Used Kunzmann Milling Machine for sale (74)

Condition: used, Year of construction: 2013, functionality: fully functional, KUNZMANN WF 600M Milling Machine (2013) Manufacturer: KUNZMANN Type: WF 600M Milling Machine Year of manufacture: 2013 Condition: Used X/Y/Z: 600/400/400 mm Spindle taper: SK 40 Milling table clamping area: 800 x 425 mm Clamping slots: 6 slots, width 14 H 7 Slot spacing: 63 mm Maximum load: 300 kg Kodpfezy Srcjx Ag Ajnc Spindle speeds S I: 1 – 1125 min-1 Spindle speeds S II: 1126 – 4500 min-1 Feed rate: 0 – 2000 mm/min Rapid traverse X and Y: 5000 mm/min Rapid traverse Z: 4000 mm/min Hydraulic clamping system Main drive motor: 5.5 kW Weight: approx. 2000 kg - Dimensions: approx. 2 x 2 x 2 m

Condition: excellent (used), Year of construction: 2009, operating hours: 2,542 h, Kunzmann WF 4/3 Milling Machine TNC 320 Manufacturer: Kunzmann Type: WF 4/3 Milling Machine Year of manufacture: 2009 Condition: used, from a training workshop, cleaned and operational, ready for demonstration Spindle hours: 2,542 hours X-axis travel: 400 mm Y-axis travel: 350 mm Z-axis travel: 400 mm Tool holder: SK 40 Spindle speeds: 1.0 - 4,500 rpm Feed rates: 0 - 2000 mm/min Quill stroke: 60.0 mm Table size: 650 x 350 mm T-slots: 14 H7 Control system: TNC 320 Motor power: 5.5 kW Weight: 1920 kg Space requirement: approximately 2000 x 2000 x 2100 mm Ksdpozza Smsfx Ag Ajnc Total power consumption: approximately 7 kVA Central lubrication system Coolant system CE compliant Scope of delivery: – Technical documentation – Full protection enclosure – LED machine light

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 124 control – in very good condition. CE compliant! Technical data: >> Year of manufacture 2000, machine no. 343017 >> Fixed angular table >> Speed: continuously variable up to 4000 rpm >> Feed rate: continuously variable in 3 axes from 0 to 2000 mm/min >> Travel distances X/Y/Z: 400/320/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg Knjdpfx Agez E R Ahj Aec >> Vertical quill stroke: 60 mm >> Vertical quill and horizontal quill – SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 13 KVA Accessories and equipment: >> Heidenhain TNC 124 control >> Hydraulic chuck, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control, and programming examples >> Handwheels >> Coolant system >> Electronic handwheel Heidenhain >> Heidenhain probe About the machine: Offered is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 124 control. This universal milling machine is in very good, original condition. It comes from a company where it was used primarily for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for both vertical and horizontal operation. The conversion from vertical to horizontal is very simple by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on-site while it is powered up.

Condition: like new (used), Kunzmann WF 7/3 Tool milling machine Kunzmann WF7/3 with Heidenhain TNC 124 control, manufactured in 1997, in good CONDITION. CE compliant!! The machine comes from the vocational school of the HWK Augsburg and, according to the master craftsman, has approximately 300 operating hours. Technical data: Knedpozy Uh Tofx Ag Aec Year of manufacture: 1997 Fixed angular table Clamping slots: 6 Slot width: 14 H 7 Slot spacing: 63 mm Maximum load: 300 kg Spindle speeds S I: 1 – 1125 min-1 Spindle speeds S II: 1126 – 4500 min-1 Feed rate (potentiometer 100%): longitudinal and transverse 0 – 2000 mm/min. Rapid traverse: longitudinal and transverse 5000 mm/min. Feed rate: vertical 0 – 2000 mm/min. Rapid traverse: vertical 4000 mm/min. Travel distances X/Y/Z: 600/400/400 mm Vertical and horizontal quill - SK40 Hydraulic clamping system Weight: approx. 2000 kg Dimensions: approx. 2 x 2 x 2 m Main drive motor: 7.5 kW Accessories and equipment: Heidenhain TNC 124 control Hydraulic chuck, vertical and horizontal Automatic central lubrication Spindle brake Technical documentation, spare parts diagrams, operating manual for the control unit and programming examples Handwheels Coolant system About the machine: Offered is a tool milling machine Kunzmann WF7/3 with a Heidenhain TNC 124 control. This universal milling machine is in very good original condition. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic clamping both vertically and horizontally. Switching from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on-site under power. You can find more milling machines from well-known manufacturers on our website.

