Used Traub Cnc Lathe for sale (97)

Condition: good (used), Year of construction: 2007, Traub TNX 65/42 Milling and Turning Center Mfd. 2007 Gsdsq Npqmjpfx Aa Ijtt Serial #7060107 Commissioned in 2010 TX 8i-S control (Mitsubishi/Traub based control with Mitsubishi drives and motors) 15 CNC axis’s (4) X-Y-Z turrets with 10 positions each. Up to 20 tools per turret 65 mm thru hole main and sub spindle (sub spindle has coolant flush) Foot pedal control for clamp/unclamp of spindle chucks Servo driven gantry receiver Hydraulic swivel w/ pneumatic finished part and bar remnant gripper Finished part conveyor belt RESY paper band coolant filter Knoll Coolant tank with BKW refrigerated coolant temperature control 20 Bar High pressure and 8 Bar Low pressure coolant pumps Knoll chip conveyor FMB Turbo 5-55 magazine bar feeder (new in 2010) 2) Single stick turning tool holders 2) Double stick turning tool holders 1) Cut-off tool holder 1) Overdriven double radial live ER Collet tool holder 1) Overdriven radial live ER Collet tool holder 4) Radial live ER Collet tool holders 1) Radial live End Mill tool holder 1) Angle adjustable live ER Collet tool holder 2) Radial live Shell Mill tool holders 2) Axial live End Mill tool holders 6) Axial live ER Collet tool holders 43) Additional tool holders on separate list (see supplemental attachment) Hainbuch main spindle collet chuck Rohm sub spindle 2 jaw chuck 2 Spare sets of spare Z-axis ball screws and bearing packs.

Condition: good (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 246, turning length: 900 mm, travel distance X-axis: 280 mm, travel distance Z-axis: 400 mm, total height: 2,700 mm, total length: 5,000 mm, total width: 2,000 mm, overall weight: 7,000 kg, controller manufacturer: TRAUB, controller model: SYSTEM TX 8H, number of slots in tool magazine: 12, TRAUB TNA 400 CNC Lathe - Operating voltage: 400 V - Frequency: 50 Hz Gjdjx Tzx Ispfx Aa Istt - Connected load: 36 kW - Rated current: 70 A - Includes a tailstock and a HAINBUCH chuck, also equipped with a chip conveyor, TOOL EYE, and an additional chuck by FORKHARDT, diameter: 250 mm Note: The item must be picked up, bindingly, between 18th and 26th February 2026 on a date to be arranged. FCA D-78087 Mönchweiler - loaded onto truck

Condition: used, Year of construction: 2000, turning diameter 275 mm turning length 450 mm control SYSTEM TX 8H swing over plan sled 395 mm greates pass round over bed 520 mm spindle passage 65 mm spindle tunring speed 4.000 U/min spindle drive 11 kW Gedpfx Aaex Sr Hae Ijtt torque 280 Nm number of toolholder-holes 12 y-axis ± 35 mm rapid traverse (x/z/y) 15/18/10 m/min Number of working hours ca. 36.206 h In our assessment, the machine is in good used condition and can be inspected under power by appointment. Technical specifications & accessories: - Y-axis - Various accessories Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice. Prior sale is reserved.

Condition: used, Year of construction: 2011, controller manufacturer: Mitsubishi, controller model: TX-8i, _____ Description: Year of manuf. : 2011 Control : Mitsubishi TX-8i Turning length : 50 mm Mainspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Barcapacity:15 mm Movement in Z1:50 mm Workpiececlamping:Collet chuck Subspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Movement in X4/Z4:222/139 mm Rapid travers in X3/Z4:15 m/min Workpiececlamping:Collet chuck Toolcarrier I (X/Y): Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Movement in X1/Y1:35/37,5 mm Rapid travers in X1/Y1:15 m/min Toolcarrier II (X/Z): Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Gtedpfx Aox E Inmsa Iot Movement in X2/Z2:35/50 mm Rapid travers in X2/Z2:15 m/min Front attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:12.000 rpm, 4 kW, 7 Nm Number of driven stations:4 Movement in X3/Z3:222/139 mm Rapid travers in X3/Z3:15 m/min Rear attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Number of driven stations:4 Movement in X4:39 mm Rapid travers in X4:15 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Coolant pump Rawmaterialfeed:Bar loader, FMB minimag 20/3200 Finishedpartremoval:Workpiecehandling (Tube) Oilmistseparation:Interface mechanical prepared Toolholder:Misc. static and driven toolholder

