Used Scm Panel Saw for sale (594)

Condition: used, Year of construction: 2023, Cutting area: 5600x5600 mm 1x Gabbiani G 3 130 (56) - High-performance panel saw 1x Compact label printer 1x "eye-M EVO" operating console 1x Human-machine interface software (HMI) MAESTRO ACTIVE 1x Maestro Pattern 1x High-performance fixed air cushion table with guide, 2500x600 mm, with infeed rollers 3x High-performance movable air cushion table - 2500x600 mm, with infeed rollers 1x Double lateral automatic aligner with motor drive 1x Foot switch for START/STOP of operating cycle 1x Grooving device with height-adjustable saw blade via control system 1x "Autosetting" device on the saw carriage for cut length/width 1x Main saw blade motor 25 HP (18 kW) 50 Hz with star-delta starter 1x Quick-clamping of saw blades with mechanical "AKE" flanges 1x Selective collet closure (area 0 - 1600 mm) 3x Additional double collets 4x Additional single-finger collets 1x Compact office label printer 1x Cut editor 1x Maestro Optiwise - Advanced - No. 1 license 1x Maestro Connect: service contract for 1 year (including "plug & play" gateway kit) 1x Base 1x MACHINE LANGUAGE: German 1x PC LANGUAGE: GERMAN 1x SPEC01 special version 01 Bsdsxlvktspfx Af Rslh 1x European safety regulations (CE marking) Including 123 hours of on-site commissioning (within Germany) (daily working time is 8 hours including travel time). Includes 1 day online training for MAESTRO OPTIWISE PRO (as required) Includes 1 year MAESTRO CONNECT Includes MAESTRO PATTERN IMPORT (normally €255 - free of charge) Location:

Condition: excellent (used), Year of construction: 2006, track width: 300 mm cutting height: 120 mm max. disc diameter: 350 mm motor power: 30 kW table width: 750 mm feed adjustable via frequency inverter fence adjustable pneumatically Blodpfx Ajwxrrvjf Roh

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, cutting height (max.): 90 mm, cutting width (max.): 3,800 mm, saw blade diameter: 380 mm, overall weight: 4,400 kg, cutting length (max.): 3,800 mm, main saw diameter: 380 mm, Beamsaw SIGMA IMPACT 90 (SCM Group) suitable for furniture panels precize cutting by one or more panels overlapped. Manufacturer: SCM Group Model: Sigma Impact 90 Production year: 2017 Cutting width: 3.800 mm Cutting depth: 3.200 mm Bedpjx Nc Aysfx Af Rolh Max. cutting height: 90 mm Front tables (air cushion): 1x 2.500x600mm, 3x 2.500x600mm Machine basement with air-cushion. Max. main blade diameter: 380 mm Scorer diameter: max. 300 mm PUSHER: brushless motor, max. speed 120 m/min ! SAW CARRIAGE: brushless motor, max. speed 150 m/min ! THK linear guides for the saw carriage movement. THK linear guides for the PUSHER movement. Automatic centralized lubrication of THK linear guides. Hi-Tronic kit: - main motor 15 kW (mode S6) - vertical movement of main and scoring blade by price ball-screws - optimized stroke of the main blade - electronic scorer adjustment in 2 axis (vertical, horizontal) - grooving with the main blade (electronic depth adjustment) - postforming cuts - window cut outs (blind cuts) - AKE flange for main and scoring blade Quantity of clamps (grippers): 10 pcs (maximum) Automatic exclusion of the clamp acting on the panels edge (up to 800 mm width). Start/stop pedal. Label printer. Control SW: WINCUT Optimalisation program: OTTIMO PERFECT CUT TOP (1x HW key) Control PC Eye-S: Windows + LCD touch screen 21" Air conditioning device for the electric box. Panel´s dimension automatic measuring. Laser line for the visualisation of the cutting line. Automatic double side aligner - motorized (60-2.200 mm). Machine stat: fully working Possibility to see in actuall production. Availability: cca April 2026

