: 2,000 mm Travel Y-axis: 400 mm Cpsdeyhnfcjpfx Ah Iow Travel Z-axis: 425 mm Total number of axes: 3 Table length: 2,280 mm Table width: 450 mm Number of T-slots: 3 T-slot spacing: 150 mm T-slot width: 18 mm Spindle speed: 10,500 rpm Number of tools: 20 Tool diameter: 65 mm Diameter with free adjacent slots: 180 mm Max. tool length: 220 mm Max. tool weight: 8 kg MACHINE DETAILS Control: SIEMENS SINUMERIK 810 M Connection: 50 Hz 3x 400 Volt Spindle motor: 18 kW Total power requirement: 31 kVA Dimensions & Weight Dimensions (L x W x H): 4,000 x 3,010 x 3,040 mm Machine weight approx.: 7,200 kg EQUIPMENT Coolant system Chip conveyor Electronic handwheel

Condition: used, Year of construction: 2014, operating hours: 73,912 h, functionality: fully functional, machine/vehicle number: 173-95, travel distance X-axis: 550 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 425 mm, torque: 90 Nm, controller manufacturer: Siemens, spindle speed (max.): 10,500 rpm, coolant supply: 30 bar, number of spindles: 3, number of slots in tool magazine: 20, input voltage: 380 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, The machine is fully functional and can be inspected on site. Maintenance has been carried out exclusively by Chiron. Weight: 8,000 kg. CE certificate. Price: 20,000 euros in EXW condition. Cpjdpfjylw E Hox Ah Isw

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-06, Technical Specifications: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + 1 rotary axis (rotary table A) and 2 rotary axes (B, indexer head) with direct angular measuring system, maximum 50 rpm, accuracy +/- 5 seconds # A axis swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1–10,000 rpm # Spindle taper: DIN69893-HSK-A63 (with internal coolant) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max tool diameter: Ø82 mm / max. length 250 mm / 5 kg Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation area: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Powerline # Chip conveyor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, max. 80 bar: Knoll HL 450/1200 # Shaft, guideways, and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery: LTA AC3002 # Fire protection: Kraft & Bauer Csdpfx Asxxivceh Iepw # Presence detection: with low pressure air sensors (part present) # In-process control: Marposs T25 # Tool breakage monitoring: Blum Novotech # Tool presence detection system in spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Cover for tool magazine # Tool magazine presence sensor (BERU)

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-89, Technical characteristics: - Machining workspace: X 550 mm; Y 400 mm; Z 360 mm - Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary divider head axes B, equipped with direct angular measuring system, max rotation speed 50 rpm, accuracy +/- 5" - Axis A swivel range: +/- 110° - Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg - Rapid traverse rate: X/Y/Z 40/40/40 m/min - Distance between divider heads B1/B2: 250 mm - Spindle speed: 1–10,000 rpm - Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) - Automatic tool changer: 1x48 positions / chip-to-chip average 2.5 sec - Max. tool diameter: 82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Cpodpfx Ajxxi Rmeh Iew Electrical specifications: - Supply voltage: 3x400V/50Hz - Installed power: approx. 45 kVA / 80A Dimensions: - Installation space: approx. 4.4 x 2.3 x 3.1 m - Weight: approx. 8,500 kg Equipment includes: - CNC control: Siemens 840D Power Line - Chip conveyor: Spring Knoll - Oil cooling system - High-pressure oil filtration system (max. 80 bar): Knoll HL 450/1200 - Shaft cooling system, guideways and control cabinet - 2 oil lubrication units - Oil mist extraction/recovery: LTA - Fire protection: Kraft & Bauer - Part presence P/Y detection: with low-pressure air sensors - In-process inspection: Marposs T25 - Tool holder presence detection in spindle - Documentation: incomplete Machine status: NOT OPERATIONAL: Hydraulic power unit motor burned out.

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 191-88, Technical specifications: # Working area: X 550 mm; Y 400 mm; Z 360 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis A and 2 rotary axes B with indexing head, direct angular measuring system, max. speed 50 rpm, accuracy +/- 5" # A-axis swivel: +/-110˚ Csdjxw Upljpfx Ah Ispw # Max. clamping/part size: Ø247 x 830 mm; max. weight 360 kg # Rapid traverse rate: X/Y/Z 40/40/40 m/min # Distance between dividing heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools, tool-to-tool average 2.5 sec # Max. tool diameter: Ø82 mm / max. tool length: 250 mm / max. tool weight: 5 kg Electrical system: # Voltage: 3x400V/50Hz # Installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment includes: # CNC control: Siemens 840D Power Line # Chip conveyor: Spring Knoll # Oil cooling unit # Oil filtration system up to 80 bar: Knoll HL 450/1200 # Shaft, linear guide and electrical cabinet cooling system # 2 oil lubrication systems # Oil mist extraction/recovery unit: LTA AC3002 # Fire suppression: Kraft & Bauer # Part presence check with low-pressure air sensors # In-process control: Marposs T25 # Tool support monitoring system at spindle # Documentation: incomplete Machine condition: NOT OPERATIONAL # Operator protection screen damaged – operator panel functional # Tool magazine chain # Ballbar X # Ballbar Y # Pullbar spindle # Axis drive power supply X # Axis drive power supply Y # Main drive power supply # Complete hydraulic unit defective