Condition: used, Year of construction: 2005, control Traub TX8i weight of the machine ca. 4000 kg Gtsdpfx Aexzk Rmsa Iot

Condition: used, Year of construction: 1988, Technical details: turning diameter over bed: 360 mm turning dia. over face-slide: 160 mm turning length: 800 mm longitudinal traverse (z-axis): 810 mm facing movement (x-axis): 205 mm control: TX-8 spindle passage: 60 mm revolution per minute: 63 - 3150 / 2 step U/min feed:: 10.000 mm/min. tool turret - number of stations: 8 Gedpou Rqabjfx Aa Iott operating hours - idle run: 8834 h tailstock taper ISO: SK30 DIN 2080 tailstock quill stroke: 105 mm operating pressure: 40 bar total power requirement: 38 kW Weight approx.: 3,1 t dimension machine xH: 1,8 x 3,3 x 1,8 m dimensions of hydaulic: 580 x 400 x 750 mm Equipment: Lathe chuck Ø 200 mm, hydraulic Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system control panel Accessories Fine adjustment device for tool set-up *

Condition: not inspected (used), Year of construction: 1989, We are offering the following as part of an insolvency sale: 2 x CNC lathes (1 x with sub-spindle, 1 x with lower turret), used + Bar feeder + Accessories 1. CNC lathe with sub-spindle Make: MIYANO Model: BNC 34-S Gtedpfxex Ed A Ds Aa Iot Year: 1989 Control: Fanuc 0-T - HYDROBAR bar feeder - 2 x collet chucks - 1 x 3-jaw chuck 2. CNC lathe with 2 x turrets Make: MIYANO Model: JNC 45-T Year: 1989 Control: Fanuc 0-T - HYDROBAR bar feeder - 1 x collet chuck - 1 x 3-jaw chuck 3. Accessories - Approx. 65 x collets - Approx. 40 x jaw sets - Various tool holders + tools - Documentation The machines are untested, but they were in operation until decommissioning. Sale is ex-location; loading can be provided at extra cost.

Year of construction: 2007, operating hours: 24,593 h, condition: used, machine/vehicle number: 5010481, Max. turning diameter: 340 mm, max. turning length: 750 mm, max. spindle speed: 4,000 rpm, chip conveyor, TX 8I control system, 12-position turret Gedpfsx Akmqjx Aa Istt

Condition: used, Year of construction: 2001, turning diameter 340 mm Godpfoxwdw Eox Aa Ijtt turning length 750 mm control SYSTEM TX 8H spindle passage 80 mm swing over plan sled 530 mm greates pass round over bed 665 mm turning speed range - main spindle 3.150 min/-1 drive capacity - main spindle 22 kW number of tool places 12 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Two machines are available. Price per unit. Machine 1: - Images 1-5 - Operating hours approx. 55,790 h Machine 2: - Images 6-10 - Operating hours approx. 54,347 h Technical Features & Accessories: - Y-axis - Accessory package with rigid and driven tool holders - Chip conveyor Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Subject to changes and errors in the technical data and specifications, as well as prior sale!

Condition: used, Year of construction: 2004, controller manufacturer: Mitsubishi, controller model: TX-8i, _____ Description: Year of manuf. : 2004 Control : Mitsubishi TX-8i Turning length : 450 mm Mainspindle: Technology:Belt-driven spindle Speed:4.000 rpm Power:18,5 kW Torque:230 Nm Barcapacity:65 mm Workpiececlamping:Collet chuck, Hainbuch Spanntop Gr. 65 Subspindle: Gtjdpfx Aajxhbfns Ist Technology:Belt-driven spindle Speed:4.000 rpm Power:11 kW Torque:210 Nm Workpiececlamping:Collet chuck, Hainbuch Spanntop Gr. 65 Ejector:Hydraulic with flush Movement in Z:520 mm Rapid travers in Z:30 m/min Toolcarrier I (X/Y/Z): Technology:Turret with 10 stations Taper:VDI30 Tooldrive:4.000 rpm, 4 kW, 16 Nm Movement in X/Y/Z:140/70/450 mm Rapid travers in X/Y/Z:15/6/30 m/min Toolcarrier II (X/Z): Technology:Turret with 10 stations Taper:VDI30 Tooldrive:4.000 rpm, 4 kW, 16 Nm Movement in X/Y/Z:140/450 mm Rapid travers in X/Y/Z:15/30 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Cooling unit with Paperbeltfilter Rawmaterialfeed:Barlaoder, FMB SL80S Finished part removal:Hydraulic part catcher with coneyor belt Oilmistseparation:Electrostatic extraction, LTA AC3001 Further Accessory:Misc. Toolholder, Rinsing pistol

