Used Index Milling Machine for sale (166)

Year of construction: 1995, condition: ready for operation (used), A CNC counter-spindle lathe Index with Y-axis and bar feeder MBL 42 is available. Turning length: 400mm, turning diameter: 420mm, bar capacity: 60mm, speed: 6000rpm, machine dimensions X/Y: 4750mm/1950mm. Documentation available. An on-site inspection is possible. Bedpfx Ahjym Dgmj Iewi

Condition: used, TECHNICAL DETAILS - Number of spindles : 1 * Spindle speeds : 7000 [rpm] * Max. bar diameter : 62 [mm] * Spindle power : 16.5 [kW] NUMERICAL AXES - Slide unit 1.1 : X and Z axes controlled by NC - Slide unit 3.1 : X and Z axes controlled by NC POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 40 [kW] MACHINE HOURS - Number of spindle hours : 19475 [h] EQUIPMENT - CNC : Siemens 840D - Chips conveyor Bwodjym D Scspfx Ah Isi - Coolant tank

Condition: used, Year of construction: 1994, INDEX MS 25E Max. bar diameter round / square: 26 / 18 mm Spindle pitch circle diameter: 230 mm Bodpfx Ajymdchjh Iswi Max. bar feed: 100 mm Longitudinal slide travel (total / working / adjustment): 85 / 50 / 330 mm Cross slide travel (total / working / adjustment): 36 / 16 / 20 mm Spindle speeds (12 / 24 steps with 1.25 / 1.12): 366 – 5,020 rpm Main drive: 15 kW / 1,450 rpm Voltage: 400 V / 50 Hz Operating hours: 62,283 h Working hours: 4,916 h Dimensions (incl. bar guide): approx. L x W x H approx. 7 x 1.5 x 2 m Weight: approx. 6 t Scope of delivery: Machine INDEX MS 25E

Condition: used, Year of construction: 2000, INDEX MS42C Max. bar diameter: 42 mm Spindle pitch circle diameter: 320 mm Main spindle: - Power clamping with INDEX spring-loaded hollow clamping cylinder and collet - Max. clamping stroke: 4 mm - Actuation force: 26 kN Main spindle drive: - Rated power: 5 kW - Rated speed: 1,500 rpm - Rated torque: 32 Nm Bedpfxoymc S Ue Ah Ijwi - Max. speed: 5,000 rpm Synchronous spindle and driven tool holder: - Rated power: 5.3 kW - Rated speed: 1,500 rpm - Rated torque: 34 Nm - Max. speed: 5,000 rpm Cross slides: - Max. number: 10 - Travel (X): 70 mm - Travel (Z): 140 mm - Max. feed force +X: 11.4 kN - Max. feed force −X: 7.9 kN - Max. feed force +Z: 11.4 kN - Max. feed force −Z: 7.9 kN - Rapid traverse speed: 15 m/min Longitudinal spindles: - Quantity: 6 - Travel (Z): 240 mm - Max. feed force +Z: 15.1 kN - Max. feed force −Z: 11.6 kN - Rapid traverse speed: 15 m/min Cross slides for longitudinal spindles: - Max. number: 6 - Travel (X): 70 mm - Max. feed force +X: 11.4 kN - Max. feed force −X: 7.9 kN - Rapid traverse speed: 15 m/min Synchronous spindle: - Clamping system: spring-loaded clamping cylinder - Max. clamping diameter: 42 mm - Chuck outer diameter: 112 mm - Jaw stroke: 1 mm - Max. total clamping force: 13 kN Weight: approx. 11,000 kg Scope of delivery: - Hydraulic unit KNOLL KTS 32-48-T - Bar loader CUCCHI PLURIMANDRINO, year 2000 - Workshop cabinet with machine accessories - KNOLL VRF 500 - Chip conveyor KNOLL 400 S-1/250

