Used Scm Double End Tenoner for sale (595)

Condition: excellent (used), Year of construction: 2006, The machine is being sold on behalf of a customer. It is currently still connected and can be tested on site. We are also happy to send you a video of the machine. Further machine information will follow… Location: East Frisia region. Rsdpfsyl Numsx Afcop

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, Format Circular Saw FKS 550-3200 M A PRO - Year of manufacture: 2023 - Max. cutting height: 200 mm - Cutting height: 200/140 mm - Crosscut width left of the saw blade: max. 3200 mm - Cutting width with parallel fence: 1450 mm - Saw blade tilting: 90 – 45° - Dimensions (LxWxH in mm): 3,386 x 3,703 x 1,330 - Main saw blade with belt drive and speeds: 2800/3665/4800 rpm - Vibration-free operation due to high dead weight (1,070 kg) - Large support table with material roller - Parallel fence with round bar guide - Extendable aluminium rip fence with digital display (2 folding stops) - Quadruple ball-bearing format sliding table with twin roller carriage made of anodised aluminium, high torsional stiffness - Large pendulum safety guard with gas pressure spring - Multiple locking positions on sliding table - Motorised saw blade tilt & height adjustment with digital display - 8.8 kW main motor - Tool-free rapid system for saw blade clamping - Saw unit can be switched on and off - On/off switch on the sliding carriage Redpfx Ajxfku Tofcsp - Edging length: 3200 mm

Condition: excellent (used), Table length 300 cm Ground clearance 105 cm Redpfx Afemmci Uocsp Undercutter 5,5 kW engine

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, power: 11 kW (14.96 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, travel distance X-axis: 3,548 mm, travel distance Y-axis: 1,350 mm, travel distance Z-axis: 170 mm, workpiece length (max.): 3,540 mm, workpiece width (max.): 1,350 mm, workpiece height (max.): 160 mm, number of axes: 5, number of slots in tool magazine: 12, controller manufacturer: SCM, Equipment: documentation/manual, 5-axis CNC machining center with a very robust design (portal construction) Control via XYLOG and Maestro Extended working area in X-direction (comparable to approx. X5 HD 36) Beam table, details (equipment): 12x TV MORBIDELLI suction cups X=145 Y=145 H=50 Support surface dimensions: 145 x 145 mm Suction cup height: 50 mm Integrated blanking valve 6x Rotatable TV MORBIDELLI suction cups X=145 Y=55 H=50 Support surface dimensions: 145 x 55 mm Suction cup height: 50 mm 6x Rotatable TV MORBIDELLI suction cups X=145 Y=30 H=50 Support surface dimensions: 145 x 30 mm Suction cup height: 50 mm Redpfeymgllox Afcop Vacuum cups can be positioned using the laser system Tool changer traveling in X-direction, HSK 63 tool holder Chip conveyor, automatic central lubrication The drilling unit consists of: - 10 individually selectable vertical drilling spindles in X-direction - 8 individually selectable vertical drilling spindles in Y-direction - 4 horizontal spindles (2+2) for drilling in X-direction - 4 horizontal spindles (2+2) for drilling in Y-direction - 1 grooving saw unit (max. diameter 120 mm) in X-direction Safety fence (original Morbidelli provided); we use a custom safety solution for the machine, which has been accepted by BGHM. Both safety devices will be supplied. The machine is in very good condition. Demonstration possible by arrangement. Tools and tool holders shown in the photos are not included in the offer. A comprehensive range of tools/tool holders can be purchased on request. Offer is ex works Frankfurt am Main (EXW) Machine available immediately!