Condition: new, Year of construction: 2025, type of input current: three-phase, cutting width (max.): 1,250 mm, saw blade diameter: 400 mm, cutting length (max.): 3,200 mm, main saw diameter: 400 mm, CIRCULAR SAW model SCM SI 4 . CN Bsdpfx Afjglp I No Relh NEW machine in prompt delivery CE regulation: YES CN control "READY" 2 controlled NC axes (lifting and tilting of the blade) - blade lifting and tilting management - tool data settings with automatic correction of the height of the blade with respect to the inclination - electric and automatic NC mode with 99 storable programs digital display on the parallel guide n.02 reversible stops on the squaring guide extension floor out with scoring unit : YES max diameter saw blade 400 mm length of the squaring carriage mm 3200 main blade motor power Hp 9.5 scoring unit motor power Hp 1,7 3 main blade rotation speed rpm. 3000 /4000 / 5000 volt. 380/50

Condition: used, Year of construction: 2001, machine/vehicle number: AE/22614, functionality: fully functional, cutting width (max.): 4,500 mm, total length: 5,000 mm, total width: 7,000 mm, total height: 2,350 mm, cutting length (max.): 3,200 mm, SECOND-HAND PANEL SAW SCM MOD. SIGMA 65 - CE RULES - Cutting dimensions: 4500X3200 mm - Main blade projection: 65mm - N. 6 clamps - Saw carriage speed: 12m/min Bedpfxox Rvazs Af Rslh - Main blade diameter: 300mm - shaft diameter 80mm - Scorer blade diameter: 160mm - shaft diameter 55mm - Main blade motor: 5,5kW - Overall dimensions: 7000x5000x4350 - S/N AE/22614 - Year 2001

Condition: excellent (used), SCM M3 multi-track saw Width of track 300mm Cutting height max 120mm Main engine power 37kw Feed speed adjustable on variator 6-45m/min Disc diameter max/min 350/200mm Maximum piece width 1000mm Minimum workpiece length 600mm 3 rows of anti-rejection latches Spindle diameter 50mm Bushing diameter 70mm Central track lubrication CE certificate Extraction spigot 200mm Bjdpfx Asm Rg Dgof Rolh

Condition: good (used), Year of construction: 2000, Multiblade tracked SCM M3 4 - Italian production - year of production 2000 - DTR Bljdpfx Afog Tdfdj Rsh TECHNICAL SPECIFICATIONS: track width 300 mm cutting height 120 mm engine power 25 kW max. blade diameter 350 mm max. workpiece width 1000 mm min. workpiece length 400 mm adjustable feed on the inverter pneumatically adjustable ruler on the right revolver ruler setting of 6 types three rows of anti-recoil pawls possibility of putting on a board - a shoe spindle diameter 50 mm sleeve diameter 70 mm sleeve equipped with spacers automatic central lubrication four upper pressure shafts spigot diameter 180 mm and 120 mm dimensions of the machine (length / width / height) 210/175/160 cm weight 1800 kg

Condition: ready for operation (used), Year of construction: 2009, machine/vehicle number: AA2/001125, functionality: fully functional, planing width: 240 mm, overall weight: 2,400 kg, spindle diameter: 40 mm, number of spindles: 4, TECHNICAL DETAILS Min. planing width: 25 mm Max. planing width: 240 mm Min. planing height: 6 mm Max. planing height: 120 mm Number of spindles: 4 Spindle diameter: 40 mm Bedey Tn Szspfx Af Rolh Infeed table length: 2,000 mm Diameter of feed rollers: 140 mm Conveyor motor: 2.2 kW Diameter of dust extraction nozzle: 120 mm MACHINE DETAILS Voltage: 400 V Power consumption: 58 A Fuse: 63 A Dimensions & Weight Dimensions (L x W x H): 3,500 mm x 1,800 mm x 1,650 mm Weight: 2,400 kg Motor (bottom): 5.5 kW Motor (right): 5.5 kW Motor (left): 5.5 kW Motor (top): 7.5 kW EQUIPMENT Documentation

