Used Mini Metal Lathe for sale (3,214)

Condition: used, Year of construction: 2008, chucking diameter 200/250/315 mm bar material dia. 65/90 mm spindle bore 79/100 mm control Siemens 840D powerline weight of the machine ca. 6 t dimensions of the machine ca. 4350x2460x2080 m Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Csdpfx Aceya Iiro Dsha Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: used, Year of construction: 2008, bar material dia. 65 mm turning speeds 5.000 min-1 Number of working hours 34979 h spindle hours 72260 h control FANUC 310 i weight of the machine ca. 8800 kg dimensions of the machine ca. 4500x1990x2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Chjdpfoyat Hvox Ac Dea Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm Translated with (free version)

Condition: used, Year of construction: 1996, turning diameter 250 mm turning length 1000 mm Control Philips CNC-Steuerung weight of the machine ca. 8 t PHILIPS CNC control X-axis: 295 mm / Y-axis: 295 mm Center distance: 1000 mm Chodpeyan R Ajfx Ac Dsa Max. diameter on the bed: Ø 310 mm Max. diameter when turning: Ø 250 mm. Maximum turning speed: 4500 rpm. Spindle bore diameter: Ø 78 mm Turret with 8 tools Weight: approx. 8 tons

Condition: used, Distance between centers 750 mm greates pass round over bed 400 mm swing diameter over slide rest 230 mm bed width 300 mm spindle bore 51 mm Chedszrh Rfspfx Ac Dja spindle tunring speed 66 - 2.000 U/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change and errors in technical data and specifications; subject to prior sale.

Condition: ready for operation (used), Year of construction: 1987, Immediately available ex-yard: L & Z lathe, Poreba Cjdezrdh Hspfx Ac Deha Type TR 115 Year of manufacture 1987 Swing over bed 1150 mm Distance between centers 5000 mm Swing over carriage 780 mm Spindle bore 110 mm Drive power 22 kW Spindle speeds 16 – 1250 rpm Digital display Multifix tool holders with numerous holders Faceplate Various boring tool holders Lynette chuck Weight 14 tons Price: EUR 15,000.00 plus VAT, ex-yard.

Condition: used, Brand : CMZ Model : TL-20 Cnc : FANUC 32i Fabricate year : 2011 Distance between centers: 730 mm Bar picth: 67 mm Main spindle bore: 73 mm Max Workpiece diameter on slider: 510 mm Maximum turning diameter: 430 mm Maximum diameter on bench: 680 mm Automatic turret: Yes Motorized turret: No Spindle speed: 50-4000 rpm External dimensions: 3800x1850x1920 mm Machine weight: 5.400 KG Machine equipped with: Automatic door opening and closing Cjdozq Rzkepfx Ac Deha Preseter Chain chip extractor Air-powered chip extractor for plastic, aluminium etc. Internal gripper holder

Condition: ready for operation (used), Year of construction: 1986, Immediately available from a workshop for people with disabilities: L & Z lathe, Imatec Type ID 175 Year of manufacture 1986 Center height 175 mm Diameter over bed 350 mm Diameter over cross slide 210 mm Distance between centers 1000 mm Spindle bore 41 mm Spindle speeds 35.5 – 1600 rpm Digital display Chuck Faceplate Chedpfezrbx Aex Ac Dea Multifix system with holders Coolant system Drive power 3 kW Weight 1700 kg Price: Euro 2,250.00 plus VAT, ex works.

Condition: used, functionality: fully functional, Lead and feed spindle lathe Manufacturer: Schaerer Model: UD 630 Control: conventional Cjdpfxezrh Eie Ac Doha Turning diameter over bed: 630 mm Max. turning length: 2500 mm Spindle bore: 80 mm Spindle speeds: 1800 rpm Hardened lower slideways 4-way tool holder Tailstock with quill Chip tray

Condition: used, Copy lathe Hapfo AP 5000/ME Cjdpfxezrx Sao Ac Doha

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Controller: Fanuc 18i-TB Max turning diameter: 330 mm Max turning length: 510 mm Max diameter above bed: 330 mm Spindle power: 11 kW – 4000 rpm Number of turrets: 1 Number of tools: 12 Live tooling: Spindle speed range: 45–4500 rpm Y-axis travel: Typically around ±50 mm Chsdpfxox Ryrhs Ac Dsa Live tool spindle power: 5.5 kW Machine weight: 4,750 kg.