Condition: used, Year of construction: 2013, INDEX ABC 65 Distance between main and counter spindle: approx. 250 mm Main spindle: - Spindle bore: 65 mm - Max. speed: 6,000 rpm - Power: 25 / 35 kW at 80 / 120 Nm - Chuck diameter: 160 mm - Spindle bearing (ISO 702/1): 140 mm - C-axis Bjdpfx Ahoymbp So Ijwi Upper tool turret: - 10 stations - Max. speed: 12,000 rpm - Power: 7.5 kW at 11.25 Nm - Travel X / Y / Z: 140 / ± 50 / 300 mm - Rapid traverse X / Y: 30 / 50 m/min Lower tool turret: - 9 stations - Max. speed: 12,000 rpm - Power: 9 kW at 10 Nm - Travel X / Y / Z: 140 / ± 50 / 300 mm - Rapid traverse X / Y: 30 / 50 m/min Counter spindle: - Spindle bore: 52 mm - Max. speed: 6,000 rpm - Power: 5 / 9 kW at 10.5 / 20 Nm - Chuck diameter: 110 mm - Travel X / Y: 140 / 300 mm Back machining units: - 8 units incl. 5 driven stations - Max. speed: 12,000 rpm - Power: 6.4 kW at 7 Nm Workpiece and offcut handling unit with gripper: - Travel X: approx. 1,580 mm - Speed: approx. 68 m/min - Swivel angle: approx. 33° - Max. diameter: 65 mm - Max. workpiece weight: 2 kg CNC control: INDEX C 200-4D (based on Siemens Sinumerik 840 D-sl) Dimensions: approx. 4.1 x 2.1 m Required floor space incl. bar loader and coolant/filter unit: approx. 11 x 1.5 x 2 m (L x W x H) Weight: approx. 7 t Power supply: 400 V / 50 Hz Operating hours: 30,431 h Hydraulic hours: 28,806 h Scope of delivery: - Bar loader INDEX MBL - Coolant filtration unit KNOLL KF 150 - Chip conveyor KNOLL 320 S-1/160

Condition: used, Year of construction: 2014, INDEX ABC 65 Distance between main and counter spindle: approx. 250 mm Main spindle: Bore: 65 mm Maximum speed: 6,000 rpm Power: 25 / 35 kW at 80 / 120 Nm Chuck diameter: 160 mm Bearing ISO 702/1, diameter 140 mm C-axis Upper tool turret: 10 stations Maximum speed: 12,000 rpm Power: 7.5 kW at 11.25 Nm Travel X / Y / Z: 140 / ±50 / 300 mm Rapid traverse X / Y: 30 / 50 m/min Lower tool turret: 9 stations Maximum speed: 12,000 rpm Power: 9 kW at 10 Nm Travel X / Y / Z: 140 / ±50 / 300 mm Rapid traverse X / Y: 30 / 50 m/min Counter spindle: Bore: 52 mm Maximum speed: 6,000 rpm Power: 5 / 9 kW at 10.5 / 20 Nm Chuck diameter: 110 mm Travel X / Y: 140 / 300 mm Back machining units: 8 units incl. 5 driven stations Maximum speed: 12,000 rpm Power: 6.4 kW at 7 Nm Workpiece and offcut handling unit with gripper: Travel X approx. 1,580 mm Speed approx. 68 m/min Swivel angle approx. 33° Maximum diameter: 65 mm Maximum weight: 2 kg Bwsdpfsymblaex Ah Ioi CNC control: INDEX C 200-4D (based on Siemens Sinumerik 840 D-sl) Dimensions: approx. 4.1 x 2.1 m Required space incl. bar loader and coolant/filter unit: approx. L x W x H 11 x 1.5 x 2 m Weight: approx. 7 t Voltage: 400 V / 50 Hz Operating hours: 18,384 h Hydraulic hours: 16,694 h Scope of delivery: - Bar loader INDEX MBL - Coolant filter unit KNOLL KF 150 - Chip conveyor KNOLL 320 S-1/160 - Additional cooling unit KLH SC 8.K2L.MT-00-IND

