Used Biglia CNC lathe for sale (34)

Condition: used, Year of construction: 2014, functionality: fully functional, CNC: FANUC Series 31i – MODEL B Max. workable bar diameter: 51 mm Max. workable length: 230 mm MAIN SPINDLE Godpfewari Rsx Aagebn Max. rotational speed: 5000 rpm Spindle nose: ASA 5" Spindle bore: 59.5 mm Inner bearing diameter: 90 mm Motor power: 15 kW TAILSTOCK Max. rotational speed: 5000 rpm Spindle nose: ASA 5" Spindle bore: 55 mm Useful through-hole: 45 mm Inner bearing diameter: 90 mm Motor power: 11 kW TOP TURRET: LEFT 1 TOP TURRET: RIGHT 2 BOTTOM TURRET: 3 Number of positions: 12 Rotational speed: 4,000 rpm Motor power: 3.7 kW Rotation time (1 position): 0.15 sec Max. travel on Y-axis: 90 mm (-40/+50) COOLANT Tank capacity: 450 l Total power of electric pumps: 4.8 kW DIMENSIONS - WEIGHT Overall dimensions with chip conveyor: 5033 x 2100 x 2458 mm (h) Weight with conveyor: 8200 kg THE MACHINE HAS UNDERGONE THE FOLLOWING MAINTENANCE: Main spindle belt replacement Tailstock spindle belt replacement Bearing and gear replacement for motorization Tailstock brake replacement X1 axis screw replacement Z2 axis screw replacement Motorized gear box replacement Motorized fan replacement Relay replacement Hydraulic oil filter replacement Hydraulic filter replacement Traffic light replacement Ceramic seal replacement Fanuc drive overhaul Betatron drive overhaul Battery replacement Air hose replacement Control panel replacement Ignition switch replacement Chip conveyor belt replacement Part conveyor belt replacement

Condition: ready for operation (used), Year of construction: 2013, spindle motor power: 38,000 W, spindle speed (max.): 3,000 rpm, travel distance X-axis: 515 mm, travel distance Y-axis: 210 mm, travel distance Z-axis: 1,280 mm, total height: 2,574 mm, total width: 2,274 mm, overall weight: 9,000 kg, product length (max.): 5,890 mm, number of axes: 5, This 5-axis Biglia Smart Turn B1200S was manufactured in 2013. It features a maximum turning diameter of 500 mm and a turning length of 1,280 mm. The machine is equipped with a main spindle that reaches speeds of up to 3,000 rpm and a sub-spindle with a maximum speed of 4,000 rpm. If you are looking to get high-quality turning capabilities, consider the Biglia Smart Turn B1200S turn-mill centre we have for sale. Contact us for further details. • Maximum rotation diameter: 750 mm • Maximum turning diameter: 500 mm • Maximum turning length: 1,280 mm • Main spindle nose: DIN 55026 8" • Main spindle bar capacity: 95 mm • Main spindle motor power: 30 / 38 kW • Main spindle maximum torque: 1,014 Nm • Main spindle chuck: SMW Autoblok 250 BB (250 mm diameter) • Sub-spindle maximum speed: 4,000 rpm • Sub-spindle nose: ASA 6" • Sub-spindle motor power: 30 / 40 kW • Sub-spindle maximum torque: 286 Nm • Sub-spindle W-axis travel: 1,130 mm • Sub-spindle chuck: 250 mm diameter • B-axis milling unit rotation range: 210° (±105°) • B-axis angular positioning accuracy: 0.001° • Milling spindle taper: HSK-A63 • Milling spindle maximum speed: 50–8,000 rpm • Tool magazine capacity: 40 stations • Footprint dimensions: 5,890 × 2,274 × 2,574 mm (H), including chip conveyor Additional equipment • Chip conveyor • Parts unloader arm with front conveyor belt • Tool setter probe Technical Specification Counter Spindle Yes Driven Tools Yes Gjdpfxozar Ixs Aagjbn

Condition: good (used), Different toolholders in very good condition. Gbodpfx Aasy Txiqsgon