Condition: ready for operation (used), Year of construction: 2015, machine/vehicle number: AA1/018167, functionality: fully functional, workpiece length (max.): 3,300 mm, workpiece width (max.): 1,400 mm, workpiece height (max.): 180 mm, number of axes: 5, number of slots in tool magazine: 26, TECHNICAL DETAILS Workpiece length (max.): 3,300 mm Workpiece width (max.): 1,400 mm Workpiece height (max.): 180 mm Number of axes: 5 Number of tool slots in the tool magazine: 26 MACHINE DETAILS Control system & software: Maestro Version 1.00.022.1034 Blsdpfjzarfdex Af Reh Input voltage: 400 V Input current: 59 A Dimensions (L x W x H): 6,000 x 3,500 x 3,500 mm EQUIPMENT Documentation/Manual Includes Clemex system Additional licenses: 1 3D dongle, 2 2D dongles Tool package with approx. 20 milling cutters (including DIA milling cutters, indexable insert milling cutters, roughing milling cutters, T-slot milling cutters, and rounding milling cutters) Palette CAD Two licenses for Palette CAD Vacuum pump: Type Q2EFA132M6C-34

Condition: used, machine/vehicle number: 008238, X axis working area: 3660 mm Y axis working area: 1550 mm Working Table: Flat table Bljdpfxsx A E Tfj Af Rsh Main Electrospindle power: 12 KW Number of controlled axes: 3 axes Total number of drilling spindles: 12 Total number of tool changer positions: 15

Condition: used, machine/vehicle number: 008108, Max width workable: 1050 mm Bledpfxjw Iddus Af Roh Max length workable: 2400 mm Max height workable: 250 mm

Condition: used, machine/vehicle number: 008132, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 18 m/min Maximum panel thickness: 60 mm Operating Units: 7 nr Bedpfx Ajw Idc Rof Relh