Condition: like new (used), Year of construction: 2015, functionality: fully functional, Tool milling machine Kunzmann WF 400MA with Heidenhain 3-axis active digital display. Like-new condition. CE compliant! Technical data: >> Year of manufacture 2015, Machine no. 410749 >> Milling table clamping surface 600 x 375 mm Kjdpfx Ajztwy Esg Aonc >> 5 clamping slots >> Slot width 14 H7 >> Maximum load 250 kg >> Speed range 1-4500 rpm >> Feed rate up to 5 m/min >> Travel distances X/Y/Z: 410/350/450 mm >> Vertical and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Dimensions approx.: 2 x 2 x 2 m >> Main drive motor (100%/25% ED) 8.5/16.2 kW Accessories and equipment: >> Heidenhain 3-axis active digital display >> Hydraulic chuck, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual >> Coolant system About the machine: Offered is a Kunzmann WF 400MA tool milling machine with a 3-axis active digital display from Heidenhain. It proves its qualities daily in workshops, production facilities, and training centers. This universal milling machine is in like-new condition. Furthermore, the machine has hydraulic chucks for both vertical and horizontal operation. Converting from vertical to horizontal operation is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on site while it is powered up.

Condition: like new (used), Year of construction: 2016, functionality: fully functional, Tool milling machine Kunzmann WF 400MA with Heidenhain 3-axis active digital display – in like-new condition, CE-compliant!! Technical data: >> Year of manufacture 2016, machine number 410737 >> Milling table, clamping surface 600 x 375 mm >> 5 T-slots >> Slot width 14 H7 >> Maximum load 250 kg >> Speed range 1-4500 rpm >> Feed rate up to 5 m/min >> Travel distances X/Y/Z: 410/350/450 mm >> Vertical and horizontal quill – SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Dimensions approx.: 2 x 2 x 2 m >> Main drive motor (100%/25% duty cycle) 8.5/16.2 kW Accessories and equipment: >> Heidenhain 3-axis active digital display >> Hydraulic clamping, vertical and horizontal Knedeztw I Aopfx Ag Aec >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual >> Coolant system About the machine: Offered for sale is a Kunzmann WF 400MA tool milling machine with a 3-axis active digital display from Heidenhain. It proves its qualities daily in workshops, production facilities, and training centers. This universal milling machine is in like-new condition. Furthermore, the machine has hydraulic clamping in both the vertical and horizontal positions. Converting from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on-site while it is powered up.