Year of construction: 2015, condition: ready for operation (used), A double-turret and double-spindle turning center Biglia including peripherals is available. Spindle power: 11kW/11kW, speed: 7000rpm, bar capacity: 36mm-37.5mm, max. turning diameter: 100mm, max. turning length: 140mm, tool stations: 2×12, Y-axis travel: +/-25mm, X/Z-axis travel: 85mm/300mm, rapid traverse: 15m/min, machine dimensions X/Y/Z: approx. 3700mm/1450mm/1900mm, weight: approx. 5000kg, control: Mitsubishi M730 with editor, power-on hours: approx. 47000h. Including FMB turbo 3-36 bar loader, Knoll KF10 coolant system, 700l tank, air cleaning unit and an extensive package of collets and tools. Documentation available. An on-site inspection is possible. Expected to be available starting October 2026. Gsdpoy H I E Uefx Aagebn

Condition: ready for operation (used), Year of construction: 2006, operating hours: 16,928 h, spindle speed (max.): 5,000 rpm, travel distance X-axis: 155 mm, travel distance Z-axis: 389 mm, overall weight: 3,760 kg, number of axes: 3, This 3-axis Biglia B301 SM was manufactured in 2006. It features a robust Hainbuch collet chuck for both the main and counter spindle, ensuring precision in your turning operations. The machine has a weight of 3760 kg and operates at a spindle speed of 504 RPM. If you are looking to get high-quality turning capabilities, consider the Biglia B301 SM horizontal turning machine we have for sale. Contact us for further details. • Electrical: 400 V, 3 phases, 40 A, 50 Hz • Spindle speed: 5000 RPM • Workpiece counter: 30 • Operating time: 16,928 h Additional equipment • Hainbuch collet chuck for main spindle • Hainbuch collet chuck for counter spindle • LTA dust extraction system • Not included: loading magazine, tool holders, collets Technical Specification Gbedpfx Aasyx T Raegsn Counter Spindle Yes Driven Tools Yes

Condition: good (used), Year of construction: 1999, Parts shown by hand not come. Gsdpfx Aswbz Tuoagobn

Condition: ready for operation (used), Year of construction: 2022, spindle speed (max.): 4,500 rpm, spindle motor power: 40,000 W, number of axes: 3, This 3s Biglia B1200M horizontal turning machine was manufactured in 2022. It features a maximum turning length of 620 mm and a maximum turning diameter of 360 mm, providing robust capabilities for various turning applications. With a spindle speed of 4,500 rpm and a bar capacity of 70 mm, consider the opportunity to buy this Biglia B1200M horizontal turning machine. Contact us for further details. Gedpfjyk Uitjx Aagjbn • Maximum turning length: 620 mm • Maximum turning diameter: 360 mm • Bar capacity: 70 mm • Spindle nose: ASA 8 • Driven tools power: 11 / 13 kW Additional equipment • Chip conveyor: belt type

Condition: good (used), Year of construction: 2012, 750mm Swing, 500mm max. machining diameter, 1300mm max turning length, 3000rpm main spindle, 65mm bar capacity, 8,000rpm milling 20kW, Gedpfx Aaoxqyg Nsgsbn C axis 0.001 degrees, Y axis - 90/+120mm, 40 station ATC, , milling speed 4,000rpm, 30kW spindle motors, FANUC 31i control, 3 Jaw Power Chuck, Swarf Conveyor, Coolant, tool setter, parts catcher, barfeed unit.

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, turning length: 2 mm, Cnc GE Fanuc Series 31i-TB Max. bar machining diameter mm 67.5 Max. machining length mm 250 MAIN SPINDLE Max. rotation speed rpm 4000 Spindle nose ASA 6" Spindle bore mm 75 Bearing internal diameter mm 80 Motor power kW 15 Gbjdpfxsx S Eyae Aagjn SUB-SPINDLE Max. rotation speed rpm 5000 Spindle nose ASA 5" Spindle bore mm 55 Useful through hole mm 45 Bearing internal diameter mm 80 Motor power kW 7.5/11 Offset travel mm 120 TURRET 1 & 2 Number of positions 12 Rotation time (1 position) sec 0.15 Driven tool stations No. 12 Max. driven tool speed rpm 4000 Driven tool motor power kW 3.7 Y-axis rapid traverse 100-6 COOLANT Tank capacity l 250 Total electric pump power kW 3.7 DIMENSIONS – WEIGHT Overall dimensions with chip conveyor mm 4150 x 2100 x 2200 h Weight with conveyor kg 6800