Condition: used, Year of construction: 2013, total height: 2,240 mm, total length: 5,240 mm, total width: 2,500 mm, Empty weight: 2.700 kg - Year: 2013 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: AA1/017355 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 3 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 9.5 - Type milling table: Beam table - Drilling unit present: Yes Blodpownii Rofx Af Reh - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Working range X [mm]: 3050 - Working range Y [mm]: 1250 - Z-axis working range [mm]: 1810 - Y-axis maximum stroke [mm]: 1550 - Voltage [V]: 400 - Current consumption [A]: 31 - Transport dimensions: 5240mm x 2500mm x 2244mm (l x w x h) - Transport weight [kg]: 2700kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2018, Price: On request CNC machining centre SCM ACCORD 25 FX Brand SCM Type ACCORD 25 FX  Year of construction 2018 Machine no. AA10000992 Machining table dimensions 5020x1380 mm (LxW) Worktable equipped with 2 vacuum fields Worktable equipped with 2 reference lugs Including 8 reference lugs and 8 supports  Speed XY, vector 35 m/min Movement axes Maximal speed X axis 25 m/min (pro space) Maximum speed X axis 90 m/min (pro speed) Maximum speed Y axis 90 m/min Maximum speed Z-axis 30 m/min Control unit Machine control KVARA control Windows Embedded Standard 7-64bit Hard disk storage capacity 500GB-7200rpm Microprocessor Intel Pentium-2.9GHz RAM memory 8GB-DDR4 XILOG-MAESTRO software package Including vacuum pump  Motor power 5.5 kW Pump capacity 250m3/hour Vacuum pressure maximum 0.9 bar Total dimensions 9000x4500x3000 (LxWxH) Total weight 7,500 KG.  - Year: 2018 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA10000992 - Number of milling spindles [pcs.]: 2 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 3 - - Min. spindle speed [rpm]: 6000 - - Max. spindle speed [rpm]: 18000 - - Main motor power [kW]: 15 - └ Milling spindle 2: Bljdpjycwupsfx Af Roh - - Number of controlled axes [pcs.]: 3 - - Min. spindle speed [rpm]: 600 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 12 - Type milling table: Beam table - Tool changer positions [pcs.]: 12 - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 250 - Table length [mm]: 5020 - Table width [mm]: 1380 - Working range Y [mm]: 1300 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2015, total height: 1,850 mm, total length: 2,300 mm, total width: 1,950 mm, Colour: White Empty weight: 1.240 kg - Year: 2015 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AB/222595 - Main motor power [kW]: 2.2 - Number of controlled axes [pcs]: 12 - Working range X [mm]: 3050 - Working range Y [mm]: 800 - Working range Z [mm]: 60 - X-axis max stroke [mm]: 1040 - Y-axis max stroke [mm]: 1030 - Z-axis max stroke [mm]: 100 - Number of milling spindles [pcs]: 8 - Spindle diameter [mm]: 10 - Min. spindle speed [rpm]: 1000 - Max. spindle speed [rpm]: 4000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 6 - Max. drilling depth [mm]: 18 - Vertical drilling unit: Yes - Vertical drilling spindles [pcs]: 8 - Max. drilling depth [mm]: 30 - Saw unit present: Yes - Voltage [V]: 400 - Current consumption [A]: 10 - Transport dimensions: 2300mm x 1950mm x 1850mm (l x w x h) - Transport weight [kg]: 1240kg - Transport packages [pcs.]: 1 Financial information Bjdpfezavvgox Af Rjlh VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Equipment: CE marking, documentation/manual, CNC NESTING SCM PRATIX S22-31B with AUTOMATIC UNLOADING TECHNICAL FEATURES • Moving gantry, with Bumper safety system • 3 controlled axes: X, Y, and Z Blsdpfozav Hxjx Af Rsh • Travel speed on the axes: X: 35 m/min Y: 35 m/min Z: 15 m/min • Usable working area in X: 3,086 mm • Usable working area in Y: 2,155 mm • Usable working area in Z: 150 mm • PRO-SPACE safety system. With this system, the machine does not require perimeter guards or safety mats; the operator has free access to the work area from any side. • MATRIX aluminum table, 2,220 mm x 3,150 mm • 16 retractable pneumatic stops on the table (6+6 in Y and 4+4 in X) • 8 MPS 130x130 mm suction cups, H=25 mm • 4 MPS 150x50 mm suction cups, H=25 mm • SCM TECPAD remote control with digital display, with its corresponding resting base • Lubrication of the guides by means of a centralized drive pump • 2 vacuum pumps of 250 m3/h each, located under the machine structure • Xilog-Plus control software • Maestro Nesting software. Rectangular nesting • DXF file import • Pusher for evacuating finished parts, with vacuum cleaning system • Motorized belt table for material unloading, with photocells to read parts at the end. 3,200 mm x 2,180 mm • CE COMPLIANCE • Machine in excellent condition. Year of manufacture: 2014 • Supplied with the instruction manual, machine exploded view diagram, and electrical diagram. OPERATIONAL GROUPS: ROUTER • Electro-spindle power: 6.6 kW / 9 HP. 0 - 24,000 rpm • Air blowers • Mount that allows for the attachment of a horizontal tool • Linear tool changer, TR13 model, with 13 positions • ATC for HSK F63 tool holders • Calibration sensor to automatically measure tool length MULTIPLE DRILLING UNIT • 7 vertical drill holders • 1+1 horizontal drill holders in the X direction • 1+1 horizontal drill holders in the Y direction • 1 vertical disc in the X direction

Condition: used, Used machine Jointer: Working width: 500 mm Total table length: 2200 mm 4-knife cutterhead with segmented planer knives Blodoza I Tkepfx Af Rsh Motor: 4 kW Thickness planer: Min. working height: 3 mm Max. working height: 235 mm Max. chip removal: 8 mm Digital height adjustment display with decimal readout Feed speed: 7.5/15 m/min Availability: short-term Storage location: Flörsheim