Year of construction: 2001, condition: ready for operation (used), X-axis travel: 220 mm, Z-axis travel: 635 mm, swing diameter over the bed cover: 570 mm, swing diameter over the cross-slide cover: 420 mm, speed range: 25-5,000 rpm, spindle bore diameter: 65 mm, chuck diameter: 250 mm, tailstock travel: 550 mm, main spindle drive power at 100% duty cycle: 21 kW, maximum torque: 240 Nm, C-axis holding torque: 200 Nm, control system: Heidenhain EP 4290 TP, connected load: 44 kVA, length: 3,250 mm, width: 1,750 mm, height: 2,300 mm, weight without chip conveyor: 5.3 t, operating hours: 16,930 h. Equipment: Hydraulically adjustable three-jaw chuck with various interchangeable jaws, MK4 tailstock quill, 12-station VDI 30 disc turret with 6 driven tool stations, tool measuring arm, workpiece pick-up device, coolant system, chip conveyor, coolant mist extraction system, various tool holders, Drehwerk turning and milling tools including driven tools, two tool cabinets and documentation. The main spindle produces running noise. An on-site inspection is possible. Chsdpfszrn H Tox Ac Dja

Year of construction: 1999, condition: ready for operation (used), Turning diameter: 500 mm, swing diameter over the cross slide: 290 mm, turning length: 1500 mm, spindle speed: 8 to 2800 rpm with three gear ranges, spindle bore diameter: 70 mm, three-jaw chuck diameter: 250 mm, tailstock quill taper: MT4, quill travel: 180 mm, connected load: 24 kVA, control system: Heidenhain Manual Plus, length: 3200 mm, width: 1700 mm, height: 1800 mm, weight: 3.2 t, operating hours: 42,733 h. The machine is equipped with a manual tailstock, chuck guard, coolant system, Multifix tool holder, various tool holders, various drill chucks, various turning and drilling tools, interchangeable jaws for the three-jaw chuck, a depth stop for the main spindle, a tool cabinet and documentation. The machine was completely overhauled by the manufacturer in 2010. An on-site inspection is possible. Chedpjzrn Idofx Ac Dea

Condition: used, Year of construction: 2009, turning height: 3,500 mm, workpiece weight (max.): 20,000 kg, turning diameter: 3,400 mm, faceplate diameter: 2,950 mm, workpiece diameter (max.): 3,300 mm, VERTICAL LATHE SCHIESS CNC FAGOR 8070 (C-AXIS + LIVE TOOLING) TECHNICAL SPECIFICATIONS Brand: Schiess Model: TVMF 320-3000 Year: 2009 Maximum turning diameter: 3400 mm Maximum turning height: 2580 mm Load capacity: 20 t C-axis (0.001°) CNC: Fagor 8070 (70 kW) Table diameter: 2950 mm Distance between columns: 3300 mm Angular milling head Codpsxh Hmkefx Ac Deha PRICE AND FURTHER INFORMATION ON REQUEST (CNC, SIEMENS, HASS, LAGUN, FAGOR, CINCINNATI, HEIDENHAIN, MACHINING, PINACHO, MORISEIKI, MILLING MACHINE, LATHE, GRINDER, BORING MACHINE, PRESS, LASER, SHEAR, PRESS BRAKE)

