Used Scm Panel Saw for sale (627)

Year of construction: 2010, operating hours: 540 h, condition: ready for operation (used), travel distance X-axis: 3,060 mm, travel distance Y-axis: 1,735 mm, travel distance Z-axis: 250 mm, overall weight: 2,000 kg, number of axes: 4, This 4-axis SCM TECH Z2-27-C wood boring machine was manufactured in 2010. It features a maximum workpiece height of 160 mm, length of 2700 mm, and width of 1300 mm. The machine includes a routing spindle and a horizontal boring unit, ensuring versatility in operations. If you are looking to get high-quality wood processing capabilities, consider the SCM TECH Z2-27-C machine we have for sale. Contact us for further details. Isdpfx Ahey Dd R Io Aeti • Electrical: 400 V, 3 + N, 33 A, 50 Hz, breaking capacity 10 kA • Control: Xilog Plus • Machining units: saw unit (included), horizontal boring unit (included), routing spindle: 1 • Workpiece capacity: max height 160 mm; max length 2700 mm; max width 1300 mm; max width (double posts) 1210 mm • Max travel speed: 60 m/min • Clamping system: pneumatic locking bars; number of clamping bars: 6 • Suction cup sizes: 120x120 mm and 55x120 mm • Machine on: 5.500 h

Condition: used, machine/vehicle number: 008439, X axis working area: 3000 mm Y axis working area: 1300 mm Working Table: Pod and Rail Isdjyngzcspfx Ah Aoti Main Electrospindle power: 8.5 KW Number of controlled axes: 4 axes Total number of drilling spindles: 18 Total number of tool changer positions: 18

Condition: used, machine/vehicle number: 008111, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Iodpfey Dq Iasx Ah Asti Corner Rounding Unit: yes Max feed speed: 25 m/min Maximum panel thickness: 60 mm Operating Units: 9 nr

Condition: used, machine/vehicle number: 007113, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 22 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr Iedpfx Aerl Ur Tjh Aeti

Condition: used, machine/vehicle number: 007984, Max. machining width: 1300 mm Min. machining thickness: 4 mm Working Table: Fixed pass height Vacuum feed belt: yes No. Operating units: 4 Nr Iodpfswqdbmox Ah Aeti

Condition: used, machine/vehicle number: 007802, Max. panel width: 800 mm Max. panel length: 2000 mm Length of conveyor: 8320 mm Panel return for edgebander: Left Iedpfexn Nf Nex Ah Asti

Condition: used, machine/vehicle number: 008319, X axis working area: 6380 mm Y axis working area: 1380 mm Itodjx A Tc Iopfx Ah Asi Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 5 axes Total number of tool changer positions: 32

Condition: used, machine/vehicle number: 008471, X axis working area: 6360 mm Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Ijdpfxjywaf Us Ah Aoti Total number of tool changer positions: 36

Condition: used, machine/vehicle number: 008019, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 40 m/min Maximum panel thickness: 60 mm Itedpfxewvq E Ns Ah Aoi Operating Units: 14 nr

Condition: used, machine/vehicle number: 007966, Position 1: Panel Feeding and Loading SCM-EVOLUTION C undefinedPosition 3: Panel Stacking and Offloading SCM-EVOLUTION C Ijdpfx Aewu Agpjh Asti

Condition: used, machine/vehicle number: 008381, X axis working area: 4250 mm Y axis working area: 2280 mm Working Table: Flat table Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 11 Iedex Swc Hopfx Ah Aoti Total number of tool changer positions: 24

Condition: used, machine/vehicle number: 008431, X axis working area: 6360 mm Y axis working area: 1905 mm Working Table: Pod and Rail Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 60 Ijdjym Rphspfx Ah Aoti

Condition: used, machine/vehicle number: 008116, Max. machinable height: 120 mm Max. forward feed speed: 25 m/min Iedpfx Aow Iddzjh Aeti Operator shafts number: 6

Condition: used, machine/vehicle number: 008391, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 28 m/min Maximum panel thickness: 60 mm Isdpfxjygta No Ah Aeti Operating Units: 7 nr

Condition: used, machine/vehicle number: 008473, X axis working area: 4900 mm Itjdsywaf Ispfx Ah Aei Y axis working area: 1680 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 5 axes Total number of drilling spindles: 10 Total number of tool changer positions: 36