Condition: used, Year of construction: 2007, operating hours: 26,721 h, number of spindles: 6, spindle speed (max.): 10,000 rpm, bar diameter (max.): 22 mm, total width: 1,800 mm, total length: 3,200 mm, total height: 2,850 mm, travel distance X-axis: 62 mm, travel distance Y-axis: 12 mm, travel distance Z-axis: 85 mm, overall weight: 6,500 kg, Working spindles: Quantity: 6 Maximum bar diameter: 22 mm Spindle pitch circle diameter: 230 mm Travel distances X / Z: 62 / 85 mm Rapid traverse speed: 15 m/min Synchronous hollow spindle drives: Quantity: 6 Maximum speed: 10,000 rpm Nominal speed: 8,300 rpm Power: 15 kW at 18 Nm Chuck diameter: 110 mm Swiveling synchronous spindles: Quantity: 2 Z-axis travel: 120 mm Feed force: 2.5 kN Rapid traverse speed: 15 m/min Swiveling angle: 132° Bwsdpfeymaw Iex Ah Iei Counter spindle: Maximum speed: 10,000 rpm Nominal speed: 8,000 rpm Power: 9.2 / 12 / 14 kW at 11 Nm Tool carriers: Maximum quantity: 11 Travel distances X / Y / Z: 62 / ± 12 / 85 mm CNC control: C 200-4D (Siemens Sinumerik 840D) Dimensions: approx. L x W x H 3.2 x 1.8 x 2.85 m Weight: approx. 6.5 t Operating hours: 61,997 h Working hours: 42,235 h Scope of delivery: - INDEX bar loader - Bar loader IEMCA SIR MS22 P, year 2008 - Coolant unit with belt filter - Chip conveyor KNOLL 400 S-1/290 - Coolant filter unit KNOLL FKA/1780 RSF 100 - Workshop cabinet with machine accessories

Condition: used, Year of construction: 2015, operating hours: 26,721 h, number of spindles: 6, spindle speed (max.): 10,000 rpm, bar diameter (max.): 22 mm, total width: 1,800 mm, total length: 3,200 mm, total height: 2,850 mm, travel distance X-axis: 62 mm, travel distance Y-axis: 12 mm, travel distance Z-axis: 85 mm, overall weight: 6,500 kg, number of tool stations in tool turret 3: 11, INDEX MS 22C Working spindles: Bsdpfjyl U Npex Ah Iowi Number: 6 Maximum bar diameter: 22 mm Spindle pitch circle diameter: 230 mm X / Z axis travels: 62 / 85 mm Rapid traverse: 15 m/min Synchronous hollow spindle drives: Number: 6 Maximum speed: 10,000 rpm Nominal speed: 8,300 rpm Power: 15 kW at 18 Nm Chuck diameter: 110 mm Swiveling synchronous spindles: Number: 2 Z axis travel: 120 mm Feed force: 2.5 kN Rapid traverse: 15 m/min Swiveling angle: 132° Counter spindle: Maximum speed: 10,000 rpm Nominal speed: 8,000 rpm Power: 9.2 / 12 / 14 kW at 11 Nm Tool carriers: Maximum number: 11 Travels X / Y / Z: 62 / ±12 / 85 mm CNC control: C 200-4D (Siemens Sinumerik 840D) Dimensions (approx.) L x W x H: 3.2 x 1.8 x 2.85 m Weight (approx.): 6.5 t Operating hours: 26,721 h Machine hours: 20,859 h Scope of delivery: INDEX bar loader Coolant unit with belt filter