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: A3347169, functionality: fully functional, number of axes: 3, CNC machine SCM, Record 100 AL action line, 3-axis woodworking line, 400V, year built 16/07/2008, electric cabinet, control with safety mat, partition wall, working area 305 x 122 cm, total machine dimensions: approx. 565 x 250 x 260 cm, self-dismantling required. 3 axes. In perfect working condition. 1 large vacuum with detailed white plate and 1 small vacuum: Year 2019 / No. A3347169, Type VTLF2.250/0-79, Frequency 50/50Hz, Speed 950/1150min-1, Power required 5.5/6.4kW, Inlet capacity 244/286m³/h, Max vacuum 200/200mbar. Redsxg El Aepfx Afcsp

Condition: used, Year of construction: 2001, Storage location: Supplier Rodpfjym D Eijx Afcep

Condition: used, Number of machnines 9 Stk. Wooden window production line for sale on behalf of a customer. Machines still in operation can be viewed. Sale includes machines, tools, and programming of the systems produced. Includes angled window and arched window production. Item 1: Weinig Powermat 500, year of manufacture 2010, window version ----- - 6 spindles, 5 of which are PowerLock - 8,000 rpm - Large PowerCom control system - Spindles 2, 3, and 4 axially CNC-controlled - Spindles 2, 3, 4, and 5 radially CNC-controlled - Window package for glazing bead removal: Pneumatic indexing of right and top spindles for bead removal - Includes existing Leitz planing and beading tools - Linked to a Maweg Saturn Duo single-slice wood sander, year of manufacture 1985 and a workpiece return conveyor Item 2: SCM Windor 40 R window system, year of manufacture 2006 ----- - 2 long CNC-controlled slotting spindles - Optima 16: Drilling units for face and longitudinal drilling - ROTATEN: Angled window attachment - 3 long CNC-controlled profile spindles + top and bottom drilling units - Rebating carriage for small sashes - Workpiece return - Includes Leitz window and door tools - Includes separate OKOMA UF 3 rebating machine with tools Item 3: HOMAG CNC machining center BMG310/42/F/K, year of manufacture 2018 ----- - Gantry machine, 5-axis Drive 5C+ with 15 kW - Ceiling laser - Working dimensions 4200 mm length, 1350 mm depth - 32-position disc changer - 8-position linear changer - Fixed drilling head with 18 spindles V12/H6/S0/90 degrees - 8 consoles - 6 lifting rails - Connection for 8 PowerClamp clamps - Approx. 30 vacuum clamps - 4 x PowerClamp clamps - WoodWop - Chip conveyor belt - Various small solid wood clamps, used for casement windows - Including Leitz tools for Homag with arched window production - Including Barbaric vacuum lifter, year of manufacture 2015 Item 4: Löwer MZP 1 mini dovetail press ----- - ??For arched window production Item 5: S+S frame press type Bavaria 200 L, year of manufacture 2014 ----- - Working dimensions 4000 x 2600 mm - With center pressure beam and cross pressure device - Motorized width adjustment - Basic equipment counter profiles - Slanted window control - Pendulum pressure plates + extension for pointed windows - Intermediate insert for small-scale crimping - Various carrier plates for counter profiles and counter profiles Item 6: Striffler sash fitting table ----- - With automatic screwdriver and screw feeder - Fitting rack - Punch for Roto fitting Item 7: Stegherr KF counter milling machine ----- - With existing tools Item 8: Tools Redpfoyclwxox Afcsp ----- All tools belonging to the machines for the wood+wood-aluminum systems IV 72 + 92 mm shown in the PDF - Windows - Lift-and-slide doors - Round and angled windows - Box windows - Entrance doors in many variations - Putty rebate variations - ... Sale of the tools in their current condition, scope, and with accessories as they are currently available. Note regarding window...

Condition: used, Year of construction: 2017, total height: 1,800 mm, total length: 4,800 mm, total width: 1,000 mm, Price: On request - Year: 2017 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Number of units [pcs]: 9 - └ 1st unit type: Pre-milling unit - - Tools available: Yes - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Tools available: Yes - └ 4th unit type: Cap unit Rjdpfjyll Snsx Afcsp - - Tools available: Yes - └ 5th unit type: Corner rounding unit - - Tools available: Yes - └ 6th unit type: Radius scraping unit - - Tools available: Yes - └ 7th unit type: Corner rounding unit - - Tools available: Yes - └ 8th unit type: Flat scraping unit - - Tools available: Yes - └ 9th unit type: Brushing unit - - Tools available: Yes - Glue system: Glue pot - Voltage [V]: 400 - Current consumption [A]: 42 - Transport dimensions: 4800mm x 1000mm x 1800mm (l x w x h) Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Rsdpfxjw Dcccj Afcjp