Condition: not inspected (used), Year of construction: 1995, SCM Compact 23 Moulder Description Spindle sequence bottom-right-left-top Infeed table length 2000mm Max. Working width 230mm Max. Working height 120mm Feed speed 6-12 mtr / min Spindle speed 6,000 rpm 400Volt 50Hz Iodpfx Ahjq Iipxj Ajti CE (All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!) (Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten! Keine Garantie auf gedruckte Daten!) Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: not inspected (used), Year of construction: 1997, SCM Compact 23 K Moulder Description Spindle sequence bottom-right-left-top Infeed table length 2500mm Max. Working width 230mm Max. Working height 120mm Feed speed 6-12 mtr / min Spindle speed 6,000 rpm 400Volt 50Hz CE Itedpfswc A R Djx Ah Asi (All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!) (Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten! Keine Garantie auf gedruckte Daten!) Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: used, Spindle moulder SCM T130 NPS - used - fine-adjustable fence, tenoning and slotting table, right-/left-hand rotation ----- Technical Data ----- Table size: 1,080 x 750 mm, Spindle diameter: 30 mm, Speeds: 3,000/4,500/6,000/7,000/10,000 rpm, Extraction port Ø: 120 mm, Itedpfow Nv Nfox Ah Aji Lower extraction port Ø: 120 mm

Condition: used, Thickness planer SCM S 63 - used - Segmented pressure beam, Under-table roller, Separate feed motor ----- Technical specifications ----- Planing width: 630 mm, Number of knives: 4 pcs., Passage height: 235 mm, Feed speed: 6 /9/12/18 m/min., Extraction nozzle Ø: 180 mm, Weight: 1035 kg Itedpfx Asxm R Uvjh Aei

Condition: used, Wide Belt Sander SCM UNO RCS - used - Combination unit with contact roller and sanding pad, contact roller made of steel, rubber-coated contact roller, sanding belt oscillation, infeed and outfeed table extension. ----- Technical Specifications ----- Working width: 920 mm Number of belts: 2 units Sanding belt size: 930 x 1,525 mm Feed speed: 4.5 / 9 m/min Max. workpiece thickness: 160 mm Min. workpiece thickness: 3 mm Extraction port Ø: 2x160 mm Motor power: 11 kW Dimensions (LxWxH): 1,700 x 1,480 x 1,600 mm Weight: 1,175 kg Iodpsy Dhudofx Ah Aoti

Condition: used, Year of construction: 2011, AXES Working Range X-Y-Z Axes * mm 3050-1300-180 Workpiece length for pendulum operation mm 1390 Stroke X-Y-Z Axes mm 3460-1735-250 Max. traverse speed of X-Y axes m/min 60 WORK TABLE Number of workpiece supports and vacuum cups 6 / 2 standard type Standard end stops / position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles std/quantity/speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles std/quantity/speed 1/min 6 (4X-2Y) / 4000 Integrated grooving / saw unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power std./opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer traveling with unit carrier in X 4 places, pneumatic INSTALLATION Isdpfeyymz Uox Ah Asti Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction connection diameter mm 150+150 (200) Machine weight Kg 3000 * X: distance between stops; Y: milling center as reference point; Z: workpiece passage GENERAL FEATURES CNC-controlled drilling and milling center, C-frame design, and worktable with adjustable workpiece supports and vacuum suction cups, for: - Vertical drilling on the panel surface - Horizontal drilling on all four workpiece sides - Groove milling with disc cutter in the “X” direction - General milling work Self-supporting structure and work table Structure made from welded steel construction with control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV carrier options. Box construction made from cold-rolled steel with internal stiffening ribs and protective devices comprising a drilling head with vertical spindles, horizontal spindles, an integrated grooving and saw unit, and an SCM electrospindle with HSK 63 F quick-change tool system. Movement paths of the portal and unit carrier Movement in the X, Y, and Z axes is via linear prismatic guideways with preloaded ball bearings. The X-axis movement (moving gantry) uses a preloaded, backlash-free rack-and-pinion drive with helical gearing. Movement of the unit carrier in Y and Z directions is also preloaded for precision. Positioning of the working units and machine function control is through "brushless" AC servo motors and digital drives. CNC CONTROL The control unit comprises a numerical control for the milling and drilling machines and a PC with a graphical user interface "XILOG PLUS". PC office operating system Windows XP - 17" LCD color screen - QWERTY keyboard - Swiveling control panel - Machine interface: Xilog Plus software Xilog Plus Features Programming - Parametric, graphical, and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation on three axes, spatially linear, spirally on selected plane - Supported programming with graphical and syntax assistance for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Possibility to shift panel zero point for drilling on slanted or curved panel sides - Full compatibility with CAD/CAM Routocam (SCM) – AlphaCam Integrated additional functions - Calculator for direct transfer of computed data - S