Condition: used, Year of construction: 1994, Motor 6 / 7.5 kW with 4-roller feed, fixed speeds. Speed extensions. Height of worktable: 920 mm. Spindle tilting: -10° + 45°. Max. spindle projection above table: 175 mm. Spindle speeds: 3250/6500-5000/10000 rpm. Max. tool diameter: 250 mm. Weight: approx. 950 kg. Location: Nattheim. Bljdpow Enw Iefx Af Reh

Condition: excellent (used), Unique condition Sandya 1100 carpet and roller, like new. Pneumatic sanding shoe, continuously adjustable feed rate. Bljdpfx Ajzbct Isf Rjh

Condition: good (used), Motor output 3 kW Blodpfx Afjza Htpo Rsh sanding width 150 mm Weight 490 kg

Condition: new, - NEW -description- Stable cast steel construction- Milling spindle can be swiveled backwards from 0 ° to -45 °- Three spindle speeds from 3500 - 10000 rpm- As standard with right-left rotation of the milling spindle- Large-sized milling unit made of gray cast iron,attached directly to the table- Solid and precise gray cast iron table- Quick and easy speed change- Powerful 5.0 kW industrial motor- Standard curved milling protection hoodEquipment detailsAluminum sliding carriage- Equipped with a thousand times tried and testedBall contact system- torsion-resistant, extremely precise, smooth-running andproblem-free in daily use- 10 year Holzkraft guarantee on wear and tearof the guidewaysGray cast iron milling unit- Attached directly to the router table- Milling spindle mounted high up with precision ball bearings,thus the lowest possible bearing loadand the longest possible service life- 3 milling speeds from 3500 to 10000 rpmPowerful engines- Equipped with a powerful three-phase motorMilling protection- The milling protection is standard for maximum safetywith a height-adjustable guide railand ling stop- Exact milling stop with a quick adjustmentand a fine adjustment with a scale on the stop jaw- The integrated suction connection ensures a clear viewRouter table opening- A large router table opening also enablesthe use of larger flattening cuttersand tenoning and slotting toolsabove and below the tableArc milling protection hood- Included as standard in the scope of deliveryReversible stop jaws- Versatile integrated stop for bridgingthe tool gap- Allows you to work safely withnarrow workpiecesTechnical specifications:Dimensions and weightsWeight (net) approx. 290 kgConnection suctionExtraction nozzle diameter 2 x 120 mmWork tableWorking table length 1000 mmSlide length 1000 mmWorking table width 435 mmSlide carriage width 270 mmTable height 900 mmInstallation informationRequired space length 1945 mmMachine body width / depth 710 mmRequired space width / depth 2220 mmWorking area length 1600 mmExplanation of space requirementsThe dimensions take into account maximum travels or useful king area width / depth 1600 mmMachine body length 1000 mmExplanation of the work areaPlease add the specified dimensions with the space required in order to obtain the free installation area recommended for the ctrical dataConnection voltage 400 VMains frequency 50 HzPhase (s) 3 PhDrive motor power 5.0 kWType of current ACMilling spindleSpindle inclination 0 to -45 °Spindle speed (s) 3500/7000/10000 min¯¹Usable length of the spindle 100 mmSpindle mandrel diameter 30 mmSpindle overhang r table 130 mmMilling tool diameter l diameter can be lowered 180 mmTool diameter max. Tenon milling 275 mmTool diameter file milling 210 mmscope of deliveryArc milling protection hoodAnodized aluminum sliding carriageTelescopic miter fenceAluminum stop jawsItem No. 5502045 Bljdpfx Aovwf Ucof Rsh

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: AB/129942, F410 SURFACER Surfacing width: 410 mm Total table length: 2600 mm Table height: 855 mm Infeed table length: 1450 mm Adjustable aluminum fence, up to 45° Fence dimensions: 1100 x 170 mm 4-knife cutterblock, diameter: 120 mm Cutterblock rotation speed: 5000 rpm Motor power: 4 kW SCM surfacing guard integrated into the machine frame Dust extraction port diameter: 120 mm Manual star-delta switch Motor circuit breaker, undervoltage release Bodpfx Ajzadchsf Rjlh Main switch, lockable Automatic motor brake Adjustable auxiliary fence Available in ARDENNES