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-09, Technical Characteristics: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + rotary table axis A and 2 rotary axes B, equipped with an index divider head with direct angular measuring system, max. rotation speed 50 min⁻¹, accuracy +/- 5" # Axis A swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg # Rapid traverse: X/Y/Z 40/40/40 m/min # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max. tool diameter: Ø 82 mm / max. length 250 mm / max. weight 5 kg Electrical Connection: # Voltage: 3x400V/50Hz # Total installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment Includes: # CNC control: Siemens 840D Power Line # Chip extractor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, up to 80 Bar: Knoll HL 450/1200 # Cooling system for spindle, linear guides, and control cabinet # 2 independent oil lubrication systems # Oil vapor extraction/recovery system: LTA AC3002 # Fire suppression system: Kraft & Bauer # Part presence detection: with low-pressure air sensors # In-process measurement: Marposs T25 # Tool breakage detection: Blum Novotech # Tool holder detection system in spindle # Documentation: incomplete Codpjxwmvkofx Ah Ispw Machine Condition: NOT OPERATIONAL # Hydraulic oil leakage at Peiseler rotary table # New hydraulic pump available in stock

Condition: good (used), Year of construction: 2014, functionality: fully functional, Siemens 840 control, pallet changer table, 20-position tool changer, through-spindle coolant (IKZ), Knoll coolant system. Cjdpfxeyg H U Hs Ah Iepw

Condition: excellent (used), Year of construction: 2002, CHIRON FZ 15S with 4 axis in Perfect Condition Cjdergqu Hspfx Ah Iopw Machine can be inspected any time under power

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, nominal power (apparent): 24 kVA, 2 PCS CNC CHIRON DZ15 W MAGNUM HS Drilling capacity in steel: 60: 2 x 6 36 mm (with indexable insert drill) Cpodpfxsyiyyuo Ah Iow Guides: with long-life grease lubrication Speed range: 20-12,000 rpm CNC control: SIEMENS 840D Distance between spindles on X-axis: 250 mm X-axis: 300 mm Y-axis: 400 mm Z-axis: 425 mm (with variable tool change plan) Rapid traverse: 60 m/min on X, Y, and Z axes Main spindle drive: 1 unit with 2 AC motors Power at 100% continuous operation: 9.5 kW Power at 15% intermittent operation: 14.0 kW

Condition: ready for operation (used), Year of construction: 2007, operating hours: 16,000 h, functionality: fully functional, machine/vehicle number: 259-45, travel distance X-axis: 800 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 550 mm, controller model: Siemens 840 D, spindle speed (max.): 12,000 rpm, The following automation is also being auctioned from the same location: System 3R Workpartner (Search ID: 21119877) System 3R Workpal 1 (Search ID: 21119737) System 3R Transformer Workmaster (Search ID: 21119557) TECHNICAL DETAILS X-axis travel: 800 mm Y-axis travel: 550 mm Z-axis travel: 550 mm Codpjyfum Usfx Ah Ijpw Tool holder: HSK 63 Spindle speed: 12,000 rpm Number of tool positions: 65 MACHINE DETAILS Control: Siemens 840 D Spindle hours: approx. 16,000 h EQUIPMENT Knoll chip conveyor Knoll paper belt filter Blum LaserControl laser measuring system Renishaw digital 3D touch probe Automation interface Automatic door Oil mist extraction Internal coolant supply

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 550 mm, controller model: Siemens 840D solution line, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 3,000 mm Travel Y-axis: 630 mm Travel Z-axis: 550 mm Rapid traverse speed: 60 m/min Spindle speed: 12,000 rpm Clamping area: 3,600 x 710 mm T-slots: 5 Number of axes: 3 Tool magazine: 40 positions Traverse path in pendulum mode per work area: 1,250 mm Csdpfoyfgf Nox Ah Ispw MACHINE DETAILS Control: Siemens 840D solution line Machine weight: 9,600 kg EQUIPMENT 24-position tool magazine Coolant system 900 l High-pressure system 30 bar Internal coolant supply tools Chip conveyor Hydraulic unit 200 bar 6 hydraulic connections for 200 bar 2 connector couplings A+B (3 per table side) Variable Chiron clamping logic Prosin Plus tool breakage monitoring for diameters > 3 mm Automatically opening and closing loading door Machine preparation for 1 x NC axis