Condition: excellent (used), Year of construction: 1996, operating hours: 46,282 h, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, total height: 2,600 mm, total length: 11,000 mm, total width: 2,000 mm, overall weight: 6,000 kg, controller manufacturer: TRAUB, controller model: TX 8F, counter spindle speed (max.): 4,000 rpm, number of slots in tool magazine: 10, - Includes two 10-position tool turrets with driven tool stations - Includes HAINBUCH chuck system - Includes sub-spindle, bar feeder (manufacturer: STAMAG) - Includes chip conveyor TECHNICAL DATA: - Operating voltage: 400 V - Frequency: 50 Hz - Control voltage: 230 V - Rated current: 85 A - Connection: 54 kW - Connected load: 39 kW - Noise emission value at operator position: 71 dB(A) Ambient conditions: - Temperature: 5 – 40°C - Air humidity: max. 70% - Workpiece removal via sub-spindle - Max. sub-spindle speed: 4000 min-1 - Max. workpiece diameter: 56 mm - Programming: EIA and ISO code Input and output resolution: - X/Z: 0.001 mm - C axis: 0.001° - Rapid traverse: max. 15 m/min - Fine interpolation cycle: 0.34 ms - Largest thread pitch: 999.999 mm - Largest radius: 99,999.999 mm - Feed override: 0…200% - Rapid traverse override: 0…100% - Speed override: 50…120% - Speed input: 5 digits - Cutting speed input: 4 digits - Tool input: 4 digits - Program number: 8 digits - Subprogram number: 8 digits - Block number: 4 digits - M-functions: 3 digits - B-functions: 6 digits - Memory capacity: 32,000 characters - Tool correction pairs: 40 NUMERICALLY CONTROLLED TURNING AND POSITIONING UNIT (C AXIS): Main spindle: - Max. speed: 80 min-1 - Torque at 100% duty cycle: 100 Nm Gedpfxowpa Ruo Aa Istt - Accuracy: +/- 3 min Sub-spindle: - Max. speed: 80 min-1 - Torque at 100% duty cycle: 30 Nm - Accuracy: +/- 3 min TOOL CARRIER 1 & 2: - Driven tools per tool carrier: 10 (14) - Max. speed: 4000 (8000) - Power at 100% duty cycle: 1.5 kW - Power at 15% duty cycle: 4 kW - Torque at 15% duty cycle: 12.4 (4) Nm - Tool holder/tool carrier quantity: 10 (14) - Cylindrical shank as per DIN 69880: Ø 30 x 55 (25 x 48) mm - Chisel cross-section: 20 x 20 (16 x 16) mm - Chip-to-chip time (per VDI 2852): 1.2 s - Switching time one station: 0.6 s - Over 5 stations: 1.5 s SUB-SPINDLE (NUMERICALLY CONTROLLED IN Z DIRECTION): - Max. speed: 4000 min-1 - Max. clamping diameter: 65 mm - Three-phase motor steplessly programmable: 11 kW - Torque: 210 Nm - Feed force at 100% duty cycle: 6000 N - Feed travel: 520 mm - Ball screw operation: Ø 32 x 10 mm HYDRAULICS: - System pressure: 60 bar - Tank capacity: 150 l COOLANT LUBRICATION: - Per tool carrier: 1-stage centrifugal pump - Pump pressure: 5/12 bar - Tank capacity: - without chip conveyor: 300 l - with chip conveyor: 280 l NOTICE: Due to sporadic work, the operating hours may still change slightly.