Condition: good (used), Year of construction: 2007, CNC - lathe machine Machine type: Mori Seiki NZ-S 1500 / 1000 Control: Fanuc MSC-701 Year: 2007 SPECIFICATIONS Max. turning length: 1.055 mm Turningdiameter: 120 mm Max. swing over bed: 285 mm Rapid motion: (X/Z): 20 m/min Main Spindle Max. revolution: 3.500 rpm Spindle power: 7,5 / 5,5 kW Bar capacity: 43 mm Spindle nose: A2-6 Amount of turrets: 2 Tool capacity: 6 + 6 Tool: Capto Codpezinn Eefx Ac Doha Tailstock Quill diameter: 85 mm Quill: MK 4 quill range: 70 mm Tailstock cross travel: 520 mm Steady rest: hydraulisch Steady rest: SMW SLU-1-Z Equipment Chip conveyor Cooling pumps Tool setter

Condition: new, Year of construction: 2026, functionality: fully functional, spindle bore: 38 mm, turning diameter: 280 mm, turning diameter over top slide: 165 mm, center height: 140 mm, turning length: 700 mm, total length: 1,280 mm, total width: 700 mm, total height: 1,650 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 70 rpm, bed width: 180 mm, type of input current: three-phase, overall weight: 320 kg, quill mount: MK 5, three-jaw chuck diameter: 160 mm, Equipment: rotational speed infinitely variable, WMP290V-F Lathe & Milling Combination with frequency inverter including 2-axis digital readout SINO including premium base cabinet LATHE Centre distance ----- 700 mm Centre height ----- 140 mm Swing over bed ----- 280 mm Swing over cross slide ----- 165 mm Spindle bore ----- 38 mm Spindle taper ----- MT5 Lathe speed range ----- 70-1800 stepless rpm Tailstock taper ----- MT3 Motor power ----- 1.5 kW Weight ----- 230 KG MILLING UNIT Milling head outreach ----- 185 mm Milling speed range ----- 50-2250 stepless rpm Milling spindle taper ----- MT2 Milling head swiveling ----- +/- 90° Quill stroke ----- 50 mm Chsdpfx Acopz I Iqs Doa Motor power ----- 750W Weight ----- 75 KG

Condition: new, functionality: fully functional, spindle bore: 21 mm, turning diameter: 180 mm, turning diameter over top slide: 110 mm, center height: 90 mm, turning length: 300 mm, total length: 800 mm, total width: 480 mm, total height: 1,260 mm, spindle speed (max.): 2,500 rpm, bed width: 100 mm, type of input current: DC, overall weight: 65 kg, quill mount: MK 3, three-jaw chuck diameter: 100 mm, Equipment: rotational speed infinitely variable, WM180V - ROGI vario metal lathe 230V-1 Phase Turning diameter over bed ----- 180 mm Turning diameter over cross slide ----- 110 mm Center height ----- 90 mm Distance between centers ----- 300 mm Bed width ----- 100 mm Cross slide travel ----- 75 mm Tool post travel ----- 55 mm Spindle bore ----- 21 mm Spindle mounting ----- MK3 Spindle speed range ----- variable 50 - 2500 rpm Whitworth threading ----- 10 - 44 TPI (8) Metric threading ----- 0.5 - 3 mm (10) Tailstock travel ----- 60 mm Tailstock diameter ----- 30 mm Tailstock mounting ----- MK2 Motor power ----- brushless 600 Watt Weight ----- 60 kg STANDARD ACCESSORIES * 3-jaw chuck 100 mm - self-centering * 4-way tool holder * Splash guard * Back guard * Chuck guard * Lead screw guard * Tool post guard * Set of change gears * Digital speed display * Fixed centers * Left / Right operation * Tools in box Cjdpfxoga T Ebe Ac Dsha * STAND OPTIONS * Independent 4-jaw chuck 100 mm * Flange for 4-jaw chuck 100 mm * Fixed steady rest * Traveling steady rest * Faceplate 170 mm * TOOA0 quick-change tool holder * Turning tool set

