Used Biesse Edgebander for sale (338)

Condition: used, Double edgebanding machine BIESSE STREAM SB2 10.5 usable as 1st and 2nd machine in a edgebanding line Numerical Control with Sintra Software Machine suitable for 1st + 2nd pass of the panel Opening of the mobile shoulder motorized by C.N. mm 3000 Panel height 60 mm Pvc/Abs mm 3 Continuously variable feed speed from C.N. (up to 40 m/min) Working height electronically adjustable by C.N. (up to 60 mm) Opening of the moving shoulder electronically adjustable by C.N. Motorized rubber belt with higher pressure Track with bearings with hidden pins - distance between PINS mm 500 Automatic system for supporting large panels Anti-adhesive group Part to be squared composed of (for each side): * Automatic timed anti-splinter group * Double shredder group * Two-motor grinding group Border part composed of (for each side): * Gluing unit for EVA hot melt glue with pre-melter * Edge pressure group on straight profiles with electronically adjustable pressure rollers by C.N. Ndedpfx Asu Rim Hef Hsc * 6-position reel magazine with automatic edge change by C.N. * End trimming unit with 2 motors with automatic inclination * Overlapping trimming group with 2 motors * Edge trimming group with 2 tilting motors electronically adjustable by C.N. * Multifunction rounding unit with 4 motors (cornering tool + rounding tool) with numerical control adjustment automatically * Toupie Group (with 2 motors on the fixed left side \ with 1 0-90° tilting motor on the mobile right side) * Electronically controlled edge scraper group by C.N. * Glue scraper group * Oscillating brush group * Phon group

Condition: used, Year of construction: 2002, BIESSE Stream SB2 10.5 Double-Head Edge Bander. Nsdpfxsz Dp Ruo Af Hsdc

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, workpiece length (max.): 3,000 mm, workpiece width (max.): 1,000 mm, workpiece height (max.): 60 mm, overall weight: 3,000 kg, Equipment: CE marking, Biesse Skipper 100 CNC Drilling Machine – 2013 Ndjdpfx Afoz Ibqbj Hoc Well-maintained Biesse Skipper 100 CNC drilling and processing machine in very good working condition. The machine was originally manufactured in 2013 and has since been refurbished. It has been carefully maintained and is currently in excellent condition for its age. The machine is being sold only because the current owner has recently invested in a new Biesse drilling machine. It has therefore become surplus to production requirements. The Skipper 100 is a highly versatile CNC machining solution designed for drilling, routing, and panel processing. Its compact design and flexible operation make it particularly suitable for furniture, cabinet, and panel manufacturing applications. Key Highlights: Manufacturer: Biesse Model: Skipper 100 Year: 2013 Refurbished Very good mechanical and operational condition Regularly maintained Suitable for CNC drilling and panel processing Proven Biesse industrial construction Machine is available due to replacement with a newer Biesse drilling machine, not because of technical issues The machine can be inspected by appointment. Further technical information, photos, videos, and machine details can be provided upon request.

Condition: good (used), Year of construction: 2013, Edge thickness Roll 0.4/3 mm / Straps 0,4/22 mm Workpiece thickness 10-65 mm Workpiece overhang 140 mm Feed sppeds 10-14-18-20 m/min Equipped with Twin edge milling unit Gluing unit Snipping unit Rough trimming unit Fine trimming unit Profile trimming unit Universal trimming unit Flat scraping unit Edge buffing unit " Sintra " control unit Dimensions (l x w x h) approx. 7000 x 1400 x 2100 mm Weight approx. 3600 kg Ndsdsu Hldmjpfx Af Hoc Machine number 94391 Year of construction 2013 CE

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Smart Touch Numerical Control with Sintra HD Software Panel height mm 10 – 60 Solid mm 22 Pvc/Abs mm 3 Feed speed up to mt/min 25 Working height electronically adjustable by N.C. Motorized and electronically adjustable panel support guide by N.C. Anti-adhesive group Rectifying group with 2 motors electronically adjustable by N.C. Reel holder plate with n° 1 position Gluing group for EVA hot melt glue with glue pot End trimming group with 2 motors with dynamic suction system that follows the blades in each of its movements. Staggered trimming/cornering unit with 2 motors electronically adjustable by C.N Anti-stick unit Rounding unit with 2 multifunction motors (cornering unit + rounding unit) Electronic edge scraping unit electronically adjustable by C.N Glue scraping unit Njdpfxjwlbxlo Af Hedc Brush unit “SP-501” Automatic piece return system with Winner 4A bridge unloading