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Kunzmann WF7/3 tool milling machine with Heidenhain TNC 124 control – in SUPER condition, CE compliant!! Technical data: >> Year of manufacture 2007, machine no. 370648 >> Swiveling and tilting table Kodpezq Edmjfx Ag Aonc 6 mounting slots Slot width 14 H7 Slot spacing 63 mm Maximum load 300 kg >> Spindle speeds S I 1 – 1125 min-1 Spindle speeds S II 1126 – 4500 min-1 >> Feed rate (potentiometer 100%) longitudinal and transverse 0 – 2000 mm/min Rapid traverse longitudinal and transverse 5000 mm/min Feed rate vertical 0 – 2000 mm/min Rapid traverse vertical 4000 mm/min >> Travel distances X/Y/Z: 600/400/400 mm >> Vertical and horizontal quill – SK40 >> Hydraulic clamping system >> Weight approx. 2000 kg >> Dimensions approx.: 2 x 2 x 2 m >> Main drive motor: 7.5 kW Accessories and equipment: >> Heidenhain TNC 124 control >> Hydraulic clamping, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual >> Coolant system About the machine: We offer a Kunzmann WF7/3 tool milling machine with a Heidenhain TNC 124 control. This universal milling machine is in very good condition. A special feature of this machine is the 4th axis and a digital display for the quill. It comes from a company belonging to an automotive manufacturer, where it was used primarily for training purposes. It has a very user-friendly control system. Furthermore, the machine has hydraulic clamping in both vertical and horizontal positions. Switching from vertical to horizontal is very easy by folding down the vertical head. The guides are lubricated regularly by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site while it is powered up.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 124 control – in very good condition, CE-compliant! Technical data: >> Year of manufacture 2006, machine no. 346143 >> Fixed angular table >> Speed: continuously variable up to 4000 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Travel distances X/Y/Z: 400/320/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Vertical quill stroke: 60 mm >> Vertical quill and horizontal quill – SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 13 KVA Accessories and equipment: >> Heidenhain TNC 124 control >> Hydraulic clamping, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating instructions for the control system and programming examples >> Handwheels >> Coolant system >> Electronic handwheel HR410 About the machine: Ksdpozrwqzofx Ag Aonc Offered for sale is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 124 control. This universal milling machine is in very good condition. It comes from a company where it was only used to a limited extent for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic clamping in both the vertical and horizontal positions. Changing from vertical to horizontal configuration is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on site while it is powered up.

Condition: excellent (used), Year of construction: 2014, Kunzmann WF 600 M Tool Milling Machine Kunzmann WF 600 M with Heidenhain TNC 124 Control Year of manufacture 2014 Excellent CONDITION CE-compliant!! Technical Data: Year of manufacture: 2014 Ksdpfsy Sihzsx Ag Ajnc Fixed angle table Spindle speed: continuously variable up to 4000 rpm Feeds: stepless in 3 axes from 0 to 2000 mm/min Travel X/Y/Z: 600/400/400 mm Rapid traverse x/y/z: 5 / 5 / 4 m/min Table size: 650 x 350 mm Table load: 250 kg Vertical quill travel: 60 mm Vertical and horizontal spindle, SK40 Hydraulic clamping system Weight approx. 1700 kg Space requirement approx.: 2.3 x 2 x 2 m Drive power: 12 KVA Accessories and Equipment: Heidenhain TNC 124 control Hydraulic clamping vertical and horizontal Automatic central lubrication Spindle brake Technical documentation, spare parts diagrams, operating manual for the control and programming examples Handwheels, coolant unit, tool holders, vise About the Machine: Offered here is a Kunzmann WF 600 M tool milling machine equipped with a Heidenhain TNC 124 control. This universal milling machine is in very good original condition. It comes from a facility where it was only lightly used for training purposes. The control is very easy to operate. Furthermore, the machine features hydraulic clamping both vertically and horizontally. Converting from vertical to horizontal is straightforward, simply by swinging away the vertical head. The guides are reliably lubricated via central lubrication. The Kunzmann has been mechanically and electrically tested at our facility. Take the opportunity to inspect and test the Kunzmann under power at our premises. You can find more milling machines from renowned manufacturers on our website.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE-compliant, from a training workshop! Technical data: >> Year of manufacture 2008, machine no. 347139 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axis 5000 mm/min >> Z axis 4000 mm/min >> Travel distances X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 control system >> Hydraulic clamping, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic clamping in both vertical and horizontal positions. Changing from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on site while it is powered up. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately. Knedsz Eh Tqjpfx Ag Ajc