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 180 mm turning length: 490 mm swing diameter: 450 mm cross travel: Z-Weg: 168 mm control: Traub TX8D revolution per minute: 20 - 4000 U/min spindle passage: Ø 60 mm operating hours - idle run: 23.495 h tool turret: 12 tools total power requirement: 38 kW Weight approx.: 4,2 t dimension machine xH: 3,6 x 2,5 x 2,2 m Tool holder straight shank DIN 69880 (VDI 3425) Ø 40x63 Röhm lathe chuck Ø 200mm hydraulic clamping Operation via double foot switch and control panel/operating panel. Coolant device The Traub carries an integrated chip conveyor with an ejection height of 1,100mm (currently without function). Accessories: multiple small parts 8 x machine feet without tailstock i.D. Gedpsu Ix N Ssfx Aa Istt *

Condition: good (used), Year of construction: 2004, control TRAUB SYSTEM TX8H weight 3500 kg range L-W-H 3960 x 1640 x 1800 mm output 11 kW number of spindle speeds 5600 / 4000 min-1 Torque 200 / 280 Nm The TRAUB turning machine TNA 300 was designed for the following machining of workpieces with a turning length of 450 mm. --> for machining metal and plastics with a defined cutting edge using suitable tools. --> for mounting in jaw chucks of sizes 160 to approx. 250 --> for machining material bars up to a Ø of 42 or 65 mm --> with EHS special version Workpiece removal device --> chip conveyor 800 mm long -> Technical data Working range Spindle diameter: 42 mm --> Spindle head DIN 55026, size: A5 --> Clamping fixture diameter: 160-175 mm / 200-250 mm --> turning diameter max: 275 mm --> Distance over turning centre: 35 mm --> max. turning length: 450 mm --> Swing diameter over cross slide: 395 mm --> Swing diameter over bed: 520 mm --> Tool carrier Tool holders for cylindrical shank DIN 60880: 12 pcs. --> Shank diameter: 30 mm --> Chisel cross-section: 20x20 mm --> Switching time 1 station: 0.5 sec. --> Switching time each additional station: 0.15 sec. Gtodpfx Ajwwl Iuja Ist --> Feed drives X-axis: --> Slide travel: 210 mm --> Feed force: 5000 N --> rapid traverse/path speed: 15 m/min --> Z-axis: --> Slide travel: 450 mm --> Feed force: 6000 N --> rapid traverse/path speed: 18 m/min --> Y-axis: --> slide path: +- 35 mm --> Feed force: 6000 N --> rapid traverse/path speed: 10 m/min --> C-axis: --> Speed: 100 min-1 --> Torque: 140 / 196 Nm --> electrical resolution: 0.001 degree --> tailstock quill diameter: 70 mm --> quill stroke: 60 mm --> Stroke of the quick retraction: 280 mm --> quill setting force at 55 bar: 8600 N --> Mounting according to DIN 228: Mk 4 --> Steady rest Clamping range: 8 - 95 mm --> Workpiece removal device Max. part length: 250 mm --> Max. part weight: 3 kg

Condition: used, Year of construction: 2003, max. bar material dia. 65 mm max. bar length 3.000 mm control System TX 8H CNC lathe | TRAUB - TNC 65 equipped with bar loader . The machine is in a well-maintained condition and can be inspected at any time under power. The machine videos from the production plant will be shared on request. Gjdpjxbtp Eofx Aa Iott Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TNC65 | TNC-65

Condition: used, TECHNICAL DETAILS Gtsdpfx Aaeuhawhs Iot - Number of axes : 8 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 13 [mm] - Max. machining length : 130 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 2,5 [kW] - C axis indexing precision : 0,001 [°] - Number of spindle hours : 26.709 [h] COUNTER-SPINDLE - Max. bar diameter : 13 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 2,5 [kW] - C axis indexing precision : 0,001 [°] - Number of spindle hours : 16.854 [h] - Number of turrets : 2 UPPER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X stroke : 35 [mm] - Z stroke : 50 [mm] - Live tools speed : 8.000 [rpm] LOWER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X stroke : 35 [mm] * Y stroke : -9,5 / +28 [mm] - Live tools speed : 8.000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 16 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.850 x 1.100 [mm] - Machine height : 1.480 [mm] - Machine weight : 2.000 [kg] EQUIPMENT - CNC : Traub TX 8i - Rotating guide bush - Parts catcher - Parts conveying strip - Chips conveyor : KNOLL 160 S-1 - Coolant tank : 500 [l] * with paper filtering unit - Bar loader : FMB Minimag 18 / 3200 C - Oil mist extractor : UAS SMOG HOG SH-05 - Number of fixed tool holders : 5