Condition: used, Year of construction: 2014, - Machine available from: 2026-03-30 - Year: 2014 - Documentation available: Yes - CE certificate present: Yes - Serial number: AA1/017825 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - Type milling table: Beam table - Drilling unit present: Yes - Tool changer positions [pcs.]: 12 - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: VTLF 2.250/0-791 - └ Year of manufacture: 2014 - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 244 Bljdpfx Afsx Hwhxo Rsh - └ Vacuum pressure [bar]: 200 - Working range X [mm]: 5200 - Working range Y [mm]: 1550 - Z-axis working range [mm]: 160 - Installed length [mm]: 9000 - Installed width [mm]: 5000 - Installed height [mm]: 3100 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: excellent (used), Catalogue number: 7863 TECHNICAL DATA - Track width: 300mm - Working shaft width: 300mm - Max. disc diameter: 350mm - Disc bore diameter: 70mm - Max. cutting height: 120mm - Table width with extension: 750mm - Table length: 1530mm - Top: - Kickback barriers (protection against material reversing) - Metal sliding roller - Kickback barriers - Metal sliding roller - Shaft with saw blades - 2 smooth metal sliding rollers - Bottom: - Guide bar Bledpfx Afjzbavgj Roh - Kickback barriers - Track - Laser - Centralised track lubrication - Infinitely variable feed speed via inverter - Feed motor: 1.5kW - Main motor: 26kW - Brake - Extraction port diameter: 200mm - Overall dimensions (L/W/H): 1700x1400x1600mm - Weight approx.: 1700kg ADVANTAGES - Italian manufacture - Equipped with laser - Very good condition - Used multi-blade saw Net price: 39,900 PLN Net price: 9,500 EUR (based on an exchange rate of 4.2 EUR) (Prices may vary subject to higher exchange rate fluctuations)

Condition: used, Year of construction: 2011, AXES Working Range X-Y-Z Axes * mm 3050-1300-180 Workpiece length for pendulum operation mm 1390 Stroke X-Y-Z Axes mm 3460-1735-250 Max. traverse speed of X-Y axes m/min 60 WORK TABLE Number of workpiece supports and vacuum cups 6 / 2 standard type Standard end stops / position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles std/quantity/speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles std/quantity/speed 1/min 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Blodpfoyymz Ujx Af Rjh Motor power std./opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer traveling with unit carrier in X 4 places, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction connection diameter mm 150+150 (200) Machine weight Kg 3000 * X: distance between stops; Y: milling center as reference point; Z: workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center, C-frame design, and worktable with adjustable workpiece supports and vacuum suction cups, for: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutter in the “X” direction - General milling work Self-supporting structure and work table Structure made from welded steel construction with control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV carrier options. Box construction made from cold-rolled steel with internal stiffening ribs and protective devices comprising a drilling head with vertical spindles, horizontal spindles, an integrated grooving and saw unit, and an SCM electrospindle with HSK 63 F quick-change tool system. Movement paths of the portal and unit carrier Movement in the X, Y, and Z axes is via linear prismatic guideways with preloaded ball bearings. The X-axis movement (moving gantry) uses a preloaded, backlash-free rack-and-pinion drive with helical gearing. Movement of the unit carrier in Y and Z directions is also preloaded for precision. Positioning of the working units and machine function control is through "brushless" AC servo motors and digital drives. CNC CONTROL The control unit comprises a numerical control for the milling and drilling machines and a PC with a graphical user interface "XILOG PLUS". PC office operating system Windows XP - 17" LCD color screen - QWERTY keyboard - Swiveling control panel - Machine interface: Xilog Plus software Xilog Plus Features Programming - Parametric, graphical, and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation on three axes, spatially linear, spirally on selected plane - Supported programming with graphical and syntax assistance for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on slanted or curved panel sides - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional functions - Calculator for direct transfer of computed data - S