Condition: used, Year of construction: 1983, functionality: fully functional, feed length X-axis: 460 mm, feed length Y-axis: 200 mm, overall weight: 1,300 kg, Universal milling machine Kunzmann UF6/3 Year of manufacture: 1983 The machine is in good condition, and the spindle runs very smoothly. The feed motor has been fitted with new carbon brushes, and the Z-axis spindle has a new telescopic spring. The cam control system in 3 axes is perfect for the production of small series. --- Price net plus VAT (shown on invoice) --- Travel distances, feed/manual - Longitudinal: 450/460mm - Transverse: 190/200mm - Vertical: 400/410mm The milling head can be adjusted by approximately 100mm by hand, which increases the transverse working area. Table clamping surface (surface with 3 T-slots): 860 x 265 mm T-slots: 14mm Spindle speeds, horizontal: 30-1280 RPM Spindle speeds, vertical: 50 - 2150 RPM Feeds: 0-1000 mm/min, stepless Feed, vertical: 0-250mm/min Rapid traverse: 1000 mm/min Knsdpfxozmfz Do Ag Aec Vertical milling head with fixed quill Tool holder: SK40 (Ott system) Distance, table - spindle lower edge: 440mm Accessories: - Manual - Counter support for horizontal milling - Cam control system in 3 axes (adjustable cams for switching off the feed) - Chip tray Drive power: 2.6/3.2 kW Connection: 400V three-phase Space requirement: approx. 1250 x 1200 x 1800 mm Weight: approx. 1300 kg Shipping by freight forwarder on request.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE-compliant, from a training workshop! Technical data: >> Year of manufacture 2008, machine no. 347141 Ksdpjz Eh Uuefx Ag Aenc >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axis 5000 mm/min >> Z axis 4000 mm/min >> Travel ranges X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 control system >> Hydraulic chuck vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating instructions for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a tool milling machine Kunzmann WF4/3 with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for both vertical and horizontal operation. The conversion from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site under power. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE compliant, from a training workshop! Technical data: Knedpoz Eh T Defx Ag Asc >> Year of manufacture 2008, Machine No. 347142 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axis 5000 mm/min >> Z axis 4000 mm/min >> Travel distances X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Vertical quill stroke: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 control system >> Hydraulic chuck, vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered for sale is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for vertical and horizontal operation. Changing from vertical to horizontal operation is very easy by folding down the vertical head. The guideways are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take advantage of the opportunity to inspect and test the Kunzmann on-site with power connected. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 CNC control in very good condition, CE-compliant, from a training workshop! Technical data: >> Year of manufacture 2008, Machine No. 347140 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axis 5000 mm/min >> Rapid traverse Z axis 4000 mm/min >> Travel distances X/Y/Z: 400/350/400 mm Knsdpfxsz Eh Uze Ag Asc >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: >> Heidenhain TNC 320 CNC control >> Hydraulic chuck vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a tool milling machine Kunzmann WF4/3 with a Heidenhain TNC 320 CNC control. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control. Furthermore, the machine has a hydraulic chuck in both vertical and horizontal positions. Changing from vertical to horizontal is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site while it is powered up. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Tool milling machine Kunzmann WF4/3 with Heidenhain TNC 320 control system, in very good condition, CE-compliant, from a training workshop! Technical data: >> Year of manufacture 2008, machine no. 347138 >> Fixed angular table >> Speed: continuously variable up to 4500 rpm >> Feed rate continuously variable in 3 axes from 0 to 2000 mm/min >> Rapid traverse X and Y axes 5000 mm/min >> Z axis 4000 mm/min >> Travel distances X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load: 250 kg >> Quill stroke vertical: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic clamping system >> Weight approx. 1800 kg >> Space requirement approx.: 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and equipment: Kodpfx Agoz Eh Ubo Ajnc >> Heidenhain TNC 320 control system >> Hydraulic chuck vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Technical documentation, spare parts diagrams, operating instructions for the control system and programming examples >> Handwheels >> Coolant system (not shown in the pictures) About the machine: Offered is a Kunzmann WF4/3 tool milling machine with a Heidenhain TNC 320 control system. This universal milling machine is in very good condition and has only a few operating hours. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Furthermore, the machine has hydraulic chucks for vertical and horizontal operation. Switching from vertical to horizontal operation is very easy by folding down the vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. Take the opportunity to inspect and test the Kunzmann on site while it is powered up. There are 5 identical Kunzmann WF4/3 milling machines available from a vocational school. The machines are available immediately.