Condition: used, Year of construction: 2011, Panel dividing saw Manufacturer: Biesse Selco Type: Sektor 430 Year of manufacture: 2011 Technical data - Rated power of the system: 15.5 kW - Total length of the cutting line: 3865 mm - Maximum cross-cut length: 3500 mm - Maximum package thickness for processing: 65 mm Njdpfo Ad Ignsx Af Hodc - Positive programmed end position of the feed carriage: 3150 mm - Negative programmed end position of the feed carriage: 35 mm - Drive of the feed carriage: brushless - Additional encoder for position monitoring: yes - Left stop: yes Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 2008, Edgebander manufactured in 2008. This BIESSE Edge Stream B1 features a comprehensive set of tools including a PU-gluing machine, pre-milling unit, edge trimmer, and fine milling unit. It also includes rounding and edge scraper units, along with swaying brushes and an edge heater. If you are looking to get high-quality edging capabilities, consider the BIESSE Edge Stream B1 machine we have for sale. Contact us for further details. • Liquid spray unit (ADZ) • Pre-milling unit (RT) • PU gluing unit (SP10, Nordson) • Edge trimmer (IT90) • Balance tool trimmer (RS10) • Fine milling unit (RF40) • Rounding unit (AR60) • Edge scraper (RB40) Ndsdpfxszuhd Rj Af Hjc • Glue scraper unit (RC20) • Swaying brushes • Edge heater (PH10)

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Working area X: 3200 mm Working area Y: 1560 mm Z-axis workpiece passage: 165 mm 13.2 kW electro-spindle, HSK F63 connection, and air cooling HSK F63 twin-head unit for horizontal milling, one head aligned with the electro-spindle Vertical drilling heads: 10 Horizontal drilling heads X: 4 Horizontal drilling heads Y: 2 Blade for grooving in the X direction Disc tool changer with approx. 16 positions Work table with 6 rows Nedpfxjz R I Sgo Af Hsdc Programming software: Biesse b_solid Vacuum pump with a capacity of 100/120 m3/h Safety mats Protective screens Weight approx. 2685 kg. Only 412 operating hours for the electro-spindle and 92 hours for the drilling unit Includes 1 horizontal unit with 2 heads for door grooving

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Double table machining center Working range X 2,590 mm Working range Y 2,260 mm Working range Z 400 mm Number of milling spindles 2 Liquid-cooled spindle Main motor 19.2 kW Max rotational speed 24,000 rpm Aggregate heads 4 C-axis Ndedpeuqw E Nsfx Af Hoc Tool clamping system HSK-F63 Tool change positions central magazine 24 Tool change on each head from 12 positions Boring heads vert. 20 (for each head) Horizontal boring heads X 8 Horizontal boring heads Y 8 Blade for grooves in X, in Y 2 Platens Number 4 360 m³/h vacuum pumps T Jet system for chip blowing Nesting Manual labeling Bar code reader Tool length measurement Software BIESSE BIESSEWORKS ADVANCED, BIESSE B_NEST Weight 17,900 kg

Condition: used, Year of construction: 2011, functionality: fully functional, machine/vehicle number: 19823 i 19251, input frequency: 50 Hz, input current: 116 A, working width: 3,100 mm, total width: 6,617 mm, total length: 6,900 mm, total height: 2,550 mm, overall weight: 11,000 kg, input voltage: 380 V, workpiece length (max.): 1,000 mm, workpiece width (max.): 3,100 mm, workpiece height (max.): 60 mm, type of input current: three-phase, actuation type: electric, Equipment: CE marking, documentation/manual, TECHNO KERNEL FD I SD – a line of 2 through-feed drilling machines. Each machine has 6 upper and 6 lower drilling heads, with 2 independent motor units for each. On each unit, it is possible to install an assembly with 11 vertical spindles, arranged either along the X-axis or the Y-axis with a 32 mm spacing, or assemblies for dedicated machining operations. The first machine also has two horizontal drilling units, each consisting of 2 independent assemblies equipped with 11 spindles with a 32 mm spacing. In the second machine, instead of the horizontal spindles, there are 4 glue and dowel insertion units installed on each side. Ndodpfszyrpnsx Af Hec It is possible to load the components manually, or to connect the machine to automated loading and unloading systems for operation in a production line.