Condition: good (used), Year of construction: 1993, - TRAUB control TX 8F - spindle passage 42 mm - Working spindle speed: 40 - 4.000 1/min - 4 grooving slides: stroke 60 mm - 8-fold turret - high pressure pump 25 bar - backworking (2 spindles) - bar feeder (3 m) Godpfx Aeldd Iqja Iott - chip conveyor

Condition: not inspected (used), Year of construction: 1996, operating hours: 46,282 h, functionality: unexamined, machine/vehicle number: 18770, controller model: TX 8F, clamping diameter: 65 mm, counter spindle speed (max.): 4,000 rpm, workpiece diameter (max.): 56 mm, No minimum price – guaranteed sale to the highest bidder! Payment deadline for the machine is 20.11.2025! Bidding obligates the buyer to collect within the collection period from 01.12.2025 to 05.12.2025! TECHNICAL DETAILS Max. workpiece diameter: 56 mm Max. clamping diameter: 65 mm Max. counter spindle speed: 4,000 rpm Counter spindle power: 11 kW Counter spindle constant power range: 1:8 Counter spindle torque: 210 Nm Tool drive Max. tool drive speed: 4,000 rpm Tool drive power at 100% duty cycle: 1.5 kW Tool drive power at 15% duty cycle: 4 kW Tool drive torque at 15% duty cycle: 12.4 Nm (4 Nm) Number of tool stations: 10 (14) Cylindrical tool holder: ∅ 30 x 55 mm (25 x 48 mm) Tool shank cross section: 20 x 20 mm (16 x 16 mm) Chip-to-chip time: 1.2 s Indexing time per station: 0.6 s Indexing time over 5 stations: 1.5 s Positioning unit X/Z: 0.001 mm Positioning unit C-axis: 0.001° Fine interpolation increment: 0.34 ms Max. thread pitch: 999,999 mm Max. radius: 99,999.999 mm Max. speed (C-axis): 80 rpm Torque (main spindle C-axis) at 100% duty cycle: 100 Nm Accuracy (main and counter spindle C-axis): ± 3 min Rapid traverse and path speed: 30,000 mm/min Rapid traverse: max. 15 m/min Thrust at 100% duty cycle: 6,000 N Travel distance: 520 mm Ball screw size (∅ x pitch): 32 x 10 mm Feed override: 0 – 200% Rapid traverse override: 0 – 100% Spindle speed override: 50 – 120% MACHINE DETAILS Control: TX 8F Dimensions & Weight Dimensions (L x W x H): 11,000 x 2,000 x 2,600 mm Weight: 6,000 kg Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 230 V Nominal current: 85 A Connection rating: 54 kW Power consumption: 39 kW Noise emission at operator position: 71 dB(A) Temperature range: 5 – 40 °C Max. humidity: 70% System hydraulic pressure: 60 bar Hydraulic tank capacity: 150 l Coolant pump pressure: 5/12 bar Tank capacity without chip conveyor: 300 l Tank capacity with chip conveyor: 280 l Input Spindle speed input: 5 digits Cutting speed input: 4 digits Tool input: 4 digits Program number: 8 digits Subprogram number: 8 digits Block number: 4 digits M-codes: 3 digits B-codes: 6 digits Gjdpjxpgl Aefx Aa Iett Memory capacity: 32,000 characters Operating hours: 46,282 h (as of 17.10.2025) EQUIPMENT Two 10-station tool turrets with driven tool stations HAINBUCH chuck system Counter spindle Bar feeder from STAMAG Chip conveyor

Condition: used, Year of construction: 1996, max. bar material dia. 65 mm max. swing diameter 175 mm max. bar length 3.000 mm control System TX 8F travel -x axis 140 mm travel -z axis 520 mm CNC lathe | TRAUB - TNC 42/65 DG equipped with bar loader. The machine is in a well-maintained condition and can be inspected at any time under power. The machine videos from the production plant will be shared on request. Gtjdpfjxbtq Nox Aa Ist Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TNC65 | TNC-65 |TNC 42-65 DG | TNC 42/65DG

Condition: used, Swiss-type cnc lathe TRAUB TNL 12/7 Gjdpfx Asxbtz Uea Iott

Condition: used, Year of construction: 1996, spindle passage 80 mm max. turning diameter 395 mm Max. Turning length 750 mm control System TX 8H max. Spindle speed 3.150 U/min. CNC lathe | TRAUB - TNA 400 The machine is in a well-maintained condition and can be inspected at any time under power. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Gtedpoxbtqvefx Aa Iot #Tags:TNA400 | TNA-400