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, Tool milling machine Kunzmann WF4/3 Heidenhain digital display year of manufacture 1994 very good CONDITION!! Technical data: >> Year of manufacture 1994 >> Rigid angle table >> Speed from 40 to 2550 rpm Biojv7Igbpa >> Continuous feed in X Y Z axis from 0 to 2000 mm/min >> Travels X/Y/Z: 400/320/400 mm >> Rapid traverse in all axes >> Vertical quill stroke: 60 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic tightening system >> Weight approx. 1500 kg Accessories and equipment: Knjdovyr R Nepfx Ag Asc >> 3-axis Heidenhain digital display >> Electric central lubrication >> Machine feet >> Handwheels >> Coolant system About the machine: Offered is a Kunzmann WF4/3 tool milling machine in very good condition. It comes from a state-owned company where it was only used a little. Converting from vertical to horizontal is very easy, by folding away the vertical head. The Kunzmann has been mechanically and electrically tested by us. Take the opportunity to view and try out the Kunzmann on site with power.

Condition: used, Univ. NC Tool Milling Machine KUNZMANN Type WF 3/4 Machine No. 341020 Year of Manufacture 1998 Travel X: 400 mm Y: 320 mm Z: 400 mm Table Size 650 x 350 mm Spindle Taper SK 40 Spindle Speed 40 - 2500 rpm Feeds X, Y and Z axes 0 - 1000 mm/min, stepless Rapid Traverse X, Y axis 4000 mm/min Rapid Traverse Z axis 3000 mm/min Pinol Adjustment Vertical 60 mm Drive Power Spindle Motor 3 kW Mains Connection 400 Volt, 50 Hz - NC path control Heidenhain TNC 124 - Stepless spindle speed control via belt drive with electric variable speed adjustment, spindle speed programmable - Reduction gearbox with 2 gear stages for two speed ranges - Main motor with belt drive via variable gearbox and stepless control via electronic system - Vertical milling head swiveling +/- 90° - Hydraulic tool clamping - Fixed angle table - All 3 axes with ball screw and mechanical handwheels - Control cabinet fixed to the machine - Coolant tank with pump located beside the machine - Central lubrication - Lighting Space Requirement L x W x H 1800 x 1800 x 1900 mm Weight 1300 kg Good condition Knjdpslvyrbefx Ag Asc

Condition: used, Year of construction: 1977, Technical details: x-travel: 450 mm y-travel: 200 mm z-travel: 400 mm spindle taper ISO: SK 30 distance table/horizontal spindle: max. 400 mm cross rail adjustment - horizontal: 400 (manuell) mm Kodpfxevc Awfe Ag Ajnc range of revolution per miute: horizontal: 30 - 1275 / 18 step U/min spindle taper: horiz.+vertikal: SK30 distance between table/spindle: vertikal: max. 430 mm quill travel: 60 mm swival range +/-: 90° Grad range of revolution per miute: Vertikalspindel: 50 - 215 / 18 step U/min clamping surface area: 860 x 240 mm table swivable approx.: 45° feed:: 0 - 1.000 / steples mm/min rapid traverse: 2.000 mm/min. total power requirement: 6,0 kW machine weight approx.: 3100 kg dimension machine xH: 1,6 x 1,6 x 1,9 m Coolant device 3-way DRO Heidenhain control panel Optional accessories *