Condition: used, Year of construction: 2014, x-travel 2000 mm y-travel 630 mm z-travel 550 mm Control Siemens 840 D total power requirement 7,5 - 22,5 kW weight of the machine ca. 10,5 t Maximum table load:1,000 kg / m table length Movement range: X-axis:2000 mm Y-axis:630 mm Z-axis:550 mm Speed range up to:12,000 min-1 Maximum speed range:140 Nm Drilling power:average 42 mm (with insert drill) Milling power:600 cm³/min Tool places:24 Tool shaft:HSK A 63 DIN 69893 Tool average:max. 75 mm Csdeyan Rcopfx Ah Ijpw Tool average with: free neighbouring places:max. 160 mm Tool length:max. 320 mm Tool weight:max. 8 kg (max. magazine load 100 kg Tool change time:approx. 1.5 s (depending on control

Condition: used, Year of construction: 1995, x-travel 2000 mm y-travel 425 mm z-travel 425 mm Number of working hours lässt sich nicht auslesen h cooling Kühlung ja max. 10.500 Csdper D Tu Ijfx Ah Iepw ja control Simens Sinumerik 810 weight 6700 kg

Condition: used, Year of construction: 2010, 2 Cpsdpfx Ahjqn A Rkj Isw Number of axles 4 St. tool taper HSK 63 toll turrets 60 weight 9600 kg

Year of construction: 2000, condition: used, serial number 143-86 x-travel 550 mm y-travel 300 mm z-travel 425 mm Number of working hours 58046 h cooling Innen nein max. 10.500 nein control Simens Sinumerik 810D Cjdpfor D Tu Dsx Ah Ijpw weight 4600 kg

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, For sale is a fully functional machining center of the Chiron type FZ 08 W. Cpsdpsx Swg Sjfx Ah Iew

Condition: excellent (used), Year of construction: 2006, HEIDENHAIN iTNC 530 control Working travels 550 x 400 x 360 mm Spindle taper HSK 63 Spindle speeds -20'000 rpm Tool magazine with 48 Pos. Swivel rotary table with B- + C-axis Roboter for workpiece loading EROWA ERS 3D-measuring tracer Misc. accessories MARCELS MASCHINEN CH Csdpfxox R Uxpo Ah Ispw

Condition: used, Technical details: x-travel: ca.1000 mm y-travel: 400 mm Cedju Idnmepfx Ah Iepw z-travel: 420 mm control: Siemens Sinumerik 805/810 thread cutting up to max.: M 22 bore capacity in St 60 - full boring: 25 mm milling area: Leistung in St 60:150 mm sawing stroke: ca. 55mm mm range of revolutions per minute - continous: 20-6000 U/min Number of working hours: manual 26180 h tool turret: 12 Plätze/places tool taper: SK 40 total power requirement: 18 kVA weight of the machine ca.: 5,0 t machine dimensions LxWxH: 2,9x2,5x2,8 m transport measurements machine: 2,4x2,6x2,75 m Equipment: - special equipment/device ( modulating clamping system) for milling jobs of profile materials with an automatic longtitudinal cutting to length device for workpieces via circular saw module. (without functionality) - hotrizontal tool clamping ( force fitted) with vise clamping system and parallel ledges.(momentarily approx. 80mm) - tool changer type Chiron - basket tool changer - tool clamping mechanically locked, infeed force 5000N - swarf conveyor make Knoll - loading and unloading system FMB LM RP 3000 The machine is not fuctional. On sale as is for a small budget i.D. *

Condition: good (used), Year of construction: 2006, operating hours: 9,911 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, rapid traverse X-axis: 75 m/min, rapid traverse Y-axis: 75 m/min, rapid traverse Z-axis: 75 m/min, nominal power (apparent): 17 kVA, total height: 2,300 mm, total length: 1,500 mm, total width: 2,600 mm, overall weight: 3,400 kg, spindle speed (max.): 30,000 rpm, spindle nose: HSK40, number of slots in tool magazine: 40, input voltage: 400 V, Equipment: documentation/manual, CNC machining center CHIRON FZ08 KS Magnum High Speed Plus (HSP) TECHNICAL CHARACTERISTICS: Year of manufacturing: 2006 CNC control : FANUC 18i-MB5 Number of axes : 7 Stroke X axis : 450 [mm] Stroke Y axis : 270 [mm] Stroke Z axis : 310 [mm] Traversing feeds X, Y and Z axes : 75000 [mm/min] Max. bar diameter in turning spindle : 32 [mm] Main spindle max. speed : 8000 [rpm] Main spindle max. power : 12 [kW] Angular A axis stroke : 360 [°] A axis indexing precision : 0.001 [°] B axis swivelling stroke : -20° / +115 [°] B axis indexing precision : 0.001 [°] Spindle type : HSK40 Max. spindle speed : 30000 [rpm] Tool changer magazin number of stations : 40 Part turnaround by robot (6th side machining) : Yes RS232 Interface : Yes Total power required : 17 [kVA] Supply voltage : 400 [V] Number of running hours : 9911 [h] Dimensions : 1500 x 2600 x 2300 [mm] Weight : 3400 [Kg] Cpjdpfex Iiw Isx Ah Isw EQUIPMENT INCLUDED: x1 RENISHAW TS27R tool probe x1 spindle cooling unit x1 parts catcher x1 coolant tank x1 unit for 6th face machining (gripping system not included) x29 tool holders type HSK40 BIG KAISER x10 collets type F37 SCHAUBLIN x1 washing gun x1 3-color status light x1 maintenance manual x1 electrical diagrams manual x1 operator's manual x1 programming manual Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed Machine similar to brands such as Okamoto, ELB, GER, Tacchella, Karstens, Jones & Shipman, Jung, Favretto, Blohm. Internal and external grinding (ID/OD) also to be considered. Surface grinder, lathe, machining center, milling machine.