Condition: used, Year of construction: 1997, turning diameter 420 mm turning length 400 mm Bwodpjylp Awefx Ah Iei spindle tunring speed 5.000 U/min power capacity 44 kW bar material dia. 60 mm In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: ready for operation (used), Year of construction: 2003, operating hours: 92,000 h, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 5, This 5-axis Index G 200 RATIO LINE was manufactured in 2003. It features a Y-axis travel of 120 mm, a main spindle diameter of D65, and a counter spindle diameter of D60. The machine is equipped with a turret that has 12 stations and driven tools on turret 1 and 2. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details. • C-axis on main and counter spindle • Thread cutting without compensating chuck • Electronic shaft • Additional V24 RS232 interface in control cabinet • Transmit-/Tracyl function • MDE interface (machine on, machine running, parts counter) • Marposs (Brankamp) collision monitoring CMS100 Bwedpfx Ahjylw Dcs Isi • 3D machine model for kinematic simulation in CAM programming system • Control cabinet cooling unit • Main spindle D65 • Counter spindle D60 • Coolant flushing of counter spindle (electrically controlled shut-off valve) • Foot switch • Turret (12 stations) bottom and top • Driven tools on turret 1 and 2 • Control function “synchronous tailstock” for turret 2 • Y-axis 120 mm • Automatic sliding door (hydraulic) • Coolant pump 80 l / 8 bar • High-pressure coolant connection slide 1 and 2 with solenoid valve • Coolant flushing gun • Preparation for extraction and filter system connection • Operating hours approx. 92,000 h Additional equipment • Portal unloading device with actuated gripper, NC-controlled • Gripper fingers D4–45 mm and D40–65 mm • Indexed conveyor belt • UNIMAG interface • Chip conveyor (hinged belt), discharge height 1250 mm • Vacuum rotary filter KNOLL (emulsion use) • High-pressure pump 80 bar • Workholding: • Collet chucks for draw tube, HAINBUCH (main and counter spindle) • Power chucks D210 with quick jaw change, Schunk (main and counter spindle) • Stop device

Condition: ready for operation (used), Year of construction: 2006, operating hours: 115,000 h, travel distance Y-axis: 120 mm, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 5, This 5-axis Index G 200 RATIO LINE was manufactured in 2006. It features a Y-axis travel of 120 mm, a turret with 12 stations, and driven tools on both turrets. The machine is equipped with a Siemens 840D control system and includes a collision monitoring system. If you are looking to get high-quality turning and milling capabilities, consider the Index G 200 RATIO LINE turn-mill centre we have for sale. Contact us for further details. • C-axis on main spindle and sub spindle • Electronic gearbox • Additional V24 RS232 interface in electrical cabinet • Transmit / Tracyl function • MDE interface (machine on, machine running, part counter) • Collision monitoring system Marposs (Brankamp) CMS100 • 3D machine model for kinematic simulation in CAM system • Electrical cabinet cooling unit (2 units) • Main spindle D65 with HAINBUCH pull-type collet clamping • Sub spindle D60 with HAINBUCH pull-type collet clamping • Stop device • Coolant flushing of sub spindle (electrically controlled shut-off valve) • Foot switch • Turret (12 stations) upper and lower • Driven tools on turret 1 and 2 • Control function “synchronous tailstock” for turret 2 • Automatic sliding door (hydraulically actuated) • ROTOCLEAR viewing window • Coolant pump 80 liters / 8 bar • High-pressure pump 80 bar • High-pressure coolant connection for slide 1 and 2 with solenoid valve • Coolant flushing gun • Preparation for extraction and filter system connection • UNIMAG interface • Operating hours: approx. 115,000 h Additional equipment • Portal unloading unit with actuated NC-controlled gripper • Gripper fingers D4–45 mm and D40–65 mm • Indexed conveyor belt • Chip conveyor (hinged belt), discharge height 1250 mm • KNOLL vacuum rotary filter (for emulsion use) • Multi-channel bar loader: Breuning / IRCO PROFImat 65.8 PR*270/8 Bjdpfx Ahoylwuhj Iewi • Year of manufacture: 2006 • Bar capacity: up to 3 m length • Maximum bar diameter: D65