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Rsdpew Dcb Sofx Afcsp

Condition: used, Year of construction: 2022, PANEL SAW WITH TILTING SAW BLADE Linvincibile SI 5 KEY FEATURES SLIDING TABLE: GUARANTEED SUPERIOR CUTTING QUALITY OVER THE LONG TERM TELESCOPIC ARM: AN “UNBEATABLE” SMOOTH MOVEMENT SAW UNIT: FOR A PERFECT CUT Technical Data SI 5 Main saw blade diameter (mm): 550 Cutting capacity with extendable fence - with table 3200 mm - with table 3800 mm 3200x3200 3800x3200 Saw blade tilt (degrees): 46 Max. cutting height at 90° (mm): 200 Max. cutting height at 45° (mm): 130 Saw blade speed (rpm): 2500-3500-5000 Scoring blade speed (rpm): 8500 - Extractor port diameter: - on frame - on blade guard 120 100 Main motor power [S6 -40%] Hz50 kW: 7 Scoring motor power [S6 -40%] Hz50 kW: 0.9 Cutting width at rip fence (mm): 1600 Standard equipment and accessories - Optimizer/Process control app for tablets: SCM Thundercut. The app can be downloaded from the App Store or Play Store for tablets compatible with iPadOS or Android. It can be activated via the QR code supplied with the machine. The app enables: * Management of machine fleet and material/panel storage * Creation and editing of projects, importing projects from main furniture design software (file format "cpout"), importing cutting lists * Optimization of cutting lists by selecting one or more proposals from the optimization software integrated into the app * Correct machine settings for each cut, thanks to the simple and intuitive graphics of the 3D sequencer, guiding the operator step by step * Printing barcode labels to identify the various parts, via Bluetooth connection with compatible label printers. - 10-year warranty on the sliding table guide system - Sliding carriage entirely made of aluminum structure with guidance on crimped, hardened and arc-ground steel rails with large contact area - Max. saw blade diameter* up to 450mm with scoring blade mounted* up to 550mm without scoring blade - eye-S 15" electronic control including: * 15" touchscreen monitor * Direct control of the following working axes with manual, semi-automatic, automatic, and incremental modes: - Height adjustment of the main saw blade - Tilt adjustment of the saw unit - Rip fence adjustment - Height and lateral adjustment of the scorer (the scorer is automatically raised to the set position on activation and lowered on deactivation) * Operator assistance functions for complex cuts * Ability to store up to 1000 programs with associated image * Ability to store up to 1000 different tools with associated image * Cutting process management of preloaded parametric machining programs * Environment for creating and storing new sequenced working programs * Automatic import of working dimensions from Thundercut app * USB port * Ready for network connection - Auxiliary function of the electronic control, including: * Determination of correct fence position on rip fence for format processing with tilted saw blade * Determination of correct fence position on rip fence for angle cuts with mitre fence on the work table with or without tilted saw blade - Pivoting control panel above the table - Scoring unit with independent Redpfoxqtvqox Afcjp