Condition: used, Year of construction: 2011, functionality: fully functional, For sale are 2 CNC milling machines Chiron FZ 08K W, year of manufacture 2011, including automated loading – robot arm cell. The machines are in very good condition, have been regularly maintained, and are ready for immediate operation. They impress with their precision, reliability, and compact design – ideal for series production. Csdpfx Ahew Rba Se Iopw

Condition: excellent (used), Year of construction: 2006, operating hours: 14,300 h, functionality: fully functional, machine/vehicle number: 414-46, Year 2006 with Fanuc Series 18i-MB5 Country of manufacture: CE - Germany Net machine weight: 3,400 kg Dimensions: 185x259x250 cm TECHNICAL SPECIFICATIONS Travel X / Y / Z: 450 / 270 / 310 mm Acceleration X / Y / Z: 0.7 / 0.7 / 1.0 g Rapid traverse X / Y / Z: 40 / 40 / 60 m/min Spindle speed max.: 15,000 rpm Tool interface: HSK A 40 Milling capacity in St 60: max 60 cm3/min Drilling capacity in St 60: max Ø 16 mm Threading: up to M12 Tool magazine / positions: 24 – special version with 40 on this machine Tool change time: approx. 0.8 sec Chip-to-chip time: approx. 2.2 sec 5-axis version NC rotary tilting table: +/- 100° Rotary plate diameter: 100 mm Grid drill pattern: M6 x 50 mm Cedpfx Asxqmwbsh Iepw 4th axis speed: 40 rpm 5th axis speed: 60 rpm Direct measuring system for 4th and 5th axes: +/-20’’ / +/-20’’ Distance spindle nose – table surface: 170 – 450 mm Maximum workpiece weight: 6 kg Technical information is provided without engagement and subject to errors or omissions.

Condition: excellent (used), Year of construction: 2005, operating hours: 9,100 h, functionality: fully functional, machine/vehicle number: 414-38, TECHNICAL DATA Cpedpfokx Ek Tjx Ah Isw Travels  ; X / Y / Z 450 / 270 / 310 mm. Acceleration ; X / Y / Z 0,7 / 0,7 / 1,0 g Fast speeds ; X / Y / Z 40 / 40 / 60 m/min Spindle speeds max. 15’000 min-1 Tool connection HSK A 40 Milling cap. in St 60 max 60 cm3/min Drilling cap. In St 60 max dia. 16 mm Threading up to M12 Magazine / tool posts 24 – special on this one 40 Tool changing time abt. 0,8 sec. Time clamp-to-clamp abt. 2,2 sec. 5 axes execution NC Table tilting rotating +/- 100° Circular plates 100 mm « Rasterbohrbild » M6 x 50 mm Rotations 4th. axis 40 min-1 Rotations 5th. axis 60 min-1 Direct measuring system for 4th. And 5th. axis +/-20’’ / +/-20’’ Distance spindle nose – table surface 170 – 450 mm Max transportable weight 6 kg errors and omissions excepted-data given without obligation

Condition: good (used), CHIRON FZ 08 KS Magnum is a 5‑axis machining center engineered for precision, high accuracy and reliable production. Travels X450×Y270×Z310 mm; drilling 12 mm; tapping M8. Tool magazine 24 pos., tool Ø max 47 mm (100 mm free), length 160 mm, tool wt 1.2 kg. Spindle HSK‑A40 0–36000 rpm; spindle motor 7 kW; rapid 75 m/min; 3×400V 50Hz; air 6 bar; installed power 14 kW (19 kVA); machine ≈3400 kg; dims 2308×1405×2447 mm. Features: tool‑break control, RS232, switch‑cabinet air‑con, status light. Delivers tight tolerances for automotive, aerospace, medical, watchmaking. Codpfxoxx U Nze Ah Iepw