Year of construction: 1999, condition: good (used), Edgebander Biesse Polymac ERGHO 5, year 1999 Biesse Italy S/N 80709 max. panel thickness 10-45 mm min and max banding strip heught 13-60mm max thickness of banding material in rolls: 0,4mm- 3mm min. panel width 50 mm min. length 150 mm operating speed m/min 10/20 Technical information: Glue Pot VC 700 End trimming unit 701 Edge trimming unit RS 700 Corner rounding CR 200 Tilting Edge Trimming unit +Chamfering RI 700 Compact edge scraper RBK501 Brushes SP700 Ndodpfx Afegtx Aqj Hjc Edge Sanding unit LV 700 heated infeed guide PLC control panel support guide Large diameter roll holder edge cutting device for 3mm thick rolled edges 400 V , 50 Hz CE- marked Dimensions of the Maschine: ( Lx W x H ) = 4950mmx 1700mm x 1530mm 2900 Kg Technical information under subject of correction

Condition: good (used), Year of construction: 2018, machine/vehicle number: 1000028154, functionality: fully functional, Equipment: rotational speed infinitely variable, The machine was commissioned in 2019, single owner. It has seen very little use. Description Useful working area, 5-axis configuration: X=3280mm, Y=1600mm Axis travel: X=3706mm, Y=2294mm, Z1=515mm, Z2=371mm Axis traverse speed: X=80m/min, Y=60m/min, Z=30m/min Electrospindle: HSD, 5 axes 11 kW, with continuous 360° rotation on B and C axes, enabling high-precision machining of complex shapes liquid-cooled Drilling head: HSD 20 vertical spindles 4 horizontal spindles grooving discs on X-axis grooving discs on Y-axis Work table: 6 cross beams Isbjwhypnjni Itxtobb 4 suction cups per beam preparation for uniclamp Tool magazines: 16-position revolver-type tool changer Nsdpfx Afoxdl H Uo Hjdc Vacuum system: Vacuum pump with a capacity of 250 m³/h, ensuring firm clamping of the parts during processing