Condition: ready for operation (used), Year of construction: 2006, spindle speed (max.): 6,300 rpm, number of axes: 12, This 12s Index MS32C multi-spindle turning machine was manufactured in 2006. It features a maximum bar diameter of 32 mm and a maximum spindle speed of 6,300 rpm. The machine is equipped with a Siemens 840D CNC control and includes a bar loader, coolant tank, and chip conveyor. If you are looking to get high-quality turning capabilities, consider the Index MS32C machine we have for sale. Contact us for further details. • Number of spindles: 6 • Max. bar diameter: 32 mm • Slide units 1.1–6.2: CNC-controlled X and Z axes • Synchronous unit at spindle position 6.1 • Counter spindle • CNC control: Siemens 840D with control panel and 2× NCU Additional equipment • Bar loader: IEMCA SIR MS32 F • Coolant tank: KNOLL, with high-pressure pump • Chip conveyor: KNOLL • Cooling unit (chiller): Riedel WTS 030.02-NE Bodeylk R Aspfx Ah Ijwi • Unloading system with 2 CNC axes • Fire extinguishing system: KRAFT UND BAUER

Condition: used, Year of construction: 1994, Technical details: turning diameter: 200 mm swing diameter: 260 mm Bjdoyk Utropfx Ah Iswi turning height: 200 mm Tool table: 1054 x 400 mm Dimensions (L/W/H): 2200 x 2300 x 2300 mm weight: 3300 kg slide travel radial ( X-axis ): 520 mm slide travel axial ( Z-axis ): 200 mm no pallet circulating belt, no C-axis, no driven tools *

Condition: used, Year of construction: 2015, Technical details: number of spindles: 6 spindle passage: 22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. * Bedpfxjxc Idmj Ah Ijwi

Condition: used, Year of construction: 1969, Automatic turret lathe brand: INDEX type: B60 new in: 1967 equipped with: 6x turret Bwedpfxoylht Us Ah Ioi Thread turning device Material feed

Condition: used, 2x 6-spindle bar automatics as a package Bwsdpfx Asylhlqjh Iei Make: INDEX Model: MS25E (1 machine defective, used as a parts donor)

Condition: used, Year of construction: 1987, 6-spindle bar automatic lathe Manufacturer: INDEX Model: MS25 Bodpfxow S Hd Sj Ah Iewi Year of manufacture: 1987

Condition: used, Year of construction: 2008, operating hours: 67,000 h, functionality: fully functional, turning length: 2,000 mm, turning diameter: 630 mm, spindle speed (max.): 12,000 rpm, travel distance X-axis: 640 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 270 mm, spindle motor power: 68,000 W, rotational speed (max.): 12,000 rpm, total height: 2,616 mm, total length: 6,300 mm, total width: 2,760 mm, torque: 900 Nm, overall weight: 21,000 kg, controller manufacturer: Siemens, controller model: 840D PL, number of slots in tool magazine: 80, Equipment: chip conveyor, Manufacturer / Model: Index G400 Ratio Line CNC Lathe with Milling Function Year of Manufacture: 2008 Control System: Siemens 840D Powerline Workpiece Diameter: Ø 630 mm Workpiece Length / Turning Length: 2,000 mm Main Spindle Power D102: Power at 100/40% 53/68 kW Torque: 675/900 Nm Steady Rest Diameter: Ø 45 mm – 310 mm Travel Paths: X-Axis: 640 mm, Z-Axis: 2,000 mm, Y-Axis: 270 mm Motorized Milling Spindle: HSK-63, max. speed 12,000 rpm Number of Tools: Right Disc Magazine: 40 tool positions (HSK-63), Left Disc Magazine: 40 tool positions (HSK-63) Operating Hours: 67,000 h (Hydraulics on) – see page 9 for details Dimensions (L × W × H): 6,300 x 2,760 x 2,616 mm Machine Layout Plan: see pages 5 and 6 Weight: 21,000 kg Equipment & Accessories: Bedoyk Etcepfx Ah Iewi 2 pcs. 3-jaw chucks Coolant System Knoll Type KF150/1100 Chip Conveyor Knoll Type 400 S – 1/370 Safety Devices Standard Accessories Condition of Index G-400: Machine is ready for immediate operation Regularly serviced (once per year by the machine manufacturer) Visually well maintained, normal signs of use The machine is in good overall condition Documentation: Operating manuals available Maintenance records / inspection reports available