Condition: used, Year of construction: 2000, centre height 280 mm centre distance 1200 mm turning diameter over bed 570 mm Codpfxex E Dn Ao Ac Doha turning diameter over slide 365 mm turning length 1000 mm spindle taper DIN 55027 Gr. 8 control Sinumerik 810 D SIEMENS bed width 360 mm spindle bore 62 mm turning speed range 3 - 2500 U/min feed: 5000 mm / min rapid travel - longitudinal/face 10 m/min 3-jaw-chuck diameter 250 mm quick change toolholder SANDVIK Coromant Capto drive capacity - spindle motor 25 kW taper in tailstock-quill MK 5 dia. of quill 100 mm quill stroke 190 mm voltage 400 V weight of the machine ca. 5,0 t dimensions of the machine ca. 3,55 x 2,20 x 1,95 m - Serial No.: 2022-3742-03 - CNC-Control SIEMENS Sinumerik 810 D - Rapid feed - Coolant equipment - Machine lamp

Condition: ready for operation (used), WEILER MATATOR VS 2, including new 3-axis digital display, from a school workshop -Maximum turning height: 140 mm -Maximum turning length: 500 mm -Spindle speed: 15 - 3550 rpm -Automatic longitudinal / crossfeed Codpfxezrnbds Ac Doha -Threading / Metric / Inch, etc. -New three-axis digital display -Electric chuck guard -Work light -Multifix base with inserts -Coolant system -Three-jaw chuck -Tailstock MK3 -Documentation Dimensions: L x W x H 1.5 x 0.6 x 1.5 meters / Weight 650 kg Errors and omissions excepted.

Condition: good (used), Colchester Master 2500 In good condition. Cjdpfozp U Apox Ac Deha Includes some accessories. Transport can be arranged.

Condition: excellent (used), Year of construction: 1959, Schaublin 102 VM In very good condition. Chedezp Uz Sepfx Ac Dsa Includes accessories as shown in the pictures. Transportation can be arranged.

Condition: excellent (used), spindle bore: 36 mm, total length: 1,600 mm, total width: 700 mm, total height: 1,400 mm, spindle speed (max.): 3,550 rpm, Weiler Matador VS1 in very good condition. Includes accessories as shown in the pictures. Codpfezp Uzlsx Ac Doha Transportation can be arranged.

Condition: used, Year of construction: 2009, Technical details: turning diameter: 380 mm turning length: 538 mm total power requirement: 26 kW Cjdpfozq S Dyox Ac Djha weight of the machine ca.: 5,2 t

Condition: used, Year of construction: 2010, bar material dia. 20 mm spindle passage 24 mm turning length 350 mm turning speeds 10.000 U/min Control CNC Siemens 840Di/Yaskawa c-axis 0,01° ° gripping station 20 mm c-axis 0,01° ° speeds 10.000 U/min rapid traverse 20 m/min turret (x-stations) 3 x 8 + (3x Y-Achse) Chedpjzrh Ecefx Ac Dja total power requirement 5,5 kW weight of the machine ca. 4.850 t dimensions of the machine ca. 3,2 x 1,75 x 1,9 +FMB m CNC sliding headstock automatic lathe Star ECAS 20T (12 axes) with 2 spindles, 3 turrets and barloader FMB.

Condition: used, Year of construction: 2002, turning diameter 300 mm turning length . mm control Mazatrol 640 T x-travel 190 mm y-travel 1000 mm z-travel 575 mm turning speeds 4000 U/min feed 30 m/min number of tools 12 bar loader nein total power requirement 18,5 kW weight of the machine ca. 5,9 t dimensions of the machine ca. 5600x2100x2200 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are Cedszdu Stspfx Ac Dsha possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), The Colechester Bantem 1600 is a small compact lathe. It was mainly used in the educational sector providing training for its safe use to students. It was a well maintained machine, will little use and as a result has little or no backlash in its carriage's. It comes complete with 3 & 4 Jaw chucks, faceplates, and a set of gears for expanding the speed range of its spindle. It also has a range of tool holders and cutting tools. It has an integrated cabinet of the safe storage and easy access for its accessories. This machine is a strong, sturdy and compact machine and is suitable for may applications. Codpfx Aozmhmvsc Djha