Condition: used, Year of construction: 2005, total width: 1,100 mm, total height: 1,120 mm, Dimensions (LxBxH): 100 x 110 x 112 cm - Year: 2005 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AB 173436 - Max. planing width [mm]: 500 - Max. planing height [mm]: 250 - Worktable length [mm]: 60 - Worktable width [mm]: 520 - Number of cylinders height adjustment [pcs]: 4 - Extraction nozzle diameter [mm]: 140 - Voltage [V]: 400 - Transport dimensions: 1000mm x 1100mm x 1120mm (l x w x h) Rsdpfx Afewnhmhocsp - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2003, total width: 1,200 mm, total height: 1,600 mm, Dimensions (LxBxH): 365 x 120 x 160 cm Four-sided planer SCM Compact P Year of construction 2003 Min/max working height 6/120mm Min/max working width 25/230mm Minimum input length is 450mm Working speed 6/12 m/min Rsdpfxjwnhtzs Afcop Spindle speed 6000 Rpm Spindle diameter 40mm Min/max tool diameter vertical spindle 120/165mm Input table length 2480mm Exclusive tools. Engines 1st Spindle - Under 5,5kW 2nd/3rd Spindle - Left/Right 7,5kW 4th Spindle - Above 7,5kW Dimensions 3600x1200x1500mm (LxWxH), Weight 1500kg - Year: 2003 - Documentation available: No - CE certificate present: No - Serial number: 021918 - Number of spindles [pcs.]: 4 - └ Spindle 1: - - Spindle type: Bottom - - Motor power [kW]: 4 - - Spindle diameter [mm]: 40 - - Cutterhead speed [rpm]: 6000 - - Max. planing block diameter [mm]: 125 - └ Spindle 2: - - Spindle type: Right - - Motor power [kW]: 5.5 - - Spindle diameter [mm]: 40 - - Cutterhead speed [rpm]: 6000 - - Max. planing block diameter [mm]: 125 - └ Spindle 3: - - Spindle type: Left - - Motor power [kW]: 5.5 - - Spindle diameter [mm]: 40 - - Cutterhead speed [rpm]: 6000 - - Max. planing block diameter [mm]: 125 - └ Spindle 4: - - Spindle type: Top - - Motor power [kW]: 4 - - Spindle diameter [mm]: 40 - - Cutterhead speed [rpm]: 6000 - - Max. planing block diameter [mm]: 125 - Max. planing width [mm]: 230 - Max. planing height [mm]: 120 - Feed table length [mm]: 2000 - Feed roller diameter [mm]: 140 - Feed motor [kW]: 1 - Lubrication system: Automatic - Feed speed: - └ Min. feed speed [m/min]: 6 - └ Max. feed speed [m/min]: 12 - Transport dimensions: 3650mm x 1200mm x 1600mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, total width: 1,000 mm, total height: 1,600 mm, Empty weight: 925 kg Dimensions (LxBxH): 340 x 100 x 160 cm Four-sided planer SCM Sintex 380V 4 spindles Spindle below / above 7.5kW Spindle left/right 7.5kW Max working height 105mm Max working width 180mm Input table 2300mm Spindle diameter 40mm Redpfx Aewng Iwjfcjp Total dimensions 3400x980x1600mm (LxWxH), weight 925kg - Documentation available: No - CE certificate present: No - Transport dimensions: 3400mm x 1000mm x 1600mm (l x w x h) - Transport weight [kg]: 925kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), SCM T150 Rodpfxsymyd Ij Afcsp 2 spindles 30/40 mm Motor 5.5 kW Table length 250 cm Table width 37/100 cm Electric angle adjustment

Condition: excellent (used), 3 kW motor 4 knives Rjdpfeymyapsx Afcop Table width: 40 cm Table length: 250 cm

Condition: used, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, cutting height (max.): 120 mm, cutting width (max.): 300 mm, saw blade diameter: 350 mm, height adjustment type: mechanical, saw blade bore: 70 mm, actuation type: electric, - Operating manual, DTR - Italian production TECHNICAL SPECIFICATIONS: - Track width: 300 mm - Cutting height: 120 mm - Max. blade diameter: 350 mm - Motor power: 30 kW - Table width: 750 mm - Min. workpiece length: 600 mm Rodpfeym Ag Sox Afcep - Feed speed adjustable via gearmotor - Three rows of anti-kickback pawls - Possibility to mount a board – shoe - Spindle diameter: 50 mm - Sleeve diameter: 70 mm - Sleeve equipped with spacers - Automatic central lubrication - Four upper feed rollers - Extraction port diameter: 200 mm - Machine dimensions (L/W/H): 155 / 165 / 160 cm - Weight: 1800 kg

Condition: excellent (used), Year of construction: 2021, Sale on behalf of customer. Machine details to follow… Location: Friedeburg area Dismantling and delivery available at extra cost. Rsdpfx Afsylp S Eecsp