Condition: used, Year of construction: 2010, Working range X = 4,600 mm Y = 1,535 mm Z = 275 mm Designed for heavy-duty applications, making it ideal for machining large solid wood components and structural timber. The 5-axis controlled machining head enables the production of complex three-dimensional workpieces. • Central lubrication system • Desktop PC o Intel Celeron D CPU 2.66 GHz or higher o 512 MB RAM o 40 GB hard drive o 15" LCD monitor o Keyboard o Mouse o CD-ROM drive o Parallel port o RS-232 serial port o USB port o Ethernet card for connection to the office network • Remote service o Direct modem access for remote diagnostics and service • Electrical control cabinet • Air conditioning for the electrical cabinet • Safety system o Two pressure-sensitive safety mats on the front side of the machine with integrated control unit, ensuring safe alternating operation. • Signal lights for alternating (pendulum) machine operation • Job recovery function o Allows machining to resume after an emergency stop. • CE safety protection systems Worktable and accessories • Multizone table for 10 beams and 40 vacuum pods o Allows multiple workpieces to be loaded simultaneously, reducing tool changes and increasing productivity. o Vacuum clamping system o Pneumatic clamping system • 10 ATS beams, each equipped with 4 vacuum pods, L = 1,525 mm • EPS electronically positioned table for 10 beams • Rear stop row for 10 beams with 115 mm travel • Additional stop row at 375 mm with 140 mm travel • Additional stop row at 770 mm with 140 mm travel • Front stop row at 1,175 mm with 140 mm travel • 4 side stops with 140 mm travel (2 left + 2 right) complete with mounting hardware • 2 additional side stops with 140 mm travel (1 left + 1 right) complete with mounting hardware • Position sensors for all stops • 4 lifting devices for easier loading and unloading of workpieces for H = 74 mm modules • Vacuum unit 132 × 146 × H74 mm Nodpfx Afszlz Svs Hodc • Vacuum unit 132 × 75 × H74 mm • Vacuum unit 132 × 54 × H74 mm • UNICLAMP workpiece clamping system • Window manufacturing kit H = 74 mm, 40–98 mm • 6 UNICLAMP double-acting quick-connect clamps • 2 UNICLAMP modules for short workpieces • Chip and waste conveyor • Vacuum generator for 250 m³/h vacuum pump o 250 m³/h vacuum pump • Spindle and machining equipment • Motor power: o 12 kW at 12,000 rpm (S1 duty) o 15 kW at 12,000 rpm (S6 duty) • Maximum spindle speed: 22,000 rpm • Tool interface: HSK F63 • C-axis: continuous 360° • B-axis: ±100° • Coolant unit with 1,600 W cooling capacity • 15-position tool magazine for the 5-axis head • Additional Z carriage for rear units • 8.6 kW PEAK POWER electrospindle with HSK F63 interface and air cooling, specially designed for applications requiring high torque at low spindle speeds • Gear-driven C-axis rotating unit (360°) • BH9 drilling unit o 9 independently controlled drill spindles o Includes: o 5 vertical drills with 32 mm spacing o 2 independent dual-output horizontal drills o Separate 3 kW drive motor • 22-position tool magazine with 180 mm centre distance • Automatic lubrication system Two Leitz tool sets are available for EUR 19,000 + VAT: • LEITZ IV 68 tool set • LEITZ IV 90 tool set This machine is offered for sale on behalf of a customer. Viewing is available by prior arrangement. Please contact us through the platform's messaging system for further information and the relevant technical contact details.

Condition: used, Year of construction: 2009, Used machine Year of manufacture: 2009 Single-sided automatic edge banding machine with CNC control, 10" touch screen Industrial conveyor chain 1 1/4" Joint milling unit FI-502 Glue application unit VC-710 End trimming unit IN-801 Top and bottom flush trimming unit RS-100 2 motorized multifunction profiling units - contour milling unit CR-202 (FAST system with 4 standard positions) Scraper unit RBK-503, NC 2 positions Flat scraper RCC-701 Workpiece thickness: 10-65 mm Max. workpiece height with contour milling unit (depending on profiles): 35-65 mm Edge thickness from roll: 0.4-3 mm Edge thickness from strip material: 0.4-22 mm (depending on unit) Minimum workpiece length: 140 mm Minimum workpiece width (with length 140 mm): 85 mm Minimum workpiece width (with length 250 mm): 50 mm Feed speeds: 10-14-18-20 Central extraction connection: 200 mm Extraction connection, edge banding: 80 mm Extraction connection, joint milling: 120 mm Njdpfxjv R Nk Uo Af Hjdc Glue pot capacity: approx. 3 kg Heat-up time at half fill: approx. 10 min Length: 6000 mm Width: 1780 mm Height: 1770 mm Machine is offered without the workpiece return unit shown in the pictures Availability: short-term Location: Flörsheim

Condition: used, Year of construction: 2008, machine/vehicle number: 97457, functionality: fully functional, input voltage: 380 V, input current: 52 A, input frequency: 50 Hz, type of input current: three-phase, workpiece length (max.): 1,550 mm, workpiece width (max.): 3,100 mm, workpiece height (max.): 60 mm, number of slots in tool magazine: 120, actuation type: electric, total height: 2,600 mm, total length: 6,500 mm, total width: 7,500 mm, overall weight: 12,000 kg, Equipment: CE marking, documentation/manual, FTT Insider R8 drilling center with transverse feed, equipped with 4 upper tool heads. Each head features: a) two sets of vertical drills with a 32mm spacing: 18 spindles in the Y-axis, 14 spindles in the X-axis, and an additional 4 horizontal spindles in the Y-axis. b) an electric spindle unit with a power of 3.8 kW and an ISO30 chuck. Nedpfx Afszypnbe Hjdc The machine also has two horizontal drilling units, each consisting of two units equipped with 18 spindles with a 32mm spacing. The machine is equipped with two chain-type tool magazines for vertical drills: 60 positions each. Belt conveyors at the inlet and outlet allow for manual loading of parts; it is also possible to operate the machine in a production line.