Condition: used, Year of construction: 2011, Usable working width: 520 mm Thickness table dimensions: 520 x 900 mm Iedpfxozimbdo Ah Aeti Max. working height: 300 mm Min. working height: 3.5 mm Min. workpiece length: 220 mm Max. material removal: 8 mm Cutterhead diameter (number of cutters): 120 mm (4 pieces) Cutterhead speed: 4500 rpm Feed rate: 5-8-12-18 m/min Motor power: 7 kW Dust extraction port diameter: 150 mm Dust extraction volume: 1300 m³/h Weight: approx. 680 kg Dimensions: 1150 x 1100 x 1250 mm Storage location: Garbsen

Condition: excellent (used), Catalog number 8036 TECHNICAL DATA max. width of workpiece 1100mm max. height of workpiece 170mm 2 units: – from above: rubber roller, pressure roller, knurled 1) metal roller, knurled, for calibrating rubber roller, pressure roller 2) rubber roller, knurled + sequential shoe + metal roller rubber roller, pressure roller total power of units 15kW -from below: 2 rubber rollers, slip rollers Iedpszin Sdsfx Ah Asti conveyor belt 2 rubber rollers, slip rollers grinding thickness potentiometer belt blowing system pneumatic belt oscillation controlled by photoelectric sensors electric table lifting + manual (for precise adjustment) 2 feed speed types 0.3kW with pneumatic brake working pressure 6-8bar diameter of dust extraction nozzle 2x140mm overall dimensions L/W/H 1840x1650x2000mm weight 1160kg – unpainted – made in Italy – automatic shoe – 2 units – grinding thickness potentiometer – DTR documentation – used grinder, very good condition Net price: 48900 PLN Net price: 11640 EUR, depending on the exchange rate of 4.2 EUR (Prices may vary due to significant fluctuations)

Condition: repair required (used), Year of construction: 1996, MACHINING CAPACITIES: - Height (thickness): 3 to 160 mm - Maximum workpiece width: 1100 mm - Minimum workpiece length: 390 mm - Abrasive belt speed: 18 m/s - Conveyor feed speed: 4.5 – 9 m/min - Suitable belt dimensions: 2150 x 1115 mm MACHINE CONFIGURATION: - 4 infeed rollers and 4 outfeed rollers - Table positioning with sensor Iedpsy I Srzsfx Ah Aeti - Vacuum conveyor system (perforated belt and motorized fan) - Pneumatic foot switch 1) Calibration 2) Calibration / sanding 3) Finishing sanding MACHINE SPECIFICATIONS: - Main power supply: 400V, three-phase, 50Hz - Automatic star-delta starter - Ammeter(s) for power consumption monitoring - Pneumatic tensioning, oscillation, and retraction of rollers - Pneumatic supply, working pressure: 6 bar - Dust extraction, 3 upper ports, Ø mm Recommended air flow: 2500 m³/h per hood Note: For optimal performance, please ensure that sanding belts are released when the machine is not in use, and avoid any moisture, including condensation, inside your facility during winter. Machine dimensions: 1920 x 2050 x h.2240 mm

Condition: used, Year of construction: 2006, functionality: fully functional, type of input current: three-phase, input voltage: 400 V, grinding height: 150 mm, input frequency: 50 Hz, - Year of manufacture: 2006 - In stock - After technical inspection - CE certified TECHNICAL SPECIFICATIONS: - Working height: 150 mm - Sanding belt dimensions: 150 x 2150 mm - Two sanding belt speeds - Table dimensions: 22 x 144 cm - Both tables adjustable at an angle within the range of 0-30 degrees - Motor power: 3.5 kW / 4.5 HP - Pneumatic belt tensioning and oscillation - Adjustable platen for sanding veneer on one side and a "back" of 15x75 cm on the other - Attachment, protractor for angle sanding - Additional table for profile sanding - Dust extraction port: diameter 140 mm Iodpfx Aozinpceh Asti - Overall dimensions: 144 x 71 x 130 cm (length x width x height) - Weight: approx. 450 kg