Condition: like new (used), Year of construction: 2024, operating hours: 120 h, functionality: fully functional, planing height: 200 mm, spindle diameter: 50 mm, planing width: 260 mm, jointer table length: 2,500 mm, number of spindles: 5, Profile milling machine Superset NT V5 carpenter's version with 2 axes Equipment as per attachment Rjdjym A A Hjpfx Afcsp Machine connected and ready for demonstration Availability: 1 to 2 weeks

Condition: used, Year of construction: 2020, total height: 2,450 mm, total length: 6,100 mm, total width: 2,600 mm, Empty weight: 4.160 kg Price: On request - Year: 2020 - Documentation available: Yes Rjdpfx Afsyla Iqjcjp - CE marking present: Yes - CE certificate present: Yes - Serial number: 3005 - Type milling table: Flat table - Tool clamping system: HSK-F63 - Drilling unit present: Yes - Tool changer positions [pcs.]: 18 - System/software: SCM Maestro - Safety feature: Bumper guard - Vacuum pump present: Yes - Tools included: Yes - Table length [mm]: 3756 - Table width [mm]: 1892 - Working range X [mm]: 3700 - Working range Y [mm]: 1870 - Transport dimensions: 6100mm x 2600mm x 2450mm (l x w x h) - Transport weight [kg]: 4160kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: excellent (used), CATALOG NUMBER 7618 TECHNICAL DATA - shaft width: 500 mm Rodjymnm Dspfx Afcjp - number of knives: 4 pcs - max thickness of workpiece: 230 mm top section: - anti-kickback fingers - toothed, feed, swivel, sequential infeed shaft - pressure rollers - planing shaft - pressure roller - smooth feed outfeed shaft bottom section: - 2 slip rollers in the table - motor: 5.5 kW - manual table height adjustment - 2 feed speeds: 7.5; 13 m/min - extraction port diameter: 160 mm - dimensions (L/W/H): 1100x1000x1200 mm - weight: 600 kg ADVANTAGES – made in Italy – original paint (not repainted) – used thickness planer, in very good condition Net price: 15,900 PLN Net price: 3,780 EUR (based on exchange rate 4.2 PLN/EUR) (Prices may change with significant exchange rate fluctuations)

Condition: used, Year of construction: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting working area mm 0 x 800/0 x 800 X axis stroke mm 750 Max. travel speed of X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y one common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed grooving saw (direction) X Grooving saw diameter mm 100 Max. grooving saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Grooving saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. Diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit. Positioning of the workpiece and drive of the work unit: A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the work unit during machining. Movement in the X and Y axes takes place on THK guides with transmission to reinforced toothed rails. Movement in the Z axis is pneumatically controlled on ball-bushing guides with adjustable stop positioning. The positioning of the work units is carried out using technology and drives with DC motors. CNC CONTROL The control system was specially developed for use in drilling and milling machines. CN - 7" color screen with touchscreen function - Alphanumeric keyboard - Self-diagnosis and any error messages or malfunctions that may occur, in the operator's language Programming - Programming via the CN - Automatic optimization of drilling operations - Option of plate zero point shift - Option of saving and importing drilling programs via USB dongle - Option of importing drilling programs from CAD-CAM external software Configuration - User interface in the same language as the instruction manual Graphic representation of the unit configuration Vacuum suction cups "B-Power Vacuum suction cups with double vacuum connection, recommended for particularly porous panels (e.g. MDF light). Machine user interface software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; Multicore processor recommended - Memory capacity: 1GB min., recommended 2GB - Free disk space: 5GB - Graphic card: Compatible OpenGL (The code includes a DVD for installation and a USB key) Xilog Maestro Features Programming - Parametric, graphic programming - Assisted programming with graphic and syntax help for drilling operations - Possibility to create and save machining macros Integrated additional functions - Self-diagnosis and possible error messages or malfunctions, in the operator's language - User interface in Redpfx Afsvvi I Rocjp

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Redpfx Aovwbp Aefcjp

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Rsdpevvi Htefx Afcjp Storage location: Sonnefeld

Condition: used, Year of construction: 2004, Storage location: Nattheim Redpfxsvvi Hyo Afcep