Condition: new, Year of construction: 2024, Universal milling and drilling machine Kunzmann WF 610 M with Heidenhain TNC 128 control system Paths X/Y/Z = 610/400/450 mm Speed 1-4500 rpm Power 8.5 kW at 100 % ED Spindle SK40 DIN 69871 (form AD) with tightening bolt DIN 69872 Kodsuf Sv Djpfx Ag Aonc Fixed angle table 800x 425 mm 6 x 14 H7 T-slots coolant device 66 liters electric handwheel HEIDENHAIN HR 510 FS Further technical data is available on request. The machine is located at our premises in 71334 Waiblingen-Beinstein, is immediately available and can also be inspected. Please register in advance.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Tool Milling Machine Kunzmann WF4/3 with Heidenhain TNC 320 CNC Control – Excellent Condition, CE-Compliant, from Training Workshop! Technical Specifications: • Year of manufacture: 2010, Machine No. 347283 • Fixed angular table • Infinitely variable spindle speed up to 4,500 rpm • Infinitely variable feed in 3 axes from 0 to 2,000 mm/min • Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min • Travel X/Y/Z: 400/350/400 mm • Table size: 650 x 350 mm • Table load capacity: 250 kg • Vertical quill stroke: 60 mm • Vertical and horizontal quill – SK40 taper • Hydraulic clamping system • Weight approx. 1,800 kg • Space requirement approx.: 2.3 x 2 x 2 m • Drive power: 15 KVA Accessories and Equipment: • Heidenhain TNC 320 CNC control • Hydraulic clamping, vertical and horizontal • Automatic central lubrication • Spindle brake • Technical documentation, spare parts diagrams, control manuals and programming examples • Handwheels • Coolant system Kedpfxsxuppus Ag Aonc • Electronic handwheel HR410 About the Machine: Offered for sale is a Kunzmann WF4/3 tool milling machine with Heidenhain TNC 320 CNC control. This universal milling machine is in excellent condition and has seen very few operating hours. It comes from a facility where it was used exclusively for training purposes. The control is very user-friendly. Additionally, the machine features hydraulic clamping both vertically and horizontally. Changing from vertical to horizontal operation is very straightforward by swinging away the vertical head. The ways are regularly lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann on-site under power. There are 7 units of Kunzmann WF4/3 with the TNC 320 Heidenhain milling machines available. The machines are available immediately.

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Kunzmann WF4/3 Tool Milling Machine with Heidenhain TNC 320 Contouring Control – Excellent Condition, CE-compliant, from a Training Workshop!! Technical Data: >> Year of manufacture: 2010, Machine No. 347247 >> Fixed angle table >> Infinitely variable spindle speed up to 4,500 rpm >> Infinitely variable feed on 3 axes from 0 to 2,000 mm/min >> Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min >> Travel X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load capacity: 250 kg >> Vertical quill stroke: 60 mm >> Vertical and horizontal quill - SK40 >> Hydraulic tool clamping system >> Weight: approx. 1,800 kg >> Space requirement: approx. 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and Features: Kjdpfx Agoxupc Uj Asnc >> Heidenhain TNC 320 contouring control >> Hydraulic clamping for vertical and horizontal axes >> Automatic central lubrication system >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control, and programming examples >> Handwheels >> Coolant system >> Electronic handwheel HR410 About the Machine: Offered here is a Kunzmann WF4/3 tool milling machine equipped with a Heidenhain TNC 320 contouring control. This universal milling machine is in excellent condition, with very few operating hours. Previously used exclusively for training purposes, it features a highly user-friendly control system. The machine offers hydraulic clamping for both vertical and horizontal operation. Conversion from vertical to horizontal milling is extremely easy via the tilting vertical head. Guideways are continuously lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann machine under power at our facility. A total of 7 Kunzmann WF4/3 milling machines with TNC 320 Heidenhain controls are available. The machines are immediately available.