Condition: as good as new (ex-display), Image No. 1408 As-new VDI40 DIN 69880 toolholder collet chuck Collet: DIN 6388-A; Type: 444E Item no. 433011- Further used VDI40 toolholders can be found at www:/wk-sales.de or on request. Collets DIN 444E or ER 40 with clamping nut. Bwodpfxjk Nz Ehs Ah Iji Collet not included in the scope of delivery. Outer diameter: 50mm External clamping length: 65mm

Condition: not inspected (used), functionality: unexamined, machine/vehicle number: 8208124, quill stroke: 100 mm, controller model: INDEX S3T B, spindle diameter: 103 mm, tailstock quill diameter: 100 mm, No reserve price – guaranteed sale to the highest bidder! Submitting a bid obligates timely collection between 08.04.26 and 16.04.26! TECHNICAL DETAILS Working spindle diameter: 103 mm Tailstock quill diameter: 100 mm Quill stroke: 100 mm Number of turret stations: 16 Turret head: EFG 250 MACHINE DETAILS Control: INDEX S3T B Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 100 A Dimensions & weight L x W x H: 3500 x 2400 x 2600 mm Machine weight: 3 t Bwodpfx Ajyk E Sxjh Ioi

Condition: good (used), Year of construction: 2012, functionality: fully functional, Control: SIEMENS Spindle bore: 65 mm Turning length: 660 mm Max. speed: 6,000 rpm Bwjdpfeyi Uk Iex Ah Ioi Counter spindle Z= 700 mm TOOL CARRIER 1 with milling spindle Milling spindle: 7,200 rpm B-axis: 360° 14 stations with driven tools Tool speed: 7,200 rpm Travel: X= 230 / Y= ±65 / Z= 845 TOOL CARRIER 2 14 stations with driven tools Tool speed: 7,200 rpm Travel: X= 140 / Y= ±45 / Z= 810 Chip conveyor Filter Bar feeder INDEX MBL

Condition: ready for operation (used), functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Index G42 lathe with 3m bar feeder, fully functional. Max. bar diameter: 42mm. The machine is equipped with an automatic bar catcher. Includes chip conveyor and coolant tank. Turret VDI30 without driven tool stations. With internal coolant supply. The machine is being sold due to the operator's retirement. A wide range of accessories is included, such as bar guide bushings, collets, etc. – see pictures. Machine manuals and documentation are available. The machine is ready for collection from our facility. Bjdox Nbk Nspfx Ah Iswi