Condition: used, TECHNICAL DETAILS - maxi bar diameter : 12.7 [mm] - main headstock strokes (fixed/rotary sleeve) : 130/80 [mm] - spindle power : 4 [kW] - rotation speed : 12 000 [rpm] - upper turret : 6 positions - lower turret : 6 positions - number of rotary positions on turret : 6 - sub-spindle maxi diameter : 12.7 [mm] - sub-spindle rotation speed : 12 000 [rpm] - dimensions : 2850 x 110 x 1480 [mm] - hours in production : 12408 [H] - spindle hours : 9400 [H] EQUIPMENT - CNC TRAUB TX 8i control - bar feeder LNS Alpha ST 320 - C axis on main spindle and sub-spindle - brake on main spindle and sub-spindle - parts catcher with conveying strip Gedpsuhav Djfx Aa Istt - anti fire device - lubricating tank with pump with cooling unit - chip conveyor - various fixed and driven tool holders

Condition: used, Year of construction: 1997, spindle passage 80 mm max. turning diameter 460 mm Max. Turning length 1.000 mm Gjdpfoxbtpxox Aa Iett control System TX 8F max. Spindle speed 2.800 U/min. CNC lathe | TRAUB - TNA 500 The machine is in a well-maintained condition and can be inspected at any time under power. Technical data of the machine will follow soon. We ask for your understanding ! - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags:TNA500 | TNA-500

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 12.7 [mm] - Max. machining length : 130 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.5 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 12.7 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.5 [kW] - C axis indexing precision : 0.001 [°] - Number of turrets : 2 UPPER TURRET Gsdpfouhaw Uox Aa Iott - Number of positions : 6 - Number of motorized positions : 6 - X stroke : 35 [mm] - Y stroke : -9.5/+28 [mm] - Z stroke : 48 [mm] LOWER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X/Z stroke : 35/79.5 [mm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 10000 [rpm] - X/Z stroke : 415/138.5 [mm] SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 10000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] EQUIPMENT - CNC : Traub TX8i - Rotating guide bush - Coolant tank - Bar loader : FMB Minimag

Condition: used, TECHNICAL DETAILS - Number of axes : 9 - Number of spindles : 2 Godpfeuhaxfsx Aa Iett MAIN SPINDLE - Max. bar diameter : 12.7 [mm] - Max. machining length : 130 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.5 [kW] - C axis indexing precision : 0.001 [°] COUNTER-SPINDLE - Max. bar diameter : 12.7 [mm] - Spindle speeds : 12000 [rpm] - Spindle power : 2.5 [kW] - C axis indexing precision : 0.001 [°] - Number of turrets : 2 UPPER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X stroke : 35 [mm] - Y stroke : -9.5/+28 [mm] - Z stroke : 48 [mm] LOWER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X/Z stroke : 35/79.5 [mm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 10000 [rpm] - X/Z stroke : 415/138.5 [mm] SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 10000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] EQUIPMENT - CNC : Traub TX8i - Rotating guide bush - Coolant tank - Bar loader : LNS TRYTON HYBRID

Condition: used, TECHNICAL DETAILS - Number of axes : 7 - Number of spindles : 2 - Number of turrets : 1 MAIN SPINDLE - Max. bar diameter : 12,7 [mm] - Max. machining length : 130 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 2,5 [kW] - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Max. bar diameter : 12,7 [mm] - Spindle speeds : 12.000 [rpm] - Spindle power : 2,5 [kW] LOWER TURRET - Number of positions : 6 - Number of motorized positions : 6 - X/Z stroke : 35/50 [mm] - Live tools speed : 8.000 [rpm] END ATTACHMENT - Number of positions : 4 SECONDARY OPERATION - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 12.000 [rpm] Gtsdpfxsuhawzs Aa Iet POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 18 [kW] EQUIPMENT - CNC : Traub TX8i - Interface : RJ45 / PCMCIA - Spindle brake : on main spindle - Parts catcher - Coolant tank : 200 [l] - Chips conveyor : KNOLL - Bar loader : FMB Minimag 3200 C - Number of turning tool holders : 2 - Number of fixed tool holders : 14 - Collets collection for chuck : F20 - Collets collection for chuck : F16 - Sockets : 4 - Set of shells and collets for bar feeder - Set of spare parts