Condition: like new (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 400 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 4,000 rpm, quill stroke: 60 mm, table width: 650 mm, table length: 350 mm, overall weight: 1,800 kg, Equipment: documentation/manual, Dear Sir or Madam, For sale is a CNC milling machine of the type Kunzmann WF4/3 from year of manufacture 2004. The machine can be operated manually and under control. The Heidenhain TNC124 control is excellent for learning the basics of CNC programming and is still very popular in production as well as for machining special parts. The very quickly folding vertical milling head makes the Kunzmann a real all-rounder with nevertheless low space requirements. You will receive this machine from us workshop tested, partially overhauled or completely overhauled, available with or without cabin. Availability: on request Year: 2004 Control: Heidenhain TNC124 Table: fixed angle table 650x350mm Travel: X400mm/Y350mm/Z400mm Quill stroke: 60mm Connected load: approx. 7kW Speed range: 1-4000 rpm Feed: 0-2000 mm/min Tool holder: SK40 Equipment and accessories: coolant system, central lubrication, manual, documentation, machine feet, electronic handwheel, etc. Our service promise to you: - We are a certified master workshop in the field of mechanical engineering - All machines are thoroughly checked - All lubricants and, if necessary, worn parts are replaced in advance - On request we can completely or partially overhaul the selected machine for you - On request you can order additional accessories such as tools, etc., directly Knsdou H U Hkopfx Ag Asc - On request we can also install other accessories such as safety devices - We are also happy to take care of shipping and/or installation

Condition: good (used), Year of construction: 2003, machine/vehicle number: 347001, Used universal tool and cutter grinding machine Kunzmann WF 4/3 Heidenhain linear control TNC 124 Travels X/Y/Z = 400/350/400 mm Spindle speed 1-4000 rpm Knedpfxjz Spfxo Ag Aoc Spindle SK40 DIN 69871 Fixed angle table 650x350 mm, 5 x 14 H7 T-slots Coolant system, foldable acrylic splash guard for attaching to the angle table. Electric handwheel HEIDENHAIN HR 410 Further technical data is available upon request. The machine is located at our facility in 71334 Waiblingen-Beinstein, is immediately available and can be inspected at any time. Please register in advance.

Condition: excellent (used), Year of construction: 2002, Used CNC tool milling machine Year of manufacture: 2002 Control manufacturer: Heidenhain Control type: TNC 426 Working area: X: 400 mm Y: 350 mm Z: 400 mm Clamping surface: 650 x 350 mm (fixed table) Milling spindle tool holder: SK40 Ksdpfx Agjxz Rkys Asnc Spindle speed range: 5 – 5000 rpm Feed rate: 0–2 m/min Tool changer: none Accessories: Standard, chip tray, handwheel & documentation including declaration of conformity and data backup

Condition: used, Year of construction: 1996, functionality: fully functional, Universal Milling Machine Kunzmann WF7/3 CNC with Heidenhain TNC 124 Control – Excellent Condition!! Technical Data: • Year of manufacture: 1996, Machine No. 370173 • Rigid angle table • Infinitely variable spindle speed up to 3,700 rpm • Feeds on 3 axes, continuously variable from 0 to 1,000 mm/min • Travel distances X/Y/Z: 600/400/400 mm • Rapid traverse X/Y/Z: 5 / 5 / 4 m/min Ksdow Rx Tijpfx Ag Aonc • Table surface: 650 x 350 mm • Table load capacity: 300 kg • Vertical quill stroke: 60 mm • Vertical and horizontal quill – SK40 • Hydraulic tool clamping system • Weight: approx. 1,800 kg • Space requirement: approx. 2.3 x 2 x 2 m • Main drive motor: 4 kW • Total power consumption: approx. 7 kVA Features and Equipment: • Heidenhain TNC 124 CNC control • Hydraulic clamping for vertical and horizontal operations • Automatic central lubrication • Spindle brake • Technical documentation, spare parts lists, control manual, and programming examples • Full safety enclosure • Coolant system • Electronic handwheel About the machine: For sale is a Kunzmann WF7/3 universal milling machine equipped with a Heidenhain TNC 124 CNC control. This universal milling machine is in outstanding condition. It comes from an automotive manufacturer where it was used only sparingly for training purposes. The control unit is very user-friendly. Additionally, the machine features hydraulic clamping for both vertical and horizontal modes. Switching from vertical to horizontal operation is easy, achieved by simply swiveling the vertical head aside. The guideways are automatically lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically inspected at our facility. Take the opportunity to view and test the Kunzmann under power at our location.