Condition: good (used), Year of construction: 2017, On behalf of our client, we offer for sale a Biesse machine approximately 10 years old in good condition. A suitable investment for starting new production with a limited budget. Ndsdpjywup Uofx Af Hsc

Condition: used, Year of construction: 2007, with feed unit for molded parts with hot melt glue specification Top condition cleaned, function tested, tested, trial run Nedjvwgizspfx Af Hsdc used, good condition Manufacturer: Artech-Biesse Type: Single Year of manufacture: 2007 Machine no.: 91009 CE type tested with automatic edge trimming, round edge banding tilt-adjustable worktable – for bevel edge banding extendable table extension with roller support feed system – steplessly adjustable edge thickness 0.4 - 3.0 mm workpiece height min. 10, max. 120 mm required space approx. 1400 mm x 1000 mm x 1600 mm weight approx. 320 kg total connected load 5.2 kW Location 97447 Gerolzhofen, free loaded, unpacked Transfer in as-inspected condition, without warranty or guarantee.

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, Working area X: 6,400 mm Working area Y: 1,500 mm Number of milling spindles: 1 Nedowlcqvopfx Af Hodc Main motor: 13 kW Maximum rotation speed: 24,000 rpm Tool clamping system: HSK-F63 Tool change positions: 8 Vertical drilling heads: 20 Horizontal drilling units X: 4 Horizontal drilling units Y: 4 2 vacuum pumps, each 360 m³/h Nesting Remote control Software: BIESSE WORKS Overall dimensions: 11,004 × 5,334 mm Weight: 4,900 kg

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Spraying device Grinding unit with AirForce System, hot air edge gluing unit without joint Edging unit Trimming and finishing unit Spraying device Nsdpfsz Aqydox Af Hodc Radius milling unit Edge scraper unit Glue scraper unit Spraying device Brush unit Weight approx. 1650 kg. Only 62,853 meters of edge material processed 2 additional glue tanks for PUR and EVA

Condition: used, Year of construction: 2018, machine/vehicle number: 1000023651T, functionality: fully functional, power: 50 kW (67.98 HP), input frequency: 50 Hz, cutting height (max.): 95 mm, cutting width (max.): 3,200 mm, Equipment: documentation/manual, Selco WNAR 6 miter saw center. Ndedpfx Ajzl T Hljf Hec

Condition: excellent (used), functionality: fully functional, pre-milling aggregate granulate glue station maximum working height 60 mm guillotine for trimming edge band from the roll precision edge band trimming unit milling aggregate for trimming edge band excess from the top and bottom of the panel Njdezlc H Uopfx Af Hodc profile scraper flat scraper polishing units machine length 420 cm year of manufacture 2012 CE mark

Condition: used, machine/vehicle number: 008247, Type of edging: Thin edge, Thick edge Gluing System: PUR Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Ndsdpfxjzbrn Uj Af Hoc Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 9 nr

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 1000056636, functionality: fully functional, cutting width (max.): 3,500 mm, overall weight: 3,969 kg, cutting length (max.): 3,200 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Nedpoz Ni Eqjfx Af Hjdc Max. cutting length: 3,200 mm Max. cutting width: 3,200 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 8,000 x 2,400 x 2,400 mm Weight: 3,969 kg Shipping packages: 4 units EQUIPMENT CE marking Documentation

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Njdewuz Ekopfx Af Hodc Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16

Condition: used, machine/vehicle number: 008249, Type of edging: Thin edge, Thick edge Ndedpfezbrl Tex Af Hoc Gluing System: PUR Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr