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,000 rpm, travel distance X-axis: 640 mm, travel distance Y-axis: 210 mm, travel distance Z-axis: 2,000 mm, spindle motor power: 67,000 W, total height: 2,591 mm, total width: 2,199 mm, overall weight: 21,000 kg, product length (max.): 6,300 mm, tool weight: 5,000 g, swivel angle B-axis (max.): 360 °, swivel angle C-axis (max.): 360 °, number of axes: 4, This 4-axis Index G 400 horizontal turning machine was manufactured in 2008. It features a maximum turning diameter of 630 mm, a length capacity of 2000 mm, and supports a workpiece weight up to 300 kg. Equipped with a high-speed milling spindle at 6000 rpm and a main spindle speed of 3000 rpm, it offers robust machining capabilities. Consider the opportunity to buy this Index G 400 horizontal turning machine. Contact us for more information. Bedpfx Asx D D Ecjh Iswi Main spindle 0102 direct driveMaximum material throughput: 102 mmMaximum speed: 3000 rpmFront bearing diameter: 170 mmVariable hollow shaft motorPower at main spindle D102:Power at 100/40% duty cycle: 53 kW/68 kWTorque: 675 Nm/900 NmWork spindle alignment and switching device D1022.5° increments via indexing discHydraulicly actuated hollow clamping cylinder D102 with analog clamping stroke monitoringMaterial clearance: 102 mmStroke: 48 mmMaximum clamping force (tension/compression): 10,900 dNMulti-clamping pressure deviceClamping pressure adjustable from 8 to 80 bar via a multi-stage parts catalog for the main spindle clamping cylinder. Chuck release movement required for transitioning to a lower clamping l carrier 1 (standard equipment)Cross slide X, Z, turning length 2000 h internal coolant supply and shut-off valve, ball screws D=40 mmin the X-axis, D=50 mm in the Z-axis. Axis drives protected by overload clutches, counterweight in the s X ZWorking travel mm: 320 2000Rapid traverse speed m/min: 20 40Feed force N: 14000 14000X-axis measuring system: Glass scale (absolute)Z-axis: ROQ encoder (absolute)X-Y-Z-B housing (WT1)Turret with AC motor, positioned by spur gears, hydraulically lockedY-axis quill, hydrostatically mounted, lockable via spur gearsBall screw, D=40 mmOverload clutchTravel: 220 mmRapid traverse speed: 12 m/minFeed force: 24,000 NROQ encoder (abs)B-axis drive with AC motorSwivel angle: 360°Tool drive unitwith two clutches:Maximum speed: 6,000 rpmPower (25%) at n= 6,000: 17 kWMaximum torque (25%): 37 NmDisc turret with 12 stations on cross slide 1Tool holder system DIN 69880-40x63Increased repeatability during tool changes due to additional W-slotsMultifunction unit on cross slide 1Maximum speed: 6,000/1,500 rpmGearbox: i=4Torque: 36/144 NmTools: SK50Front bearing diameter: 75 mmInternal coolant feedthrough, disc spring clampingTool carrier 2, right - X, ZTurning length 2000 mm, preferably oncounter spindle machine with internal coolant supply and shut-off valve, turret control via AG motor, ball screws D= 50 mm for Z-axis, D= 40 mm for X-axis. Axis drives protected by overload clutches, counterweight system in ret head oriented to the right towards the counter s X ZTravel mm 210 2000Rapid traverse speed m/min 20 40Feed force N 8600 14000X-axis measuring system: glass scale (abs)Z-axis: ROD encoder (abs)Disc turret with 10 on cross slide 2Tool holder system DIN 69880-40x63Increased repeatability during tool changes thanks to additional W-slotsPositioned by face gearing, hydraulically lockedCounter spindle D102, size 11-DIN 55026/55021 and ISO 702/1Turning length 2000 mmZ-axis slide driven by AC motor and 50 mm diameter ball screwAxis drive protected by overload clutchIn the working position, the slide is held against the stop by the AC motor.

Condition: used, Year of construction: 2022, INDEX - C200 - 2022 - less used condition as shown on photos Bjdpjyl Nnaofx Ah Iswi - under power, can be tested

Condition: used, _____ Description: Year of manuf. : 2009 Control : Siemens C200-4D SL In General: Year of construction:2009 Control system:Siemens 840 Dsl (C200-4D SL) Bar capacity:65 mm Milling spindles:18,000 rpm Main spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm Bedpfxsvxmy No Ah Iswi C-axis:0.001° Z-axis:390 mm Bar capacity:65 mm Clamping cylinder:Hollow clamping cylinder Chuck:3-jaw chuck Sub spindle: Technology:Motorised spindle Speed:5,000 rpm Max. power:35.5 kW Torque max.:170 Nm C-axis:0.001° X-axis:600 mm Z-axis:390 mm Bar capacity:65 mm Chuck:3-jaw chuck Tool carrier I: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 X-axis:350 mm Y-axis:160 mm (+/- 80 mm) B-axis:230° Tool carrier II: Technology:Milling spindle on cross slide Speed:18,000 rpm Tool holder:HSK 40 Y-axis:160 mm(+/- 80 mm) B-axis:230° Tool magazin: Technology:Chain magazine Number of stations:80 pieces Tool changer:Double gripper Tool length max.:180 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system with filter Parts removal:Gantry-type pick-up Bar loader interface:Electrically prepared Tool monitoring:Drill breakage monitoring
